GreenWorks LMC420 Bedienungsanleitung

GD60LM51SP

LMC420

OPERATOR MANUAL / BEDIENUNGSHANDBUCH / MANUAL DEL OPERARIO /

MANUALE DELL’OPERATORE / MANUEL OPÉRATEUR / MANUAL DE UTILIZAÇÃO /

GEBRUIKSAANWIJZING / KÄYTTÖOPAS /ANVÄNDARHANDBOK /

BRUKERVEILEDNING / BRUGSVEJLEDNING / INSTRUKC / JAUŻYTKOWNIKA /

NÁVOD K OBSLUZE / NÁVOD NA OBSLUHU / Uporabniški priročnik / PRIRUČNIK

ZA RUKOVANJE / HASZNÁLATI ÚTMUTATÓ / MANUAL DE UTILIZARE /

РЪКОВОДСТВО НА ОПЕРАТОРА / ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ / / KULLANIM

KILAVUZU / / OPERATORIAU VADOVAS / LIETOTĀJA ROKASGRĀMATA /

KASUTUSJUHEND

OriginalInstructions / ÜbersetzungderOriginalanweisungen/ Traduccióndelasinstruccionesoriginales/ Traduzionedelleistruzionioriginali/ Traductiondes

instructionsd'origine/ Traduzidoapartirdasinstruçõesoriginais/ Vertalingvandeoriginelegebruiksaanwijzing/

Alkuperäistenohjeidenkäännös /

Översättningavoriginalinstruktionerna/ Produsentensinstruksjoner/ Oversættelseafdeoriginalevejledninger/ Tłumaczenie oryginalnejinstrukcji/

Překladoriginálníhonávodu/ Prekladoriginálnehonávodu/ Prevodoriginalnihnavodil/ Prijevodizvornihuputa/ Azeredetiutasítás fordítása/

Traducerea instrucțiunilororiginale/ Преводнаоригиналнитеинструкции/ Αυθεντικέςοδηγίες/ / Orijinal Talimatların

Tercümesi/ / Originaliųinstrukcijųvertimas/ Instrukcijutulkojumsnooriģinālvalodas/ Originaalkasutusjuhenditõlge

Name and address of the Authorized representative:

Name: Garden Equipment Ltd

Address: First Floor, 3a Groveley Road, Christchurch, Dorset, BH23 3HB, UK

Name and address of the person authorised to compile the technical file:

Name: Simon Del-Nevo

Address: First Floor, 3a Groveley Road, Christchurch, Dorset, BH23 3HB, UK

Here with we declare that the product

Category: Lawn Mower

Model: LMC420 (GD60LM51SP)

Serial number: See product rating label

Year of Construction: See product rating label

• is in conformity with the relevant provisions of the Supply of Machinery (Safety) Regulations 2008.

• is in conformity with the provisions of the following other UK legislation:

• Electromagnetic Compatibility Regulations 2016

• Noise Emission in the Environment by Equipment for use Outdoors Regulations 2001

• The Restriction of the Use of Certain Hazardous

• ubstances in Electrical and Electronic Equipment Regulations 2012

Furthermore, we declare that the following standard have been used:

BS EN 60335-1, BS EN 60335-2-77, BS EN 62233, BS EN 55014-1, BS EN 55014-2,

BS EN ISO 3744, ISO 11094, BS EN 62321-3-1, BS EN 62321-4, BS EN 62321-5,

BS EN 62321-6, BS EN 62321-7-1, BS EN 62321-7-2, BS EN 62321-8

Conformity assessment method to SCHEDULE 9 Noise Emission in the Environment by Equipment

for use Outdoors Regulations 2001.

