OPERATING MANUAL

Lithium Power Sweeper

Model number: SW22

IMPORTANT SAFEGUARDS:

IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE.

RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.

Do not use in rain or leave outdoors whilst raining.

WARNING: Basic safety precautions should always be observed when

using an electrical appliance, including the following to reduce the risk of

re, electrical shock, or injury:

Personal Safety:

• Store indoors in a dry place out of the

reach of children.

• Always use responsibly. This

appliance can be used by children

aged from 8 years and above and

persons with reduced physical,

sensory or mental capabilities or

lack of experience and knowledge

if they have been given supervision

or instruction concerning use of

the appliance in a safe way and

understand the hazards involved.

• Don’t let children play with the

appliance; supervise children using or

maintaining the appliance.

• Use only manufacturer’s

recommended attachments as

described in this manual; misuse or

use of any accessory or attachment

other than those recommended, may

present a risk of personal injury.

• Take extra care when cleaning stairs.

• Keep the appliance and accessories

away from hot surfaces.

• Particularly keep hair away from

openings and moving parts.

Electrical safety:

• Only use batteries and chargers

supplied by Gtech.

• Never modify the charger in any way.

• The charger must only be used for

UK mains supply.

A charger that is suitable for one

type of battery pack may create a

risk of re when used with another

battery pack; never use the charger

with another appliance or attempt

to charge this product with another

charger.

• Before use, check the charger cord

for signs of damage or ageing.

A damaged or entangled charger

cord increases the risk of re and

electric shock.

• Do not abuse the charger cord.

• Never carry the charger by the cord.

• Do not pull the cord to disconnect

from a socket; grasp the plug and

pull to disconnect.

• Don’t wrap the cord around the

charger when storing.

• Keep the charger cord away from hot

surfaces and sharp edges.

• The supply cord cannot be replaced.

If the cord is damaged the charger

should be discarded and replaced.

• Do not handle the charger or the

appliance with wet hands.

• Do not store or charge the appliance

outdoors.

• Unplug the charger before removing

the battery, cleaning or maintaining the

appliance.

Battery safety:

• This appliance includes Li-ion

batteries; do not incinerate batteries

or expose to high temperatures,

as they may explode.

• Liquid ejected from the battery may

cause irritation or burns.

• In an emergency situation contact

professional help immediately.

• Leaks from the battery cells can

occur under extreme conditions. Do

not touch any liquid that leaks from

the battery. If the liquid gets on your

skin wash immediately with soap

and water. If the liquid gets into your

eyes, ush them immediately with

clean water for a minimum of 10

minutes and seek medical attention.

Use gloves to dispose of the battery

immediately in accordance with local

regulations.

• Shorting the battery terminals may

cause burns or re.

• Store battery away from metal objects

that could connect the terminals.

• When you dispose of the appliance

remove the battery and dispose of the

battery safely in accordance with local

regulations.

Service:

• Before using the appliance and after

any impact, check for signs of wear or

damage and repair as necessary.

• Do not use the appliance if any part is

damaged or defective.

• Repairs should be carried out

by a service agent or a suitably

qualied person in accordance with

relevant safety regulations. Repairs

by unqualied persons could be

dangerous.

• Never modify the appliance in any

way as this may increase the risk of

personal injury.

• Only use replacement parts

or accessories provided or

recommended by Gtech.

Intended use:

• This appliance has been designed for

domestic dry sweeping only.

• Do not use on wet surfaces.

• Do not pick up anything that is

ammable, burning or smoking.

• Use only as described in this manual.

• Don’t use on concrete, tarmacadam or

other rough surfaces.

WARNING:

• Do not use water, solvents, or

polishes to clean the outside of the

appliance; wipe clean with a dry

cloth.

• Never immerse the unit in water and

do not clean in a dish washer.

Thank you for choosing a Gtech Power Sweeper

“I started Gtech to create sensible, easy to use products, which do a great job. Your opinion is

important to us. Please take the time to write a review of the Sweeper either on the website of

the store you bought it from or by emailing us at support@greytechnology.co.uk. We will use

your feedback to improve our products and services and let other people know what it’s like to

be part of the Gtech family.” Nick Grey – Inventor, Owner of Gtech

www.gtech.co.uk/warrantyregistration or call 08000 518353

Keep your receipt with this manual. You will need it if you ever have a warranty claim.

