MODEL NO 型號: GMFH15W
1500W
MINI MIst FaN WItH
HEatING FuNctION
迷你放濕機 (加熱功能)
A GILMAN GROUP BRAND
2
Please read and retain for future reference.
• Verify that the mains voltage is the same as that indicated on the rating plate
on the appliance before use.
• Make sure that you always use a grounded wall socket to connect the appliance.
• Always remove the plug from the wall socket when the appliance is not in use.
• Remove the plug from the wall socket by pulling the plug, not the power cord.
• Make sure that the appliance, the power cord and plug do not make contact
with water.
• Make sure that the appliance, the power cord and plug do not make contact
with hot surface, such as a hot hob or naked ame.
• Check the appliance’s power cord regularly to make sure it is not damaged.
• Do not use the appliance if the power cord is damaged. If the power cord is
damaged, it must be replaced by an electrical technician or a person with
similar qualication, in order to avoid any hazards.
• The appliance needs space to allow heat to escape, thereby preventing the
risk of re. Make sure that the appliance has sufcient space around it, and
does not come in contact with ammable material. The appliance, the air
vents must not be covered or blocked when use.
SAFETY INSTRUCTION - GENERAL
SAFETY INSTRUCTION - ELECTRICITY AND HEAT
• Use this appliance solely in accordance with these instructions.
• This appliance is for household use only, not for commercial purpose.
• Remove all packaging material from the appliance before use.
• This appliance shall not be used by children of 0 to 8-year old.
• This appliance can be used by children older than 8-year old and persons
with reduced physical, sensory or mental capabilities or lack of experience
and knowledge, but only if they have been given supervision or instruction
concerning use of the appliance in safe way and understand the hazards
involved.
• Children should be supervised to ensure that they do not play with the appliance.
• Cleaning and maintenance must not be done by children.
• Have any repairs carried out solely by a qualied electrician. Never try to repair
the appliance yourself.
• Do not handle the plug or appliance with wet hands.
• Do not immerse the main body in water.
• Children shall not play with the appliance.
• Do not leave the appliance unattended when connected to the mains supply.
• Keep hair, loose clothing, ngers and all parts of the body away from openings
of the appliance.
• Only use the attachments/accessories supplied with the product.
3
• Never use the appliance in the vicinity of ammable material.
• Certain part of the appliance may get hot, such as air outlet. Do not touch
these part to prevent scalding yourself.
• Do not use the appliance in areas such as garages where petrol, paint or
other ammable substances are used or stored.
• Do not place the appliance to furniture, animals, curtains or other inammable
objects.
• Do not place the appliance on bedding or on thick and long pile carpet where
the openings may be blocked.
• The appliance should not be used in the immediate vicinity of water, such as
bathtub, washbowls, bathroom swimming pool etc. where the likelihood of im-
mersion or splashing could occur.
• A common cause of overheating is deposits of dust and uff entering the
appliance. Ensure these deposits are removed regularly by unplugging the
appliance.
• Be sure that no other high current appliances are plugged into the same
circuit with your heater as an overload can occur.
• Don’t close the inlet and outlet of the appliance to the wall, curtain and other
entities, so as not to block the air ow, affect the air supply effect or other
dangers.
• When adding water, the water level shall not exceed the highest (max)
indicating scale-around 420ml, nor lower than the lowest (min) indicating
scale-around 75ml;
• Don’t place the appliance in tilted or other unbalanced places, so as not to
cause water tank overow, the appliance rollover, resulting in product damage
or other safety accidents; if the appliance is accidentally dumped, stop using
the product immediately, pull out the power plug, check whether there is water
inside the product, dry the product fully and ensure safety before using it, and
send it to the maintenance department for repair if necessary.
• Don’t pull the appliance shaking head mechanism, so as not to damage the
internal structure.
• The appliance has mist function, recommend to use pure water, and clean
the water tank before usage. To avoid breeding bacterial, scale and foreign
matter, etc; After use, the excess water in the water tank is discharged clean,
if not used for a long time, the water tank should be cleaned.
• It is prohibited to use essential oils on the appliance.
• If this appliance is used in an air-conditioned room, it is normal occurrence for
water droplets to ow back or stay at the spray nozzle.
SAFETY INSTRUCTION - DURING OPERATION
4
Front view
1. Water Tank
2. Air outlet
3. Mist Vent
4. Base
5. Heating element
6. Housing
7. Tip-over switch
8. Main power On/Off button
1
2
5 6
3
4
Back view
PRODUCT OVERVIEW
7 8 9 10 11 12
13
14
15
9. OSC button
10. Mist button
11. Heating mode button
12. Power button
13. Water tank cover
14. Absorbent cotton
15. Absorbent cotton sleeve
5
1. Carefully remove the appliance from the plastic bag and the carton.
2. Place the appliance on a at surface oor.
3. Pull out the water tank, pick up the tank cover, add water to the water tank to max.
line-around 420ml. (Suggest to use pure water)
OPERATING INSTRUCTION
4. When adding water, the water level shall not exceed the highest (max) indicating
scale-around 420ml, nor lower than the lowest (min) indicating scale-around 75ml;
5. After adding water, don’t tilt, lie on the side or invert the water tank to prevent water
from inltrating the circuit board.
