Grill-Max Express X30 Bedienungsanleitung

GRILL-MAXEXPRESS

ROLLER GRILLS

X30, X45, X50, X75

Innite Controls

BUN WARMERS

XBW-30, XBW-50

Installation and

Operation

Instructions

2M-Z13702 Rev. A 12/22/2010

IL2072

These symbols are intended to alert the user to the presence of

important operating and maintenance instructions in the manual

accompanying the appliance.

RETAIN THIS MANUAL FOR FUTURE REFERENCE

NOTICE

Using any part other than genuine Star factory supplied parts relieves the

manufacturer of all liability.

Star reserves the right to change specications and product design without

notice. Such revisions do not entitle the buyer to corresponding changes,

improvements, additions or replacements for previously purchased

equipment.

Due to periodic changes in designs, methods, procedures, policies and

regulations, the specications contained in this sheet are subject to change

without notice. While Star International Holdings Inc., Company exercises

good faith efforts to provide information that is accurate, we are not

responsible for errors or omissions in information provided or conclusions

reached as a result of using the specications. By using the information

provided, the user assumes all risks in connection with such use.

MAINTENANCE AND REPAIRS

Contact your local authorized service agent for service or required maintenance.

Please record the model number, serial number, voltage and purchase date in the area below and have it ready when

you call to ensure a faster service.

SAFETY SYMBOL

Model No.

Serial No.

Voltage

Purchase Date

Business 8:00 am to 4:30 p.m. Central Standard Time

Hours:

Telephone: (800) 264-7827 Local (314) 781-2777

Fax: (800) 396-2677 Local (314) 781-2714

E-mail [email protected]

[email protected]

W[email protected]

Website: www.star-mfg.com

Service Help Desk

Authorized Service Agent Listing

Reference the listing provided with the unit

for an updated listing go to:

Website: www.star-mfg.com

E-mail [email protected]

Telephone: (800) 807-9054 Local (314) 781-2777

Mailing Address: Star International Holdings Inc., Company

10 Sunnen Drive

St. Louis, MO 63143

U.S.A

TABLE OF CONTENTS

PAGE NUMBER

GENERAL SAFTEY INFORMATION 3

GENERAL INSTALLATION INFORMATION 4

 ConnectionLoad&Sepecications 4

GENERAL OPERATING INSTRUCTIONS 5

Cleaning 5

ROLLERGRILL EXPLODED VIEW 6

PARTS LIST

30 MODEL SERIES 7

45 MODEL SERIES 8

50 MODEL SERIES 9

75 MODEL SERIES 10

WIRING DIAGRAM 11

BUN WARMER EXPLODED VIEW 12

PARTS LIST

XBW-30 & XBW-50 MODEL 13

WARRANTY 14

GENERAL SAFETY INFORMATION

Thisequipmentisdesignedandsoldforcommercialuseonlybypersonneltrainedandexperiencedin

itsoperationandisnotsoldforconsumeruseinandaroundthehomenorforusedirectlybythegeneral

publicinfoodservicelocations.

Beforeusingyournewequipment,readandunderstandalltheinstructions&labelsassociatedwiththe

unitpriortoputtingitintooperation.Makesureallpeopleassociatedwithitsuseunderstandtheunits

operation&safetybeforetheyusetheunit.

Allshippingcontainersshouldbecheckedforfreightdamagebothvisibleandconcealed.Thisunithas

beentestedandcarefullypackagedtoinsuredeliveryofyourunitinperfectcondition.Ifequipmentis

receivedindamagedcondition,eitherapparentorconcealed,aclaimmustbemadewiththedelivering

carrier.

Concealeddamageorloss-ifdamageorlossisnotapparentuntilafterequipmentisunpacked,a

requestforinspectionofconcealeddamagemustbemadewithcarrierwithin15days.Becertainto

retainallcontentsplusexternalandinternalpackagingmaterialsforinspection.Thecarrierwillmake

aninspectionandwillsupplynecessaryclaimforms.

CAUTION

GENERAL INSTALLATION INFORMATION

Thegrillshouldbeconnectedtoawalltypereceptacle,adirectlineorindividualbranchcircuit.

Anindividualbranchcircuitispreferred.Ifconnectedtoanoverloadedcircuitthegrillwillnot

operateproperly.Theunitshouldbelevelwheninstalled.Adjustable1-inchlegsarestandard

onallmodels.

BunWarmersmustbelevelforselfclosingfeature.