Measured sound power level 94.6 dB(A)

Guaranteed sound power level 98 dB(A)

Place, date: Christchurch, Dorset, UK 07.06.2021 Signature: Ted Qu, Quality Director

DECLARATION OF CONFORMITY (UK)

Notified body involved:

Name: Intertek Testing & Certification Ltd

Address: 9 Brook St, Brentwood CM14 5NQ United Kingdom

Name and address of the manufacturer:

Name: Globe Technologies Europe GmbH

Address: Brunnenweg 17, 64331 Weiterstadt, Germany

1 Description...................................4

1.1 Purpose......................................................4

1.2 Overview.................................................... 4

2 Safety............................................4

3 Installation................................... 4

3.1 Unpack the machine...................................4

3.2 Unpacking and handle assembly............... 4

3.3 Unfold the lower handle..............................4

3.4 Install the grass catcher............................. 5

3.5 Install the mulch plug..................................5

3.6 Install the side discharge chute..................5

3.7 Set the blade/cutting height........................5

3.8 Install the battery pack............................... 5

3.9 Install the battery pack............................... 5

3.10 Remove the battery pack........................... 6

4 Operation..................................... 6

4.1 Start the machine....................................... 6

4.2 Stop the machine....................................... 6

4.3 Operate the self-propel drive system......... 6

4.4 LED Headlights.......................................... 6

4.5 Empty the grass catcher.............................6

4.6 Operate on slopes......................................6

4.7 Operation tips.............................................7

5 Maintenance.................................7

5.1 General maintenance.................................7

5.2 Replace the blade...................................... 7

5.3 Store the machine...................................... 7

5.4 Vertical storage...........................................8

6 Troubleshooting.......................... 8

7 Technical data..............................9

8 Warranty.......................................9

9 EC Declaration of conformity.....9

English EN

1 DESCRIPTION

1.1 PURPOSE

This machine is used for domestic lawn mowing. The

cutting blade must be approximately parallel to the

ground. All four wheels must touch the ground while

mowing.

1.2 OVERVIEW

Figure 1~13

1Start button

2Start handle

3Self-propel drive lever

4Upper handle

5Lower handle

6Grass catcher

7Rear discharge flap

8Height adjustment lever

9Battery compartment flap

10 Mulch plug

11 Side discharge chute

12 Handle hole

13 Handle bolt

14 Handle nut

15 Handle pin

16 Grass catcher handle

17 Grass catcher hook

18 Door rod

19 Side discharge flap

20 Pivot

21 Safety key

22 Battery pack

23 Battery capacity indicator

24 Self-propel speed control

25 Blade bolt

26 Spacer

27 Blade

28 Battery release button

29 Turbo button

30 Headlight

31 Rubber edge guard

2 SAFETY

WARNING

Make sure that you follow all safety instructions.

Refer to Safety Manual.

3 INSTALLATION

WARNING

Do not use accessories that are not recommended by

the manufacturer.

WARNING

Do not put in the safety key or the battery pack until

you finalised the assembly of all the parts.

3.1 UNPACK THE MACHINE

WARNING

Make sure that you correctly assemble the machine

before use.

WARNING

• If parts of the machine are damaged, do not use

the machine.

• If you do not have all the parts, do not operate the

machine.

• If parts are damaged or missing, contact the

service center.

1. Open the package.

2. Read the documentation provided in the box.

3. Remove all the unassembled parts from the box.

4. Remove the machine from the box.

5. Discard the box and packing material in compliance

with local regulations.

3.2 UNPACKING AND HANDLE

ASSEMBLY

Figure 2

1. Place the mower upright in vertical position.

2. Remove the packing material from the cable.

3. Remove the rubber edge guard from the upper

handle.

4. Insert the upper handle into the lower handle.

5. Put the bolts through the holes and tighten with the

nuts.

WARNING

Do not damage the cable while installing the upper

handle.

3.3 UNFOLD THE LOWER HANDLE

Figure 3

1. Pull up on the handle holes to release the lower

handles.

English

2. Fold the lower handle up until the handle pins lock

into position.

NOTE

Make sure that the two handle pins are in the same

position.

3.4 INSTALL THE GRASS CATCHER

Figure 4

1. Remove the mulch plug.

2. Remove the side discharge chute.

3. Open the rear discharge flap and hold it.

4. Hold the the grass catcher by its handle and engage

the hooks on the door rod.

5. Close the rear discharge flap.

3.5 INSTALL THE MULCH PLUG

Figure 5

1. Remove the grass catcher.

2. Open the rear discharge flap and hold it.

3. Hold the mulch plug by its handle and fit it in the

discharge chute.

4. Close the rear discharge flap.

3.6 INSTALL THE SIDE DISCHARGE

CHUTE

Figure 6

CAUTION

When you use the side discharge chute,

• Do not install the grass catcher.

• Keep the mulch plug installed.

