Gigabyte GA-7IXE Bedienungsanleitung

FCC Compliance Statement:

This equipment has been tested and found to

comply with limits for a Class B digital device,

pursuant to Part 15 of the FCC rules. These

limits are designed to provide reasonable

protection against harmful interference in

residential installations. This equipment

generates, uses, and can radiate radio

frequency energy, and if not installed and used

in accordance with the instructions, may cause

harmful interference to radio communications.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does cause

interference to radio or television equipment

reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the

following measures:

-Reorient or relocate the receiving antenna

-Move the equipment away from the receiver

-Plug the equipment into an outlet on a circuit different from that to which

the receiver is connected

-Consult the dealer or an experienced radio/television technician for

additional suggestions

You are cautioned that any change or modifications to the equipment not

expressly approve by the party responsible for compliance could void Your

authority to operate such equipment.

This device complies with Part 15 of the FCC Rules. Operation is subjected to

the following two conditions 1) this device may not cause harmful interference

and 2) this device must accept any interference received, including

interference that may cause undesired operation.

DECLARATION OF CONFORMITY

Per FCC Part 2 Section 2. 1077(a)

Responsible Party Name: G.B.T. INC.

Address: 18305 Valley Blvd., Suite#A

LA Puent, CA 91744

Phone/Fax No: (818) 854-9338/ (818) 854-9339

hereby declares that the product

Product Name:

Model Number:

Mother Board

Conforms to the following specifications:

FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),

Class B Digital Device

Supplementary Information:

This device complies with part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) This device may not cause harmful

and (2) this device must accept any inference received, including

that may cause undesired operation.

Representative Person's Name: ERIC LU

Signature:

Date: Jan. 12, 2000

Eric LuEric Lu

GA-7IXE

Declaration of Conformity

We, Manufacturer/Importer

(full address)

G.B.T. Technology Träding GMbH

Ausschlager Weg 41, 1F, 20537 Hamburg, Germany

declare that the product

( description of the apparatus, system, installation to which it refers)

Mother Board

GA-7IXE

is in conformity with

(reference to the specification under which conformity is declared)

in accordance with 89/336 EEC-EMC Directive

EN 55011 Limits and methods of measurement EN 61000-3-2* Disturbances in supply systems caused

of radio disturbance characteristics of EN60555-2 by household appliances and similar

industrial, scientific and medical (ISM electrical equipment “Harmonics”

high frequency equipment

EN55013 Limits and methods of measurement EN61000-3-3* Disturbances in supply systems caused

of radio disturbance characteristics of EN60555-3 by household appliances and similar

broadcast receivers and associated electrical equipment “Voltage fluctuations”

equipment

EN 55014 Limits and methods of measurement EN 50081-1 Generic emission standard Part 1:

of radio disturbance characteristics of Residual, commercial and light industry

household electrical appliances,

portable tools and similar electrical EN 50082-1 Generic immunity standard Part 1:

apparatus Residual, commercial and light industry

EN 55015 Limits and methods of measurement EN 55081-2 Generic emission standard Part 2:

of radio disturbance characteristics of Industrial environment

fluorescent lamps and luminaries

EN 55020 Immunity from radio interference of EN 55082-2 Generic immunity standard Part 2:

broadcast receivers and associated Industrial environment

equipment

EN 55022 Limits and methods of measurement ENV 55104 Immunity requirements for household

of radio disturbance characteristics of appliances tools and similar apparatus

information technology equipment

DIN VDE 0855 Cabled distribution systems; Equipment EN 50091- 2 EMC requirements for uninterruptible

part 10 for receiving and/or distribution from power systems (UPS)

part 12 sound and television signals

CE marking (EC conformity marking)

The manufacturer also declares the conformity of above mentioned product

with the actual required safety standards in accordance with LVD 73/23 EEC

EN 60065 Safety requirements for mains operated EN 60950 Safety for information technology equipment

electronic and related apparatus for including electrical business equipment

household and similar general use

EN 60335 Safety of household and similar EN 50091-1 General and Safety requirements for

electrical appliances uninterruptible power systems (UPS)

