Mini300PE

AM/FM/SHORTWAVE RADIO

OPERATION MANUAL

www.etoncorp.com

MINI 300PE OPERATION MANUAL

DO YOU NEED HELP?

Here’s how to contact us:

• From the United States: (800) 872-2228

• From Canada: (800) 637-1648

• From Everywhere Else: (650) 903-3866

• Email: customersvc@etoncorp.com

• Internet: www.etoncorp.com

TABLE OF CONTENTS

BASIC CONTROLS ...........................................................

BATTERIES ......................................................................

POWER ON/OFF/ VOLUME ..............................................

FM RADIO .....................................................................

AM/SW1-7 RADIO .........................................................

ANTENNA .....................................................................

CLOCK .............................................................................

ALARM ............................................................................

SLEEP FUNCTION ............................................................

INTRODUCTION TO SHORTWAVE .....................................

SHORTWAVE BANDS .....................................................

GUIDELINES ...................................................................

STATIONS .........................................................................

SERVICE INFORMATION ...................................................

ONE YEAR LIMITED WARRANTY ....................................

page

BASIC CONTROLS continued

MINI 300PE OPERATION MANUAL

1BASIC CONTROLS

ANTENNA

DISPLAY

HOUR

MINUTES

TUNNING KNOB

VOLUME KNOB

POWER

SLEEP

ALARM

TIME

BATTERY COVER

EAR PHONE JACK

BAND SWITCH

4FM RADIO

Select the FM band by using the band selector switch (13).

Use the tuning knob (5) to tune the radio to the desired

frequency.

MINI 300PE OPERATION MANUAL

2BATTERIES

Remove the battery compartment’s cover by pushing the

cover in the direction of arrow. Install two ‘AA’ batteries

according to the polarity. For easy removal, place the bat-

teries on top of lift out ribbon. If the sound becomes low

or distorted, replace with new batteries. If the radio will

not be used for a long time, remove all the batteries to

prevent possible battery leakage.

98 7

3POWER ON/OFF/VOLUME

Turn the radio on by pressing the POWER button (7). Use

the volume knob (6) to adjust the volume.

5AM RADIO

6AM RADIO

A. For AM (MW) the radio uses an internal, directional,

ferrite bar antenna. Rotate the radio for best reception.

B. For FM/SW, fully extend the telescopic antenna (1).

For FM, rotate the antenna for best reception.

Select the desired band, AM or SW 1-7, by using the band

selector switch (13). Turn the tuning knob (5) to the

desired frequency, which appears in the display (2) or just

tune around and listen for stations. Note that MW appears

in the display when AM is selected, as the AM band is

called MW for medium wave in some parts of the world.

SW appears in the display when SW1-8 is selected.

8ALARM

With the radio turned off, keeping the ALARM button (9)

pressed, set the correct wake up hour and minutes with the

HOUR (3) and MINUTE (4). They can be pressed with quick,

short presses to advance slowly or they can be kept pressed

rapidly. When finished, release the ALARM button and this

will cause the loudspeaker symbol appears in the display.

If you want to deactivate the alarm, press the ALARM but-

ton (9) again and the loudspeaker symbol will disappear

from the display.

When the activated alarm turns the radio on, it can be

turned off by pressing the ALARM button (9) again. The

Power button (7) cannot be used for this purpose.

While the radio is playing in alarm mode and without any

manual interruption to deactivate the alarm, it will turn off

automatically after 60 minutes.

MINI 300PE OPERATION MANUAL

7CLOCK

The clock displays time in 12 hour, AM/PM format. While

keeping the TIME button (10) pressed, set the correct

hour and minutes with the HOUR (3) and MINUTE (4)

buttons. They can be pressed with quick, short presses

to advance slowly or they can be kept pressed down to

advance rapidly. When finished, release the TIME button.

NOTE: The sleep function cannot be activated again

within 2 minutes after this function was deactivated

before.

MINI 300PE OPERATION MANUAL

9SLEEP FUNCTION

The sleep function enables the radio to play for a specified

time before automatically shutting off (from 1 hour 59

minutes to just one minute).

With the radio turned off, press and do not release the

SLEEP button (8). This turns the radio on and “0:59”

appears in the display. This also activates the sleep timer

activation symbol in the display.

To set SLEEP function for 59 minutes, release the SLEEP

button. To set SLEEP function as desired, continue to keep

the SLEEP button pressed and use the HOUR and MINUTE

buttons to adjust the sleep time for you needs. When fin-

ished, release the SLEEP button.