1. Open the side discharge flap and hold it.

2. Line up the recesses of the side discharge chute

below the pivot.

3. Close the side discharge flap.

3.7 SET THE BLADE/CUTTING

HEIGHT

The machine can be set to different blade/cutting

heights.

Figure 7

1. Pull the height adjustment lever rearward to

increase the blade/cutting height.

2. Push the height adjustment lever forward to

decrease the blade/cutting height.

3.8 INSTALL THE BATTERY PACK

Figure 8.

WARNING

• If the battery pack or charger is damaged, replace

the battery pack or the charger.

• Stop the machine and wait until the engine stops

before you install or remove the battery pack.

• Read, know, and do the instructions in the battery

and charger manual.

NOTE

The machine has an automatic switch function that

lets the other battery work when the first cannot

operate.

1. Open the battery compartment flap.

2. Align the lift ribs on the battery pack with the

grooves in the battery compartment.

3. Push the battery pack into the battery compartment

until the battery pack locks into place.

4. When you hear a click, the battery pack is installed.

5. Close the battery compartment.

NOTE

The engine starts only when you put in the safety key.

3.9 INSTALL THE BATTERY PACK

Figure 8.

WARNING

• If the battery pack or charger is damaged, replace

the battery pack or the charger.

• Stop the machine and wait until the engine stops

before you install or remove the battery pack.

• Read, know, and do the instructions in the battery

and charger manual.

NOTE

The machine has an automatic switch function that

lets the other battery work when the first cannot

operate.

1. Open the battery compartment flap.

2. Align the lift ribs on the battery pack with the

grooves in the battery compartment.

3. Push the battery pack into the battery compartment

until the battery pack locks into place.

4. When you hear a click, the battery pack is installed.

5. Close the battery compartment.

NOTE

The engine starts only when you put in the safety key.

English EN

3.10 REMOVE THE BATTERY PACK

Figure 8

1. Remove the safety key.

2. Open the battery compartment flap.

3. Push and hold the battery release button.

4. Remove the battery pack from the machine.

4 OPERATION

WARNING

Wear eye protection during operation.

4.1 START THE MACHINE

Figure 9

1. Make sure safety key is inserted into slot.

2. Push and hold the start button.

3. While you hold the start button, grab the start

handles in the direction of the handle bar.

4. Once the machine has started, you can release the

start button.

5. Press the Turbo button to speed up to 3,200/min.

4.1.1 BATTERY CAPACITY INDICATOR

Lights Capacity

4 Green

Lights

The battery is above 80% capacity.

3 Green

Lights

The battery is between 80% and 60% ca-

pacity.

2 Green

Lights

The battery is at between 60% and 40% ca-

pacity.

1 Green

Light

The battery is between 40% and 20% ca-

pacity .

Lights

go out

The battery is less than 20% capacity and

requires charging immediately.

4.2 STOP THE MACHINE

Figure 9

1. Release the handle switch to stop the machine.

WARNING

Wait until the blade fully stops before you start the

machine again. Do not quickly turn the machine off

and on.

WARNING

Always remove the safety key and battery pack after

you complete the work.

4.3 OPERATE THE SELF-PROPEL

DRIVE SYSTEM

Figure 10

1. Start the machine.

2. While you hold the start handles, grab either of the

drive levers and pull towards the handle bar.

3. Hold the start handles and the drive levers at the

same time.

4. Release either set of start handle and drive lever

from the same side.

5. Adjust the speed control with your free hand.

• Slide the speed control button in the direction of

the Rabbit Symbol to increase the speed.

• Pull the speed control button in the direction of

the Turtle Symbol to decrease the speed.

6. Release the drive levers to close the self-propel

system.

To engage the self-propel drive system while the

mower is not running:

• Press and hold the start button, then pull up on the

drive lever.

• Pull up on the drive lever, then press the start

button.

4.4 LED HEADLIGHTS

Figure 11

1. When the mower is ready to start, you may grab the

start handle or the self-propel lever to turn on the

LED headlights.

2. Release the start handles and self-propel levers to

turn off the headlights.

4.5 EMPTY THE GRASS CATCHER

1. Stop the machine.

2. Remove the safety key.

3. Remove the battery pack.

4. Open the rear discharge flap and hold it.

5. Hold the grass catcher by its handle and unhook it

from the door rod.