What’s in

the box

Sweeper

Upper Handle

Telescopic Handle Tubes

Lower Handle

Fast Charge Stand

Duster

Duster clip

The three parts of the telescopic handle

also click into place. The duster can be

clipped onto the back of the handle.

Assembly

Place the lower handle into the socket.

Push the locking clip back into place.

Push handle forward.

To assemble the lower handle

Pull out the locking clip.

Pull back the handle and press the “on”

button with your foot. When running, the

light shows green for a full charge, orange

for 20% charge and red for 10%. When

the sweeper needs recharging the light will

ash red and the sweeper will stop.

Remove the dust tray by pinching the

window slightly and pulling it out.

Normal operation

Push at over the oor.

Deeper cleaning

Lift the handle to lower the

brush bar into the carpet.

Tip the dirt into the bin. If you need to you

can wipe the tray clean with a dry cloth.

Operation

Emptying the bin

Remove the telescopic handle by pressing

the button at the front of the lower handle

and pulling the tube out.

The telescopic handle can now be

attached to the duster.

Remove the visor by unclipping the bottom

outer edges at the same time then lifting off.

Push lower handle fully forward.

Use on stairs, starting at the top and

front of each step then moving down and

towards you.

Removing telescopic handle and using duster

Handheld use and stair cleaning

Recharging

From time to time you may need to remove

hair and thread from the brush bar. Take off

visor and use a pair of scissors to remove

the hair.

Try to avoid carrying the sweeper ‘nose

down’ as you risk spilling dirt from the

dust tray.

Plug in the charge stand

and lower the sweeper onto it so that the

terminals connect at the back.

Clearing the brush bar Carrying

The 3 colour LED shows red when

charging starts, yellow when partially

charged and green when fully charged.

This will only take around 3 hours.

Product Care

Troubleshooting

Your Gtech sweeper doesn’t need much maintenance: empty the dust tray, remove hair

and bre from the brush bar and edge wheel and charge the battery. Wipe it with a dry

cloth if it gets dirty, including in and around the bin. Never wash it with liquid or run it

under a tap. Avoid cleaning over rug tassels or frayed carpets as this will tangle the brush

bar. The battery, drive belt, brush bar and side brush are all replaceable items.

If you nd you ever need to replace these items there is an FAQ section on our website at

www.gtech.co.uk

Sweeper is not cleaning well 1. Empty the bin.

2. Remove any build-up of hair from

brush bar and edge wheel.

Sweeper has stopped

or won’t work

1. Fully recharge for 3 hours.

If this doesn’t solve your problem don’t worry, we will help.

Go to www.gtech.co.uk or call 01905 345 891

The ecocharge stand has an efcient standby function to top up the battery when

needed. If not being used the product can be left on the charging stand so it will always

be fully charged until it is needed for use.

WARRANTY – TERMS AND CONDITIONS

Grey Technology has provided this sweeper with a 12-month guarantee.

In Guarantee:

Please retain your receipt as proof of purchase. In the rare and unfortunate event of your

Gtech product being faulty, please accept our apologies and we will aim to remedy the

problem as fast as possible once brought to our attention. However please be aware

that due to Company Policy, Grey Technology can only repair or replace all or part of the

product if proof of purchase is provided and the claim is made within 12 months of the

purchase date.

If your product is within the 12 months warranty period you should either return this product

with its receipt to the retailers where the product was purchased or if a simple part or advice is

required ring the Gtech Helpline where we will be more than happy to assist.

Note: Gtech cannot refund any monies if the product was brought from a third party.

Note: The battery is a consumable item and is not covered by this guarantee.

We would like to remind our customers that the Gtech guarantee does not cover any

unauthorised repairs and will be annulled:

• If the product has been damaged due to incorrect use or maintenance.

• If any part is modied or replaced or if it is used in any way that is not

recommended by Gtech.

• If it is used with any parts not produced or not recommended by Gtech.

• If it is used for purposes other than those specied by Gtech.

If after reading the manual and following the instructions you are sure that the product is

defective please call the Gtech Helpline on 01905 345891.

A Customer Service Advisor will be available to deal with any problems you have with our

product. To assist them please be ready with the product, a detailed description of the

problem, and your proof of purchase.

Out of Guarantee:

If your Gtech product is over 12 months old and you need any parts or advice then please

contact our Helpline. Parts will be sent out usually within 2 weeks of request.

Customer helpline 01905 345891

support@greytechnology.co.uk

www.gtech.co.uk
