User Guide of M1121 Phone

1. Phone Introduction

1.1 Keypad Area

There are 23 keys on keypad of this phone, which can be divided into two parts:

•Number/letter area, total 12 keys

•Control keys area, total 11 keys

1.1.1 Number/letter key

Number/letter area consists of 12 keys, which arranges according to definite standard,

and includes [0]~[9], [*] and [#].

Keys in keypad area allows users input numbers or characters, according to different

screen environment, same key can produce different key value, which is shown as following

table:

Multi-Tap Number

(Dialing)

Keypad

Label Capital letter

ABC

Small letter

abc

Short

press

Long

press

Password Tim

e Counter

1 Blank 1@_#=

<>()&£$¥

Blank

1@_#=

<>()&£$¥

1 1 1 1 1

2ABC ABC2AÄÅÆç abc2àäåæç 2 2 2 2 2

3DEF DEF3ÉE　　 def3éè　　 3 3 3 3 3

4GHI GHI4　　 ghi4 ì　4 4 4 4 4

5JKL JKL5　jkl5　5 5 5 5 5

6MNO MNO6ÑòÖØ mno6ñòöø 6 6 6 6 6

7PQRS PQRS7ß　　　 pqrs7ß　　

　7 7 7 7 7

8TUV TUV8Üùtuv8üù 8 8 8 8 8

9WXYZ WXYZ9　　　 wxyz9　　

　9 9 9 9 9

0 .0/”’?!,:;¡¿*+-%

.0/”’?!,:;¡¿

*+-% 0 . 0 0 0

* Switching input

mode

Switching

input mode * +

Press and hold for a

long time: switching

capital and small

mode

Press and hold for a

long time: input

symbols

Press and hold

for a long time:

switching

capital and

small mode

Press and hold

for a long time:

input symbols

# wp .

1.1.2 Control key

[On/Off]:

Right red key at keypad area, also called red key or power key.

•Press and hold the key for a long time to turn on the phone when it is off.

•Press and hold for a long time under state to turn off the phone when it is on.

•Press and hold for a short time under menu and edit state to return stand-by menu.

•Press the key to end current call during the call.

•Press the key to reject answering when you receive a call.

[PickUp]:

Left green key at keypad area, also called green key or send key. Press the key to answer

call or dial phone number.

[SKL] and [SKR]

[SKL] is at left and upper area of keypad, and [SKR] is at right and upper area of key pad.

They usually have different functions corresponding to the functions indicated at SK hint

area of lower menu according to different definition of program.

Direction key: includes up, down, left and right four keys.

[Up] and [Down]:

•Turn over page to display stand-by character in editor.

•Scroll screen up and down.

•Turn over page on stand-by row under Pinyin and Bihua input state.

•Browse short message or other long text message.

•Turn to last and next picture when previewing pictures.

Note: [Up] and [Down] keys have automatic repeating function; if we press and hold

one key of them for a long time, it is equal to press the key for many times. It means that when

the time you press the key exceeds preset time, phone starts the automatic repeating function

of the key. Interval for automatic repeating has been preset, and you can’t change it.

[Left] and [Right]:

•Move cursor to left and right in editor.

•Move selected words or pin combination under pinyin and bihua input states

•Browse main menu

•Turn to last and next picture when previewing pictures

[OK]

In the middle of four direction keys, also called middle key. It is ok key in default.

Up/down keys on side

•Press and hold for a short time to answer the call when you receive a call and when

phone cover is closed and earphone is inserted.

•Press and hold for a long time when you receive a call to stop ring, vibration and

shining of background light when phone cover is closed, nor matter if earphone is

inserted.

•Press and hold for a long time to hang up current call in call state when phone cover

is closed and earphone is inserted.

•Press and hold for a short time to adjust volume of headphone or earphone during

call.

•Press and hold for a long time to stop ring and vibration when you receive a call no

matter if earphone is inserted.

1.1.3 Key operation under stand-by state

When screen displays stand-by menu, you can.

•Press [PickUp] to enter dialed phone list.

•Press [OK] to enter WAP.

•Press [Up] to enter message.

•Press [Down] to enter STK.

•Press [Left] to visit Phonebook.

•Press [Right] to enter camera.

•Press [SKL] to enter calllist.

