GW Instek GPP-3650 Bedienungsanleitung

Programmable DC Power Supply

GPP-3060/GPP-6030/GPP-3650

User Manual

ISO-9001 CERTIFIED MANUFACTURER

This manual contains proprietary information, which is protected by

photocopied, reproduced or translated to another language without

prior written consent of Good Will company.

The information in this manual was correct at the time of printing.

However, Good Will continues to improve products and reserves the

rights to change specification, equipment, and maintenance

procedures at any time without notice.

Good Will Instrument Co., Ltd.

No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.

SAFETY INSTRUCTIONS

Table of Contents

SAFETY INSTRUCTIONS .................................................. 6

Safety Symbols........................................................... 6

Safety Guidelines ....................................................... 7

Power cord for the United Kingdom ......................... 10

Introduction............................................................. 12

Key Features ............................................................ 15

Front Panel .............................................................. 17

Rear Panel................................................................ 23

Constant Voltage/Constant Current Crossover

Characteristics ......................................................... 25

GETTING STARTED........................................................ 26

Start Up ................................................................... 27

Load Connection ...................................................... 28

Select front/rear panel output.................................. 30

Turning the Output On/Off ...................................... 31

BASIC OPERATION ........................................................ 32

Display Change ........................................................ 33

Source Function ....................................................... 36

Independent Output Mode ..................................... 41

Tracking Series and Tracking Parallel Modes......... 43

Load Function .......................................................... 48

Sequence Function ................................................... 52

Set Sequence Output............................................... 52

Set Group Parameter............................................... 55

Construct Templet................................................... 56

Menu Tree................................................................ 59

Save and Recall ........................................................ 61

Delay Function ......................................................... 64

GPP-3060/6030 User Manual

Set Delay Output ..................................................... 64

Set Group Parameter............................................... 67

Menu Tree................................................................ 70

Save and Recall ........................................................ 72

Monitor Function ..................................................... 75

Set Monitor.............................................................. 75

Recorder Function.................................................... 79

Set Recorder............................................................. 79

External I/O Control................................................. 83

Key Function Description ........................................ 84

FILE OPERATION ........................................................... 87

Save/Recall .............................................................. 88

Restore Factory Default Settings .............................. 91

SYSTEM SETTINGS ........................................................ 92

System Information ................................................. 93

System Settings ....................................................... 94

Firmware Upgrading ................................................ 96

Description of Using Flash Drive ............................. 97

REMOTE CONTROL ....................................................... 99

Connection Usage .................................................. 101

RS-232 ...................................................................... 102

USB .......................................................................... 104

GPIB......................................................................... 105

LAN .......................................................................... 107

Command Syntax ................................................... 113

Command List ....................................................... 117

Measurement Instructions...................................... 117

Display Functions .................................................... 117

Output Commands ................................................. 117

SAFETY INSTRUCTIONS

Source and Load Commands.................................. 118

Status Commands ................................................... 123

System Commands ................................................. 124

System Related Commands .................................... 125

IEEE488.2 Common Commands ............................ 126

Command Details .................................................. 127

Measurement Commands ...................................... 127

Display Commands ................................................. 129

Output Commands ................................................. 131

Source and Load Commands.................................. 136

Status Commands ................................................... 180

System Commands ................................................. 187

System Related Commands .................................... 196

SCPI Status Registers SCPI .................................... 197

Event Registers ........................................................ 199

Enable Registers ...................................................... 199

Status Byte Register................................................. 199

Standard Event Register .......................................... 201

Status Byte Register Commands............................. 202

Standard Event Register Commands...................... 203

Other Status Register Commands .......................... 205

Errors..................................................................... 206

Error Message.......................................................... 206

Command Errors ..................................................... 206

APPENDIX ....................................................................210

Replacing the Fuse ................................................. 210

Specifications ........................................................ 211

Optional Accessories ............................................. 214

Declaration of Conformity ...................................... 215

SAFETY INSTRUCTIONS

This chapter contains important safety

instructions that you must follow during

operation and storage. Read the following before

any operation to insure your safety and to keep

the instrument in the best possible condition.