6. Don’t dip the tank lid into the water because it has a circuit board inside.
7. Close the water cover and water tank, gently push the water tank in to the appliance,
and push in position properly.
8. Inset the product power cord plug into the power socket, press the main On/Off but-
ton to “I” (ON) position, hear the sound of “di”, indicating that the appliance has been
connected to the power, the power indicator is red, into the standby state, according
to the need to select the function.
9. Power button : press this button in standby state, the power indicator turns green,
the appliance starts to work, default fan & mist mode, press this button again, the
appliance shutdown into standby state; press this button under heating mode, the
appliance will turn off about after 30 seconds delay.
10. Heating mode button : Press this button when the appliance is on, the Low-heat
indica
tor lights up, the appliance is in low heat mode, press the heating button again, the
High-heat
indicator lights up, the appliance is in high-heat mode, press the heating
button in third, the product turns to fan mode. Fan => Low-heat mode => High-heat
mode, cycle work.
11. Mist button : press this button when the appliance is on, the mist indicator will light
up and the mist function will start. Press this button again, the mist indicator is off and
the mist function is closed.
Note:
It is recommended to clean the water tank every 72 hours during use. This appli-
ance has a 72-hour cleaning reminder function: (both on and standby time), after
72 hours accumulated, the appliance enters the cleaning reminder state: the mist
indicator and the power indicator ash at the same time, and the buzzer sounds
once every 10 seconds. Press the power button of the control panel, the appliance
exits the cleaning reminder state and cleans the water tank. Clean the water tank
6
CLEAN & STORAGE
TIP-OVER AUTO-OFF SAFETY SYSTEM
• Your appliance must be switched OFF and disconnect to the main power supply
and unplugged before proceeding with any cleaning work.
• Clean the housing with a lightly damp cloth of the appliance.
• Never use ammable or abrasive cleaning agents such as benzene or spirit to
clean the appliance.
• Never immerse the appliance in water!
• Clean the air outlet regularly.
• If the appliance is not used for an extended period it must be protected against
excessive dust and dirt. Please pack the appliance and store in a dry place away
from sunlight and dirt.
• Clean the Absorbent cotton (Page 4. Item 14): Suggest replace every 3 to 6 months.
Open the water tank cover, take out the absorbent cotton sleeve & absorbent
cotton if scale and dirties on the surface of the absorbent cotton, it can be washed
with water or washed with citric acid.
When appliance inclines from vertical or tip-over, it will stop working. When appli-
ance is returned to upright position, it can connect the power again and returns to
standby mode, set the desire setting to start operating again. Do not use on thick
and long pile carpet, as the appliance may not work due to the tip-over switch not
been activated.
and install in the appliance, turn it on again or in the standby state, after accumulating
to 72 hours, the 72-hour cleaning reminder function will be automatically activated.
Remark when the main power or tip-over switch were disconnected , the 72 hours
will be recovered.
This appliance uses intelligent timing or water tank without water reminder to add
water; every time you start spraying, the countdown starts, and continuous spraying
for 6 hours or water tank without water will automatically remind you to add water.
When entering the reminder, the buzzer will sound “beep beep beep” , then the mist
indicator ashes and the mist function is turned off; before adding water, please push
power button of the control panel to turn off the appliance. After adding water to reset,
you need to press mist button again to enter the mist function.
12. OSC button : press this button when the appliance is on, the OSC indicator will
light up and OSC function will start. Press this button again, the OSC function is
closed.
7
TROUBLESHOOTING
PROBLEM CAUSE SOLUTION
Don’t work
• The power cord plug is not inserted or poor
contact.
• The power switch behind the fuselage is not
opened.
• The table is not smooth, the Tip-over switch
is disconnected.
• The power button on the control panel is not
pressed.
• Plug in the power cord and make it in good
contact.
• Press the Main power On/ Off Button
behind the fuselage to the “I” (on) position.
• Put the product in a at position.
• After switching on the power, press the
power button to start working.
Don’t mist
• There is not water in the water tank.
• The water tank is not install in position of
the appliance properly.
• Pull out the water tank, open the water tank
cover, add water.
• Install the water tank and push in position
properly.
Don’t heat • The air outlet is blocked.
• Thermostat trips.
• Check the air outlet to make sure it is not
blocked.
