Hagie UpFront 120 Bedienungsanleitung

ANY PICTURES CONTAINED WITHIN THIS OPERATOR'S MANUAL THAT

DEPICT SITUATIONS WITH SHIELDS, GUARDS, RAILS, OR LIDS REMOVED

ARE FOR DEMONSTRATION ONLY. HAGIE MANUFACTURING STRONGLY

URGES THE OPERATOR TO KEEP ALL SHIELDS AND SAFETY DEVICES IN

PLACE AT ALL TIMES.

HAGIE MANUFACTURING COMPANY

OPERATOR’S MANUAL

FOR

HAGIE 120ft BOOM

COVERS 120ft BOOM ATTACHMENT OPTION NUMBERS: U61510

721 CENTRAL AVENUE WEST

BOX 273

CLARION, IOWA 50525-0273 (515) 532-2861

07-09 493487

Congratulations on your selection of a Hagie Model 120ft Boom. We recommend

that you study this Operator’s Manual and become acquainted with the adjustments and

operating procedures before attempting to operate your new sprayer. As with any piece

of equipment, certain operating procedures, service, and maintenance are required to

keep it in top running condition.

We have attempted herein to cover all of the adjustments required to fit varying

conditions. However, there may be times when special care must be considered.

Hagie Manufacturing Company reserves the right to make changes in the design and

material of any subsequent sprayer without obligation to existing units.

We thank you for choosing a Hagie sprayer and assure you of our continued interest

in its satisfactory operation for you. If we might be of assistance to you, please call us.

We are proud to have you as a customer.

A WORD FROM HAGIE MANUFACTURING COMPANY

INTRODUCTION

TO THE OPERATOR:

The following pages and illustrations will help you operate and service your new 120ft boom attach-

ment. It is the responsibility of the user to read the Operator’s Manual and comply with the safe correct

operating procedures and lubricate and maintain the product according to the maintenance schedule.

The user is responsible for inspecting the attachment and having parts repaired or replaced when

continued use of the product causes damage or excessive wear to other parts.

Keep this manual in a convenient place for easy reference when problems arise. This manual is

considered a permanent fixture with this fixture. In the event of resale, this manual should accompany the

boom. If you do not understand any part of the manual or require additional information or service,

contact the Hagie Customer Support Department:

Hagie Manufacturing Company

721 Central Avenue West

Box 273

Clarion, Iowa 50525-0273

(515) 532-2861

INTRODUCTION

This symbol indicates a hazardous situation which,

if not avoided, will result in death or serious injury.

This symbol indicates a potentially hazardous

situation, which if not avoided, could result in death

or injury.

This symbol indicates a potentially hazardous

situation which, if not avoided, may result in minor

or moderate injury. It may also be used to alert

against unsafe practices.

The following symbols, found throughout this manual, alert you to situations that could be po-

tentially dangerous conditions to the operator, service personnel, or the equipment.

iii

Table of Contents

Introduction ....................................................................................................................................................... i-ii

Table of Contents .............................................................................................................................................. iii

Safety.............................................................................................................................................................05-1

Decals ............................................................................................................................................................10-1

Specifications.................................................................................................................................................15-1

Operator’s Station..........................................................................................................................................20-1

MD3 ..............................................................................................................................................................25-1

The Boom ......................................................................................................................................................30-1

Operating Instructions....................................................................................................................................35-1

Norac Operating Instructions.........................................................................................................................40-1

Quick-Tach System .......................................................................................................................................45-1

Calibration......................................................................................................................................................50-1

Norac Calibration ...........................................................................................................................................55-1

Transporting...................................................................................................................................................60-1

Service ..........................................................................................................................................................65-1

Storage ..........................................................................................................................................................70-1

Troubleshooting .............................................................................................................................................75-1

Warranty ........................................................................................................................................................80-1

Index ..............................................................................................................................................................85-1

Most accidents occur as the result of failure to

follow simple and fundamental safety rules. For this

reason, most accidents can be prevented by recog-

nizing the real cause and doing something about it

before the accident occurs.

Many conditions cannot be completely safe-

guarded against without interfering with efficient

operation and/or reasonable accessibility. Therefore,

you must study this Operator’s Manual and learn how

to use the attachment safely. Likewise, do not let

anyone operate without instruction.