Safety Symbols

These symbols may appear in the manual or on the instrument.

WARNING

Warning: Identifies conditions or practices that

could result in injury or loss of life.

CAUTION

Caution: Identifies conditions or practices that

could result in damage to the GPP or to other

properties.

DANGER High Voltage

Attention Refer to the Manual

Protective Conductor Terminal

Earth (ground) Terminal

Do not dispose electronic equipment as

unsorted municipal waste. Please use a

separate collection facility or contact the

supplier from which this instrument was

purchased.

SAFETY INSTRUCTIONS

Safety Guidelines

General

Guideline

CAUTION

Do not place any heavy object on the unit.

Avoid severe impact or rough handling that

leads to damaging the unit.

Do not discharge static electricity to the unit.

Do not block the cooling fan opening.

Do not perform measurements on circuits that

are directly connected to mains power.

Do not disassemble the GPP unless you are

qualified.

(Measurement categories) EN 61010-1:2010

specifies the measurement categories and their

requirements as follows. The GPP Series falls

under category I .

․Measurement category IV is for measurement

performed at the source of low-voltage

installation .

․Measurement category III is for measurement

performed in the building installation.

․Measurement category II is for measurement

performed on the circuits directly connected to

the low voltage installation.

․Measurement category I is for measurements

performed on circuits not directly connected to

Mains.

GPP-3060/6030 User Manual

(Pollution Degree) EN 61010-1:2010 specifies

pollution degrees and their requirements as

follows.Pollution refers to “addition of foreign

matter, solid, liquid, or gaseous (ionized gases),

that may produce a reduction of dielectric

strength or surface resistivity”. The GPP Series

falls under degree 2.

․Pollution degree 1: No pollution or only dry, non-

conductive pollution occurs. The pollution has no

influence.

․Pollution degree 2: Normally only non-conductive

pollution occurs. Occasionally, however, a

temporary conductivity caused by condensation

must be expected.

․Pollution degree 3: Conductive pollution occurs, or

dry, non-conductive pollution occurs which

becomes conductive due to condensation which is

expected. In such conditions, equipment is

normally protected against exposure to direct

sunlight, precipitation, and full wind pressure, but

neither temperature nor humidity is controlled.

Power Supply

WARNING

AC Input voltage range:

100V/120V/220V/230V ±10%

Frequency: 50Hz/60Hz

To avoid electrical shock connect the protective

grounding conductor of the AC power cord to

an earth ground.

Fuse

WARNING

Fuse type: 100V/120V：T12A/250V，

220V/230V：T6.3A/250V

To prevent fire, replace the fuse only with the

specified type and rating.

Disconnect the power cord before replacing the

fuse.

Make sure the cause of fuse blowout is fixed

before replacing the fuse.

SAFETY INSTRUCTIONS

Cleaning the

power supply

Disconnect the power cord before cleaningit .

Use a soft cloth dampened in a solution of mild

detergent and water. Do not spray any liquid

into it.

Do not use chemicals containing harsh products

such as benzene, toluene, xylene, and acetone.

Operation

Environment

Location: Indoor, no direct sunlight, dust free,

almost non-conductive pollution (Note below)

Relative Humidity: < 80%

Altitude: < 2000m

Temperature: 0°C to 40°C

Storage

environment

Location: Indoor

Relative Humidity: < 70%

Temperature: -10°C to 70°C

GPP-3060/6030 User Manual

Power cord for the United Kingdom

When using the power supply in the United Kingdom, make sure

the power cord meets the following safety instructions.

NOTE: This lead/appliance must only be wired by competent persons

WARNING: THIS APPLIANCE MUST BE EARTHED

IMPORTANT: The wires in this lead are coloured in accordance with the

following code:

Green/ Yellow:

Earth

Blue:

Neutral

Brown:

Live (Phase)

As the colours of the wires in main leads may not correspond with

the coloured marking identified in your plug/appliance, proceed as

follows:

The wire which is coloured Green & Yellow must be connected to

the Earth terminal marked with either the letter E, the earth symbol

or coloured Green/Green & Yellow.

