Gold Note IS-10 Bedienungsanleitung
USER
MANUAL
IS-10
EN
IT
Thank you for purchasing one of our units
and welcome into the Gold Note world,
where we turn High-End audio and music
into a new experience.
Maurizio Aterini,
founder of Gold Note
EN
IT
|
IMPORTANT SAFETY
| INFORMATION
the third prong are provided for your safety.
If the provided plug does not fit into
your outlet, consult an electrician for
replacement of the obsolete outlet. or
pinched particularly at plugs, convenience
receptacles, and the point where they exit
from the apparatus.
|Only use attachments/accessories specied
by the manufacturer.
|Use only with the cart, stand, tripod,
bracket, or table specied by the
manufacturer, or sold with the apparatus.
When a cart is used, use caution when
moving the cart/apparatus combination to
avoid injury from tip-over.
|Unplug this apparatus during lightning
storms or when unused for long periods
of time. Refer all servicing to qualied
service personnel only. Servicing is required
when the apparatus has been damaged in
any way (such as when the power cord or
plug is damaged, liquid has been spilled
or objects have fallen into the apparatus,
the apparatus has been exposed to rain
or moisture) and in any case when the
apparatus does not operate normally or
has been dropped.
PLEASE NOTE
1 Do not disassemble any part of the
product.
2 Do not use any part of the product for
other purposes.
3 For service and problems of any kind,
contact qualified Gold Note personnel.
4 Protect the product from rain, humidity
and keep away from heat sources, electric
and electronic motors etc. The power
cord supplied must be used only on this
unit.
5 Gold Note does not have responsibility
for any improper use of this unit.
GENERIC INFORMATION
|Read these instructions and store them.
|Heed all warnings.
|Follow the instructions.
|Do not use this apparatus near water.
|Clean only with a dry cloth.
|Do not block the ventilation openings
and install in accordance with the
manufacturer’s instructions.
|Do not install near heat sources such as
radiators, heat registers, stoves or other
apparatus (including ampliers) that
produce heat.
|Do not defeat the safety purpose of
the polarised or grounding-type plug: a
polarised plug hastwo blades with one
wider than the other.
|A grounding type plug has two blades and
a third grounding prong. The wide blade or
This appliance has a serial number located on the rear panel.
Please record the model and serial number and retain them for your records.
MODEL
SERIAL NUMBER
CAUTION!
To reduce the risk of electric shock, do not
remove cover (or back). No user-serviceable
parts inside. Refer only to qualified Gold
Note service personnel for service.
WARNING!
To prevent fire or shock hazard, do not
expose this appliance to rain or moisture.
GOLD NOTE - Information on the correct management of waste from
household Equipment pursuant to the European Directive 2012/19/EU
The crossed-out wheelie bin symbol shown on the equipment or its packaging indicates
that the product, at the end of its useful life, must be collected separately from other waste
to allow its proper treatment and recycling. The user must therefore deliver, free of charge,
the end-of-life equipment to the centres for the separate collection of waste electrical and
electronic equipment, or return it to the dealer in accordance with the procedures established
by the legislation.
The appropriate separate collection of discarded equipment allows for proper recycling,
treatment and environmentally compatible disposal, helping to avoid the possible dispersion
of hazardous substances and negative effects on the environment and health, favouring
the reuse and/or recycling of the materials of which the equipment is composed of. Illegal
dumping of the product by the user involves the application of administrative sanction
provided for by the legislation in force. We invite you consult the current legislation and the
measures adopted by the public service operating in your country or territory.
EN
IT
| INDEX
| PACKAGE CONTENT
1x
IS-10
1x
USER
MANUAL
1x
POWER
CABLE
1x
WI-FI
ANTENNA
1x
REMOTE
CONTROL
TECHNICAL SPECIFICATIONS 1
FRONT PANEL 3
REAR PANEL 4
SELECT FUNCTIONS 5
NETWORK SETUP 6
FEATURES AND FUNCTIONS 8
SETTINGS 11
CONNECTING OTHER SOURCES 13
CONTROL APP 14
REMOTE CONTROL 18
FIRMWARE UPDATE 19
PRODUCT REGISTRATION 19
TROUBLESHOOTING 20
EN
IT
1
MAIN FEATURES
|Integrated Amplier:
90W into 8Ω / 4Ω (Stereo)
280W into 8Ω / 4Ω (Mono with PA-10 EVO)
|D/A Converter AKM AK4493 PCM up to
32bit/384kHz and DSD256
|Frequency response:
5Hz-50kHz (@ -3dB)
|THD (Total Harmonic Distortion):
0,01% (1kHz @ 1W)
|Signal to Noise ratio:
125dB
|Dynamic range:
120dB
POWER
|Power supply:
100-240V / 50-60Hz
|Power consumption:
20W
|Fuse:
5A T
AUDIO OUTPUTS
|Speaker terminals:
Binding posts
|Preamp:
Headphone output with 6.3 mm jack
|Mono right:
RCA unbalanced (single connector)
ANALOGUE INPUT
RCA unbalanced (pairs)
DIGITAL INPUTS
TOS-Link PCM asynchronous up to
24bit/192kHz
RCA coaxial PCM asynchronous up to
24bit/192kHz
USB-A port DSD256 and PCM up to
32bit/384kHz, formatted in FAT32/NTFS
(32Gb max for pen drives)
NETWORK CONNECTIVITY
|LAN/WLAN (Wi-Fi):
802.11a/b/g/n/ac Dual Band (10/433Mbps)
|Bluetooth:
High-Definition 5.0 (44/16)
| TECHNICAL SPECIFICATIONS
2x
1x
1x
2x
1x
1x
RESOLUTION
PCM 24/192 PCM 32/384 DSD256
NETWORK
RCA
TOS-Link
USB-A
INPUT
2
HIGH QUALITY STREAMING
|Roon Ready
|Airplay
|MQA
|Qobuz
|Deezer
|Spotify Connect
|Tidal
|Tidal Connect
|vTuner
ROON READY
Being Roon Ready means that Gold Note
uses Roon streaming technology, for an
incredible user interface, simple setup, rock-
solid daily reliability, and the highest levels of
audio performance, without compromise.
|SUPPORTED AUDIO FORMATS
(NETWORK)
Up to PCM 32bit/384kHz
|DSD256 (DSF, DFF)
|AIFF (.aif, .aiff, .aifc)
|ALAC
|WAV (.wav) packed/unpacked
|FLAC
|MP3
|Apple Lossless
|OGG
|Monkey’s
IMPORTANT
UPnP server must support DSD streaming in
order to stream DSD files.
SUPPORTED MEDIA SERVERS
|All UPnP
|DLNA
|Roon
DIMENSIONS AND WEIGHT
Dimensions:
200W | 80H | 260D mm
Weight:
kg. 4 net
kg. 5 boxed
REMOTE CONTROL
Multifunctional remote control
GN CONTROL APP
EN
IT
3
FRONT PANEL OVERVIEW
The IS-10 has been designed for ease of use
and thanks to the SKC (Single Knob Control)
the unit becomes a friendly plug-and-play
source that can be fully controlled even
| FRONT PANEL
1
2
4
5
3
without the remote.
All the features are easily accessed access on
the display at any time.
Headphone output (6.3mm jack)
LED status light:
Red = standby
Blue = ON
Display
IR
LED status light
SKC (Single Knob Control)
2
1
3
5
4
