H2oLabs 300CG Bedienungsanleitung

One Gallon Glass Carafe

Instruction Manual

H2oLabs Model 300CG

SAFETY INSTRUCTIONS - Read Before Assembly

▲CAUTION: Always handle the glass Carafe with care to avoid

breakage and possible injury.

▲Discontinue use of the Carafe if it is cracked or chipped. Ordinary

imperfections in the glass such as bubbles, are completely normal and

not a cause for concern.

▲Broken glass should be carefully collected and placed into a rigid box

or container so it can be handled and disposed of properly without

injury.

▲Follow Assembly Instructions accurately to ensure safety. An

improperly assembled glass Carafe could cause damage to it or result in

personal injury.

▲Place a towel on the table surface underneath the Carafe to prevent

sliding or damage during assembly or while cleaning.

▲When using Carafe, use both hands for proper support.

▲When setting Carafe on any hard surface, (especially when full), take

care to rest it gently on the surface to avoid damage.

- 2 -

CARAFE ASSEMBLY INSTRUCTIONS

Only tool required: Phillips (Cross-Head) Screwdriver, (not included)

Note: Please use caution when handling the glass Carafe.

1. Remove all parts from the

protective Styrofoam. Do not

assemble if the Carafe is

cracked or chipped.

2. Check Styrofoam packaging to locate all parts as specified below:

Handle

Handle Cover

Lid

Nozzle with Glass Insert, (Activated Carbon Sachet Housing)

Glass Carafe with 2-Stainless Steel Straps and 2-Phillips, (cross-

head), screws attached.

- 3 -

3. Use the Styrofoam as an

assembly platform. Place the

Carafe spout facing down and the

screws facing up.

4. Remove the screws and peel off

the blue protective film from the

stainless steel straps.

5. Align the right-hand side of the screw

holes to the black reference line on the

Carafe.

6. Position the Handle over the 2

screw holes and align it with the

black reference line along the right

edge of the handle.

- 4 -

7. Insert the top screw first using a Phillips,

(cross-head), screwdriver. Turn the screw

until barely snug. Do not tighten yet.

8. Insert the lower screw next and turn it till

barely snug. Move the handle to the right a

little so that the black reference line is just

covered evenly by the handle edge.

9. While making sure

the handle is vertically

aligned with the black

reference line, tighten

both screws. The

handle should be

opposite the spout. If

necessary, loosen the

screws to re-adjust.

10. Lift the Carafe by the handle a few inches

above table surface and GENTLY shake the

Carafe to verify that the handle is securely

assembled. Tighten the screws more if the

handle feels loose.

- 5 -

11. Clip the Handle Cover onto

the Handle. Push it all the way in.

12. Wash the Carafe thoroughly prior

to use with a couple drops of dish soap

and warm water and rinse well. Place

the lid on the Carafe with the opening

facing the spout. The Carafe is now

ready to use.

Always handle the glass Carafe carefully and set it gently on hard

surfaces as it is breakable.

Since the Carafe is heavy when full,

(approx. 9 lbs.), it should be lifted

and carried with both hands. One

hand should be holding the handle

and the other hand supporting the

bottom of the Carafe. An easy way

to pour from a full Carafe is to

allow it to rest on the counter-top,

(thereby supporting the weight),

while tilting it to fill a drinking

glass, etc.

- 6 -

NOZZLE AND GLASS INSERT

1. Carefully remove the Glass Insert from the Nozzle and gently wash,

rinse and dry both parts. (It may be helpful to use a small flat head

screwdriver to release the retaining tab.) Reinsert the Glass Insert back

into the Nozzle.

Should the Glass Insert break, replacements are available. However it is

perfectly acceptable to continue using the distiller without the Glass

Insert as the Nozzle is made from safe, food-grade material.

2. Install the Nozzle onto the

water outlet spout on the

head of the unit. Insert the

two raised edges of the

Nozzle into the two slots

under the Distilled Water

Outlet.

3. Line up the Nozzle outlet with

the spout of the Glass Carafe to

collect the distilled water.

Position the Carafe accurately so

that water will not drip on the

side of the Carafe or onto the

countertop.

- 7 -

It is not necessary to remove or clean the Nozzle

until it is time to replace an Activated Carbon

Sachet. When removing the Nozzle, press the top

side tabs carefully and tilt out of the slots. It may

be helpful to use the small flat head screwdriver

to push the Nozzle tabs in to release them from

the slots and remove the Nozzle easily. If using a

screwdriver, be careful not to enlarge or damage

the slots.

To order Activated Carbon Sachets, Cleaning Crystals,

parts and accessories, or for information on High Capacity

Automatic Units and other helpful products or information ...

Visit www.H2oLabs.com

or Call 1-800-990-3560

(Monday through Friday 8:00 AM to 5:00 PM Central time.)