The wire which is coloured Blue must be connected to the terminal

which is marked with the letter N or coloured Blue or Black.

The wire which is coloured Brown must be connected to the

terminal marked with the letter L or P or coloured Brown or Red.

If in doubt, consult the instructions provided with the equipment or

contact the supplier.

This cable/appliance should be protected by a suitably rated and

approved HBC mains fuse: refer to the rating information on the

equipment and/or user instructions for details. As a guide, a cable

of 0.75mm2should be protected by a 3A or 5A fuse. Larger

conductors would normally require 13A types, depending on the

connection method used.

Any exposed wiring from a cable, plug or connection that is

engaged in a live socket is extremely hazardous. If a cable or plug is

deemed hazardous, turn off the mains power and remove the cable,

any fuses and fuse assemblies. All hazardous wiring must be

immediately destroyed and replaced in accordance to the above

standard.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere GW Instek Stromversorgung Handbücher

GW Instek

GW Instek ASR-2000 Series Bedienungsanleitung

GW Instek

GW Instek SPS-1230 Bedienungsanleitung

GW Instek

GW Instek PSW Series Betriebsanleitung

GW Instek

GW Instek GPS-2303 Bedienungsanleitung

GW Instek

GW Instek PSP-603 Bedienungsanleitung

GW Instek

GW Instek PEL-3000AH Series Bedienungsanleitung

GW Instek

GW Instek PFR-100MGP Bedienungsanleitung

GW Instek

GW Instek GPD-2303S Bedienungsanleitung

GW Instek

GW Instek PSW-Multi Series Bedienungsanleitung

GW Instek

GW Instek PSW 30-36 Bedienungsanleitung

GW Instek

GW Instek PPH-1503 Bedienungsanleitung

GW Instek

GW Instek PPX Series Bedienungsanleitung

GW Instek

GW Instek GPP-3323 Bedienungsanleitung

GW Instek

GW Instek GPD-3303 Series Bedienungsanleitung

GW Instek

GW Instek ASD Series Bedienungsanleitung

GW Instek

GW Instek PRP Series Betriebsanleitung

GW Instek

GW Instek GPP-1326 Bedienungsanleitung

GW Instek

GW Instek PSS-3203 Bedienungsanleitung

GW Instek

GW Instek PST Series Bedienungs- und Wartungshandbuch

GW Instek

GW Instek PFR-100 Series Betriebsanleitung

GW Instek

GW Instek GPP-3060 Bedienungsanleitung

GW Instek

GW Instek PSP-603 Bedienungsanleitung

GW Instek

GW Instek SPD-3606 Bedienungsanleitung

GW Instek

GW Instek PSB-2000 series Bedienungsanleitung

Beliebte Stromversorgung Handbücher anderer Marken

Monacor

Monacor PS-12CCD Bedienungsanleitung

VOLTIMA

VOLTIMA MagicBox 15 Bedienungsanleitung

Agilent Technologies

Agilent Technologies 6032A Bedienungsanleitung

Miller

Miller Auto Deltaweld 452 Bedienungsanleitung

BCP

BCP PUOUBK Merkblatt

HC 2210 Bedienungsanleitung

Puls

Puls CT5.241 Bedienungsanleitung

OCZ

OCZ ZX1250W Bedienungsanleitung

iseg

iseg ECH 238 Bedienungsanleitung

Power

Power XXL A Series Bedienungsanleitung

Agilent Technologies

Agilent Technologies 6631B Bedienungsanleitung

Renogy

Renogy PHOENIX 300 Bedienungsanleitung

HP 6200B Service-Handbuch

Epson

Epson Stylus Scan 2500 Betriebsanleitung

Pulsar

Pulsar GREEN POWER CCTV PoE POE044816 Bedienungsanleitung

Puls

Puls MiniLine ML50.100 Bedienungsanleitung

Puls

Puls AS-Interface SLA4.100 Bedienungsanleitung

Kenwood

Kenwood PS-60 Bedienungsanleitung
