GA-H61N-USB3

User's Manual

Rev. 1001

12ME-H61NUB3-1001R

Motherboard

GA-H61N-USB3

Jul. 15, 2011

Motherboard

GA-H61N-USB3

The trademarks mentioned in this manual are legally registered to their respective owners.

Disclaimer

Information in this manual is protected by copyright laws and is the property of GIGABYTE.

Changes to the specications and features in this manual may be made by GIGABYTE without

prior notice. No part of this manual may be reproduced, copied, translated, transmitted, or

published in any form or by any means without GIGABYTE's prior written permission.

Documentation Classications

In order to assist in the use of this product, GIGABYTE provides the following types of documentations:

For quick set-up of the product, read the Quick Installation Guide included with the product.

For detailed product information, carefully read the User's Manual.

For product-related information, check on our website at:

http://www.gigabyte.com.

Identifying Your Motherboard Revision

The revision number on your motherboard looks like this: "REV: X.X." For example, "REV: 1.0"

means the revision of the motherboard is 1.0. Check your motherboard revision before updating

motherboard BIOS, drivers, or when looking for technical information.

Example:

- 4 -

Table of Contents

Box Contents...................................................................................................................6

Optional Items .................................................................................................................6

GA-H61N-USB3 Motherboard Layout .............................................................................7

GA-H61N-USB3 Motherboard Block Diagram.................................................................8

Chapter 1 Hardware Installation .....................................................................................9

1-1 Installation Precautions.................................................................................... 9

1-2 Product Specications.................................................................................... 10

1-3 Installing the CPU and CPU Cooler ............................................................... 13

1-3-1 Installing the CPU...................................................................................................13

1-3-2 Installing the CPU Cooler .......................................................................................15

1-4 Installing the Memory..................................................................................... 16

1-4-1 Dual Channel Memory Conguration .....................................................................16

1-4-2 Installing a Memory ...............................................................................................17

1-5 Installing an Expansion Card ......................................................................... 18

1-6 Back Panel Connectors.................................................................................. 19

1-7 Internal Connectors........................................................................................ 21

Chapter 2 BIOS Setup ..................................................................................................29

2-1 Startup Screen ............................................................................................... 30

2-2 The Main Menu .............................................................................................. 31

2-3 MB Intelligent Tweaker(M.I.T.)........................................................................ 33

2-4 Standard CMOS Features.............................................................................. 41

2-5 Advanced BIOS Features .............................................................................. 43

2-6 Integrated Peripherals.................................................................................... 45

2-7 Power Management Setup............................................................................. 47

2-8 PC Health Status............................................................................................ 49

2-9 Load Fail-Safe Defaults.................................................................................. 50

2-10 Load Optimized Defaults................................................................................ 50

2-11 Set Supervisor/User Password ...................................................................... 51

2-12 Save & Exit Setup .......................................................................................... 52

2-13 Exit Without Saving........................................................................................ 52

- 5 -

Chapter 3 Drivers Installation........................................................................................53

3-1 Installing Chipset Drivers ............................................................................... 53

3-2 Application Software ...................................................................................... 54

3-3 Technical Manuals.......................................................................................... 54

3-4 Contact........................................................................................................... 55

3-5 System ........................................................................................................... 55

3-6 Download Center ........................................................................................... 56

3-7 New Utilities ................................................................................................... 56

Chapter 4 Unique Features...........................................................................................57

4-1 Xpress Recovery2.......................................................................................... 57

4-2 BIOS Update Utilities ..................................................................................... 60

4-2-1 Updating the BIOS with the Q-Flash Utility.............................................................60

4-2-2 Updating the BIOS with the @BIOS Utility .............................................................63

4-3 EasyTune 6 .................................................................................................... 64

4-4 Dynamic Energy Saver™2.............................................................................. 65

4-5 Q-Share.......................................................................................................... 67

4-6 Smart 6™....................................................................................................... 68

4-7 Auto Green..................................................................................................... 72

4-8 Cloud OC ....................................................................................................... 73

Chapter 5 Appendix ......................................................................................................75

5-1 Conguring Audio Input and Output............................................................... 75

5-1-1 Conguring 2/4/5.1/7.1-Channel Audio...................................................................75

5-1-2 Conguring S/PDIF Out..........................................................................................78

5-1-3 Conguring Microphone Recording........................................................................79

5-1-4 Using the Sound Recorder .....................................................................................81

5-2 Troubleshooting.............................................................................................. 82

5-2-1 Frequently Asked Questions ..................................................................................82

5-2-2 Troubleshooting Procedure ....................................................................................83

- 6 -

Box Contents

GA-H61N-USB3 motherboard

Motherboard driver disk

User's Manual

Quick Installation Guide

Two SATA cables

I/O Shield

Optional Items

2-port USB 2.0 bracket (Part No. 12CR1-1UB030-5*R)

2-port SATA power cable (Part No. 12CF1-2SERPW-0*R)

The box contents above are for reference only and the actual items shall depend on the product package you obtain.•

The box contents are subject to change without notice.

