Geratech EGE-UHDAUD-AMP Bedienungsanleitung

EGE-UHDAUD-AMP

Integrated Zone Amplifier with HDBaseT Capability

EGE-UHDAUD-AMP

Integrated Zone Amplifier with HDBaseT Capability

DISCLAIMERS

The information in this manual has been carefully checked and is believed to be accurate.

Cypress Technology assumes no responsibility for any infringements of patents or other

rights of third parties which may result from its use.

Cypress Technology assumes no responsibility for any inaccuracies that may be contained

in this document. Cypress also makes no commitment to update or to keep current the

information contained in this document.

Cypress Technology reserves the right to make improvements to this document and/or

product at any time and without notice.

No part of this document may be reproduced, transmitted, transcribed, stored in a retrieval

system, or any of its part translated into any language or computer le, in any form or by

any means—electronic, mechanical, magnetic, optical, chemical, manual, or otherwise—

without express written permission and consent from Cypress Technology.

Version VR1.0 January 2015

TRADEMARK ACKNOWLEDGMENTS

All products or service names mentioned in this document may be trademarks of the

companies with which they are associated.

EGE-UHDAUD-AMP

Integrated Zone Amplifier with HDBaseT Capability

SAFETY PRECAUTIONS

Please read all instructions before attempting to unpack, install or operate this equipment

and before connecting the power supply.

Please keep the following in mind as you unpack and install this equipment:

• Always follow basic safety precautions to reduce the risk of re, electrical shock and

injury to persons.

• To prevent re or shock hazard, do not expose the unit to rain, moisture or install this

product near water.

• Never spill liquid of any kind on or into this product.

• Never push an object of any kind into this product through any openings or empty slots

in the unit, as you may damage parts inside the unit.

• Do not attach the power supply cabling to building surfaces.

• Use only the supplied power supply unit (PSU). Do not use the PSU if it is damaged.

• Do not allow anything to rest on the power cabling or allow any weight to be placed

upon it or any person walk on it.

• To protect the unit from overheating, do not block any vents or openings in the unit

housing that provide ventilation and allow for sufcient space for air to circulate around

the unit.

REVISION HISTORY

VERSION NO. DATE DD/MM/YY SUMMARY OF CHANGE

RDV1 23/01/14 Preliminary Release

RDV2 17/04/15 Power Adaptor

RDV3 29/05/15 e-Audio connection

EGE-UHDAUD-AMP

Integrated Zone Amplifier with HDBaseT Capability

CONTENTS

1. Introduction.............................................................1

2. Applications ............................................................1

3. Package Contents ..................................................1

4. System Requirements............................................1

5. Features...................................................................2

6. Operation Controls and Functions .......................3

6.1 Front Panel..........................................................3

6.2 Rear Panel...........................................................4

6.3 RS-232 Pin Assignment.......................................5

6.4 IR Cable Pin Assignment.....................................6

6.5. Remote Control ..................................................7

6.6 OLED Menu.........................................................8

6.7 Telnet & RS-232 Command.................................9

6.8 Telnet Control ....................................................11

6.9 WebGUI Control ................................................13

7. Connection Diagram ............................................14

8. Specications .......................................................15

EGE-UHDAUD-AMP

Integrated Zone Amplifier with HDBaseT Capability

1. INTRODUCTION

The HDBaseTTM 4K UHD with Digital Presentation Amplier can accept analog and

digital audio from 3.5Ø line in, L/R RCA, HDMI, optical and coaxial inputs and output

synchronously to L/R speaker, HDMI and HDMI over CAT5e/6/7 Receiver. Suitable for

any musical events use, sound addition, sound amplifying and AV extension. With audio

sampling rate supports up to 96kHz and I/O data rate supports up to 24-bit, it provides

a high standard of quality sound presentation and can amplier sound up to -80dB. The

system also support HDBaseTTM features including the transmission/receiving high

denition audio and video, PoC (Power over Cable), RS-232 and Ethernet up to 100

meters. The HDMI input/output resolution supports up to 4Kx2K, 3D, 36-bit Deep color, Hi-

Def. new lossless audio and other features dened by the HDMI specications.

2. APPLICATIONS

• Public Speech

• Show even audio set up

• Home theater/Entertainment

• Educational/Lecture presentation

3. PACKAGE CONTENTS

• 1 x HDBaseT 4K UHD with Digital Presentation Amplier

• 1 x Remote Control CR-141

• 1 x 24V/3.75A DC Power Adaptor

• 1 x Power Cable

• 1 x Rack Ears Set

• Operational Manual

4. SYSTEM REQUIREMENTS

Input audio source equipment such as DVD/Blu-ray players, PC, CD player, MP3, HDMI

over CAT5e/6/7 Transmitter and Receiver and etc…. with output display TV/monitor and

active speakers and connection cables.

