Gorenje DP7C Bedienungsanleitung

Gorenje reserves the absolute and unrestricted right to change product materials and speciﬁcations, at any time, without notice. Warranties: Please see the Use & Care manual or Gorenje Canada website for a statement of limited warranty.

GENERAL PROPERTIES

Front/Top Load Front Load

Colour White

FEATURES

Drying Capacity 1-7KG

Door Diameter Drum 35cm

Door Opening Angle 180 °

Reversible Drum Action l

Keys Start/Pause

Controls Button/Selector Knob

Type of Display LED Display

Drying Time Selection Step Setting

Dryness Level Setting l

Low temperature option l

StartDelay l

Easy ﬁlter cleaning l

Vacuum feet l

Humidity sensor l

Galvanized drum l

Personalized Settings For all programs

Lockable Control Panel l

StableTech Side Panels l

End Program Indicator l

PROGRAMS & MODES

Bedding Downwear

Cotton Storage Baby

Normal Sportswear

Iron Shirts

Mix Storage Time (30'/60'/90')

Wool GentleCare (Mode)

Sensitive ExtraDry (Mode)

Air Refresh

TECHNICAL SPECIFICATIONS

Noise Level Drying 64 dB(A)re 1 pW

Electrical Connection 208/230 V / 15 Amp / 60Hz

Connected Load 2,600 W

Consumption in Standby Mode 0.5 W

DIMENSIONS & WEIGHT

Unit (WxHxD) inch 235/8” x 337/16” x 245/8”

Unit (WxHxD) mm 600 mm x 850 mm x 625 mm

Net Weight (KG) 34 KG

Gross Weight (KG) 38.4 KG

ENVIRONMENTAL STANDARDS

ENERGYSTAR®l

DP7C

24” 7KG Front Load Vented Dryer

Simple interface Sleek door

Sensor drying

AirRefresh

Sport Programme

Bedding

Baby

StartDelay

Anti crease

StableTech

Vacuum Feet

Drying Modes

gorenjecanada.ca/product/dp7c/

TECHNICAL SPECIFICATIONS

Noise Level Drying 64 dB(A)re 1 pW

Electrical Connection 208/230 V / 15 Amp / 60Hz

Connected Load 2,+00 W

Consumption in Standby Mode 0.5 W

DIMENSIONS & WEIGHT

Unit (WxHxD) inch 235/8” x 337/16” x 245/8”

Unit (WxHxD) mm 600 mm x 850 mm x 625 mm

Net Weight (KG) 34 KG

Gross Weight (KG) 38.4 KG

ENVIRONMENTAL STANDARDS

ENERGYSTAR®l

• The dryer has two humid air exhaust openings on the front and rear

side (options a/b). Close one of them with a cap and connect the air

exhaust duct to the other one.

• The distance between the dryer and the air evacuation opening

(ventilation opening, window) may not exceed 2 meters. Otherwise,

moisture could accumulate in the air exhaust duct.

• Do not evacuate the air from the dryer through channels used for

appliances or devices that use natural gas or other fuels for their

operation.

• The dryer may not be in contact with a wall or adjacent furniture. For

optimum dryer operation, we recommend observing the clearance

from the walls as indicated in the ﬁgure. In case of failure to heed the

required minimum clearance, the dryer may overheat.

• Vents on the appliance back wall, and humid air exhaust opening on

the side or back wall may not be obstructed.

• Place the appliance in a thoroughly ventilated room with a window or

ventilation fan.

• Connect the exhaust duct to the air exhaust opening. Do not connect

the exhaust to a duct that is also used for evacuation of combustion

gases from other appliances or gases from appliances that use other

combustible substances for their operation.

• The dryer emits heat. Therefore, do not place it in a very small room, as

the drying process may take longer due to limited amount of available

air.

• Lighting in the room should be sucient to allow reading the

information on the display unit on the control panel.

DP7C

SPECIFICATIONS

SELECTING THE ROOM

EVACUATION OF HUMID AIR

DRYER PLACEMENT

• If you also have a Gorenje dryer of corresponding (same) dimensions, it can be placed on top of the Gorenje washing machine; in this

case, vacuum feet must be used. Alternatively, the dryer can be placed next to the washing machine (ﬁgures 1 and 2).

• The unit is supplied with vacuum feet for stacking.

• The surface on which the appliance is placed should be clean and level.

OPENING THE DRYER DOOR BIRDSEYE VIEW

A. = 24½” (625 mm)

B. = 44½” (1134 mm)

DP7C

SPECIFICATIONS

1 2

VENTED DRYER

• Air is warmed up through a heater and is blown through the

clothes.

• Humidity is taken away in the process.

• Hot humid air is then vented outside of the home.

CONDENSER DRYER

• Hot, humid air is blown through a condenser, where it is

cooled by using air from the surrounding area.

• Condensate vapour from hot air takes place

on the ribs of the condenser.

• Water is then pumped from the bottom of the dryer to a

reservoir.

• Condensation dryer does not release

moisture back into your home and does not require any extra

external venting.

HEAT PUMP DRYER

• Heat pump dryers uses the same condensation principal as a

con-denser dryer to remove water from your clothes.

• Instead uses a heat pump instead of an electric heater to heat

the air.

• Heat pump dryers do not require any outdoor venting all while

boasting very high energy eciency results.

• Heat pump dryers are the most cost eective in terms of

energy consumption.

DP7C

DRYER TECHNOLOGY EXPLAINED

Download Speciﬁcations & Literature

WARRANTY INFORMATION

GORENJEAppliances aredesignedandmanufactured to thehigheststandards.Each appliance is covered by a com-

prehensive 2-year parts and labour warranty.

Refer to product warranty policy for complete terms and conditions.

FOR PARTS & SERVICE

Euro-Parts & Service

39822 Belgrave Road, Belgrave, ON. N0G 1E0 1 866 722 2262

www.euro-parts.ca • [email protected] • service@euro-parts.ca

Gorenje appliances are imported and distributed in North America by Euro-Line Appliances Inc. For more information,

please visit one of our showrooms or www.ela.ca / www.elawest.ca

871 Cranberry Court, Oakville, ON L6L

6J7 Canada

905 829 3980

1 800 421 6332

[email protected]

101-1014 Homer Street, Vancouver, BC

V6B 2W9 Canada

604 235 3980

1 855 ELA WEST (352 9378)

[email protected]