6. Close the rear discharge flap.

7. Empty the grass catcher.

4.6 OPERATE ON SLOPES

WARNING

Do not mow on the slopes with incline more than 15°.

If you are not comfortable, do not mow on a slope.

English

WARNING

Please keep a low self-propelled speed when you

mow on a slope.

• Do not go up and down on a slope, mow across the

face of the slope. Be careful when you change the

direction on a slope.

• Monitor the holes, ruts, rocks, and other hidden

objects that can cause you to fall. Remove all

obstacles such as rocks and tree limbs.

• Make sure that your footing is stable. If you are out

of balance, release the start handle immediately.

• Do not mow near drop-offs, ditches, or

embankments.

4.7 OPERATION TIPS

• Do not try to override the operation of the start

button or handle switch.

• Do not tilt the machine when you start it.

• Do not put hands or feet near or below the turning

parts.

• Keep the discharge chute clean.

• Do not cut wet grass.

• Higher blade height is necessary for new or thick

grass.

• Clean the bottom of the mower deck after each

use. Remove grass clippings, leaves, dirt, and other

debris.

5 MAINTENANCE

WARNING

Remove the safety key and battery pack from the

machine before maintenance.

WARNING

Keep the motor and battery pack free from grass,

leaves or too much grease.

CAUTION

Use only approved replacement parts.

CAUTION

Do not let brake fluids, gasoline, petroleum-based

materials touch the plastic parts. Chemicals can

cause damage to the plastic, and make the plastic

unserviceable.

CAUTION

Do not use strong solvents or detergents on the plastic

housing or components.

NOTE

Recommended tightening torque (blade): 33-37 Nm.

5.1 GENERAL MAINTENANCE

• Before each use, examine the machine for

damaged, missing, or loose parts such as screws,

nuts, bolts and caps.

• Tighten correctly all the fasteners and caps.

• Clean the machine with a dry cloth. Do not use

water.

5.2 REPLACE THE BLADE

Figure 12

WARNING

Use only approved replacement blades.

WARNING

Wear heavy gloves or wind cloth around the blade

when you touch the blade.

1. Stop the machine.

2. Make sure that the blades fully stop.

3. Remove the safety key and battery pack.

4. Turn the machine to its side.

5. Use a piece of wood to prevent the movement of the

blade.

6. Remove the mounting screw and spacer with a

wrench or socket.

7. Remove the blade.

8. Install the new blade. Make sure that the arrows

engage the holes in the blade.

9. Put in the mounting screw and spacer and tighten

them.

5.3 STORE THE MACHINE

• Remove the safety key.

• Remove the battery pack(s).

• Clean the machine before storage.

• Make sure the motor is not hot when you store the

machine.

• Make sure that the machine does not have loose

or damaged parts. If it is necessary, follow these

instructions:

• Replace the damaged parts.

• Tighten the bolts.

• Speak to a person at an approved service

center.

• Store the machine in a dry area.

• Make sure that children cannot come near the

machine.

English EN

5.4 VERTICAL STORAGE

Figure 13

1. Remove the grass catcher.

2. Remove the battery and safety key.

3. Pull through the handle holes to fold away the

handles.

4. Lock the handles into position.

5. Stand the machine on end and make sure that the

brackets touch the floor.

6 TROUBLESHOOTING

Problem Possible cause Solution

The handle is

not in position.

The bolts are not

engaged correct-

ly.

Adjust the height

of the handle

and make sure

that the knobs

and bolts are

aligned correctly.

The machine

does not start.

The battery ca-

pacity is low.

Charge the bat-

tery pack.

The handle

switch is defec-

tive.

Replace the han-

dle switch.

The safety key is

not put in.

Put in the safety

key.

The machine

cuts grass un-

evenly.

The lawn is

rough.

Examine the

mowing area.

The blade height

is not set cor-

rectly.

Adjust the blade/

cutting height to

a higher position.

The machine

does not mulch

correctly.

Wet grass clip-

pings attach to

the deck.

Wait until the

grass dries be-

fore mowing.

The mulch plug

is missing.

Install the mulch

plug.

The machine is

hard to push.

The grass is too

tall, or the blade

height is too low.

Increase the

blade/cutting

height.

The grass catch-

er and the blade

drags in thick

grass.

