Grandview Large Sky-Show Bedienungsanleitung

Grandview Large Sky-Show

User Manual

Imported and Distributed in Australia by

Herma Technologies

Factory 4A, 6 Albert St

Preston, VIC 3072

For more information please go to

www.grandviewscreens.com.au

or call 1300 730 025

Protecting Your Screen:

• Keepawayfromdirectsunlightor

 hightemperatures.

• Examineboththefrontandback 

 surfacesbeforeretractingintothe 

 casetomakesureitisfreeofdust, 

 dirt,insectsorotherforeignmatter.

• Useasoftbrushorclothtolightly 

 removeanyforeignparticles.

Cleaning Your Screen:

• Donotuseanysolvents,chemicals 

 orabrasivecleanersonthe

 screensurface.

• Useamilddetergentwithwarmwater 

 toremoveanymarksonthesurfaceor 

 screencase.

• Alwaysimmediatelydabthescreen 

 withasoftclothtoavoidsoapmarks.

• Donotscrubthesurface.

Warranty: 12 Months

RS 232/485 Input Settings / Close Contact

Back View

CrystalSocket

Control Emitter Function / Address

1Commonline 5CasingDown

2Retractingthescreen 6Stop

3Loweringthescreen 7Rs232InputB

4Casingup 8Rs232InputA

EXTERNAL CTRL

8P8C

RS-232

Stop

SW-PBS1

SW-PB

Casing Down

Casing Up

ScreenDown

Screen Up

1. CentralControlFormatAgreementCommunication

AgreementSetting:databits:8bits,startbits:1bit,

stopbits:1bit,BaudRatio:2400.

2. Retractingthescreen:

oxFFoxEEoxEEoxEEoxDD

3. Stoppingthescreen:

oxFFoxEEoxEEoxEEoxCC

4. Loweringthescreen:

oxFFoxEEoxEEoxEEoxEE

5. Retractingthecasing:

oxFFoxEEoxEEoxEEoxC9

6. Loweringthecasing:

oxFFoxEEoxEEoxEEoxE9

7. 232setting:2400,n,8,1acontinuousdatasends

twotimes,eachtimeintervalof200ms.

Cable

Box

Ethernet Cable Box

Retractor

Central Control Input

GV_Sky_Show_Large_Jun11_v1

Casing

Buckle

Brake

Mechanism

Brake Mechanism

Hanging Piece

Step 3

Cable

Secure

positioning piece

Please secure your safety

limit lug at least 10mm

above the new limit

Up for cable

Down for cable

Screen Limit Settings

Thescreenisfittedwithtwolimits.Thelimits

automaticallystopthescreeninthefullyUp(toplimit)

andfullyDown(bottomlimit)positions.Youcanadjust

thebottomlimittosetyourviewingheight.

Setting The Bottom Limit

Caution:Settingthebottomlimitbeyondtheblack

leadermayrenderyourscreeninoperableandvoid

yourwarranty

Thebottomlimitswitchisaccessiblethrougha

grommetedholeatthebackoftheleftsidecasing.

Lowerthescreentotheoperatingpositionthen

insertthesuppliedAllenkeyintothewhitecoloured

screw.Turnitclockwisetoraisethescreenorturn

itanti-clockwisetolowerthescreen.

Whenloweringthebottomlimitthescreenwillmoveas

youadjustit.

Whenraisingthebottomlimitpleaseliftandlowerthe

screenwiththeremotetoseethenewposition.

Insertthecableboxplugandattachbreakmechanism.

Using RF Remote

Yourremotecontrolcomeswithbatteriesinstalled.

Tooperateyourremote:

Presstoliftthescreen

Presstostopthescreen

Presstolowerthescreen

TheMicroswitch

isusedforretractingor

loweringcable.

UP for screen fabric

Down for screen fabric

Down for cable

Up for cable

STOP for fabric & cable

PlugthepowercordintotheCableBox.

Step 4

Cable

Box

Socket on

Cable Box

Ceiling

Plug Socket

Plug

PlugthepowercordintotheCableBox.

Step 4

Cable

Box

Socket on

Cable Box

Ceiling

Plug Socket

Plug

Mountthebreak

mechanismandscreen

asshownbelow.

Step 2Step 1

Carefullyunpackthe

screen.Securelyattachthe

cableboxtotheceiling.

To the Owner:

CongratulationsonpurchasingaGrandviewSky-Show.

Important Notes:

• Pleasereadthisinstructionmanualbeforeuse.

• Pleasedonotattempttoadjustorrepair

theproduct.Youwillvoidthewarranty.

• Pleaseretainthisinstructionmanualfor

futurereference.

• Handlethescreencarefullyduringtransportation.

•Toensurelonglastingviewingenjoyment,alwayskeep

thescreenrolledupwhennotinuse.

Warning

• Ensurethescreenishungbythelooped

suspensioncables.

• Thescreenmustbesecurelymountedbeforebeing

operated.Failuretocomplycancausethesuspension

cablestounravelresultinginthecablesbeingtangled

andpossiblescreendamageoccurring.

• Whensuspendingthescreenunderload-bearing

support,ensurethescreenishunglevel/straight.

• Damagecausedtotheproductduetoincorrect

installation,suspensionoroperationisnotcovered

bywarranty.

Supplied

Cable BoxPower cord Multimedia

Cable Box

Cable Lock

Allen Key RF RemoteBrake Mechanism

Operational Instructions Cable Limit Settings

(The limits are preset at min 300mm and max 4950mm)

•Turntheremotecontrolovertolocatethe

“ProgrammingMode”activationtoggleswitch.

•PresswithafinetipandtheLEDshouldlightup,

indicating“ProgrammingMode”ison.

•Pressthemicro“UP/DOWN”buttonstomovethe

screencasetotherequiredposition.Pressthe

STOPbuttonwhenthedesiredlimitisachieved.

•PresstheProgrammingModetoggleswitchagainto

switchoffprogrammingmodeandsetthenewlimit.