Do not make modifications such as weldments,

add-ons, adaptations, or changes from the original

design of attachment. Such changes and/or

modifications may become safety hazards to you and

to others and will void all warranties.

Replace missing, faded, or damaged safety

signs. See the operator’s manual for correct sign and

placement.

Reference to right hand and left hand used

throughout this manual refers to the position

when seated in the operator’s seat facing

forward.

SAFETY

05-1

The purpose of this manual is to guide you in operating the 120ft boom. Please be sure to read this man-

ual along with the sprayer’s manual and all other manuals that are included with the machine. This man-

ual is only intended to cover the 120ft boom attachment and any differences in the operation of the

sprayer’s controls. It will not give complete instruction on the operation of the basic functions that are al-

ready discussed in the sprayer’s manual.

Operating Sprayer Booms

• Cradle booms when leaving sprayer unat-

tended.

• Make sure booms are folded when cradled.

• Select a safe area before unfolding booms.

Avoid power lines and overhead structures.

SAFETY

General Safety

• The hydraulic and electrical control systems

are optimizes for use with this attachment.

Any modification to these systems may lead

to unintended or uncontrolled motion. DO

NOT install add-on control systems that are

not approved by Hagie Manufacturing Com-

pany.

• Some conditions can not be completely safe-

guarded against without interfering with effi-

cient operation of the machine and/or reason-

able accessibility. In these cases decals have

been installed to provided the operator with

information on the hazard. DO NOT remove

the decals for any reason. If a decal is dam-

aged, contact Hagie Customer Support De-

partment for a replacement.

05-2

SAFETY

05-3

Boom Leveling System

• Unplug all cylinder sensors before welding on

the machine or boom.

Wear Protective Clothing

• Do not wear loose fitting clothes that could

get caught in moving parts. Wear safety

equipment that is appropriate for the job.

• Do not store chemical soaked clothes in the

cab. Clean off as much mud and dirt from

your shoes as you can before entering the

cab.

Safe Hydraulic Maintenance

• Always practice personal safety when per-

forming service or maintenance on the hy-

draulic system.

• Use caution when working with hydraulic fluid

under pressure. Escaping fluid can have suffi-

cient force to penetrate your skin causing se-

rious injury. This fluid may also be hot

enough to burn.

• Always lower the load or relieve the pressure

before repairing a hydraulic oil leak.

SAFETY

Avoid Heating Near Pressurized Lines

• Avoid torching, welding, and soldering near

pressurized hydraulic lines. Pressurized lines

may accidentally burst when heat goes be-

yond the immediate flame area.

Be Prepared

• Be prepared for an emergency. Keep a fire

extinguisher handy. Keep a first aid kit and

clean water in the cab also.

• Make sure to service the fire extinguisher

regularly. Keep an accurate inventory of sup-

plies in the first aid kit and dispose of any-

thing that has expired.

General Repair/Maintenance Safety

• Turn off sprayer engine before checking, ad-

justing, repairing, lubricating, or cleaning any

part of the attachment.

• Disconnect the battery ground cable and turn

the main battery switch off before servicing

electrical system or welding on attachment.

05-4

SAFETY

05-5

Handle Agricultural Chemicals Safely

Agricultural chemicals used in applications can be

harmful to your health and the environment if not

used carefully.

• Always follow the manufacturer’s label direc-

tions for use.

• Never allow chemicals to come in contact

with your skin or eyes.

• Never pour chemicals into an empty tank, fill

tank half full of water first.

• Dispose of empty chemical containers prop-

erly.

• Wash spilled chemicals or spray residue from

the sprayer to prevent corrosion and deterio-

ration.

• Select a safe area to fill, flush, calibrate, and

clean sprayer where chemicals will not run off

to contaminate people, animals, vegetation,

or water supply.

• Never place a spray nozzle to your lips in an

attempt to unclog it.

• Do not spray when wind is in excess of

chemical manufacturer’s recommendation.

• Store chemicals in their original containers

with the label intact.

• Store chemicals in a separate, locked build-

ing.

• Wear protective equipment as recommended

by chemical manufacturer.