•Press [SKR] to enter phonebook menu.

•Input phone number directly by digit number, then dial phone and enter relevant option

menu.

•Use hotkey, which should be customized. (Refer to hotkey setup).

1.1.4 Key operation without SIM card

•Press [OK] to enter first level menu.

•Pres [SKR] to enter SOS.

1.2Display

The phone has single liquid crystal display, graphic area of the display is 128（width）×160

（Height）pixels, can display 64K colors and takes CSTN technology.

Following icons can only be displayed under stand-by state, used to display current state

of phone, such as electricity, network signal and etc.

Icon Name of icons Description

Battery Display energy of battery, there is five battery indicator levels. The icon

scrolls during charge process.

Network

Nework icon is divided into two parts, left part indicates if it register in

network, left part indicateds signal strength, which is divided into five

levels (from no signal to strongest signal).

Roam When phone regesters in network outside home network, display the icon .

Otherwise don’t display the icon.

Home network When phone registers in home network, display the icon. Otherwise

don’tdisplay the icon. (The function needs network support)

If logon GPRS Display when GPRS network exist and phone logon GPRS, otherwise

nodisplay. (The function needs network support)

MMS

Above two icons show at least one MMS is not read now in message list

and MMS memory is full respectively. If there is unread MMS and

MMS memory is also full, only display the full icon.

Message

Above icons shown there is at least one message that is not read now in

message list and message memory is full respectively. If there is unread

MMS and MMS memory is also full, only display the full icon.

Voicemail Shows there are untreated voicemails

Alarm clock Shown alarm clock is enabled.

Vibration Shows phone will vibrate when receiving a call.

Call transfer Shows call transfer function is enabled.

Silent Shows silent function is enabled.

No answer Shows no answer function is enabled.

Only answer Shown answer function is enabled.

Stand-by screen event

¾Unansowered call: when there is unreceived call indication, you press [OK] to see it and

press [On/Off] to enter stand-by state. Once exit, there is no new indication any more.

¾New message: when phone receives new messages or MMS it displays them on stand-by

screen, you can press [OK] to see it and press [On/Off] to enter stand-by state. Once exit,

there is no new indication any more.

¾Notepad prompt: priority is the lowest, once there are incidents with high priority, there is

only prompt sound and no pictures displayed, the prompt pictures will be displayed when

you quit other event. Press [OK] to see it and press [On/Off] to enter stand-by screen.

Dial dialed number

Pess [PickUp] on stand-by screen, phone displays the list of dialed number. You can use

[Up]/[Down] to select one of them and press [PickUp] to dial the number directly.

1.3 Install and remove battery

Install battery

1. Back of phone face upwords, hold phone, see from the direction of phone back,

thereisa opening at side of phone, move outside at the opening to remove back cover of

phone.

2. Aim positive and negative metal sheet on battery at four metal sticks in battery slot

ofphone;

3. Push batter to phone and press it until it is locked.

4. Cover back cover (aim arc side of back cover at arc side of phone and press the two

corner of straight side tightly).

Remove battery

Move small regular handle at left of bottom of battery and pull it outside to separate

battery from phone, then remove it.

1.4 Install and remove SIM card

Install SIM card

Purchase SIM cards from your network service provider. Your phone number and user

your phone number and register information is invariable.

· Confirm phone is turned off

· Turn phone back upwords, hold phone, see from the back of phone, there is a opening at side

of phone, move outside at the opening to remove back cover of phone.

· Remove battery of phone.

· Make metal side of SIM card toward down (facing phone), bevel of SIM card is at left-up

corner, insert the SIM card into slot flatly.

· Push inside flatly until it reaches the end.

· Install battery

· Cover back cover (aim arc side of back cover at arc side of phone and press the two corner of

straight side tightly).

Remove SIM card

· Remove back cover and battery of phone after it is turned off.

· Press SIM card with finger and pull it out flatly.

· Remove SIM card.

· Install battery and cover the back cover.

1.5 Battery charge

· Plug the pin charger into 220AC power socket.

· Plug adapter of charger into the interface at the bottom of the phone (the side with arrow sign

up), plug adapter into interface socket.

· When phone is turned on, battery stick in battery icon on screen start to scroll, which showsn

that mobile is in charging state. When phone is charged under off state, screen will display

charging act.