Empty the grass

clippings from

the grass catch-

er.

There is a high

vibration in the

machine.

The blade is un-

balanced and

worn.

Replace the

blade.

Problem Possible cause Solution

The motor shaft

is bent.

1. Stop the mo-

tor.

2. Remove the

safety key

and battery

pack.

3. Inspect for

damage.

4. Repair the

machine be-

fore you start

it again.

The machine

stops during

mowing.

The blade height

is too low.

Increase the

blade/cutting

height.

The battery pack

is out of power.

Charge the bat-

tery pack.

The grass clip-

pings attach to

the deck or the

blade.

Remove the bat-

tery pack and

check the deck.

Operation tem-

perature of the

machine is too

high.

Cool the ma-

chine.

* If you cannot find the solution to these problems, go to

the service center.

English

7 TECHNICAL DATA

Voltage 60 V

No load speed 2800 / 3200 / min

Cut width 510 mm

Cut height 25 - 80 mm

Self-propelled speed 0,6 - 1,5 m/s

Grass catcher capacity 60 L

Weight (without battery

pack)

29.5 kg

Measured sound pressure

level

LPA= 87.9 dB(A) , K = 3

dB(A)

Guaranteed sound power

level

LWA.d= 98 dB(A)

Vibration < 2,5 m/s2 , K = 1,5 m/s2

Battery model G60B4 and other BAC

series

Charger model G60UC and other CAC

series

Double-insulated con-

struction

IPX IPX4

8 WARRANTY

(The full warranty terms and conditions can be found on

Greenworks website https://www.greenworkstools.eu)

The Greenworks warranty is 3 years on the product,

and 2 years on batteries (consumer/private usage)

from the date of purchase. This warranty covers

manufacturing faults. A faulty product under warranty

might be either repaired or replaced. A unit that has

been misused or used in other ways then described

in the owner’s manual might be rejected for warranty.

Normal wear, and wear parts are not considered as

warranty. The original manufacturer warranty is not

affected by any additional warranty offered by a dealer

or retailer.

A faulty product must be returned to the point of

purchase in order to claim for warranty, together with

the proof of purchase (receipt).

9 EC DECLARATION OF

CONFORMITY

Name and address of the manufacturer:

Name: Globe Technologies Europe GmbH

Address: Brunnenweg 17, 64331 Weiterstadt, Ger-

many

Name and address of the person authorised to compile

the technical file:

Name: Ralf Pankalla

Address: Brunnenweg 17, 64331 Weiterstadt, Ger-

many

Herewith we declare that the product

Category: Lawn Mower

Model: LMC420 (GD60LM51SP)

Serial number: See product rating label

Year of Construc-

tion:

See product rating label

• is in conformity with the relevant provisions of the

Machinery Directive 2006/42/EC.

• is in conformity with the provisions of the following

other EC-Directives:

• 2014/30/EU

• 2000/14/EC & 2005/88/EC

• 2011/65/EU & (EU)2015/863

Furthermore, we declare that the following parts,

clauses of harmonised standards have been used:

• EN 60335-1, EN 60335-2-77, EN 62233, EN

ISO 3744, EN 55014-1, EN 55014-2, ISO 11094,

IEC 62321-3-1, IEC 62321-4, IEC 62321-5, IEC

62321-6, IEC 62321-7-1, IEC 62321-7-2. IEC

62321-8

Conformity assessment method to Annex VI Directive

2000/14/EC.

Measured sound power level LWA: 94.6 dB(A)

Guaranteed sound power level LWA.d : 98 dB(A)

Notified body involved:

Name: Intertek Deutschland GmbH (Notified Body

0905)

