Gefen EXT-2DVI-DLKVM-CAT6 Bedienungsanleitung
®
2x Dual Link
DVIKVM Extender
Over CAT-6a
EXT-2DVI-DLKVM-CAT6
User Manual
www.gefen.com
Technical Support:
Telephone (818) 772-9100
(800) 545-6900
Fax (818) 772-9120
Technical Support Hours:
8:00 AM to 5:00 PM Monday through Friday, Pacic Time
Write To:
Gefen, LLC
c/o Customer Service
20600 Nordhoff St
Chatsworth, CA 91311
www.gefen.com
Notice
Gefen, LLC reserves the right to make changes in the hardware, packaging and
any accompanying documentation without prior written notice.
2x Dual Link DVIKVM Extender Over CAT-6a is a trademark of Gefen, LLC
© 2012 Gefen, LLC. All rights reserved.
All trademarks are the property of their respective owners.
ASKING FOR ASSISTANCE
Rev A2
CONTENTS
1 Introduction
2 Operation Notes
3 Features
4 Sender Unit Layout
5 Sender Unit Descriptions
6 Receiver Unit Layout
7 Receiver Unit Descriptions
9 Connecting the 2x Dual Link DVIKVM Extender Over CAT-6a
9 Wiring Diagram
10 DIP Switch Conguration
12 Adjusting the Signal Quality
13 Network Cable Wiring Diagram
14 Specications
15 Warranty
1
INTRODUCTION
Congratulations on your purchase of the 2x Dual Link DVI KVM Extender Over
CAT-6. Your complete satisfaction is very important to us.
Gefen
Gefen delivers innovative, progressive computer and electronics add-on solutions
that harness integration, extension, distribution and conversion technologies.
Gefen’s reliable, plug-and-play products supplement cross-platform computer
systems, professional audio/video environments and HDTV systems of all sizes
with hard-working solutions that are easy to implement and simple to operate.
The Gefen 2x Dual Link DVI KVM Extender Over CAT-6a
The 2x Dual Link DVIKVM Extender over CAT-6a is a cost-effective solution that
allows the extension of keyboard, video and mouse to a remote workstation up
to 200 feet (60 meters away). This product is particularly useful because it is able
to extend dual link resolutions beyond the limitations of standard DVI cables.
Dual-link resolutions up to 3840 x 2400 are supported using two CAT-6a cables
for each display. USB 2.0 data rates up to 480 Mbps are supported in addition to
backward-compatibility with USB 1.1. The Receiver unit allows the connections
of up to four USB devices, providing access to printers, scanners, cameras,
external storage media, digital signage, and automated control systems.
How It Works
Place the 2x Dual link DVIKVM Extender over CAT-6a Sender unit next to the
DVI sources. Use the included DVI cables to connect the DVI sources to the
Sender unit. Use the supplied USB cable to connect the USB host (source)
device to the USB port on the Sender unit. Connect the Receiver unit to two
dual-link DVI displays using DVI cables. Connect up to four USB devices to
the Receiver unit. Use ve CAT-6a cables, each up to 200 feet (60 meters), to
connect the Sender to the Receiver unit. Connect the included locking power
supplies to the Sender and Receiver units and plug both power cords into
available electrical outlets.
READ THESE NOTES BEFORE INSTALLING OR OPERATING
THE 2X DUAL LINK DVIKVM EXTENDER OVER CAT-6A
• The 2x Dual Link DVIKVM Extender Over CAT-6a was designed for use with
high quality CAT-6a (augmented) cabling. This unit will either not perform to
specication if cabling other than CAT-6a is used.
• When using CAT-5e cables, the maximum extension distance is 150 feet
(30 meters) at 1080p Full HD or 2560 x 1600.
• When eld terminating CAT-6a cabling please adhere to the TIA/EIA-568-B
specication shown on page 12.
• USB can be extended up to 330 feet (100 meters).
2
OPERATION NOTES
IMPORTANT: When extending Dual Link resolutions, both CAT-6a
cables must be exactly the same length.
3
Features
• Extends two dual-link DVI sources with USB 2.0 up to 200 feet (60 meters)
using CAT-6a cables.
• Supports 1080p Full HD at 120Hz and dual-link resolutions up to
3840 x 2400
• HDCP-compliant
• Supports 480 Mbps using USB 2.0
• Backward-compatible with USB 1.1 devices
• Supports DDWG standard for DVI-compliant monitors
• Supports any Operating System (OS)
• EDID management for rapid intergration of source and display devices
• EQ adjustment trim pots on Receiver unit to equalize the signal to
compensate for cable length and the quality/skew variances found among
different CAT-5e/ CAT-6a cables
• Rack-mountable
• Plug and Play
Applications
• This product is used for dual-display extended desktop applications.
Package Includes
(1) 2x Dual Link DVIKVM Extender over CAT-6a - Sender Unit
(1) 2x Dual Link DVIKVM Extender over CAT-6a - Receiver Unit
(2) 6ft. Dual-Link DVI cable (M-M)
(1) 6ft. USB Cable (A-B)
(2) 5V DC Locking Power Supplies
(1) AC Power Cord
(2) Sets of Rack Ears
(1) Quick-Start Guide
FEATURES
4
Front Panel
Back Panel
SENDER UNIT LAYOUT
1
2 8 93 4 10
11
7
6
5
5
1 Power
This LED indicator will glow bright red once the included 5V DC locking power
supply is properly connected between the unit and an available electrical outlet.
2 CAT-6 / Link 1.1
Connect a CAT-6a cable between this port and the CAT-6 / Link 1.1 port on the
Receiver unit.
3 DVI In 1
Connect a dual-link cable from this connector to the DVI (digital only) source.
4 CAT-6 / Link 1.2
Connect a CAT-6a cable between this port and the CAT-6 / Link 1.2 port on the
Receiver unit.
5 USB In
Connect the included USB cable between this port and a computer (or other
USB host device).
6 USB Link LED
This LED indicator will glow bright green when a CAT-6a cable is connected
between the USB Link ports on both the Sender and Receiver unit.
7 USB Link
Connect a CAT-6a cable between this jack and the USB Link jack on the
Receiver unit.
8 CAT-6 / Link 2.1
Connect a CAT-6a cable between this port and the CAT-6 / Link 2.1 port on the
Receiver unit.
9 DVI In 2
Connect a dual-link cable from this connector to the DVI (digital only) source.
10 CAT-6 / Link 2.2
Connect a CAT-6a cable between this port and the CAT-6 / Link 2.2 port on the
Receiver unit.
11 5V DC
Connect the included 5V DC locking power supply to this receptacle.
SENDER UNIT DESCRIPTIONS
6
RECEIVER UNIT LAYOUT
Front Panel
Back Panel 31 2
4 1197 125 6 13
148 10