·After charging is complete, battery icon stops to scroll, and now you can take it out from phone

interface.

Note: the only way to stop charging when charging starts is to plug charger out, please try to use

power socket which is convenient for plug in and plug out.

1.6 SAR

The SAR limit of USA (FCC) and Canada (IC) is 1.6 W/kg averaged over one gram of tissue.

Device types M1211 has also been tested against this SAR limit. The highest SAR value reported

under this standard during product certification for use at the ear is 0.273 W/kg and when properly

worn on the body is 0.433 W/kg. This device was tested for typical body-worn operations with the

back of the handset kept 1.5cm from the body. To maintain compliance with FCC RF exposure

requirements, use accessories that maintain a 1.5cm separation distance between the user's body

and the back of the handset. The use of beltclips, holsters and similar accessories should not

contain metallic components in its assembly. The use of accessories that do not satisfy these

requirements may not comply with FCC RF exposure requirements, and should be avoided.

1.7 Accessories

The M1211 phone support below accessories, they are only optional, you can buy from your

vendor.

Headset.

USB cable.

2. Function introduction

2.1 Turn on

Turn on power

Usually press and hold [On/Off] to turn on the phone.

During the process of on act, press any key to stop playing the act and enter next

operation.

Please plug USB cable into phone when phone is off or when you confirm phone is

turned on, don’t plug USB cable into phone when it is being turned on to avoid to affect the

play of MIDI.

Input PIN code

To avoid others randomly to use your SIM card, you can setup protection password (PIN

code). After it is set, phone will ask you to input PIN code firstly when phone is turned on.

zInput PIN code. (For secrect, * is used to substitute input number on screen.)

zPress [OK], phone confirms PIN code is correct, and starts to register on network.

Once network name appears on screen, you can dial or answer call. If there is no network

name, it needs register newly.

Note: SIM card will be locked if worng PIN code is input for three times continuously. In

this case, please contact with SIM card provider.

2.2 Trun off

Turn off power

Press and hold [On/Off] for a long time in any situation to turn off phone power.

2.3 Dial number

•This function can be used only after network name displays on screen.

•Input phone number.

•Press [PickUp] to dial directly; or enter option menu, select dial or IP dial. The

function of Dial is completely same as [PickUp]. If you select IP dial and has input IP

number in phonebook menu (such as IP service number of China Mobile is 17951),

phone will automatically add the service number in fron of the number you input then

dial, if no IP service number is input, it will ask you to input the service number.

Stop call

You can press [Stop] or [On/Off] to stop call. Fold phone up also can stop call.

Dial up international long distance

•Press and hold [*] until + appear on screen.

•Input country number.

•Input section number (it usually doesn’t include front 0) and phone number.

•Press [PickUp] to dial directly; or enter option menu, select dial or IP dial.

Dial two phones at the same time (need network support)

You can set current call in holding state and dial another phone at the same time:

•Use Call menu to set current call in holding state. Enter phonebook and select a

number, or input the number from keypad directly.

•Press [Dial] soft key or [PickUp] to dial

Switch call (need network support)

If phone now receives two calls at the same time, one is in holding state and the other is in

active state, you can use call menu to swith between two calls.

2.4 Answer call

Answer call

Press [Answer] soft key or [PickUp] to answer.

Reject call

Press [Reject] soft key or [On/Off] to reject call.

Answer for second call (need network support)

If phone set call waiting function, it will give a prompt when there is a second call, here

you can:

•Set current call in holding state and answer for second call.

•Press [On/Off] to stop current call then take usual operation to answer for or reject

second call.

2.5 Input method

The phone uses T9 input method.

You often need to input text message when using phone. Such as, name in phonebook,

nickname of QQ book, SMS and QQ message text, test in notebook, grouping name and etc.

There are four different input modes, which is shown as following:

•T9 spanish(T9spa/T9Spa):allow to use T9 spanish;

•T9 English (T9eng/T9Eng): allow to use T9 english;

•Multi-Tap（abc/ABC）：press the key including the letters you need, first letter will be

displayed when you press the key for first time, press twice quickly to display second

letter on the key, the rest may be deduced by analogy to display required letter on

screen.