• Other abnormalities (such as blocking)
cause the thermostat to overheat and trip,
and the heating will be automatically turned
on after the temperature drops.
PRODUCT SPECIFICATIONS
Model no.: GMFH15W
Voltage: 220-240V~
Frequency: 50Hz
Output power: 1500W
Product dimensions: 269(H) x 150(W) x 133(D) mm
*The nal product specication may be varied according to a different lot of ma-
terial and actual input voltage power of the usage area.
8
安全指引 - 一般安全
安全指引 - 電子和熱能產品
- 請按照這些說明事項, 使用本產品。
- 本產品僅供家用，不作商業用途。
- 使用前，請將所有包裝材料拆除。
- 0至8歲的兒童不應使用本產品。
- 超過8歲的兒童可使用本產品，但請勿由肢體不健全、感覺或精神上有障礙或
缺乏相關經驗和知識的人使用，除非有負責他們安全的人對他們使用本產品進
行監督或指導。
- 請務必看顧好兒童，以確保他們不玩耍本產品。
- 兒童不應清潔或維修本產品。
- 當需進行任何維修，必須由專業維修人員進行維修。永遠不要嘗試自己修理本
產品。
- 手濕時不可以接觸電源插頭或本機。
- 主機不可以浸入水中。
- 兒童不可以把玩本機。
- 本機開著後不可以無人監管。
- 當本機開著時，頭髮、鬆身衣物、手指和身體其他部份都要離開本機。
- 只使用隨機附送的配件。
- 使用相符的電源和電壓，以防止觸電。
- 本產品只能使用帶接地線的電源插座。
- 當本產品不使用時，請從牆上的插座中拔掉插頭。
- 從牆上插座中拔掉插頭時，應拿著插頭而不是電源線。
- 確保本產品、電源線和插頭不與水接觸。
- 確保本產品、電源線和插頭不接觸發熱表面，如明火。
- 定期檢查本產品的電源線以確保其沒有損壞。如果電源線損壞，請勿使用其產
品，並須由專業維修人員來更換，以避免出現任何危險。
- 確保本產品的周圍有足夠空間，並且不接觸易燃物料。使用時，通風口不得覆
蓋或堵塞。
- 切勿在易燃材料附近使用本產品。
-
本產品的某部分可能會發熱。如出風口，不要觸摸這些部分，以防止燙傷自己。
閱讀下列說明事項並請妥善保管，以供日後參考。
9
安全指引 - 操作期間
- 不要在有使用和儲藏汽油、燃料和其他可燃物質的車庫之類的地方使用本產品。
- 不要在傢俱、動物、窗簾或其他可燃物體周圍使用本產品。
- 不要把本產品放在寢具或者厚厚的毛毯上，因為有可能堵塞進出風口。
- 不要在直接接近水的地方使用產品，比如浴缸、洗臉盆、浴室的游泳池等，這些
地方可能發生漏電。
- 在本產品堆積灰塵或者毛絨可能引起過熱，通過拔掉電源插頭，讓它冷卻和仔細
清洗，確保這些堆積物已被清除。
- 確保沒有其他高電流的電器同時插入和暖風機相同的電路，從而產生超負載的情
況。
- 不要將電器的出風口靠近牆壁、窗簾等實體，以免阻塞氣流，影響送風效果或其
他危險。
- 加水時，水位不得超過最高（max）指示刻度-約420毫升，也不得低於最低
（min）指示刻度-約75毫升。
- 請勿將本產品放置在傾斜或其他不平衡的地方，以免引起水箱溢水、產品側翻，
造成產品損壞或其他安全事故； 如不慎傾倒本產品，應立即停止使用，並拔掉
電源插頭，檢查產品內部是否進水，並確保完全風乾產品後再使用，必要時往維
修部門檢修。
- 請勿用力扳動產品的搖擺機構，以免損壞內部結構。
- 本產品有噴霧功能，建議使用純淨水，使用前請清洗水箱。 避免滋生細菌、水
垢和異物等； 使用後，將水箱內多餘的水排乾淨，如長期不使用，應清洗水
箱。
- 本產品禁止使用精油。
- 如果本產品用於空調房, 偶有水珠回流或水珠停留在噴霧口附近，屬於正常現
象。
10
暖風機部份介紹
1. 水箱
2. 出風口
3. 噴霧口
4. 底座
5. 發熱組件
6. 外殼
7. 翻倒自動關閉鍵
8. 主電源開關鍵
1
2
5 6
3
4
背面 正面
7 8 9 10 11 12
13
14
15
9. 自動搖擺鍵
10. 噴霧鍵
11. 加熱鍵
12. 電源鍵
13. 水箱蓋
14. 吸水棉
15. 吸水棉套管
Inhaltsverzeichnis
Andere GILMAN Lüfter Handbücher
