Gefen DIGAUD-141 Bedienungsanleitung

Digital Audio

Extender

USER MANUAL

www.gefen.com

Technical Support:

Telephone (818) 772-9100

(800) 545-6900

Fax (818) 772-9120

Technical Support Hours:

8:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen Inc.

c/o Customer Service

20600 Nordhoff St.

Chatsworth, CA 91311

[email protected]

www.gefen.com

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

The Digital Audio Extender is a trademark of Gefen Inc.

ASKING FOR ASSISTANCE

TABLE OF CONTENTS

Introduction

Box Contents

How to Connect the Digital Audio Extender

Link Cable - Wiring Diagram

System Speciﬁcations

Warranty

Thank you for purchasing the new ex•tend•it Digital Audio Extender series.

Extends S/PDIF and TOSLINK digital audio devices up to 60 meters (200 feet).

Place your digital audio components anywhere you want with Gefen’s DigitalAudio

Extender. It supports either S/PDIF or TOSLINK digital audio signals, which commonly

used to transmit stereo and multichannel (7.1, DTS, Dolby Digital, etc.) digital audio.

The Digital Audio Extender uses a sender and receiver system connected by CAT-5E

cables to extend the digital audio.

How It Works

The Digital Audio Extender’s sender unit connects to the audio source component. The

Digital Audio Extender’s receiver unit connects to the extended audio component (up to

200 feet away). One CAT-5E cable connects the sender to the receiver.

INTRODUCTION

The Digital Audio Extender system consists of:

(1) Digital Audio Extender

(1) 5 VDC power supply

(1) TOSLINK Cable (6 FT M-M)

(1) User Manual

BOX CONTENTS

READ THESE NOTES BEFORE INSTALLING

OR OPERATING THE DIGITAL AUDIO EXTENDER SYSTEM

* Industry standard Category-5 (CAT-5) cables are used to link the Digital Audio Extender

sender and receiver boxes together.

* The Digital Audio Extender units are housed in a metal box for better RF shielding.

OPERATION NOTES

HOW TO CONNECT THE DIGITAL AUDIO EXTENDER

How to Connect the Digital Audio Extender

1- Connect your digital audio source device with either TOSLINK or S/PDIF to the

Digital Audio Extender sender unit.

2- Connect the CAT5 cable from the send unit to the receive unit.

3- Connect your digital audio receiver or digital audio speaker to the Digital Audio Ex-

tender receiver unit with TOSLINK or S/PDIF. The DigitalAudio Extender supports out-

puts via TOSLINK or S/PDIF simultaneously.

4- Plug the 5 volt power supply into the Audio extender send unit.

LINK CABLE - WIRING DIAGRAM

White/Orange

Orange

White/Green

Blue

White/Blue

Green

White/Brown

Brown

RJ-45 Jack RJ-45 Jack

1818

Data Transmission Rate ................................................................................. 12.8 Mbp/S

Input/Output ...................................................... S/PDIF (Digital Coax), Optical TOSLINK

Power Supply ......................................................................................... 5 VDC (External)

Dimensions ........................................................................... 1 1/4”H x 1 1/2”W x 3 7/8”D

Weight ....................................................................................................................... 4 lbs

SPECIFICATIONS

Gefen Inc. warrants the equipment it manufactures to be free from defects in material

and workmanship.

If equipment fails because of such defects and Gefen Inc. is notiﬁed within two

(2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace

the equipment, provided that the equipment has not been subjected to mechanical,

electrical, or other abuse or modiﬁcations.

Equipment that fails under conditions other than those covered will be repaired at the

current price of parts and labor in effect at the time of repair. Such repairs are warranted

for ninety (90) days from the day of reshipment to the Buyer.

This warranty is in lieu of all other warranties expressed or implied, including without

limitation, any implied warranty or merchantability or ﬁtness for any particular purpose,

all of which are expressly disclaimed.

1. Proof of sale may be required in order to claim warranty.

2. Customers outside the US are responsible for shipping charges to and from Gefen.

3. Copper cables are limited to a 30 day warranty and cable must be free from any

scratches, markings, and neatly coiled.

The information in this manual has been carefully checked and is believed to be

accurate. However, Gefen Inc. assumes no responsibility for any inaccuracies that

may be contained in this manual. In no event will Gefen Inc., be liable for direct,

indirect, special, incidental, or consequential damages resulting from any defect

or omission in this manual, even if advised of the possibility of such damages. The

technical information contained herein regarding Digital Audio Extender features and

speciﬁcations is subject to change without notice.

WARRANTY
