Grindmaster OPOD Bedienungsanleitung
Single Cup Pod Brewer
™
www.grindmaster.com
Step 1:
Place a pod in the pod holder, push
and lock the pod drawer into place.
Step 2:
Place your cup under the drawer. Select a
brew strength (mild, medium, strong, or tea).
Step 3:
Press and release
the BREW button.
Step 4:
Enjoy your perfect cup of coffee
or tea within one minute!
Easy Operation:
Brew Control™
Adjustable brew strength control: Mild, Medium, Strong,
and Tea, allows users to fine tune their flavor preference.
Dual Water System
Brewer can be plumbed into water line or
manually filled.
See-through Water Reservoir
Reservoir is back-lit with bright blue LED to see
water in reservoir.
Bright Feedback LEDs
Bright yellow LED alerts user when brewer is low on
water (manual refill mode) and bright green LED alerts
user when water is at correct brew temperature.
Variable Pod Size
Brewer can be used with Pods ranging from 55 to 61mm
and Pod weights ranging from 8.0 to 13.0 grams.
Gourmet Pod holder available for heavier, larger Pods
(Pods heavier than 10.5 grams).
12-Month Replacement Warranty (USA only*)
Brewer will be replaced for any material or workmanship defect for 12 months
after purchase. Field serviceable unit beyond warranty - service parts available.
Your Cup.
* 12 month part replacement warranty (outside USA).
Anti-scaling Water Tank Heater
Die-cast aluminum heater has two high-tech, baked-on,
anti-scaling coatings to prevent corrosion.
Color Coded Plumbing Connections
Internal tubing connections are color-coded for ease of reconnection.
Easy-Remove Hot Water Tank
Hot water tank can be easily removed by disconnecting electrical
and water connections and removing two no-tool fastening pins.
Cooling Fan
Cooling fan prolongs component life inside brewer and
spreads the coffee aroma throughout the room.
Patented Drawer Assembly
Drawer assembly rolls on permanently lubricated roller bearings.
Drawer can be easily changed by the removal of one screw.
Designed for Serviceability.
Accessories:
Water Pump
p/n 60568
Pod Holder Rack
p/n 92836
Pod Waste Bin
p/n 92837
External Control Board Connector
Allows field reprogramming without opening unit.
Gourmet Pod Tray
p/n 92835
Small Office Revenue Potential
The untapped small office segment of the market has the potential to
generate as much revenue as the existing OCS market.
Number of small offices in the US ........................ 11.5 M
(offices with 25 or fewer employees)
Daily Revenue Opportunity ................................... $28.8 M
(average 10 cups/day/office @ $0.25 cost/cup)
Annual Revenue Opportunity ............................... $7.2 B
(250 working days/year)
Profit by the Cup
36% of the 42 million cups of coffee
consumed in the office daily are
purchased outside the office.
Why?
• Tastes better
• Large variety of flavors
15M cups of coffee
per day from
outside office
27M cups of
coffee per day
from inside office
Market Opportunity
Revenue Potential to Capture
Number of cups brought from
outside the office per day ................................... 15 M
Daily Revenue ..................................................... $3.8 M
(15M cups/day x $0.25 cost/cup)
Annual Revenue ................................................ $950 M
(250 working days/year)
Revenue that is currently being lost!
Source: Q2 Brand Intelligence
Earl Grey Tea
Irish Cream
Breakfast Blend
Cappuccino
Tropical Citrus Tea
House Blend
Chocolate
Sumatra
English Breakfast Tea
Colombian
French Vanilla
Green Tea
French Roast
Hazelnut
Kona Blend
Gives Individual Flavor Selection
Specification Model OPOD Model OPOD-E
Electrical 120V, 1300W, 10.8A 230V, 1200W, 5.2A
Frequency 60 Hz 50/60 Hz
Water Inlet Pressure (plumbed units only) 10 -145 psi
Water Reservoir Capacity 80 fl. oz. (2.4 L)
Hot Water Tank Capacity 35 fl. oz. (1 L)
Maximum Brewing Water Temperature 200°F (93°C)
Minimum Brewing Water Temperature 185°F (85°C)
Brewing Volume Approx. 12 fl. oz. (355 ml) (programmable)
Dimensions (H x W x D) 14-1/4” (19” incl. reservoir lid upswing) H x 8-1/4” W x 14” D
36 cm (48 cm incl. reservoir upswing) x 21 cm x 36 cm
Ship Dimensions (H x W x D) 16” H x 9-3/4” W x 15-3/4“ D
41 cm x 25 cm x 40 cm
Weight 12 lbs. (5.4 kg)
Ship Weight 15 lbs. (6.8 kg)
Listings NSF, UL NSF, CE
Model OPOD
Side View
14”
(36 cm)
Front View
14-1/4”
(36 cm)
8-1/4”
(21 cm)
Features
PrecisionBrew™
Innovative precision pod brewing and infusion
technology provides the ideal cup every time
BrewControl™
Adjustable brew strength control allows users
to fine tune their flavor preferences
Smartstop™ Automatic Water Shutoff
Water shuts off when pod drawer is open
Programmable Cup Size
Control the volume of beverage
dispensed into the cup
Accommodates taller mugs
Dual Water System
Brewer can be plumbed into a water
line or manually filled
Specifications are subject to improvement or change without notice.
Grindmaster® Coffee Grinders and Brewers • PrecisionBrew™ Brewing Systems • Espressimo® Espresso Machines
Crathco® Hot Beverage Dispensers • Crathco® Cold and Frozen Beverage Dispensers • AMW Coffee and Tea Systems
Tel (502) 425-4776 • Fax (502) 425-4664 • 1-800-695-4500 (USA & Canada only)
P.O. Box 35020 • Louisville, KY 40232 • USA
www.grindmaster.com • email: info@grindmaster.com
© Grindmaster Corporation, 2006
PRINTED IN USA
0107 Form # PD-250-02
