GeoVision GV-BL220D Bedienungsanleitung

GV-BL220D November 2, 2012

- 1 -

GV-BL220D 2MP H.264 IR Bullet IP Camera



•2megapixelprogressivescanCMOS

•DualstreamsfromH.264andMJPEG

•Upto30fpsat1920x1080

•IntelligentIR

•Ingressprotection(IP66)

•Cable‐concealedbracketpreventingcablefrombeingcut

•Onealarminputandsensoroutput

•MemoryCardSlot

•2‐wayaudio

•WideDynamicRange(WDR)

•Motiondetection

•Tamperingalarm

•Privacymask

•IPaddressfiltering

•DC12V/AC24V/PoE

•RemovableIR‐cutfilterforDay/Nightfunction

•SupportsiPhone,iPad,Android&3GPP

•31languagesonWebinterface

•ONVIFconformant

*NoMemoryCardSlot&localstoragefunctionforArgentina.



TheBulletCamerafeaturesaweathersealedandIP66ratinghousingforoutdooruse.Thecameraalsofeatures16IRLEDsforinfrared

illuminationinnightvisionapplications.Additionally,theBulletCamerasupportsbothDC12VandAC24Vpowersupply.



ActiveTamperingAlarm

TamperedFocusChangeCameraShift

Camera

ImageSensor1/2.5"progressivescanCMOS

PictureElements1920(H)x10(V)

Color 1Lux(1/30sec),0.5Lux(1/5sec)

B/W

Minimum

Illumination

IRON

0Lux

ShutterSpeedAutomatic,Manual(1/5~1/8000sec)

WhiteBalanceAutomatic,Manual(2800K~8500K)



GV-BL220D November 2, 2012

- 2 -



Lens

MegapixelYes

Day/NightYes(withremovableIR‐cutfilter)

LensType Varifocal

FocalLength3~9mm

MaximumApertureF/1.3

Mount Ø14mm

ImageFormat1/3”

FocusManual(w/lock)

ZoomManual(w/lock)

Operation

IrisDCDrive

Max.Torque(Focus/ZoomScrews)0.049N.m

IRLEDQuantity16IRLEDs

IRDistance15m/50ft(Max.)

Operation

VideoCompressionH.264,MJPEG

VideoStreamDualstreamsfromH.264andMJPEG

FrameRate

30fpsat1920x1080

*Theframerateandtheperformancemayvarydependingonthenumberofconnectionsanddata

bitrates(differentscenes).

ImageSettingBrightness,Contrast,Sharpness,Gamma,WhiteBalance,Flicker‐less,ImageOrientation,Backlight

Compensation,ShutterSpeed,D/NSensitivity,WDR,Defog

AudioCompressionG.711,AAC(16kHz/16bit)

*AACisonlysupportedbyGV‐SystemV8.5orlater

Two‐wayAudioYes

SensorInput1Input(DryContact)

AlarmOutput1DigitalOutput(200mA5VDC)

VideoResolution

4:31600x1200,1280x960,640x480,320x240

16:91920x1080,1280x720,640x360,448x252

MainStream

5:41280x1024,640x512,320x256

4:3640x480,320x240

16:9640x360,448x252

SubStream

5:4640x512,320x256

Network

Interface10/100Ethernet

ProtocolHTTP,HTTPS,TCP,UDP,SMTP,FTP,DHCP,NTP,UPnP,DynDNS,3GPP/ISMA,RTSP,PSIA,SNMP,QoS

(DSCP),ONVIF

Mechanical

LensMountingø14mm

TemperatureDetector Yes

Pan 0°~360°

Tilt 90°~180°

CameraAngle

Adjustment

Rotate 0°~360°

Power3‐pinterminalblock,PoE

Ethernet RJ‐45

Audio 1In(RCAfemaleformicrophone)

1Out(RCAfemaleforspeaker)

DigitalI/O I/OWires

AutoIris DCDrive

LocalStorageMicroSD/SDHC/SDXCmemorycardslot(forClass6cardorabove)

Connectors

TV‐Out None



GV-BL220D November 2, 2012

- 3 -



General

EnvironmentTemperature ‐20°C~50°C/‐4°F~122°F

Humidity 10%to90%(nocondensation)

PowerSource 12VDC/24VAC/PoE

Max.PowerConsumption 12W

CameraBody277.5x87.75x148.95mm/10.9x3.45x5.86in

CableLength1m/3.28ft

MaximumCable

Diameterø7.1mm/0.28in

Dimensions

MaximumConnector

Diameterø25.2mm/0.99in

Weight 1.35kg/2.98lb

IngressProtectionIP66

Regulatory CE,FCC,C‐Tick,RoHScompliant

PoweroverEthernet

PoEStandard IEEE802.3afPoweroverEthernet/PSE

PoEPowerSupplyType End‐Span

PoEPowerOutput PerPort48VDC,350mA.Max.15.4watts

WebInterface

InstallationManagement Web‐basedconfiguration

MaintenanceFirmwareupgradethroughWebBrowserorUtility

AccessfromWebBrowser

Cameraliveview,videorecording,changevideoquality,bandwidthcontrol,imagesnapshot,digitalI/O

control,audio,WideAngleLensDewarping,PictureinPicture,PictureandPicture,PrivacyMask,Visual

Automation,TamperingAlarm,TextOverlay

Language

Arabic/Bulgarian/Czech/Danish/Dutch/English/Finnish/French/German/Greek/Hebrew/

Hungarian/Indonesian/Italian/Japanese/Lithuanian/Norwegian/Persian/Polish/Portuguese/

Romanian/Russian/Serbian/SimplifiedChinese/Slovakian/Slovenian/Spanish/Swedish/Thai/

TraditionalChinese/Turkish

Applications

NetworkStorageGV‐NVR,GV‐System,GV‐BackupCenter,GV‐RecordingServer

SmartDeviceAccess‐GV‐EyeforAndroidsmartphone,tablet,iPhone,andiPodTouch‐GV‐EyeHDforiPad

LiveViewingIE,GV‐MultiView

CMSServersupport GV‐ControlCenter,GV‐CenterV2,GV‐VSM

Note:Specificationsaresubjecttochangewithoutnotice.


