Grandstream Networks, Inc.
Connecting GDS3710 with GXP21xx
Configuration Guide
Connecting GDS3710 with GXP21xx Configuration Guide
P a g e | 2
Table of Contents
INTRODUCTION.............................................................................................................3
PEERING SCENARIO ....................................................................................................4
GDS3710 Configuration Settings...........................................................................................................4
GXP2170 Configuration Settings...........................................................................................................6
CONNECTION USING SIP SERVER .............................................................................9
GDS3710 Configuration Settings...........................................................................................................9
GXP2170 Configuration Settings.........................................................................................................11
Table of Figures
Figure 1: GXP2170 peered with the GDS3710.............................................................................................4
Figure 2: Door System Settings ....................................................................................................................5
Figure 3: Enable Direct IP Call......................................................................................................................6
Figure 4: GXP2170 Account(x) Settings .......................................................................................................6
Figure 5: Account(x) SIP Settings .................................................................................................................7
Figure 6: GDS3710 Configuration Settings on GXP2170 .............................................................................7
Figure 7: GDS3710 Stream on GXP2170.....................................................................................................8
Figure 8: GXP2170 Connected to GDS3710 through UCM6XXX ................................................................9
Figure 9: SIP Basic Settings .......................................................................................................................10
Figure 10: Door System Settings ................................................................................................................11
Figure 11: General Settings ........................................................................................................................12
Figure 12: GDS Settings .............................................................................................................................13
Figure 13: Open Door from GXP2170 ........................................................................................................13
Connecting GDS3710 with GXP21xx Configuration Guide
P a g e | 3
INTRODUCTION
GDS3710 HD is an IP video door system with a built-in hemispheric camera and some high-definition video
capabilities. GDS3710 is ideal for monitoring from wall to wall without blind spots. Powered by an advanced
Image Sensor Processor (ISP) and state of the art image algorithms, it delivers exceptional performance in
all lighting conditions. It contains integrated PoE, LEDs, HD loudspeaker, RFID card reader, motion detector,
lighting control switch, Alarm Input/output and more.
The GDS3710 IP video door system features industry-leading SIP/VoIP for 2-way audio and video
streaming to smart phones and SIP phones, allowing to receive calls from GDS3710 on associated SIP
phones when doorbell is pressed, opening door from the SIP phone, initiate calls from the phone to
GDS3710 and get real time audio/video stream.
The GDS3710 can be connected with a SIP phone in 2 different ways, either using peering mode (without
a SIP server) or through a SIP server/registrar.
This guide illustrates needed configuration for integrating the GDS3710 with GXP21xx for both peering and
using SIP server scenarios.
Connecting GDS3710 with GXP21xx Configuration Guide
P a g e | 4
PEERING SCENARIO
In this scenario, we assume that the GDS3710 is installed on a small warehouse at front door and GXP2170
inside to monitor and control the access of the premise. Visitors needs to press the door bell button on the
GDS3710 to initiate a video call and the related person at the GXP2170 side can open the door remotely
to allow the visitors to get in as shown in the figure below.
Figure 1: GXP2170 peered with the GDS3710
- The IP address used by the GDS3710 is 192.168.6.100.
- The IP address used by the GXP2170 is 192.168.6.62.
GDS3710 Configuration Settings
The GDS3710 needs to be configured with the IP address of the phone (GXP2170 in our example), the
related SIP port, and remote PIN for door opening. Please refer to following configuration steps:
1. Access the GDS3710 Web GUI and navigate to “Door System SettingsBasic Settings”.
GXP2170
IP: 192.168.6.62
GDS3710
IP: 192.168.6.100
Front Door
Ethernet PoE connection
Power connection
Ethernet cable
Connecting GDS3710 with GXP21xx Configuration Guide
P a g e | 5
2. Choose the action to be taken when the doorbell is pressed, three options are available:
•Call Doorbell Number: when Doorbell is pressed, a call will be made to the “Number Called
When Door Bell Pressed”
•Control Doorbell Output (Digital Output 1): when Door Bell is pressed electronic lock for
Output 1 is opened.
•Both of Above: When selected, both Call Doorbell Number and Control Doorbell Output
options are enabled. In our case we will choose “Call Doorbell Number”.