The motherboard image is for reference only.•

- 7 -

GA-H61N-USB3 Motherboard Layout

(Note 1) The LAN chip is located on the back of the motherboard.

(Note 2) The BIOS ash ROM is located below the latch on the PCIEX16 slot.

R_SPDIF

VGA_DVI

CPU_FAN

LGA1155

ATX

GA-H61N-USB3

F_AUDIO

M_BIOS

PCIEX16

DDR3_1

DDR3_2

BAT

ATX_12V

Intel®H61

USB_HDMI

USB_ESATA

CODEC

TPM

SATA2_1

Fresco

FL1009

iTE IT8728

CLR_CMOS

F_PANEL

F_USB2

F_USB1

SYS_FAN

SPDIF_O

PHASE LED

SATA2_0

B_BIOS (Note 2)

Realtek

RTL8111E (Note 1)

AUDIO

USB30_LAN

- 8 -

GA-H61N-USB3 Motherboard Block Diagram

LGA1155

CPU

PCI Express Bus

CPU CLK+/- (100 MHz)

PCIe CLK

(100 MHz) DDR3 1333/1066/800 MHz

Dual Channel Memory

1 PCI Express x16

x16

DMI Interface

FDI Interface

PCI Express Bus

2 USB 3.0/2.0

Fresco

FL1009

LAN

RJ45

Realtek

RTL8111E

8 USB 2.0/1.1

3 SATA 3Gb/s

Dual BIOS

D-Sub

iTE

IT8728

LPC

Bus

HDMI

x1 x1

DVI-D

Line Out (Front Speaker Out)

MIC (Center/Subwoofer Speaker Out)

Line In (Rear Speaker Out)

CODEC

S/PDIF Out

Intel®H61

- 9 - Hardware Installation

1-1 Installation Precautions

The motherboard contains numerous delicate electronic circuits and components which can

become damaged as a result of electrostatic discharge (ESD). Prior to installation, carefully read

the user's manual and follow these procedures:

Prior to installation, do not remove or break motherboard S/N (Serial Number) sticker or•

warranty sticker provided by your dealer. These stickers are required for warranty validation.

Always remove the AC power by unplugging the power cord from the power outlet before•

installing or removing the motherboard or other hardware components.

When connecting hardware components to the internal connectors on the motherboard,•

make sure they are connected tightly and securely.

When handling the motherboard, avoid touching any metal leads or connectors.•

It is best to wear an electrostatic discharge (ESD) wrist strap when handling electronic com-•

ponents such as a motherboard, CPU or memory. If you do not have an ESD wrist strap,

keep your hands dry and rst touch a metal object to eliminate static electricity.

Prior to installing the motherboard, please have it on top of an antistatic pad or within an•

electrostatic shielding container.

Before unplugging the power supply cable from the motherboard, make sure the power sup-•

ply has been turned off.

Before turning on the power, make sure the power supply voltage has been set according to•

the local voltage standard.

Before using the product, please verify that all cables and power connectors of your hard-•

ware components are connected.

To prevent damage to the motherboard, do not allow screws to come in contact with the•

motherboard circuit or its components.

Make sure there are no leftover screws or metal components placed on the motherboard or•

within the computer casing.

Do not place the computer system on an uneven surface•

Do not place the computer system in a high-temperature environment.•

Turning on the computer power during the installation process can lead to damage to sys-•

tem components as well as physical harm to the user.

If you are uncertain about any installation steps or have a problem related to the use of the•

product, please consult a certied computer technician.

Chapter 1 Hardware Installation

- 10 -

Hardware Installation

1-2 ProductSpecications

CPU Support for an Intel®Core™i7 series processor/Intel®Core™i5 series processor/

Intel®Core™i3 series processor/Intel®Pentium®processors/Intel®Celeron®

processors in the LGA1155 package

(Go to GIGABYTE's website for the latest CPU support list.)

L3 cache varies with CPU

Chipset Intel®H61 Express Chipset

Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory

* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical

memory is installed, the actual memory size displayed will be less than 4 GB.

Dual channel memory architecture

Support for DDR3 1333/1066/800 MHz memory modules

Support for non-ECC memory modules

(Go to GIGABYTE's website for the latest supported memory speeds and memory

modules.)