While it is playing in sleep mode, it can be turned off by

pressing the SLEEP button. The power button (7) cannot be

used for this purpose. The sleep timer activation symbol will

disappear from the display. If the POWER button is pressed,

you need to press SLEEP button again to deactivate the

SLEEP function (The symbol will disappear from display)

and press POWER button again to turn off the radio.

SLEEP FUNCTION continued

MINI 300PE OPERATION MANUAL

10 INTRODUCTION TO SHORTWAVE

Shortwave enables you to hear stations from around the

world. Now that you have a shortwave radio, no doubt

you’ll want to hear worldwide stations right away. If

you’re new to shortwave, please take some time to learn

the basics outlined below. To successfully listen to short-

wave stations you must know how to find them. They are

found in the shortwave ‘bands’. On the Mini 300, the

shortwave bands are numbered 1-7. The chart below and

the one on the back of the radio show the relationship of

bands 1-7 to their official names and the frequency ranges

covered by them.

MINI 300

SWITCH

SETTING

SW1

SW2

SW3

SW4

SW5

SW6

SW7

OFFICIAL

SHORT-WAVE

BAND NAME

49 meters

41 meters

31 meters

25 meters

22 meters

19 meters

16 meters

FREQUENCY

RANGE

IN MHz

5.950-6.20

7.10-7.30

9.50-9.95

11.600-12.100

13.600-13.800

15.10-15.80

17.500-17.90

FREQUENCY

RANGE

IN KHz

5950- 6200

7100- 7300

9500- 9950

11600-12100

13600-13800

15100-15800

17500-17900

11 SHORTWAVE BANDS

12 GUIDELINES

MINI 300PE OPERATION MANUAL

HERE ARE SOME GENERAL GUIDELINES

• In general, the bands with frequencies below 13 MHz

are better at night and the bands with frequencies

above 13 MHz are best during the day. This guideline,

while approximate, is a useful general rule of thumb.

• During the day, listen in SW5-7. These may start getting

good just before sunrise and may stay good all day, until

just after sunset.

• At night, listen in SW1-4. These may start getting good

just before sunset and may stay good all night, until just

after sunrise.

• Around sunrise and sunset, both the day and night

bands might be good, sometimes exceptionally good.

• Winter shortwave is generally somewhat better than

summer shortwave.

• Holding the radio while listening to shortwave will

improve signal strengths.

GUIDELINES continued

• Getting close to a window may substantially improve

your reception because the construction materials of

some buildings do not let signals in very well. Signals

penetrate wood frame buildings easiest, while con-

crete and brick buildings usually block signals. If you

are in a building with one or more stories above you,

signals can also be impaired in strength. In such a sit-

uation, get as close to a window as possible while

listening.

• These guidelines can be used worldwide and are not

dependent on location.

13 STATION

HOW TO IDENTIFY WHAT YOU’RE

LISTENING TO AND HOW TO FIND

STATIONS THAT YOU WANT TO HEAR

For this, you’ll need to use a shortwave directory. We rec-

ommend the use of a comprehensive shortwave directory,

especially if you want to hear specific countries or to iden-

tify the station you’re listening to. Such a directory will

alphabetically list the countries broadcasting on short-

wave, showing their language, target area, broadcast time

and frequency that is used. The easiest to use shortwave

directory is PASSPORT TO WORLD BAND RADIO, available

in major bookstores and directly from the publisher.

Published by International Broadcasting Services, Ltd., Box

300, Penn's Park, Pennsylvania 18943 (www.passband.com).

This publication has separate chapters for English and

non-English broadcasts, titled World-Wide Broadcasts In

English and Voices From Home.

MINI 300PE OPERATION MANUAL

14 SERVICE INFORMATION

You may contact the Etón Service Department for additional

information:

customersvc@etoncorp.com

your unit. Should you want to return your unit for service,

pack the receiver carefully using the original carton or

other suitable container. Write your return address clearly

on the shipping carton and on an enclosed cover letter

describing the service required, symptoms or problems.

Also, include your daytime telephone number and a copy

of your proof of purchase. The receiver will be serviced

under the terms of the Etón Limited Warranty and returned

to you.

15 ONE YEAR LIMITED WARRANTY

Etón warrants to the original purchaser this product shall

be free from defects in material or workmanship for one

year from the date of original purchase. During the war-

ranty period Etón or an authorized Etón service facility will

provide, free of charge, both parts and labor necessary to

correct defects in material and workmanship. At their

option, Etón may replace a defective unit.

