REFRIGERATOR

USER INSTRUCTIONS

GKN 16830 X

FIN

Contents

1. Safety and environment

instructions 7

1.1.1 HC warning..........................8

1.1.2 For models with water

dispenser.......................................9

1.3 Child safety..........................9

1.4 Compliance with WEEE

Directive and Disposing of the Waste

Product ..........................................9

1.5 Compliance with RoHS

Directive.......................................10

1.6 Package information.........10

2. Your Cooler/freezer 11

3. Installation 12

3.1 Appropriate installation

location ........................................12

3.2 Installing the plastic

wedges.........................................13

3.3 Electrical connection ........13

3.4 Illumination lamp..............13

4. Preparation 14

4.1 Things to be done for energy

saving...........................................14

4.2 Initial use...........................15

5. Operating the product 16

5.1 Indicator panel 16

5.2 Dual cooling system 19

5.3 Freezing freshfood................

5.4 Recommendations

for preserving the frozen

food 21

5.6 Deep-freeze information 22

5.7 Changing the door

opening direction 22

5.8 Open door warning 22

5.5 Placing the

food 22

5.9 Recommendations for

freshfood compartment .............

6. Maintenance and cleaning 24

6.2 Protecting the plastic

surfaces .....................................

7. Troubleshooting 25

Please read this manual first!

Dear Customer,

We hope that your product, which has been produced in modern plants

and checked under the most meticulous quality control procedures, will

provide you an effective service

For this, we recommend you to carefully read the entire manual of your

product before using it and keep it at hand for future references.

The user manual will help you use the product in a fast and safe way.

Will help you use your appliance in a fast and safe way.

Read the manual before installing and operating your product.

Follow the instructions, especially those for safety.

Keep the manual in an easily accessible place as you may need it later.

Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

CImportant information

or useful usage tips.

Warning against

dangerous conditions

for life and property.

BWarning against

electric voltage.

Packaging materials

of the product are

manufactured from

recyclable materials

in accordance with our

National Environment

Regulations.

FIN

1. Safety and environment instructions

This section provides the safety

instructions necessary to

prevent the risk of injury and

material damage. Failure to

observe these instructions will

invalidate all types of product

warranty.

Intended use

AWARNING:

Keep ventilation openings, in

the appliance enclosure or in

the built-instructure, clear of

obstruction.

AWARNING:

Do not use mechanical devices

or other means to accelerate

the defrosting process, other

than those recommended by the

manufacturer.

AWARNING:

Do not damage the refrigerant

circuit.

AWARNING:

Do not use electrical

appliances inside the food

storage compartments of the

appliance, unless they are of

the type recommended by the

manufacturer.

This appliance is intended to be

used in household and similar

applications such as

– staff kitchen areas in shops,

offices and other working

environments;

– farm houses and by clients

in hotels, motels and other

residential type environments;

– bed and breakfast type

environments;

– catering and similar non-retail

applications.

1.1. General safety

• This product should not

be used by persons with

physical, sensory and mental

disabilities, without sufficient

knowledge and experience

or by children. The device

can only be used by such

persons under supervision

and instruction of a person

responsible for their safety.

Children should not be

allowed to play with this

device.

• In case of malfunction,

unplug the device.

• After unplugging, wait at

least 5 minutes before

plugging in again.

• Unplug the product when not

in use.

• Do not touch the plug with

wet hands! Do not pull the

cable to plug off, always hold

the plug.

• Do not plug in the refrigerator

if the socket is loose.

• Unplug the product during

installation, maintenance,

cleaning and repair.

• If the product will not be

used for a while, unplug the

product and remove any food

inside.

• Do not use the product when

the compartment with circuit

cards located on the upper

back part of the product

(electrical card box cover) (1)

is open.

• Do not use steam or steamed

cleaning materials for

cleaning the refrigerator and

melting the ice inside. Steam

may contact the electrified

areas and cause short circuit

or electric shock!

• Do not wash the product by

spraying or pouring water on

it! Danger of electric shock!