EGE-UHDAUD-AMP

Integrated Zone Amplifier with HDBaseT Capability

5. FEATURES

• Supports Digital to Analog audio Conversion (DAC) and Analog to

• Digital audio Conversion(ADC)

• Supports input sampling rate up to 96kHz and output at 48kHz

• Speaker each output channel supports 30W/4ohm

• Synchronous output sound on both digital and analog

• Supports HDTV resolutions up to 4Kx2K (3840x2160@24/25/30 & 4096x2160@30Hz)

• Supports distances up to 100 meters through CAT5e/6/7 cables

• HDBaseTTM support PoC (Power over Cable), RS-232 and Ethernet

• Supports RS-232, Telnet, WebGUI, IR and on-panel controls

• Sound supports up to -80dB

EGE-UHDAUD-AMP

Integrated Zone Amplifier with HDBaseT Capability

6. OPERATION CONTROLS AND FUNCTIONS

6.1 Front Panel

EXIT POWER

SERVICE MENU

HDBaseT™ 4K UHD with Digital Presentation Amplifier

1 2 3 4 5 6

1Service: Connect with USB ash driver for rmware update only.

2OLED: Display current input source selection and volume setting.

3IR Window: Accept IR signal from the remote control included in the package.

4MENU: This button has two usage, one for volume control and the other for menu

selection. Turn the wheel to adjust the output sound volume before entering into menu

selection or press it to enter into the menu selection then turn the wheel to rotate from

the selection and press it again to enter or to conrm the selection.

5EXIT: Press this button to exit from the menu selection. When outside the menu

selection press this button to mute the output sound, the LED will illuminate. Press it

again to unmute.

6POWER: Press this button to turn on the device and the LED will illuminate in blue,

press it again to switch to standby mode and the LED will turn red.

EGE-UHDAUD-AMP

Integrated Zone Amplifier with HDBaseT Capability

6.2 Rear Panel

SPEAKER

RS-232

CAT5e/6/7 OUTCAT5e/6/7 IN

COAX.

LANAUDIO-CAT HDMI OUT HDMI IN OPT.

IN RL

DC 24V

V+

GND

GND GND

V+

LINE IN IR IN IR OUT

RCA IN

1 3 4 6 8 1511

2 5 7 9 10 1312 14

1LAN: Connect from PC/Laptop with RJ-45 cable for Telnet/WebGUI controls.

2RS-232: Connect from PC/Laptop with D-Sub 9pin cable for RS-232 controls.

3AUDIO-CAT: Connect from audio Transmitter over CAT5e/6/7 extender for audio

receiving up to 300m.

4HDMI OUT: Connect to HD TV/monitor for both audio and video display.

5CAT5e/6/7 OUT: Connect to HDMI over CAT5e/6/7 Receiver for Audio & Video, IR, RS-

232, LAN and PoC signal sending up to 100m.

6HDMI IN: Connect to DVD/Blu-ray player or any HDMI source equipment for input audio

and video signal sending.

7CAT5e/6/7 IN: Connect from HDMI over CAT5e/6/7 Transmitter for receiving Audio &

Video, IR, RS-232 and LAN signal up to 100m away.

8OPT. IN: Connect from source equipment such as Set-top-box or PS3 or any other

source with optical output for audio signal sending.

9COAX. IN: Connect from source equipment such as Set-top-box or PS3 or any other

source with coaxial output for audio signal sending.

10 RCA IN: Connect from audio source equipment with RCA jack for stereo audio input.

11 SPEAKER: Connect from speakers with wired cable for stereo audio output.

12 LINE IN: Connect from audio device with 3.5ø pone jack for stereo audio signal input.

13 IR IN: Connect the IR Extender for IR signal reception. Ensure that remote being used

is within the direct line-of-sight of the equipment to be controlled.

14 IR OUT: Connect to IR Blaster for IR signal transmission. Place the IR Blaster indirect

line-of-sight of the equipment to be controlled.

15 DC 24V: Plug the 24V DC power supply into the unit and connect the adaptor to an AC

outlet.

EGE-UHDAUD-AMP

Integrated Zone Amplifier with HDBaseT Capability

6.3 RS-232 Pin Assignment

Remote Control

PIN Assignment PIN Assignment

1 NC 1 NC

2 Tx 2 Rx

3 Rx 3 Tx

4 NC 4 NC

5 GND 5 GND

6 NC 6 NC

7 NC 7 NC

8 NC 8 NC

9 NC 9 NC

Baud Rate: 115200bps

Data bit: 8 bits

Parity: None

Flow Control: None

Stop Bit: 1