Onboard

Graphics

Integrated Graphics Processor:

- 1 x D-Sub port

- 1 x DVI-D port, supporting a maximum resolution of 1920x1200

* The DVI-D port does not support D-Sub connection by adapter.

- 1 x HDMI port, supporting a maximum resolution of 1920x1200

Audio Realtek ALC889 codec

High Denition Audio

2/4/5.1/7.1-channel

* To congure 7.1-channel audio, you have to use an HD front panel audio module

and enable the multi-channel audio feature through the audio driver.

Support for S/PDIF Out

LAN 1 x Realtek RTL8111E chip (10/100/1000 Mbit)

Expansion Slots 1 x PCI Express x16 slot, running at x16

(The PCIEX16 slot conforms to PCI Express 2.0 standard.)

Storage Interface Chipset:

- 2 x SATA 3Gb/s connectors (SATA2_0, SATA2_1) supporting up to 2 SATA

3Gb/s devices

- 1 x eSATA 3Gb/s connector on the back panel supporting up to 1 SATA

3Gb/s device

USB Chipset:

- Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets

connected to the internal USB headers)

Fresco FL1009 chip:

- Up to 2 USB 3.0/2.0 ports on the back panel

Inhaltsverzeichnis

Andere Gigabyte Hauptplatine Handbücher

Gigabyte

Gigabyte GA-EX58-UD5 Bedienungsanleitung

Gigabyte

Gigabyte X670 AORUS ELITE AX Bedienungsanleitung

Gigabyte

Gigabyte GA-8IRXP Bedienungsanleitung

Gigabyte

Gigabyte GA-8EGXR+ Series Bedienungsanleitung

Gigabyte

Gigabyte 6VM7-4I Bedienungsanleitung

Gigabyte

Gigabyte GA-6VXD7 Bedienungsanleitung

Gigabyte

Gigabyte GA-965QM-DS2 Bedienungsanleitung

Gigabyte

Gigabyte GA-P45T-ES3G Bedienungsanleitung

Gigabyte

Gigabyte GA-73PVM-S2 Bedienungsanleitung

Gigabyte

Gigabyte GA-7ZMMH Bedienungsanleitung

Gigabyte

Gigabyte Ultra Durable 3 Bedienungsanleitung

Gigabyte

Gigabyte GA-C847N Bedienungsanleitung

Gigabyte

Gigabyte R271-Z31 Bedienungsanleitung

Gigabyte

Gigabyte B650E AORUS ELITE X AX ICE Bedienungsanleitung

Gigabyte

Gigabyte MNJ190I-FH Bedienungsanleitung

Gigabyte

Gigabyte GA-EP45-DS5 Bedienungsanleitung

Gigabyte

Gigabyte GA-8ILMT4 Bedienungsanleitung

Gigabyte

Gigabyte MZ72-HB2 Bedienungsanleitung

Gigabyte

Gigabyte GA-P55A-UD3P Bedienungsanleitung

Gigabyte

Gigabyte MS33-AR1 Bedienungsanleitung

Gigabyte

Gigabyte B760M E Bedienungsanleitung

Gigabyte

Gigabyte GA-P67A-UD7 Bedienungsanleitung

Gigabyte

Gigabyte GA-6VM7-4I Bedienungsanleitung

Gigabyte

Gigabyte GA-7VM Bedienungsanleitung

Beliebte Hauptplatine Handbücher anderer Marken

DFI

DFI SD170 Bedienungsanleitung

ASROCK

ASROCK ROMED8-2T Bedienungsanleitung

Asus

Asus P2L97A Bedienungsanleitung

Winmate

Winmate IC70 Bedienungsanleitung

Asus

Asus MES-B Bedienungsanleitung

Grantech

Grantech SYS8F377VGGA-3OMN Bedienungsanleitung

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Bedienungsanleitung

Texas Instruments

Texas Instruments ADS8372EVM Bedienungsanleitung

Commell

Commell MS-C73 Bedienungsanleitung

IBT Technologies

IBT Technologies MB860 Bedienungsanleitung

Nvidia

Nvidia TEGRA DG-04927-001_V01 Bedienungsanleitung

Biostar

Biostar M7VIT Bravo Bedienungs- und Montageanleitung

Intel

Intel D33217CK Bedienungsanleitung

Asus

Asus F1A55-M LX PLUS R2.0 Bedienungsanleitung

EPC

EPC EPC9147C Bedienungsanleitung

Asus

Asus EX-B760M-V5 D4 Bedienungsanleitung

EPOX

EPOX MU-8KHA0010 Bedienungsanleitung

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Bedienungsanleitung