3. Under Number Called When Door Bell Pressed field, enter the GXP2170 IP address and port
number which is 192.168.6.62:5060 in our example.
4. Enter the “Remote PIN to Open the Door” in order to open the door via DTMF while in active call
with the GDS3710, the remote PIN used in our example is “123456”.
5. Click button to apply changes.
Figure 2: Door System Settings
Connecting GDS3710 with GXP21xx Configuration Guide
P a g e | 6
6. You need to make sure that the Direct IP Call feature is enabled from the GDS3710 Web GUI under
SIP SettingsSIP Advanced SettingsEnable Direct IP Call.
Figure 3: Enable Direct IP Call
GXP2170 Configuration Settings
The GXP2170 related Account need to be set as “Active”, and the “Local SIP Port” need to match the port
configured on GDS3710. Please refer to following steps for configuring the GXP2170 in order to
interconnect with the GDS3710.
1. Access GXP2170 Web GUIAccountGeneral Settings and set “Account Active” to Yes, then
click on button to apply the new changes.
Figure 4: GXP2170 Account(x) Settings
2. Navigate to AccountSIP Settings and verify that the Local SIP Port configured on the GXP2170
is the same as the one on the GDS3710.
Connecting GDS3710 with GXP21xx Configuration Guide
P a g e | 7
Figure 5: Account(x) SIP Settings
3. Navigate to SettingsExternal Service to configure GDS settings as explained on the following:
•Set the Service Type to GDS.
•Select the related account, in our example, the account used is Account 1.
•Specifies the System Identification, to identify the GDS3710, in our example its
“GDS3710_Front_Door”.
•Specifies the System Number which is the GDS3710 number, the system number used in
our example is 192.168.6.62.
•Configures the Access Password for opening the door remotely and it should match the
password configured under “Remote PIN to Open the Door” on the GDS3710 Web GUI
settings. The password used in our example is “123456”.
Figure 6: GDS3710 Configuration Settings on GXP2170
Note : The GXP21xx support up to 10 GDS3710 items.
4. Press button to apply the new settings.
Connecting GDS3710 with GXP21xx Configuration Guide
P a g e | 8
Once the users press the ring button on the GDS3710, the GDS3710 stream will be played on the GXP
phone, allowing users to either answer / reject the call or press the OpenDoor softkey, then a DTMF code
for “Remote PIN for Open the Door” will be sent to the GDS3710 in order to open the door remotely as
displayed on the following screenshot.
Figure 7: GDS3710 Stream on GXP2170
Connecting GDS3710 with GXP21xx Configuration Guide
P a g e | 9
CONNECTION USING SIP SERVER
In this scenario, we assume that the GDS3710 is configured with a SIP account and the GXP2170 is also
configured with a SIP account under the same SIP server.
Figure 8: GXP2170 Connected to GDS3710 through UCM6XXX
- The IP address used by the GDS3710 is 192.168.6.100 and it’s configured with SIP account 2002.
- The IP address used by the GXP2170 is 192.168.6.62. and it’s configured with SIP account 2001.
GDS3710 Configuration Settings
As mentioned on the previous diagram, the GDS3710 should be registered with a SIP account in order to
interact with the GXP2170 trough the SIP server.
The GDS3710 SIP settings are available under the Web GUISIP SettingsSIP Basic Settings as
displayed on the following figure.
UCM6xxx
GXP2170
IP: 192.168.6.62
GDS3710
IP: 192.168.6.100
Front Door
SIP Account : 2002
SIP Account : 2001
Ethernet PoE connection
Power connection
Ethernet cable
Connecting GDS3710 with GXP21xx Configuration Guide
P a g e | 10
Figure 9: SIP Basic Settings
After configuring correctly the SIP account, users need to configure the door system settings as detailed on
the following steps:
1. Navigate to Door System SettingsBasic Settings then set the following:
•Doorbell Mode: Call Doorbell Number.
•Number Called When Door Bell Pressed: the GXP2170 number which is 2001 in our
example.
•Remote PIN to Open the Door: the remote PIN used in our example is “123456”.
2. Click button to apply changes.
The following figure shows an example of the configuration done.