Thisgrillisequippedforthevoltageshownonthenameplate.

Itwilloperateonalternatingcurrentonly,however,thespeciedvoltagemustbeapplied.

CONNECTION LOAD:

DO NOT CONNECT TO DIRECT CURRENT (DC).

IMPORTANT

UNLEVEL UNITS COULD RESULT IN HAVING PRODUCT TRAVEL FROM

ONE SIDE TO THE NEXT, OVER A PERIOD OF TIME.

WARNING

Value Roller Grill

Model No (W) Width (D) Depth (H) Height Voltage Wattage Amps Plug

X30 23-3/4” 20-5/8”

10” 120 1150 9.6 5-15PX45 28-1/2” 1650 13.8

X50 35-3/4” 20-5/8” 1535 12.8

X75 28-1/2” 240 2400 10 6-15P

Value Bun Warmer

XBW30 23-3/4” 20-5/8” 6-1/4” 120 35 0.3 5-15P

XBW50 35-3/4” 50 0.4

Nameplate

IL2071

GENERAL OPERATING PROCEDURES

Themainswitchlocatedonthecontrolpanelcontrolsallthepowertotheunit.Withthemainswitchon,the

rollerswillturn,butnoheatwillbesuppliedunlesstheheatcontrolsareturnedon.Forexibilitytheheating

sectionofthegrillisdividedintotwoindividuallycontrolledheatsections.Therightcontrolregulatestheheatto

therearsection(greyrollerseals)andtheleftcontrolregulatestheheattothefrontsection(blackrollerseals).

Theswitchislightedtoindicatewhentheunitisturnedon.Asignallightisprovidedforeachheatcontroland

indicateswhentheheatedsectionison.

COOKING

Theheatcontrolsprovideaninniterangeofsettingsforawidevarietyoffoodproductsandinstallation

conditions.Thesize,contentandshapeoftheproductandtheinstallationofanysanitaryfoodshields

orsneezeguardswilldeterminetheproperheatsetting.TheNationalSanitationFoundationrequires

thatperishablefoodsbekeptat140°Foraboveduringservingperiods.Donotkeepthefoodproduct

onalowsettingformorethantwohours.Theproductshouldbekeptrefrigerateduntilreadyforuse.

Cookingtimewillvarydependingonthestartingtemperatureandthequalitiesoftheproduct.Forbest

resultswhencookinghotdogsuseahotdogmadeforgrilling.

USE ONLY PLASTIC OR COATED UTENSILS FOR HANDLING THE FOOD

PRODUCT. METAL COULD SCRATCH THE ROLLER COATING AND AFFECT

THE CLEAN ABILITY OF THE ROLLERS.

DO NOT USE STEEL WOOL OR ABRASIVE CLEANERS ON THE ROLLERS.

SCRAPES WILL VOID THE WARRANTY. USE CAUTION WHEN CLEANING

A HOT GRILL TO PREVENT BURNS OR BODILY INJURY.

CLEANING

Beforecookingforthersttime,washtherollerswithmildsoapandwaterusingasoftcloth.Donot

use metal utensils when cooking. Scratches and scrapes will hamper the ability to easily clean the

rollers.Neverusesteelwoolorabrasivecleanersontherollers.Thiswilldamagethenishandthe

rollerbearings.Therollerscleanmosteasilywhenhot.Usecautionwhencleaningtopreventburns

andbodilyinjury.Cleantherollerswithacleanwetcloth.Wipefromtheendstothecentertoprevent

forcingdebrisintotherollerseals.Donotallowthefoodproducttobuildupandbakeontotheroller

surface.Theexterioroftheunitshouldbecleanedusingamilddetergentornon-abrasivecleaner.Clean

theentireunitdailytoinsurelonglifeandsatisfactoryperformanceaswellastomaintainanattractive

appearance.Donotcleanwithwaterjetequipment.

MAINTENANCE AND REPAIRS

Contactthefactory,aservicerepresentativeoralocalservicecompanyforserviceorrequiredmaintenance.

ReplacementcordsetsmustbepurchasedfromStarInternationalHoldingsInc.,Company.

