Gefen Ex tend it Bedienungsanleitung

4x1 HD Digital

Audio Switcher

USER MANUAL

www.gefen.com

Technical Support:

Telephone (818) 884-6294

(800) 545-6900

Fax (818) 884-3108

Technical Support Hours:

9:00 AM to 5:00 PM Monday thru Friday.

Write To:

Gefen Inc.

C/O Customer Service

6265 Variel Ave.

Woodland Hills, CA91367-9897

Notice

Gefen Inc. reserves the right to make changes in the hardware, packaging and any

accompanying documentation without prior written notice.

4x1 HD Digital Audio Switcher is a trademark of Gefen Inc.

ASKING FOR ASSISTANCE

TABLE OF CONTENTS

Introduction

Features

Panel Descriptions

Connecting and Operating the 4x1 HD Digital Audio Switcher

RMT4-IR Installation

RS-232 Interface

Speciﬁcations

Warranty

Congratulations on your purchase of the ex•tend•it 4x1 HD Digital Audio Switcher. Your

complete satisfaction is very important to us.

Gefen’s line of HDTV switches, extenders, and splitters are designed to make yourA/V

equipment use more comfortable, more productive and less expensive.

The 4x1 HD Digital Audio Switcher allow access to multiple HDTV devices, using a

single HDTV display.

The ex•tend•it line offers solutions for Home Theater, AV installation, noise, space and

security concerns, data center, information distribution, conference room presentation,

school and corporate training environments.

Our Commitment

Gefen will always offer the ﬁnest quality product at the best possible price. Included in

that price is a lifetime support from a team of outstanding engineers.

The 4x1 HD Digital Audio Switcher allows four HDTV DVI devices to be switched easily

in to one HDTV DVI compatible monitor or projector. Simply connect your HDTV display

to the Switcher’s display output and your digital audio to the digital out. The 4x1 HD

Digital Audio Switcher can also be placed at the end of a long DVI cable to regenerate

the DVI signal.

Please Note:

This particular version only supports the video portion of the HDMI signal.

INTRODUCTION

FEATURES

Features

• Switches easily between any four HDTV sources

• Maintains 480p, 720p, 1080i, and 1080p resolutions

• Extends any DVI compliant device by regenerating the DVI signal

• Maintains highest DVI single link video resolution

• Optical TOSlink or S/PDIF digital audio switching

• Supports DDWG standard for DVI compliant monitors

• Supports HDCP compliant devices

• Optional RMT-4 remote control

• DVI to HDMI cables are used to connect the DVI inputs and HD Switcher input

• Installs in seconds

Includes:

4x1 HD Digital Audio Switcher

4x 6’ HDMI cables (m-m)

4x 6’ TOSlink cables

5V DC Power Supply

RMT4-IR

User's Manual

PANEL DESCRIPTIONS

Connecting and Operating the 4x1 HD Digital Audio Switcher

How to Connect the 4x1 HD Digital Audio Switcher to your devices

1 Connect the supplied cables from the HDTV sources into the 4x1 HD DigitalAudio

Switcher inputs.

2Connect the digital audio cables from your devices into the 4x1 HD DigitalAudio

Switcher inputs. Make sure the digital audio matches the digital video input.

3Connect the cable from your display (monitor or projector) into the HDMI Out of the

4x1 HD Digital Audio Switcher.

4 Connect your digital audio receiver to the 4x1 HD DigitalAudio Switcher output.

5 Plug the 5VDC power supply into the 4x1 HD Digital Audio Switcher.

How to Control the 4x1 HD Digital Audio Switcher

Use the RMT4-IR remote control to toggle between sources.

RMT4-IR Installation

1. Remove battery cover from the back of the RMT4-IR remote.

2. Verify that dip switches 1 & 2 are in the down (OFF) position.

3. Insert the battery, hold the battery so that you can see the positive side facing up. The

side that is not marked must be facing down.

4. Test the RMT4-IR remote by pressing ONLY one button at a time. The indicator light

on the remote will ﬂash once each time you press a button. WARNING: Do not press

multiple buttons simultaneously and do NOT press buttons rapidly. These actions will

cause the remote to reset and steps 1-4 will have to be repeated.

Note: The RMT4-IR ships with two batteries. One battery is required for operation, the

second battery is complimentary.

RS-232 Interface

Binary Table

Input Binary

1 0011 0001

2 0011 0010

3 0011 0011

4 0011 0100

Terminal Settings

Bits per second ...................................................................................................... 19200

Data bits ......................................................................................................................... 8

Parity ....................................................................................................................... None

Stop bits ..........................................................................................................................1

Flow Control ............................................................................................................ None

SPECIFICATIONS

Video Ampliﬁer Bandwidth ................................................................................ 1.65 Gbps

Input Video Signal ......................................................................................... 1.2 volts p-p

Input DDC Signal .................................................................................... 5 volts p-p (TTL)

Single Link Range ............................................................................ 1080p / 1920 x 1200

Video Output .................................................................. DVI-I 29 pin female (digital only)

Video Input ............................................................................ HDMI Type A 19 pin female

Digital Audio ........................................................... S/PDIF (digital coax), optical TOSlink

Power Supply ......................................................................................................... 5V DC

Power Consumption .................................................................................. 10 watts (max)

Dimensions ............................................................................ 4.625”D x 9.25”W x 1.25”H

Shipping Weight ....................................................................................................... 6 lbs.