• In case of malfunction, do not

use the product, as it may

cause electric shock. Contact

the authorised service before

doing anything.

• Plug the product into an

earthed socket. Earthing

must be done by a qualified

electrician.

• If the product has LED

type lighting, contact the

authorised service for

replacing or in case of any

problem.

• Do not touch frozen food with

wet hands! It may adhere to

your hands!

• Do not place liquids in bottles

and cans into the freezer

compartment. They may

explode.

• Place liquids in upright

position after tightly closing

the lid.

• Do not spray flammable

substances near the product,

as it may burn or explode.

• Do not keep flammable

materials and products with

flammable gas (sprays, etc.)

in the refrigerator.

• Do not place containers

holding liquids on top of the

product. Splashing water on

an electrified part may cause

electric shock and risk of fire.

• Exposing the product to rain,

snow, sunlight and wind

will cause electrical danger.

When relocating the product,

do not pull by holding the

door handle. The handle may

come off.

• Take care to avoid trapping

any part of your hands or

body in any of the moving

parts inside the product.

• Do not step or lean on the

door, drawers and similar

parts of the refrigerator. This

will cause the product to fall

down and cause damage to

the parts.

• Take care not to trap the

power cable.

1.1.1 HC warning

If the product comprises a

cooling system using R600a

gas, take care to avoid

damaging the cooling system

and its pipe while using and

moving the product. This gas

FIN

is flammable. If the cooling

system is damaged, keep the

product away from sources

of fire and ventilate the room

immediately.

CThe label on the inner left

side indicates the type of gas used

in the product.

1.1.2 For models with

water dispenser

• Pressure for cold water inlet

shall be maximum 90 psi (6.2

bar). If your water pressure

exceeds 80 psi (5.5 bar), use

a pressure limiting valve in

your mains system. If you

do not know how to check

your water pressure, ask for

the help of a professional

plumber.

• If there is risk of water

hammer effect in your

installation, always

use a water hammer

prevention equipment in

your installation. Consult

Professional plumbers if you

are not sure that there is no

water hammer effect in your

installation.

• Do not install on the hot

water inlet. Take precautions

against of the risk of

freezing of the hoses. Water

temperature operating

interval shall be 33°F (0.6°C)

minimum and 100°F (38°C)

maximum.

• Use drinking water only.

1.2. Intended use

• This product is designed for

home use. It is not intended

for commercial use.

• The product should be used

to store food and beverages

only.

• Do not keep sensitive

products requiring controlled

temperatures (vaccines,

heat sensitive medication,

medical supplies, etc.) in the

refrigerator.

• The manufacturer assumes

no responsibility for any

damage due to misuse or

mishandling.

• Original spare parts will

be provided for 10 years,

following the product

purchasing date.

1.3 Child safety

• Keep packaging materials

out of children’s reach.

• Do not allow the children to

play with the product.

• If the product’s door

comprises a lock, keep the

key out of children’s reach.

1.4 Compliance with WEEE

Directive and Disposing

of the Waste Product

This product complies

with EU WEEE Directive

(2012/19/EU). This

product bears a

classification symbol for

waste electrical and

electronic equipment (WEEE).

This product has been

manufactured with high quality

parts and materials which can

be reused and are suitable for

recycling. Do not dispose of

the waste product with normal

domestic and other wastes at the

end of its service life. Take it to the

collection center for the recycling

of electrical and electronic

equipment. Please consult your

local authorities to learn about

these collection centers.

1.5 Compliance with

RoHS Directive

This product complies with EU

WEEE Directive (2011/65/EU).

It does not contain harmful and

prohibited materials specified in

the Directive.

1.6 Package information

Packaging materials of the product

are manufactured from recyclable

materials in accordance with our

National Environment Regulations.

Do not dispose of the packaging

materials together with the

domestic or other wastes. Take

them to the packaging material

collection points designated by the

local authorities.

FIN

Figures in this user manual are schematic and may not

match the product exactly. If the subject parts are not

included in the product you have purchased, then those parts

are valid for other models.