CAUTION

GRILL-MAXEXPRESS

VALUE ROLLER GRILL: MODEL X30, X45, X50, X75

SK2473 REV - 9/14/2010

568

Nameplate

PARTS LIST September8,2010,Rev.-

VALUE ROLLER GRILL MODEL X30, X30S, X30SG, X30F, X30SF, X30SGF

Fig No. Part Number Description Quantity Applications

1A5-Z2185 DRIP TRAY 30 1

2A5-RG3001 ROLLERASSY CHROME 11 X30, X30F

PS-RG3078 ROLLERASSY POLY WELDED X30S, X30SF

A5-RG4565 ROLLERASY HIGRIP 30S/45S X30SG, X30SGF

32N-Z2178 ELEMENT 120V 30/45 11

42A-Z8017 BUSHING IDLER 4

52P-Z8392 IDLER SPROCKETASSEMBLY 4

62C-1810 WASHER 3/16 BURR STLNP 10

7A5-Z13684 CHAIN GUIDE-11 COUNT 1

82C-Z0498 NUT 10-24 NYLK HEX STLZP 4

92C-6349 SCREW #8X3/8 B THP STL NP 27

10 2I-Z13659 INNER SEAL-BLACK 12 FRONT ROLLERS

2I-Z13660 INNER SEAL-LIGHT GRAY 10 BACK ROLLERS

11 2P-Z13661 TUBE GUIDE, 16 GA, BLACK 22

12 A5-RG30148 ASY,CHN TENSIONER W/SPKT 1

13 2P-Z8074 EXTENSION SPRING 1

14 2P-Z13743 #25 ROLLER CHAIN,188TEETH 1X30, X30S, X30SG

2P-Z13744 #25 ROLLER CHAIN,184TEETH X30F, X30SF, X30SFG

15 A5-Z13666 COVER,END PANEL,SLT,11CT 2X30, X30S, X30SG

A5-Z13669 COVER-END PANEL-FLAT-11CT X30F, X30SF, X30SFG

16 2P-Z11853 MOTOR SPROCKET 1

17 2C-1506 SCREW 10-32X1/2 RHPSTL 4

2C-200121 WASHER #10 SPLITSS 4

18 2U-Z11854 MOTOR GEAR, 120V 1

19 2K-Y3240 BUSHING HEYCO SR 17-2 1

20 A5-Z13677 COVER,BODY PANEL, X30 1

21 2K-Y8571 BUSHING SNAP 2 1/8 2

22 2A-Z11501 FOOT 1” SOLID RUBBER 4

23 2J-Z2195 INFINITE CONTROL120V 2

25 2M-Z13657 OVERLAY, MODEL X30, X45 1

26 2E-Z1858 SWITCH-LIGHTED 1

27 2R-Z1854 KNOB-CONTROL 2

28 2J-Z13654 PILOT LIGHT RECT-RED-120V 2

29 A5-Z13685 ELEMENT RETAINER,LWR-11CT 1

NI 2P-Z0584 TONGS-PLASTIC 9” 1

NI C3-G8021 CORDASSEMBLY 14-3 120V 1

NI A5-RG2006 WIREASSEMBLY #5 1

PARTS LIST September8,2010,Rev.-

VALUE ROLLER GRILL MODEL X45, X45S, X45SG, X45F, X45SF, X45SGF

Fig No. Part Number Description Quantity Applications

1A5-Z2186 DRIP TRAY 45 1 X45

2A5-RG3001 ROLLERASSY CHROME 16 X45

PS-RG3078 ROLLERASSY POLY WELDED X45S

A5-RG4565 ROLLERASY HIGRIP 30S/45S X45SG

32N-Z2178 ELEMENT 120V 30/45 16

42A-Z8017 BUSHING IDLER 4

52P-Z8392 IDLER SPROCKETASSEMBLY 4

62C-1810 WASHER 3/16 BURR STLNP 10

7A5-Z13686 CHAIN GUIDE-16 COUNT 1 X45

82C-Z0498 NUT 10-24 NYLK HEX STLZP 4

92C-6349 SCREW #8X3/8 B THP STL NP 36

10 2I-Z13659 INNER SEAL-BLACK 16 FRONT ROLLERS

2I-Z13660 INNER SEAL-LIGHT GRAY BACK ROLLERS

11 2P-Z13661 TUBE GUIDE, 16 GA, BLACK 32

12 A5-RG30148 ASY,CHN TENSIONER W/SPKT 1

13 2P-Z8074 EXTENSION SPRING 1

14 2P-Z13745 #25 ROLLER CHAIN,246TEETH 1X45, X45S, X45SG

