Globalmediapro SP001 Bedienungsanleitung
1
Online Coaxial Surge Protection Device
ITEM NO: SP001
Application for protects equipment from high voltage surges such as lightning strikes. UL
grounding requirements for coaxial cable offer protection from hazardous voltages that may occur
on the shielding. Because of the physical length of ground wires, UL grounding systems may
appear as an open circuit to lightning caused, high frequency surges and provide no protection
from these surges getting into a home and destroying CATV converters, TV sets, VCR, Camera
etc.
Features:
Performs a different function than grounding requirements.
Protects equipment from high voltage surges from nearby lightning strikes.
Two stage protection: 130V, AC/DC 12V
Wide range of applications: CCTV system,Antenna of Television, satellite receivers, FM receivers,
video camera, monitors, multiplexers & Quad processor, VCR, etc.
SP001 Coaxial Surge Protection Device BNC Connector
BNC male to BNC female. Hi Frequency for both CCTV and CATV use.
Installation View:
SP001
Application
CATV System
Antenna of Television
Video Cassette Recorders
FM receivers
Video Cameras and monitors
Multiplexers and Quad Processor
Note:
For ensuring the unit can
protect equipments, the cable
must be connected to ground.
2
Specification:
ITEM NO. SP001
Surge Protection Attack Time
1 ns
Maximum Surge Voltage
4 KV
Surge Life
300 surges of 100Amps
Normal Resistance Across Coax
10,000 MΩ
Surge Resistance
Approx. 0Ω
BAND PASS
0~1 GHZ
Power Passing Capability
130VAC / DC, 65 Vrms at10Amps
Insertion Loss
Less than 0.2 dB
Return Loss (75 ohms)
16dB
Connectors
BNC
Dimensions W x H x D mm
78x25x25
WEIGHT g
80
