Gigabyte Q2440 Bedienungsanleitung

English

Congratulations on the Purchase of Your GIGABYTE Notebook Q2440

This Manual will help you to get started with setting up your notebook.For more detailed

information, please visit our website at www.gigabyte.com.All specications are subject

to the manufacturer's conguration at the time of shipping and may change without prior

notice, written or otherwise.

Using GIGABYTE Notebook for the First Time

Check Supplied Items

AC Adapter Power Cord Battery Pack

Manual Driver CD Warranty Card

* The illustrations in this document may appear differently from your model.

To install the battery please follow these steps:

1Slide the battery into the slot until both latches (Shown as A& B) “click”

into place.You may hear a “clicking” sound, once the battery is secure.

2Slide latch Ato the right to lock the battery in place.

English

Switching on the Power

After you turn on the Q2440 for the very first time, do not turn it off until the

operating system has been configured. Please note that the volume for the

audio will not function until Windows® Setup has completed.

Booting Up the Q2440 for the First Time

Depending on your conguration, the Microsoft® Windows® Boot Screen will be

the rst screen that you will see as the notebook starts up. Follow the on-screen

prompts and instructions and enter your personal information to complete the

setup of the Windows® Operating System.

1Connect the power cord to the AC adapter.

2Connect the AC adapter to the DC-in jack on the right side of the notebook.

3Connect the power cord to the power outlet.

English

Your GIGABYTE Notebook Tour

Top View

Left View

1 2

2 3 4 5 71 6

1Webcam

2Display

3Speakers

4Power Button

5Keyboard

6TouchPad

6TouchPad Buttons

1Kensington Lock Slot

2DC-in Jack

3LAN (RJ-45) Port

4External Moniter (VGA) Port

5HDMI Port

6USB3.0 Port*2

7Audio Jack

English

Front & Bottom & Rear View

Right View

1Optical Disc Drive

2USB 2.0 Port

3 4

1 2

1Flash Memory Card Reader

2LED Power Indicators 

3Battery Bay

4Component Compartment

Power Status LED

RF Status LED

HDD Status LED

Battery Status LED

English

Using the <Fn> key with another key creates a hot key, providing a quick and

convenient method for controlling various functions. To use a hot key, rst hold down

the <Fn> key. Next, press the second key in the combination. Finally, release both keys.

Hotkey Function

Fn + ESC Bluetooth on/off

Fn + F1 Suspend

Fn + F2 Silent Mode

Fn + F3 Mute on/off

Fn + F4 Display output switching

Fn + F5 Decrease the speaker volume

Fn + F6 Increase the speaker volume

Fn + F7 Decrease the brightness level

Fn + F8 Increase the brightness level

Fn + F9 Touch Pad disable/enable

Fn + F10 WLAN on/off

Fn + F11 Webcam on/off

Function & Hot Key Indicators

English

6GIGABYTE Smart Recovery

● System Recovery (Restore your Q2440 Operating system):

The hard drive of the Q2440 has a hidden partition that contains a full backup image

of the operating system that can be used to recover the system in the event that

something happens to the operating system.

CAUTION:

If the hard drive is removed or the partition deleted. the recover options will no

longer be available and a recovery service will be needed.

● Launch System Recovery :

The system recover feature is part of the Notebook installation and it ships preset

from the factory. The options menu allows you to launch the WIndows recovery tool to

reinstall the operating system to factory defaults.

● Below will briefly describe how to launch the recovery tool and to get the recovery

started.

1.Turn off or restart the Notebook.

2.Turn the Notebook on the press and hold the F9 Key to launch the tool.

3.The recovery window will open and give you

the option to "Recovery" in the toolbar. You will

be prompted if you want to recovery. Click on

"Recovery" to begin the repair if you do.

4.The "Recoverying " windos will open and begin the

recovery.

5.Once it is complete. you will be prompted to reboot

the Notebook.

English

Model Name Q2440

CPU 3rd Generation Intel®Pentium & Core™ i3 / i5 / i7

Processor

OS Genuine Windows®7 Compliant

Display 14" 1366x768 LED backlight

System Memory DDRIII, 2 slots(Max 8GB)

Chipset Mobile Intel®HM76 Express Chipsets

Video Graphics Intel®HD Graphics 40000

Storage 2.5" 9.5mm HDD 5400rpm

ODD 9.5mm Super Multi DVD RW

I/O Port

USB(3.0)*2, USB(2.0)*1,HDMI, D-Sub, RJ45, Mic-in,

Earphone-out, 6-in-1 card reader(SD/MMC/MS/MS Pro/

SDXC/SDHC), DC-in jack

Audio Microphone

Communications

10/100/1000Mbps Ethernet

802.11b/g/n Wireless

Bluetooth V4.0

Webcam 1.3 Megapixel

Security Kensington Lock

Battery Li-on 6-cell, 4400mAh, 48.84Wh

Dimensions 343(W) X 255(D) X 25.4 (H)mm

Weight ~2.1kg(w/ODD and 6-cell battery)

* This specication is for users’ reference only. The nal conguration depends on the users' bought.

Specication

Appendix

■ Warranty & Service:

For Warranty, Service and related information, please refer to the warranty

card or GIGABYTE service website as the following link:

http://www.gigabyte.com/support-downloads/technical-support.aspx

■ FAQ:

For FAQ (Frequent Asked Questions), please refer to the following link:

http://www.gigabyte.com/support-downloads/faq.aspx
