Grace Industries In-Command Accountability System Bedienungsanleitung

Patent Protected

US 7,538,666

In-Command®

Accountability System

User’s Information

Grace Industries, Inc.

In-Command®3.05.0100

Protecting Personnel

With advanced hardware and software features,

In-Command®systems provide an unbeatable

method of protecting your firefighters and personnel

at any scene while simplifying the Accountability

responsibilities of the Incident Commander.

04-2020

Important!

*IMPORTANT* NFPA-1982, 2018 edition, RF PASS Requirements:

The NFPA-1982, 2018 edition, includes minimum requirements for RF PASS systems. The

use of the In-Command®software under its default installed-configuration is compliant with

NFPA requirements for RF PASS systems.

The host PC running the In-Command®software must have its speakers enabled

and volume turned up to a level that can be heard in loud fire ground environments.

The default installation of the In-Command®PC software uses audio files to activate or

‘play’ on the host PC’s speakers for various functions including ‘RF PASS alarm’, ‘RF

PASS Evacuation alarm initiated’ and ‘loss-of-signal alarm’. The In-Command®PC

software allows custom audio files to be used in place of the default audio files, however

any change to these audio files may jeopardize NFPA compliance if they are not of a

suitable nature. Caution should be used if the default audio files are changed.

Getting Started

Table of Contents

Introduction 5

Minimum Computer Requirements 10

Installing USB Drivers from FTDI 11

Connecting the MX900-H 12

Installing System Software 13

Operation Setup 14

Setting the System ID 23

System Settings 27

Configure Connections –

Set the Receiver Type 30

User Setup 31

Create a Name File 32

Prepared to Monitor Users 46

Configuring Incident Settings 47

Location Setup 54

GPS Device Mapping 58

Setting Audio Alarms 81

Configuring Notifications 84

Save and Exit Configuration 93

Start an Incident 95

Monitoring Screen 96

User Status Images 110

Performing Actions on Users 127

Viewing System Information 151

Saving the Incident 168

Cancelling the Incident 168

Using the Incident Viewer 169

Introduction

MX900-H

Transceiver

Thank you for purchasing a Grace Industries Accountability System

In-Command®Accountability System uses In-Command®Software and the components listed

below to provide complete accountability for your firefighters during an incident.

System Components

MX900-H Transceiver

SuperCELL®SC500-H, TPASS®5 or other Grace telemetry devices assigned to personnel

for monitoring

Micro Repeaters and External Antennas may be added as needed to

enhance system effectiveness

Return to TOC

Safety Monitoring of Personnel

Each Firefighter equipped with a SuperCELL or

TPASS telemetry device is monitored for PASS

Status such as ON, OFF or ALARM.

*PASS stands for Personal Alert Safety System

Each worn device can be sent an Evacuation, PAR, or

Roll Call Signal with a simple button press

All Firefighters on scene are automatically populated

in the In-Command software and are sorted in real-

time based on priority, with Alarm being the highest

priority

When an Alarm, Evacuation, PAR, or Roll Call signal

is present, the SuperCELL or TPASS user's device

will go into a loud audio alarm indicating to the

wearer that action is required

Return to TOC

MX900-H Transceiver

Receives and processes radio signals from

SuperCELL and TPASS devices and

transmits Evacuation, PAR, and Roll Call

signals to these firefighter worn devices

Monitors PC communications through the

USB port and goes into Alarm if the

communications fail at any time

External Antennas may also be used as

needed

Return to TOC

SuperCELL SC500-H

Personnel Monitoring for Incident Commander

2-Way Emergency Signaling

Excellent for Officers when not monitoring In-Command Computer

Small, Rechargeable, Lithium-ion Battery Powered Transceiver

Back Lit LCD Display Enhances Readability

Receives ALARM signals, Displays and Identifies other TPASS devices in ALARM

Repeats Alarm and Evacuation Signals

Receives Evacuate, PAR, and Roll Call Signals from In-Command

Audible Alarm Signal and Vibration indicate function

Ability to send and receive preloaded canned messages

Manually turn ON and OFF by pressing side buttons simultaneously

Lack-of-Motion Alarm Function

Select time to Alarm (30, 60, 90, & 120 seconds)

Single Button “Alarm” function

Side Buttons for Easy Reset and Mode Selection

LCD Display allows monitoring of other TPASS in Emergency Alarm

Complete Name Database for all users

Sturdy construction for long life

Return to TOC

TPASS-5

2-Way Emergency Signaling

and Automated Accountability

NFPA Compliant Two-way signaling TPASS transmits status

of firefighters to In-Command

Receives: Evacuation, PAR and Roll Call Signals

Smart-Signal®technology repeating function

Single button ALARM activation or automatic Lack-of-Motion

ALARM

Three axis, solid state motion sensor

Two Methods of Attachment

Over 40 hours in sensing mode

Over 95dBA at 10 feet

Return to TOC

Minimum Computer Requirements

for In-Command Systems

Processor:

1 GHz 32-bit (x86) (2Ghz or faster processor recommended)

Operating Systems:

Windows 7, 8, 10 (32-bit and 64-bit)

Administrative rights required

RAM:

4GB

Monitor:

1024×768 (Touchscreen Recommended)

Note: Use of two screens is recommended when mapping modes are in use

Internet Connection:

Required for GPS functionality

Hard Disk Size:

80GB Minimum

USB 2.0:

1 Available Required per Receiver.

Speakers

Return to TOC
