GeoVision GV-AS1010 Bedienungsanleitung

GV-AS / EV Controller

Quick Start Guide

ASEV-QG-E

Thank you for purchasing GV-AS / EV Controller. This guide is designed to assist the new user in

getting immediate results from the controllers. For advanced information on how to use the GV-

AS100 / 1010 / 110 / 1110 / 120 / 210 / 2110 / 2120 / 410 / 4110 / 810 / 8110 and GV-EV48, please

refer to GV-AS / EV Controller User's Manual on Software CD / DVD.

Under the copyright laws, this manual may not be copied, in whole or in part,

without the written consent of GeoVision.

Every effort has been made to ensure that the information in this manual is

accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind

and assumes no responsibility for errors or omissions. No liability is assumed

for incidental or consequential damages arising from the use of the information

or products contained herein. Features and specifications are subject to

change without notice.

Note: No memory card slot or local storage function for Argentina.

GeoVision, Inc.

9F, No. 246, Sec. 1, Neihu Rd.,

Neihu District, Taipei, Taiwan

Tel: +886-2-8797-8377

Fax: +886-2-8797-8335

http://www.geovision.com.tw

Trademarks used in this manual: GeoVision, the GeoVision logo and GV

series products are trademarks of GeoVision, Inc. Windows and Windows XP

are registered trademarks of Microsoft Corporation.

October 2015

October 29, 2015

Contents

Contents...........................................................................................................................i

Important Note for Maintaining Power Supply..................................................................ii

GV-AS Controller Quick Start Guide............................................................................... 1

1. Basic Setup for GV-AS100 / 1010 / 110 / 1110 / 120................................................. 1

1.1 GV-AS100 / 1010 ............................................................................................. 2

1.2 GV-AS110 / 1110 ............................................................................................. 3

1.3 GV-AS120 ........................................................................................................ 4

2. Physical Wiring for GV-AS210 / 2110 / 2120 / 410 / 4110 / 810 / 8110 and GV-EV48 5

2.1 GV-AS210 / 2110 / 2120 .................................................................................. 5

2.2 GV-AS410 / 4110 / 810 / 8110.......................................................................... 6

2.3 GV-EV48.......................................................................................................... 7

3. Accessing the Web Interface of the GV-AS Controllers ............................................. 8

4. Setting GV-AS Controller on GV-ASManager............................................................ 9

5. Optional Devices for GV-AS100 / 110 / 120..............................................................10

5.1 Physical Wiring of GV-ASBox and GV-ASNet .................................................11

5.2 Accessing the Web Interface of GV-AS100 / 110 / 120....................................12

October 29, 2015

Important Note for Maintaining Power Supply

To make sure GV-AS / EV Controllers can function properly during a power outage, be sure

to replace the internal battery on the controllers when needed. It is also recommended to

install a backup battery for compatible GV-AS Controllers.

Refer to the following sections in GV-AS Controller User Manual for instructions on how to

install a backup battery:

zGV-AS100 / 110 / 120 through GV-ASBox: See 9.1.4.F Connecting Backup Battery.

zGV-AS100 / 110 / 120 through GV-ASNet: See 9.2.4.F Connecting Backup Battery.

zGV-AS210 / 2110 / 2120: See 4.2.4 Connecting Backup Battery

zGV-AS410 / 4110 / 810 / 8110: See 5.2.4 Connecting Backup Battery

zGV-EV48: See 6.2.3 Connecting Backup Battery.

Replaceable Button Cell (GV-AS100 / 2110 / 2120 / 4110 / 8110)

For GV-AS100 / 2110 / 2120 / 4110 / 8110, you can replace the battery on your own when

you see low battery messages and icons in GV-ASManager.

Note: Make sure the plastic insulation film under the battery is removed when using GV-

AS100 / 2110 / 2120 / 4110 / 8110 for the first time. The low battery messages and icons will

appear if the plastic film is not removed.

October 29, 2015

iii

Built-in Battery (GV-AS1010 / 110 / 1110 / 120 / 210 / 410 / 810 & GV-EV48)

When the controller runs out of battery, the local time on the controller will be reverted back

to 1999/12/31. The controller time can be found on the Web interface of the controller on the

Time Setting page and in the Access Monitor / Alarm Monitor / Event Monitor of GV-

ASManager.

When you see the controller year shown as 1999 or 2000, disconnect the controller from

power and reconnect it to power. If the year is still shown as 1999 or 2000, the controller

battery needs to be replaced. When this occurs, connect the controller to a backup battery

and maintain connection with GV-ASManager at all times. When connected to GV-

ASManager, the controller’s time will be synchronized with GV-ASManager’s time.

