Hamilton Khaki Field Multi-Touch Bedienungsanleitung
03/04
Khaki Field
Multi-Touch
Minutes hand
Minutenwijzer
Aiguille des minutes
Lancetta dei minuti
Minutenzeiger
Hour hand
Urenwijzer
Aiguille des heures
Lancetta delle ore
Stundenzeiger
+ correction / CHRONO
+ correctie / CHRONO
Correction + / CHRONO
Regolazione + / CHRONO
Korrektur + / CHRONO
Activation - validation
Activeren - valideren
Activation - validation
Attivazione - conferma
Aktivierung - Freigabe
- correction / CHRONO
- correctie / CHRONO
Correction - / CHRONO
Regolazione - / CHRONO
Korrektur - / CHRONO
Scratch-resistant sapphire tactile glass
Krasvast saffier aanaakglas
Glace tactile saphir inrayable
Vetro tattile zaffiro antigraffio
Sensor Saphirglas
Digital display
Digitaal display
Affichage digital
Visualizzazione digitale
Digitalanzeige
Thermometer
Meteo
Altimeter
Select mode
Chronograph
Compass
Alarm
Page Bladzijde
ENL F I D
9
14
6
10
12
13
15
31
36
28
32
34
35
37
53
58
50
54
56
57
59
75
80
72
76
78
79
81
97
102
94
98
100
101
103
Page
Aanraakzone
Tactile area
Zone tactile
Zona tattile
Sensorbereich
SeitePagina
User manual
Handbediening
Mode d’emploi
Modalità d’uso
Bedienungsanleitung
2
24
46
68
90
32
2"
2"
Replacing the battery
Type: Renata CR 1632
Care and maintenance
We recommend that you clean your watch regularly using a soft cloth and lukewarm water.
After bathing in salt water, rinse your watch with fresh water and leave it to dry completely.
Avoid exposing your watch to excessive variations in temperature or humidity, to strong
sunlight or strong magnetic fields.
• Incorrect operation of the pushers = different alarm from the normal beep
• No operation for 30 seconds = automatic deactivation of the glass
• No operation for 3 seconds in setting mode = exit setting mode
Touching action
(without pressing)
Listening / Vision
Additional information
Hand position display
Use:
Beep
Time for pressing on
the pushers
(e. g. 2 seconds)
Repetitive actions
Adjustment:
Important notes
For the best reading of the temperature, remove the watch from your wrist and
wait for approximately 15 to 30 minutes. For more information see the
explanation of the thermometer on page 22.
For correct use of the altimeter, adjust it as often as possible. For more
information see the explanation of the altimeter on page 20.
The barometer function (METEO) indicates a trend. Hands superposed to the left
of midday = bad weather, at midday = stable weather, to the right of midday =
good weather. For more information, see the explanation of the barometer
function on page 16.
Your watch is waterproof to 30 m. However, no function can be operated if the
glass is in contact with a liquid.
General information on use
• Activate the glass by pressing
• When the glass is activated, a flashing
bar will appear on the digital display
• Select a function by touching the corresponding area on the glass
• Brief presses on the pushers = step by step movement of the hands or incrementation
(decrementation) on the digital display
• Long presses on the pushers = continuous movement or incrementation (decrementation)
Congratulations
Hamilton is happy that you have chosen a timepiece from our prestigious collection. Your
Khaki Field Multi-Touch watch incorporates state-of-the-art technology. It offers permanent
analog display of the time as well as varied digital displays. In addition, the following
functions are available by simply touching the glass: barometer, altimeter, chronograph,
compass, alarm and thermometer.
54
1"
5"
Activation of the glass
Using pushers and ,
bring the 2 hands precisely to
12 o'clock
Incrementation of the minute
hand (3 steps = 1 minute)
Incrementation of the hour
hand (3 steps = 1 minute)
Validation of the setting
Selecting the "Units" mode
(1) Procedure allowing the digital display to be synchronised
with the hands.
Note: it is not necessary to perform this synchronisation
operation when the digital display and the hands show
the same time.
h-m-s
date
units
1"
(1)
(2)
Activation of the glass
Selecting the display mode
Return to h-m-s mode
(1) The "h-m-s" and "date" modes remain active.
(2) The "units" mode is a temporary setting mode.
(3) This procedure is valid when the glass
is activated for the ALTIMETER, CHRONO,
COMPASS, ALARM, THERMOMETER and BAROMETER functions.