2P-Z13746 #25 ROLLER CHAIN, 242TEETH X45F, X45SF, X45SGF

15 A5-Z13672 COVER,END PANEL,SLT,16CT 2X45, X45S, X45SG

A5-Z13675 COVER,END PANEL,FLAT, 16CT X45F, X45SF, X45SGF

16 2P-Z11853 MOTOR SPROCKET 1

17 2C-1506 SCREW 10-32X1/2 RHP STL 4

2C-200121 WASHER #10 SPLIT SS

18 2U-Z11854 MOTOR GEAR, 120V 1

19 2K-Y3240 BUSHING HEYCO SR 17-2 1

20 A5-Z13679 COVER,BODY PANEL, X45 1 X45

21 2K-Y8571 BUSHING SNAP 2 1/8 2

22 2A-Z11501 FOOT 1” SOLID RUBBER 4

23 2J-Z2195 INFINITE CONTROL 120V 2

25 2M-Z13657 OVERLAY, MODEL X30, X45 1

26 2E-Z1858 SWITCH-LIGHTED 1

27 2R-Z1854 KNOB-CONTROL 2

28 2J-Z13654 PILOT LIGHT RECT-RED-120V 2

29 A5-Z13687 ELEMENT RETAINER,LWR-16CT 1 X45

NI 2P-Z0584 TONGS-PLASTIC 9” 1

NI C3-G8021 CORDASSEMBLY 14-3 120V 1

NI A5-RG4512 WIREASSY LONG 2

PARTS LIST September8,2010,Rev.-

VALUE ROLLER GRILL MODEL X50, X50S, X50SG, X50F, X50SF, X50SGF

Fig No. Part Number Description Quantity Applications

1A5-Z2305 DRIP TRAY 50 1

2A5-RG7501 ROLLERASSY CHROME 11 X50, X50F

A5-RG7502 ROLLERASSY POLY X50S, X50SF

A5-RG5057 ROLLERASY HIGRIP 50SG/75SG X50SG, X50SGF

32N-Z2179 ELEMENT 120V 50/75 11

42A-Z8017 BUSHING IDLER 4

52P-Z8392 IDLER SPROCKETASSEMBLY 4

62C-1810 WASHER 3/16 BURR STLNP 10

7A5-Z13684 CHAIN GUIDE-11 COUNT 1

82C-Z0498 NUT 10-24 NYLK HEX STLZP 4

92C-6349 SCREW #8X3/8 B THP STL NP 27

10 2I-Z13659 INNER SEAL-BLACK 12 FRONT ROLLERS

2I-Z13660 INNER SEAL-LIGHT GRAY 10 BACK ROLLERS

11 2P-Z13661 TUBE GUIDE, 16 GA, BLACK 22

12 A5-RG30148 ASY,CHN TENSIONER W/SPKT 1

13 2P-Z8074 EXTENSION SPRING 1

14 2P-Z13743 #25 ROLLER CHAIN,188TEETH 1X50, X50S, X50SG

2P-Z13744 #25 ROLLER CHAIN,184TEETH X50F, X50SF, X50SGF

15 A5-Z13666 COVER,END PANEL,SLT,11CT 2X50, X50S, X50SG

A5-Z13669 COVER-END PANEL-FLAT-11CT X50F, X50SF, X50SGF

16 2P-Z11853 MOTOR SPROCKET 1

17 2C-1506 SCREW 10-32X1/2 RHP STL 4

2C-200121 WASHER #10 SPLIT SS

18 2U-Z11854 MOTOR GEAR, 120V 1

19 2K-Y3240 BUSHING HEYCO SR 17-2 1

20 A5-Z13679 COVER,BODY PANEL, X50 1

21 2K-Y8571 BUSHING SNAP 2 1/8 2

22 2A-Z11501 FOOT 1” SOLID RUBBER 4

23 2J-Z2195 INFINITE CONTROL 120V 2

25 2M-Z13658 OVERLAY, MODEL X50, X75 1

26 2E-Z1858 SWITCH-LIGHTED 1

27 2R-Z1854 KNOB-CONTROL 2

28 2J-Z13654 PILOT LIGHT RECT-RED-120V 2

29 A5-Z13684 ELEMENT RETAINER,LWR-11CT 1

NI 2P-Z0584 TONGS-PLASTIC 9” 1

NI C3-G8021 CORDASSEMBLY 14-3 120V 1

NI A5-RG2006 WIREASSEMBLY #5 2

PARTS LIST September8,2010,Rev.-

VALUE ROLLER GRILL MODEL X75, X75S, X75SG, X75F, X75SF, X75SGF

Fig No. Part Number Description Quantity Applications

1A5-Z2306 DRIP TRAY 75 1

2A5-RG7501 ROLLERASSY CHROME 16 X75, X75F

