Gigabyte P37 Bedienungsanleitung

V7.0

P37

P37V5 V1.0

English

Congratulations on your purchase of the GIGABYTE Notebook.

This manual will help you to get started with setting up your notebook. The final product

conguration depends on the model at the point of your purchase. GIGABYTE reserves the

right to amend without prior notice. For more detailed information, please visit our website at

www.gigabyte.com

1Connect the power cord to the AC adapter.

2Connect the AC adapter to the DC-in jack on the right side of the notebook.

3Connect the power cord to the power outlet.

Using GIGABYTE Notebook for the First Time

Switching on the Power

After you turn on the Notebook for the very

first time, do not turn it off until the operating

system has been configured. Please note that

the volume for the audio will not function until

Windows® Setup has completed.

IMPORTANT

• Ensure that your Notebook PC is connected to a grounded power adapter before turning it on for the rst time.

• When using your Notebook PC on power adapter mode, the socket outlet must be near to the unit and easily accessible.

• Locate the input/output rating label on your Notebook PC and ensure that it matches the input/output rating information on your

power adapter. Some Notebook PC models may have multiple rating output currents based on the available SKU.

• Power adapter information: Input voltage: 100-240Vac ,- Input frequency: 50-60Hz ,- Rating output voltage: 19V or 19.5V

English

Top View & Front View 1Light sensor

2Webcam

3Microphone

4Power Button

5TouchPad

6LED Indicators

7Battery Indicator Button 

8Swappable Storage Bay

Bluetooth Status LED

Wireless Lan Status LED

HDD Status LED

Battery Status LED

Power Status LED

Press the right button of touchpad to

check the remaining battery power.

Right click to show the remaining power

percentage. As shown below, the

battery life indicator is available when

the laptop is shut down, in stand-by or

hibernation.(Battery mode)

<10%

11-30%

31-50%

51-70%

71-90%

>90%

Your GIGABYTE Notebook Tour

Booting Up the Notebook for the First Time

Depending on your conguration, the Microsoft®Windows® Boot Screen will be the rst screen that

you will see as the notebook starts up. Follow the on-screen prompts and instructions and enter

your personal information to complete the setup of the Windows®Operating System.

English

Left View

21 3 6

4 5

1 4 5 6

2 3

1Kensington Lock Slot

2Ethernet Port

3USB 3.0 Port

4SD Card Reader

5Headphone Jack

6Microphone Jack

1Mini Display Port

2USB 3.0 Port (USB Charge)

3USB 3.1 Port

4HDMI Port

5External Display (VGA) Port

6DC-in Jack

1Memory Compartment

2Speakers

Base View

Right View

Warning:

DO NOT remove the built-in lithium battery. For any service needs, please contact your local GIGABYTE

Authorized Service Center.

English

The computer employs hotkeys or key combinations to access most of the computer’s controls like

screen brightness and volume output. To activate hotkeys, press and hold the <Fn> key before

pressing the other key in the hotkey combination.

Hotkey Function Description

Fn+ESC Eject ODD Eject ODD

Fn+F1 Sleep Put the computer in Sleep mode.

Fn+F2 Wireless LAN Enables/disable the Wireless LAN function.

Fn+F3 Brightness Down Decrease the screen brightness.

Fn+F4 Brightness Up Increase the screen brightness.

Fn+F5 Display Toggle

Switche display output between the display

screen, external monitor (if connected) and

both.

Fn+F6 Touchpad Toggle Turn the internal touchpad on and off.

Fn+F7 Speaker Toggle Turn the speaker on and off.

Fn+F8 Volume Down Decrease the sound volume.

Fn+F9 Volume Up Increase the sound volume.

Fn+F10 Screen Display Toggle Turn the screen display on and off.

Fn+F11 Bluetooth Enable/disable the Bluetooth function.

Fn+F12 Webcam Turn the internal webcam on and off.

Fn+Space Keyboard Backlight

Toggle Turn the keyboard backlight on and off.

Macro key

Macro keys can be set via Macro Hub, setting combination keys for complicated and/or general

operation.

Macro key Macro key Description

GMacro group switch, press around 3 secconds as hardware

switch on/off.

G1 User Programmable Macro key

G2 User Programmable Macro key

G3 User Programmable Macro key

G4 User Programmable Macro key

G5 User Programmable Macro key

Hotkeys

English

Swappable bay Application

1Unlock swappable bay locker.

2Draw the swappable bay out.

Connect the HDD or SSD pin by sliding it into the connecter.

9.5mm HDD/SSD only

English

1Pull swappable bay back to slot.

2Lock swappable bay locker.

Gently push the plastic frame outwards. Slide in the HDD or SSD until it locks into place. There will

be a slight click.

English

Welcome to use Macro Hub ! Macro Hub makes it much easier for you to control your Macro Key

on P37. You can deal with complex key stroke combination by just one press on macro key, which

brings you benets both in work and game. Before using Macro Hub, please read following guide,

thanks.

1Launch Macro Hub

You can nd the shortcut of Macro Hub on desktop. Just double click it.

2The overview of Macro Hub

1 3

1Proles: View your current macro command settings.

2Macros: Edit macro command funtions anf settings.

3Settings: Update Macro Hub version or renew macro hub settings.

4Macro Key Group Indicators: Indicate the activated Macro Key Group (the atcivated

group indicator will light up)

5Macro Key Function: Show the programmed Macro functions under the Macro Key

Group, from G1 to G5.

Macro Hub Instruction

English

3Using Macro Hub

1Set Macro Key to basic function

a. Click the G button on the left-top of the

keyboard to switch to the Macro Key

group you would like to use

b. Click the Macro Key function brick

c. Double-click the function you would like to use(ex. Media Player) in the Basic or Macros

function area.

d. Complete the setting

English

2Edit macro command funtions anf settings.

a. Click "Macros" (you can set up to 100 sets of macro)

b. Overview of macro record panel (you can record your own macro here)

1. Start recording: Click when you’re about to record the macro

2. Pause key Switch: Enable/Disable Pause key to stop recording.

3. Macro Name: Set the name of this macro

4. Import icon: Set icon for this macro. You can use default icon or upload your own

icon

5. Record type: You can choose to record only mouse(or keyboard) movement, or

record both. You can also decide to or not to record mouse position.

6. Record interval: You can decide to or not to record the interval of each movement(or

You can set xed interval time between every movement)

7. Execution way: You can set the macro execution way (execution once, repeat

execution or repeat execution with deep press)

8. Export macro: Export your macro

9. Import macro: Import the macro

10. Delete all: Delete all movement in this macro