Manufacturer/Importer

Signature : Rex Lin

(Stamp) Date: Jan. 12, 2000 Name : Rex Lin

R-11-01-000106

7IXE

AMDTM Athlon AGP Motherboard

USER'S MANUAL

AMDTM Athlon Processor Motherboard

REV. 1.1 First Edition

How This Manual Is Organized

This manual is divided into the following sections:

1) Revision List Manual revision information

2) Item Checklist Product item list

3) Features Product information & specification

4) Hardware Setup Instructions on setting up the motherboard

5) Performance & Block Diagram Product Performance & Block Diagram

6) BIOS Setup Instructions on setting up the BIOS

software

7) Appendix General reference

Table Of Content

Revision History P.1

Item Checklist P.2

Summary of Features P.3

7IXE Motherboard Layout P.5

Page Index for Connectors / Panel and Jumper Definition P.6

Performance List P.19

Block Diagram P.20

Memory Installation P.21

Page Index for BIOS Setup P.22

Appendix P.55

7IXE Motherboard

Revision History

Revision Revision Note Date

1.1 Initial release of the 7IXE motherboard user’s manual. Jan.2000

The author assumes no responsibility for any errors or omissions that may appear in this

document nor does the author make a commitment to update the information contained herein.

Third-party brands and names are the property of their respective owners.

Jan. 6, 2000 Taipei, Taiwan, R.O.C

Item Checklist

þThe 7IXE Motherboard

þCable for IDE / Floppy device

þDiskettes or CD (TUCD) for motherboard utilities

oInternal COM2 Cable (Optional)

oInternal USB Cable (Optional)

oCable for SCSI device

þ7IXE User’s Manual

7IXE Motherboard

Summary Of Features

Form factor Ÿ26 cm x 18 cm ATX SIZE form factor, 4 layers PCB.

CPU ŸAMD Athlon(K7) Slot A Processor

Ÿ512 KB 2nd cache in CPU Module

ŸSupports 500MHz ~ 1GHz and faster

Chipset AMD750 ,consisting of:

ŸAMD 751 PCI/AGP Controller(PAC)

ŸAMD 756 PCI ISA IDE Controller

Clock Generator ŸSupports 90 / 95 / 100 / 105 / 110 / 115MHz

Memory Ÿ3 168-pin DIMM Sockets

ŸSupports SDRAM 16MB~768MB(Max)

ŸSupports only 3.3V SDRAM DIMM

I/O Control ŸWinbond 83977

Slots Ÿ1 AGP (Accelerated Graphics Port) slot

-AGP 66 / 133 MHz 3.3V device support

Ÿ5 32-bit Master PCI Bus slots

Ÿ2 16-bit ISA Bus slots

On-Board IDE ŸAn IDE controller on the AMD 756 PCI chipset

provides IDE HDD/ CD-ROM with PIO, Bus Master ,

Ultra DMA33/ATA 66 Operation modes

ŸCan connect up to four IDE devices

Hardware Monitor

(Optional) ŸCPU/Power Supply/System Fan Revolution detect

ŸCPU / Power / System Fan Control

ŸSystem Voltage Detect

ŸCPU Overheat Warning

ŸChassis Intrusion Detect

ŸDisplay Actual Current Voltage

On-Board

Peripherals Ÿ1 Floppy port supports 2 FDD with 360K, 720K,1.2M,

1.44M and 2.88M bytes

Ÿ1 Parallel port supports SPP/EPP/ECP mode

Ÿ2 Serial Ports (COMA & COMB)

Ÿ4 USB ports

Ÿ1 IrDA connector for IR

PS/2 Connector ŸPS/2Keyboard interface and PS/2Mouse

interface

BIOS ŸLicensed AMI BIOS, 2M bit FLASH ROM

To be continued…

Summary of Features

Additional Features ŸInternal/External Modem Wake up

ŸKeyboard Password Wake up

ŸMouse Wake up

ŸLAN Wake up

ŸSystem after AC back