•Number (123): allow to input number;

Switch input mode

After open a editor, press [*] to switch input mode. Press [*] repeatly to switch

circulately between four input modes.

Note: when enter editor,the default input method id ABC.

Switch capital and small English/Spanish

In English editor, press [*] can switch capital and small English.

In Spanish editor,press [*] can switch capital and small Spanish.

Input symbol

In any input mode, press [*] (in English/Spanish input mode, you need to press and hold [#]

for a long time) tow switch symbol input screen. Press corresponding number at left of

symbol to input symbol and return orginal input mode automatically. If number of symbols is

more than one screen, press [Up]/[Down] to turn.

Delete operation

When input row is non-empty, press [SKR] will delete the rightest character or symbol in

the row firstly. At the same update the content of stand-by row until whole input row is

delected. Press and hold [SKR] will clear input rows.

When stand-by row is non-empty and input row is blank, press [SKR] will clear content

in stand-by row firstly.

When input row and stand-by row all are blank, press and hold [SKR] for a short time

will delete the character at left of cursor in text area. If there is no character at left of cursor,

delete right character. Press and hold [SKR] for a long time will delect all content in text area.

When text row is blank, press [SKR] to exit current editor and return fore state.

2.5.1 T9 Spanish（T9spa/T9Spa）

To every letter of Spanish words to be input, only need press corresponding

number key with ti once without needing the arrangement of the letter on the key.

Input row will automatically display possible letter combination (maybe many kinds

Inhaltsverzeichnis

Andere Haier Handy Handbücher

Haier

Haier B8305 Bedienungsanleitung

Haier

Haier HaierPhone G31 Bedienungsanleitung

Haier

Haier C300 Bedienungsanleitung

Haier

Haier Z160 Bedienungsanleitung

Haier

Haier C3010 Bedienungsanleitung

Haier

Haier C5000 Bedienungsanleitung

Haier

Haier CG300 Montageanleitung

Haier

Haier C2040 Bedienungsanleitung

Haier

Haier HM-G552-FL Bedienungsanleitung

Haier

Haier W757 Bedienungsanleitung

Haier

Haier W858 Bedienungsanleitung

Haier

Haier HG-M161 Bedienungsanleitung

Haier

Haier M1000 Bedienungsanleitung

Haier

Haier HaierPhoneG11 Bedienungsanleitung

Haier

Haier Y-716 Bedienungsanleitung

Haier

Haier I70 Bedienungsanleitung

Haier

Haier C710 Bedienungsanleitung

Haier

Haier D2100 Bedienungsanleitung

Haier

Haier Z360 Bedienungsanleitung

Haier

Haier P-867 Bedienungsanleitung

Haier

Haier I50 Bedienungsanleitung

Haier

Haier A70 Bedienungsanleitung

Haier

Haier V700 Bedienungsanleitung

Haier

Haier M170 Bedienungsanleitung

Beliebte Handy Handbücher anderer Marken

Zte

Zte BLADE A520 Bedienungsanleitung

Nokia

Nokia Lumia 620 Bedienungsanleitung

Blackbe;rry

Blackbe;rry KEYone Bedienungsanleitung

Bea-fon

Bea-fon X5 Premium Bedienungsanleitung

Blackbe;rry

Blackbe;rry 8707 Series Bedienungsanleitung

Blackbe;rry

Blackbe;rry Storm Betriebsanleitung

LG LM-X420QN Bedienungsanleitung

LifeWatch

LifeWatch V Bedienungsanleitung

Bea-fon

Bea-fon SILVER LINE SL860 Bedienungsanleitung

IKI Mobile

IKI Mobile KF4.5i Bedienungsanleitung

Hitech

Hitech HT-850 Bedienungsanleitung

Yezz

Yezz Fashion F10 Bedienungsanleitung

Point Mobile

Point Mobile PM60 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Q10 Bedienungsanleitung

Blackbe;rry

Blackbe;rry Bold 9900 Bedienungsanleitung

Blackbe;rry

Blackbe;rry STORM 9500 - VERSION 5.0 Bedienungsanleitung

LG LM-K420EMW Bedienungsanleitung

ISAFE MOBILE

ISAFE MOBILE IS655.2 Bedienungsanleitung