2. Your Cooler/freezer

1. Butter & Cheese sections

2. Indıcator Panel

3. Egg tray

4. Adjustable door shelves

5. Bottle shelf

6. Shelter wire

7. Adjustable front feet

8. Freezer compartment

9. Crisper

10. Chiller

11. Chiller cover and glass

12. Adjustable shelves

13. Wine cellar

14. Fan

3. Installation

Refer to the nearest Authorised

Service Agent for installation of

the product. To make the product

ready for use, make sure that

the electricity installation is

appropriate before calling the

Authorised Service Agent. If not,

call a qualified electrician to have

any necessary arrangements

carried out.

Preparation of the

location and electrical

installation at the place

of installation is under

customer's responsibility.

Product must not be

plugged in during

installation. Otherwise,

there is the risk of death

or serious injury!

WARNING: Installation

and electrical connections

of the product must

be carried out by the

Authorised Service Agent.

Manufacturer shall not be

held liable for damages

that may arise from

procedures carried out by

unauthorised persons.

WARNING: Prior to

installation, visually

check if the product has

any defects on it. If so,

do not have it installed.

Damaged products cause

risks for your safety.

Make sure that the power

cable is not pinched or

crushed while pushing

the product into its place

after installation or

cleaning procedures.

3.1 Appropriate

installation location

WARNING: If the door

of the room where the

product will be placed

is too small for the

product to pass, then the

product's doors must be

removed and the product

must be turned aside to

pass it through.

• Choose a place at where

you would use the product

comfortably.

• Install the product at least 30

cm away from heat sources

such as hobs, ovens, heater

cores and stoves and at least 5

cm away from electrical ovens.

Product must not be subjected

to direct sun light and kept in

humid places after installation.

• Appropriate air ventilation must

be provided around your product

in order to achieve an efficient

operation. If the product is to be

placed in a recess in the wall,

pay attention to leave at least 5

cm distance with the ceiling and

side walls.

• Do not place the product on

the materials such as rugs or

carpets.

• Place the product on an even

floor surface to prevent jolts.

• Your product can operate in

ambinet temperatures between

-5°C to +43°C.

Inhaltsverzeichnis

Sprachen:

Andere Grundig Kühlschrank Handbücher

Grundig

Grundig GSMI14331FN Bedienungsanleitung

Grundig

Grundig GKN 27930 FX Bedienungsanleitung

Grundig

Grundig GKMI 25440 N Bedienungsanleitung

Grundig

Grundig GKFED455 Montageanleitung

Grundig

Grundig GSN 10620 Bedienungsanleitung

Grundig

Grundig GTM 14141 FN Bedienungsanleitung

Grundig

Grundig GSNE 107E20FXRN Bedienungsanleitung

Grundig

Grundig GTMU 14110 Bedienungsanleitung

Grundig

Grundig GKMI 25420 Bedienungsanleitung

Grundig

Grundig GSMI25740FN Bedienungsanleitung

Grundig

Grundig GKF3581VPS Bedienungsanleitung

Grundig

Grundig GKNI25940N Bedienungsanleitung

Grundig

Grundig GKN 27940 FXN Bedienungsanleitung

Grundig

Grundig GKNR16826XP Bedienungsanleitung

Grundig

Grundig GFT 12320 Bedienungsanleitung

Grundig

Grundig GRNE 4680 Bedienungsanleitung

Grundig

Grundig GQN21220X Bedienungsanleitung

Grundig

Grundig GTMU 10130 N Bedienungsanleitung

Grundig

Grundig GSN30311FXBR Bedienungsanleitung

Grundig

Grundig GLRN 66820 Bedienungsanleitung

Grundig

Grundig GKN 26260 XPHN Bedienungsanleitung

Grundig

Grundig GKPN46820FX Bedienungsanleitung

Grundig

Grundig GTM 10120 Bedienungsanleitung

Grundig

Grundig GKNI 25742 FN Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