Address: Stangenstr. 1, 70771 Leinfelden-Echterdingen,

Germany

Place, date: Weiter-

stadt, 03.03.2021

Signature: Ted Qu, Quality Di-

rector

English EN

1 Beschreibung.............................11

1.1 Verwendungszweck..................................11

1.2 Übersicht...................................................11

2 Sicherheit................................... 11

3 Montage......................................11

3.1 Maschine auspacken................................11

3.2 Auspacken und Griffmontage................... 11

3.3 Unteren Griff ausklappen......................... 12

3.4 Grasfangvorrichtung montieren................12

3.5 Mulcher montieren....................................12

3.6 Seitenauswurfschacht montieren............. 12

3.7 Messer-/Schnitthöhe einstellen................ 12

3.8 Akkupack einsetzen................................. 12

3.9 Akkupack einsetzen................................. 12

3.10 Akkupack entfernen..................................13

4 Bedienung..................................13

4.1 Maschine starten......................................13

4.2 Maschine anhalten................................... 13

4.3 Bedienung des Selbstfahrersystems........13

4.4 LED-Scheinwerfer.................................... 14

4.5 Grasfangvorrichtung entleeren.................14

4.6 Betrieb an Hängen................................... 14

4.7 Tipps zur Bedienung.................................14

5 Wartung und Instandhaltung....14

5.1 Allgemeine Wartung................................. 15

5.2 Messer ersetzen.......................................15

5.3 Maschine lagern.......................................15

5.4 Vertikale Lagerung................................... 15

6 Fehlerbehebung........................ 16

7 Technische Daten......................17

8 Garantie......................................17

9 EG-Konformitätserklärung....... 17

Deutsch

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere GreenWorks Rasenmäher Handbücher

GreenWorks

GreenWorks LME364 Bedienungsanleitung

GreenWorks

GreenWorks GD60LM51SP Bedienungsanleitung

GreenWorks

GreenWorks MO40B00 Bedienungsanleitung

GreenWorks

GreenWorks Optimow 4 Bedienungsanleitung

GreenWorks

GreenWorks MO13B00 Bedienungsanleitung

GreenWorks

GreenWorks DT40L00 Bedienungsanleitung

GreenWorks

GreenWorks 2540802 Bedienungsanleitung

GreenWorks

GreenWorks GRL110 Bedienungsanleitung

GreenWorks

GreenWorks 25142 Bedienungsanleitung

GreenWorks

GreenWorks 2508102 Bedienungsanleitung

GreenWorks

GreenWorks 2506402CT Bedienungsanleitung

GreenWorks

GreenWorks MO40B00 Bedienungsanleitung

GreenWorks

GreenWorks Optimow 15 Bedienungsanleitung

GreenWorks

GreenWorks 2502902BT Bedienungsanleitung

GreenWorks

GreenWorks G40LM35K2X Bedienungsanleitung

GreenWorks

GreenWorks 25292 Bedienungsanleitung

GreenWorks

GreenWorks RMQ702 Bedienungsanleitung

GreenWorks

GreenWorks GLM801601 Bedienungsanleitung

GreenWorks

GreenWorks LMF412 Bedienungsanleitung

GreenWorks

GreenWorks G48LM36 Bedienungsanleitung

GreenWorks

GreenWorks MO40B01 Bedienungsanleitung

GreenWorks

GreenWorks Elite M-210-SP-T Bedienungsanleitung

GreenWorks

GreenWorks MO40L01 Bedienungsanleitung

GreenWorks

GreenWorks MO80L08 Bedienungsanleitung

Beliebte Rasenmäher Handbücher anderer Marken

RHINO

RHINO 1958 Bedienungsanleitung

Wolf Garten

Wolf Garten Compact plus 40 B Bedienungsanleitung

Cub Cadet

Cub Cadet LTX 1045 Bedienungsanleitung

Craftsman

Craftsman 917.378461 Bedienungsanleitung

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Bedienungsanleitung

Challenge

Challenge CH18V2 Betriebsanleitung

TALEN TOOLS

TALEN TOOLS AVR HGM30 Bedienungsanleitung

DEWEZE

DEWEZE ATM-725 Bedienungsanleitung

Weed Eater

Weed Eater 180083 Bedienungsanleitung

Husqvarna

Husqvarna Poulan Pro PP185A42 Bedienungsanleitung

Better Outdoor Products

Better Outdoor Products Quick Series Bedienungsanleitung

Cub Cadet

Cub Cadet 23HP Z-Force 60 Betriebsanleitung

MTD

MTD 795, 792, 791, 790 Bedienungsanleitung

Toro

Toro Groundsmaster 3505-D Bedienungsanleitung

Dennis

Dennis FT 610 Bedienungsanleitung

AIRFORCE

AIRFORCE F-15 Gen 3 Bedienungsanleitung

MTD

MTD 126-220-000 Bedienungsanleitung

Toro

Toro 74806 Bedienungsanleitung
