Gemtek Technology WLTMS-110 Bedienungsanleitung

LTE CPE

Quick installation Guide

WLTMS-110

Connection Guide

this publication may be reproduced, transmitted, transcribed, stored in

a retrieval system, or translated into any language in any form by any

means without the written permission of Gemtek Technology Co. Ltd.

Notice

Gemtek reserves the right to change specifications without prior

notice.

While the information in this document has been compiled with

great care, it may not be deemed an assurance of product

characteristics. Gemtek shall be liable only to the degree specified in

the terms of sale and delivery.

The reproduction and distribution of the documentation and

software supplied with this product and the use of its contents is

subject to written authorization from Gemtek.

Connectors

1. One RJ-45 connector for connecting to the PoE adaptor.

2. LED indicator inside and SIM card slot for inserting SIM card.

3. A grounding screw on the rear panel.

LED Indicators _ODU

LED name

Location

Color

LED Behavior

Status Indication

LED List

●●●

MAIN power

●○○

○○○

Blue

Power On

OFF

Power Off

Ethernet

status

○●○

○○○

Yellow

Steady ON

Ethernet Connected

Blinking

Data Transmission

OFF

No Ethernet action

SIM status

○○●

○○○

Green

Steady ON

SIM Detected

Blinking when

On-hook

PUK / PIN Code

OFF

No SIM Detected

LTE Status LED : Link Status

When CPE is power on, each LED

indicates each link status

LTE 1

○○○

●○○

Red

Steady ON

CINR < 8dB

LTE 2

○○○

●●○

Red/

Yellow

Steady ON

8dB < CINR <

15dB

LTE 3

○○○

●●●

Red/

Yellow/

Green

Steady ON

15dB < CINR

Installing LTE outdoor CPE

●Selecting a Location: LTE Outdoor CPE should be pole-mounted

outdoors and aligned so its antenna faces the nearest LTE eNB.

When selecting a suitable location for the unit, consider these

guidelines:

•Place LTE Outdoor CPE as high as possible to achieve the best

possible link quality.

•Place the LTE Outdoor CPE away from power and telephone

lines.

•Avoid placing LTE Outdoor CPE too close to any metallic

reflective surfaces.

•Be sure to ground LTE Outdoor CPE with an appropriate

grounding wire (not included) by attaching it to the grounding

screw on the unit and to a good ground connection.

●Mounting the ODU: Mount LTE Outdoor CPE on a 1”-4” pole

using the supplied kit, or the optional tilt accessory.

•Using the clamp

1. Thread the M10*100mm bolt through a spring washer, flat

washer and the bracket holes.

2. With the connector facing downward, attaché LTE Outdoor

CPE to a 1”-4” pole.

3. Attach the bracket to the other side of the pole.

4. Thread the M10*100mm bolts through both holes on either

side, and tighten the nuts.

Connecting the Cables

●Outdoor Connection: Connect a grounding cable between the

Ground terminal of the LTE outdoor CPE and a good ground

connection.

●Preparing and connecting the cable: Use only UTP-FTP

4x2x24AWG CAT. 5E outdoor cable from an approved

manufacturer. The cable provides pin-to-pin connection on both

ends.

1. Prepare the cable: Use a crimp too for RJ-45 connectors to

prepare the wires. Insert them into the appropriate pins and

use the tool to crimp the connector. Make sure to do the

following:

•Remove as small a length as possible of the external jacket.

Verify that the external jacket is well inside the sealing

cover when connected to the unit, to ensure good sealing.

•Pull back the shield drain wire before inserting the cable into

the RJ-45 connector, to ensure a good connection with the

connector’s shield after crimping.

The following figure shows the required wire pair connections.

The color codes used in standard cables supplied by the

manufacturer are as listed in the table.

2. Connect the cable

•Remove the sealing cable gland plug from the gland nut.

•Open the sealing gland nut and remove it. Don not

disassembles the gland base from the bracket.

•Insert the cable into the sealing gland base and connect it to

the RJ-45 connector at the bottom of the CPE. Make sure the

connector is completely inserted and tightened.

•Insert the rubber bushing on the cable into the gland base.

•Tighten the gland nut. Use the dedicated tool for fastening

the sealing glands.

3. Seal the connector

•Attach the mastic tape (ScotchfilTM Electrical Insulation Putty)

and wrap it around the connector butting up against the

connector. Do not over stretch.

•Squeeze to tighten the mastic sealer. Make sure there are no

air bubbles.

•Slide the cold shrink sleeve on top of the connector. Make

sure that the sleeve covers both cable connector and unit

connector.

•Pull the cord slowly to shrink the sleeve.

●Indoor Connection

1. It is assumed that the RJ-45 is already connected to the LTE

outdoor CPE. Assemble an RJ-45 connector with a protective

cover on the other end of the LTE outdoor CPE cable.

2. Connect the other end of the cable from ODU to the PoE

adaptor which labeled “POE”.

3. Connect RJ45 cable from PoE adaptor which label “LAN” to a

PC/NB/Hub/Switch.

Web Interface

Please follow the steps below to configure your device through the

web interface:

Step1: Open the Web browser (Internet Explorer) and enter the

default IP address of the ODU CPE, which is :

http://192.168.15.1

Web browser

Step2: Enter ODU administrator login username/password to access

the web management interface. The default

username/password is administrator/administrator.