1. Complete and send in the Warranty Registration Card

within ten (10) days of purchase.

2. Call Etón or the nearest authorized service facility, as

soon as possible after discovery of a possible defect.

Have ready:

(a) the model and serial number.

(b) the identity of the seller and the approximate date

of purchase.

details on the electrical connection to associated

equipment and the list of such equipment.

MINI 300PE OPERATION MANUAL

ONE YEAR LIMITED WARRANTY continued

3. Etón will issue a Return Authorization number and the

address to which the unit can be shipped. Ship the unit

in its original container or equivalent, fully insured and

shipping charges prepaid.

Correct maintenance, repair, and use are important to

obtain proper performance from this product. Therefore

carefully read the Instruction Manual. This warranty does

not apply to any defect that Etón determines is due to:

1. Improper maintenance or repair, including the

installation of parts or accessories that do not conform

to the quality and specification of the original parts.

2. Misuse, abuse, neglect or improper installation.

3. Accidental or intentional damage.

4. Battery leakage.

All implied warranties, if any, including warranties of mer-

chantability and fitness for a particular purpose, terminate

one (1) year from the date of the original purchase. The

foregoing constitutes Etón entire obligation with respect to

this product, and the original purchaser shall have no

other remedy and no claim for incidental or consequential

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Grundig Radio Handbücher

Grundig

Grundig G1100 Bedienungsanleitung

Grundig

Grundig G1100 Bedienungsanleitung

Grundig

Grundig Music 61 Bedienungsanleitung

Grundig

Grundig satellit 3400 professional Bedienungsanleitung

Grundig

Grundig GUSR91DAB Bedienungsanleitung

Grundig

Grundig SATELLIT INTERNATIONAL 650 Bedienungsanleitung

Grundig

Grundig DTR 7000 Bedienungsanleitung

Grundig

Grundig Yacht Boy 215a Bedienungsanleitung

Grundig

Grundig S450DLX Bedienungsanleitung

Grundig

Grundig RR 335 Bedienungsanleitung

Grundig

Grundig DTR 5000 Bedienungsanleitung

Grundig

Grundig Globe Traveler G3 Bedienungsanleitung

Grundig

Grundig TR 1200 Bedienungsanleitung

Grundig

Grundig WKC 1904 RDS Bedienungsanleitung

Grundig

Grundig TR 2200 DAB Plus Bedienungsanleitung

Grundig

Grundig TR 1200 Bedienungsanleitung

Grundig

Grundig Cosmopolit 4 WEB DAB+ Bedienungsanleitung

Grundig

Grundig World Receiver G-2000A Bedienungsanleitung

Grundig

Grundig Sonoclock 691 DAB+ Bedienungsanleitung

Grundig

Grundig WTR 3200 BT DAB+ WEB Bedienungsanleitung

Grundig

Grundig Music 5000 DAB+ Bedienungsanleitung

Grundig

Grundig DTR 6000 2.1 BT DAB+ WEB Bedienungsanleitung

Grundig

Grundig BOY 55 Bedienungsanleitung

Grundig

Grundig Eaton G4000A Bedienungsanleitung

Beliebte Radio Handbücher anderer Marken

EisSound

EisSound KBSound iSelect Bedienungsanleitung

Midland

Midland 1001LWX Bedienungsanleitung

Konig

Konig HAV-SR41 Bedienungsanleitung

Roberts

Roberts exprssion Bedienungsanleitung

VDigi

VDigi DD3.0 Bedienungsanleitung

Radio Shack

Radio Shack 21-1863 Bedienungsanleitung

Roberts

Roberts Stream 207 Bedienungsanleitung

Sony

Sony Walkman SRF-M97 Bedienungsanleitung

Stanley

Stanley FatMax FMC770 Bedienungsanleitung

auna

auna DAB-Radio 10026947 Bedienungsanleitung

SOUNDMASTER

SOUNDMASTER UR190 Bedienungsanleitung

HYT

HYT TC-320 Bedienungsanleitung

auna multimedia

auna multimedia Yellowstone 10026851 Bedienungsanleitung

B-Tech

B-Tech GMRS-V2 Bedienungsanleitung

Weierwei

Weierwei VEV-V8 Bedienungsanleitung

SOUNDMASTER

SOUNDMASTER DAB750 Bedienungsanleitung

Telefunken

Telefunken TF-1505 Bedienungsanleitung

Makita

Makita LXRM03 Bedienungsanleitung