A5-RG7502 ROLLERASSY POLY X75S, X75SF

A5-RG5057 ROLLERASY HIGRIP 50SG/75SG X75SG, X75SGF

32N-Z2193 ELEMENT 230V 50/75 16

42A-Z8017 BUSHING IDLER 4

52P-Z8392 IDLER SPROCKETASSEMBLY 4

62C-1810 WASHER 3/16 BURR STLNP 10

7A5-Z13686 CHAIN GUIDE-16 COUNT 1

82C-Z0498 NUT 10-24 NYLK HEX STLZP 4

92C-6349 SCREW #8X3/8 B THP STL NP 36

10 2I-Z13659 INNER SEAL-BLACK 16 FRONT ROLLERS

2I-Z13660 INNER SEAL-LIGHT GRAY 16 BACK ROLLERS

11 2P-Z13661 TUBE GUIDE, 16 GA, BLACK 32

12 A5-RG30148 ASY,CHN TENSIONER W/SPKT 1

13 2P-Z8074 EXTENSION SPRING 1

14 2P-Z13745 #25 ROLLER CHAIN,246TEETH 1X75, X75S, X75SG

2P-Z13746 #25 ROLLER CHAIN,242TEETH X75F, X75SF, X75SGF

15 A5-Z13672 COVER,END PANEL,SLT,16CT 2X75, X75S, X75SG

A5-Z13675 COVER,END PANEL-FLAT-16CT X75F, X75SF, X75SGF

16 2P-Z11853 MOTOR SPROCKET 1

17 2C-1506 SCREW 10-32X1/2 RHP STL 4

2C-200121 WASHER #10 SPLIT SS

18 2U-Z11855 MOTOR GEAR, 240V 1

19 2K-Y3240 BUSHING HEYCO SR 17-2 1

20 A5-Z13683 COVER,BODY PANEL, X75 1

21 2K-Y8571 BUSHING SNAP 2 1/8 2

22 2A-Z11501 FOOT 1” SOLID RUBBER 4

23 2J-Z2192 INFINITE CONTROL 240V 2

25 2M-Z13658 OVERLAY, MODEL X50, X75 1

26 2E-Z1858 SWITCH-LIGHTED 1

27 2R-Z1854 KNOB-CONTROL 2

28 2J-Z13655 PILOT LIGHT-RECT-RED-230V 2

29 A5-Z13687 ELEMENT RETAINER,LWR-16CT 1

NI 2P-Z0584 TONGS-PLASTIC 9” 1

NI A5-RG2034 CORD SET 240V W/TERMINALS 1

NI A1-175122 LEAD IN CORDASSEM 1

NI A5-RG4512 WIREASSY LONG 2

Andere Handbücher für X30

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Grill-Max Express Grill Handbücher

Grill-Max Express

Grill-Max Express X30 Bedienungsanleitung

Beliebte Grill Handbücher anderer Marken

Orbegozo

Orbegozo GR 2300 Bedienungsanleitung

bora

bora PT11 Bedienungsanleitung

Klarstein

Klarstein 10031664 Bedienungsanleitung

Garland

Garland MWE3W Bedienungsanleitung

Char-Broil

Char-Broil 463722714 Bedienungsanleitung

Nexgrill

Nexgrill 720-0830HK Bedienungsanleitung

Kenmore

Kenmore 415.16123800 Bedienungsanleitung

Camp Chef

Camp Chef PG24CLAU Bedienungsanleitung

Tucker Barbecues

Tucker Barbecues GTR Series Montageanleitung

Monogram

Monogram ZGG540NCP1SS Bedienungsanleitung

Equipex

Equipex Sodir Savoy Bedienungsanleitung

Gaggenau

Gaggenau VR 414 610 Bedienungsanleitung

Miele

Miele KM 408-1 Bedienungsanleitung

George Foreman

George Foreman GGR50B Bedienungsanleitung

AOG

AOG T series Bedienungsanleitung

Gorenje

Gorenje TG2000CB Bedienungsanleitung

Weber

Weber Genesis Silver-B Permamount NG 051701 Bedienungsanleitung

Glen

Glen SA 3037 Bedienungsanleitung