(3)
h-m-s/date/units
(1)
SYNCHRONISATION DISPLAY MODE
76
or
1"
2"
Activation of the glass
Activation of the setting
Selecting the "h-m-s" mode
(eg. 8 h 34' 20'')
Incrementation or decrementation
by one minute
Validation of the setting,
the seconds restart at zero
Validation of the setting,
the seconds continue normally
(1)
(1) Accuracy: -0.3 to +0.5 seconds / day.
(2) Pressing continuously on or allows
continuous advance of the setting.
After one complete revolution, the minute hand stops
and the hour hand advances in one hour steps.
(2)
+or -1 minute
1"
2"
(1) The calendar is semi-perpetual, that is the number
of days per month is predefined.
For February it is necessary to reset the date when
it is only 28 days.
Activation of the glass
Activation of the setting
Incrementation or decrementation
by one day
Validation of the setting
Selecting the "date" mode
(eg. 5 July)
+or -1 day
(1)
SETTING THE TIME SETTING THE DATE
98
1"
2"
Activation of the glass
Activation of the setting
Validation of selections
Selecting the "Units" mode
Selecting "Celsius degree / meter"
or "Fahrenheit degree / foot"
Selecting "12" or "24" hours
1"
(1) For more information, see the explanation of the barometer
function on page 16.
(2) The two hands indicate a tendency while the digital display
gives the absolute pressure in hectoPascal
(1 hectoPascal = 1 millibar).
After 30 seconds, the digital display returns to "h-m-s" mode.
(2)
Activation of the glass
Activation of the barometer function
SELECTING THE UNITS METEO
Indication of the meteorological tendencies(1)
1110
1"
(1) Resolution: 1/100 of a second
Measuring range: 9 h 59' 59'' and 99/100.
(2) After 30 seconds, the hands display the time again but
the digital display remains in CHRONO mode.
After 10 h, the digital display returns to "h-m-s" mode".
Activation of the glass
Activation of the chronograph
Starting the chronograph
Stopping the chronograph
(eg. 10'' and 34/100)
Resetting the chronograph
(1)
(2)
Precise measurement of a specific duration Precise measurement of a specific duration with intermediate time
1"
Activation of the glass
Activation of the chronograph
Starting the chronograph
Displaying the intermediate time
(eg. 48'' and 15/100)
Restarting the chronograph,
taking into account the running time
Stopping the chronograph
(eg. 2' 54'' and 88/100)
Resetting the chronograph
CHRONOGRAPH CHRONOGRAPH (SPLIT)
1312
1"
2"
Activation of the glass
Activation of the adjustment
of the magnetic deviation
Activation of the compass
function
Setting the magnetic deviation
to the east (+) or west (-)
Validation of the setting (eg. 2°East)
(2)
(1)
(1) The minute hand points to the North. A more accurate
reading is obtained by holding the watch horizontally.
The digital display gives the set magnetic deviation.
After 30 seconds, the digital display returns to "h-m-s"
mode.
(2) For more information, see the explanation of the
magnetic deviation on page 18.
+or -1 degree
1"
1"
2"
(1) When the programmed time is reached,
the alarm can be stopped by pressing one of the pushers.
Activation of the glass
Activation of the alarm function
(eg. 12h19')
Setting the time
Incrementation or decrementation
by one minute
Validation of the setting
Deactivation of the alarm
Activation of the alarm
(1)
+or -1 minute
Compass. Indication of the geographical North
COMPASS ALARM
1514
1"
2"
(1) The altitude is displayed in meters or feet depending on
the units selection (see "Selecting the units" on page 8).
After 30 seconds, the hands show the time again
but the digital display remains in ALTIMETER mode.
After 10 h, the digital display returns to "h-m-s" mode
(2) The adjustment shows the altimeter setting at the value
of the actual altitude. For more information,
see the explanation of the altimeter on page 18.
Validation of the setting
(2)
Activation of the glass
Adjusting the altitude
Activation of the altimeter function
Incrementation or
decrementation (1 m or 3 ft)
(1)
+or -1 step
1"
(1) To obtain the best reading, it is necessary to remove the watch
from your wrist and wait for approximately 15 to 30 minutes.
For more information, see the explanation of the THERMOMETER
on page 22.
(2) The temperature is displayed in degrees Celsius or in degrees
Fahrenheit depending on the units selected (see "selecting the
units" on page 8).
After 30 seconds, the hands display the time again but the digital
display remains in THERMOMETER mode.
(2)
Activation of the glass
Activation of the THERMOMETER
function
Indication of altitude in relation to sea level Indication of the temperature(1)
ALTIMETER THERMOMETER