October 29, 2015

GV-AS Controller Quick Start Guide

This guide lists the basic steps required to set up a GV-AS Controller. For detailed

instructions, refer to the section number listed below each step.

1. Basic Setup for GV-AS100 / 1010 / 110 / 1110 / 120

This section covers the basic settings required to start running GV-AS100 / 1010 / 110 / 1110

/ 120. For more settings on GV-AS100 / 110 / 120, refer to 5. Optional Devices for GV-AS100

/ 110 / 120. The section numbers listed here refers to the GV-AS Controller User Manual.

October 29, 2015

1.1 GV-AS100 / 1010

1.3 Programming Mode

1.2.5 Connecting the Power

1.2.4 Connecting the PC

1.2.3 Connecting Output Devices

1.2.2 Connecting Input Devices

1.2.1 Connecting Card Readers

Connect card readers (Optional)

Connect AS100 / 1010 to a reader.

Connect input devices

Connect AS100 / 1010 to input devices (Ex: a push button to

exit).

Connect output devices

Connect AS100 / 1010 to output devices (Ex: a door lock).

Connect to PC

Connect the controller to a computer through RS485

connection (AS100) or network connection (AS100 & AS1010).

Connect to Power

Connect AS100 / 1010 to power using the supplied adaptor.

Programming the GV-AS100 / 1010

Create a Master Card (AS100) or Enroll / Delete Card

(AS1010) to add and delete cards. For other settings, use the

built-in keypad to type the commands.

GV-AS100

GV-AS1010

October 29, 2015

1.2 GV-AS110 / 1110

2.3 Programming Mode

2.2.5 Connecting the Power

2.2.3 Connecting Output Devices

2.2.2 Connecting Input Devices

2.2.1 Connecting Card Readers

Connect card readers (Optional)

Connect AS110 / 1110 to a reader..

Connect input devices

Connect AS110 / 1110 to input devices (Ex: a push

button to exit).

Connect output devices

Connect AS110 / 1110 to output devices (Ex: a door

lock).

Connect to Power

Connect AS110 / 1110 to power using the supplied

adaptor.

Programming the GV-AS110 / 1110

Create an Enroll Card and a Delete Card to add and

delete cards. For other settings, use the built-in keypad

to type the commands.

GV-AS110 / 1110

2.2.4 Connecting the PC

Connect to PC

Connect the controller to a computer through RS485

connection (AS110) or network connection (AS110 &

AS1110).

October 29, 2015

1.3 GV-AS120

3.2.1 Connecting a Wiegand Reader

Connect card readers (Optional)

Connect AS120 to a reader through Wiegand

interface.

Connect input devices

Connect AS120 to input devices (Ex: a push

button to exit).

3.2.2 Connecting Input Devices

Connect output devices

Connect AS120 to output devices (Ex: a door

lock).

3.2.3 Connecting Output Devices

Connect to PC

Connect AS120 to a computer through RS485

connection or network connection.

Connect to Power

Connect AS120 to power using the supplied 12V

DC adaptor.

3.2.5 Connecting the Power

RS485 Connection

3.2.4.A RS-485 Connection

Network Connection

3.2.4.B Network Connection

Add and delete cards

Create an Enroll Card and a Delete Card to add

and delete cards.

3.3 Programming Mode

GV-AS120

October 29, 2015

2. Physical Wiring for GV-AS210 / 2110 / 2120 / 410 / 4110 /

810 / 8110 and GV-EV48

2.1 GV-AS210 / 2110 / 2120

4.2.6 Connecting the PC

4.2.5 Connecting the Power

4.2.4 Connecting Backup Battery

4.2.3 Connecting Output Devices

4.2.2 Connecting Input Devices

Wiegand

4.2.1.A Wiegand Readers

RS485

4.2.1.B RS-485 Readers

Connect card readers

Connect AS210 / 2110 / 2120 to readers through

Wiegand or RS-485 interface.

Connect input devices

Connect AS210 / 2110 / 2120 to input devices

(Ex: a push button to exit).

Connect output devices

Connect AS210 / 2110 / 2120 to output devices

(Ex: a door lock).

Connect Backup Battery (Optional)

Connect AS210 / 2110 / 2120 to backup battery

in case the main power supply fails.

Connect to PC

Connect AS210 / 2110 / 2120 to a computer to

access its Web interface and connect with GV-

ASManager.

Connect to Power

Connect AS210 / 2110 / 2120 to power using a

12V DC adaptor (or a PoE adapter for AS2120).

GV-AS210 / 2110 / 2120
