H&S 3156 Bedienungsanleitung

Manufactured By

H&S MANUFACTURING CO.,INC.

P.O. BOX 768 (715) 387-3414 FAX (715) 384-5463

MARSHFIELD, WISCONSIN 54449

WARNING

Revision#00

3156 Starting Serial #710114

3166 Starting Serial #710068 HSMFG0517 Part#77530

READ AND UNDERSTAND THIS MANUAL

BEFORE OPERATING THIS EQUIPMENT.

UNSAFE OPERATION OR MAINTENANCE OF

THIS EQUIPMENT CAN RESULT IN SERIOUS

INJURY OR DEATH.

3156/31663156/3166

3156/3166

OPERAOPERA

OPERATT

TOR’S MANUOR’S MANU

OR’S MANUOR’S MANU

OR’S MANUALAL

ALAL

Heavy Duty

Spreader

Warranty &Warranty Registration Card . . . .. . . . . . .. . . . . . .. . . . . . .. . . . . . .. . . . . . .. . . . . . . . 1-2

Dealer Pre-Delivery Checklist . . . . . . . . . . .. . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . . . . 3

DealerDelivery Checklist . .. . . .. . . . . . . . . . . . . . . . .. . . .. . . .. . . .. . . . . . . . . . . . . . . . . . . . . . . . . . 5

SafetyInformation - BeAlertSymbol. .. . .. . . . .. . .. . . . . . . .. . .. . . . .. . .. . . . . . . .. . .. .. .. . .. . 7

SafetyInformation -Explanation ofSafety Signs. . . . .. .. .. . . . .. .. .. . . . .. .. .. . . . . . .. .. .. . . . 8

SafetyDecals . . . .. . . . .. . . . .. . . . .. . . . .. . . . .. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9-10

SafetyInformation-Warning-OwnerMustReadandUnderstand.. .... .... .... . ... . ... . ... . 11

CapScrewTorqueValues . .. . .. . . . . . . . . . .. . .. . .. . .. . .. . .. . .. . . . . . . . . . . . . .. . .. .. . .. . . . 12

Set-Up&Assembly. . .. . .. . . . . . .. . .. . . . . . . . . .. . .. . . . . . . . . . .. . .. . . . . . . . . .. . . . . . .. . .. . 13

Transporting .. . . . .. . . . .. . .. .. . .. .. . .. .. . .. .. . .. . . . .. . . . .. . . . .. . . . .. . . . . . .. . . . .. . . . .. 13

PreparingFor Operation .. . .. . . . . . .. . .. . . . . . . . . .. . .. . . . . . . . . .. . .. . . . . . . . . .. . .. . .. . 14-15

Operation . .. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. . .. .. . .. . .. . .. . .. . .. .. . . .. . .. . .. . .. . .. . 16

Adjustments. . . . .. . .. . . . .. . .. . . . .. . .. . . . .. . .. . . . .. . .. . . . .. . .. . .. . . . .. . .. . .. . . . .. . 17-18

Service. . .. . . . . . . . . .. . . . . . . . . .. . .. . . . . . .. . .. . . . . . .. . .. . . . . . .. . .. . . . . .. . . . . . .. . .. 19-20

OptionalEquipment .. .. .. .. .. . . . .. .. .. .. .. .. . . . .. .. .. .. .. .. . . . .. .. .. .. .. .. . . . . . .. .. .. 21

LubricationGuide . .. . .. . .. . .. . . . . . . . . . . . . . . .. . .. . .. . .. . .. . . . . . . . . . . . .. . .. . .. . .. . .22-24

Decal Location . . . . .. . . . . .. . . . . .. . . . . .. . . . . .. . . . . .. . . . . .. . . . . .. . . . . .. . . .. . .. . . . . . 25-28

Trouble Shooting. . . . .. . . . .. . .. .. . .. .. . .. .. . .. .. . .. . . . .. . . . .. . . . .. . . . .. . . . .. . . . .. . . . .29

ServiceNotes . . . . . .. . . . . . .. . . .. . . . . . .. . . . . . .. . . . . . . . . . .. . . . . . .. . . . . . .. . . .. . . .. . . . . . 30

Specifications......... . ........ . . ........ . ........ . ........ . ........ . . ...InsideBackCover

CONTENTS

Manure spreader was not damaged in shipment. Check for dents and loose or missing

parts. Report damage immediately to H&S Manufacturing Co., Inc.

All bolts and fasteners are tight.

Manure spreader has been correctly assembled according to instructions in this manual.

All grease fittings have been lubricated. Gearbox is filled to proper level.

Hoses and fittings are properly attached and there are no visible leaks.

Guards and shields are secure.

Wheels are properly mounted to torque specifications.

Tires are inflated to correct pressure.

Drive chain tension and alignment is correct.

Decals are in place and legible.

Main apron chains are adjusted properly.

DEALER PRE-DELIVERYCHECK LIST

AFTER COMPLETION, DEALER SHOULD REMOVE AND RETAIN FOR RECORDS

Afterthe Manure Spreader hasbeen completelyset-up,check tobecertainitis incorrectoperating order

before delivering to the customer.The following is a list of points to inspect. Check off each item as you

have made the proper adjustments and found the item operating satisfactorily.

Connect the manure spreader onto a proper horsepower tractor and attach the PTO and connect

the lights. Connect the hydraulic hoses to the tractor remote outlets. Run the manure spreader

and make sure all components operate properly.

PTO guard turns freely.

Hydraulic end gate operates smoothly.

Main apron operates smoothly.

Hydraulic system does not leak under pressure.

Lights and wiring functioning properly.

Implement and all components are functioning properly.

(Remove Dealer File Copy At Perforation)

Serial#

Dealer’s Name

Signature of Pre-Delivery Inspector

Inspection Date

ModelNumber

-3-

Intentionally Left Blank

-4-

Thischecklistthatfollows is an important reminder ofvaluableinformationthatshould be passed

on to the customer at the time this Manure Spreader is delivered.

Check off each item as you explain it to the customer.

This delivery check list, when properly filled out and signed assures the customer that the

Pre-delivery service was satisfactorily performed.

Explain to the customer that the pre-delivery inspection was made.

Explain to the customer all the safety precautions they must exercise when operating

this unit.

Explain recommended loads for different types of materials.

Explaintocustomerthat regular lubrication is required forproperoperationandlong life of

machine.

Show customer the lubrication section of Owner’s Manual.

Give the customer Owner’s Manual and make sure they read and understand all operating

and service instructions.

Have the customer sign a completed “Warranty Registration”, and mail it.

DEALER DELIVERYCHECK LIST



(Remove Dealer File Copy At Perforation)

AFTER COMPLETION, DEALER SHOULD REMOVEAND RETAIN FOR RECORDS



DateDelivered

Dealer’sName

SignatureofOriginalBuyer

Note: Warranty is not valid until warranty card is completed and returned to H&S Mfg. Co., Inc.

-5-

Intentionally Left Blank

-6-

ALERT! YOURSAFETY

ISINVOLVED.

THIS SYMBOL IS USED THROUGHOUT THIS BOOK WHENEVER YOUR PERSONAL SAFETY

IS INVOLVED. TAKE TIME TO BE CAREFUL. REMEMBER: THE CAREFUL OPERATOR IS THE

BEST OPERATOR. MOST ACCIDENTS ARE CAUSED BY HUMAN ERROR. CERTAIN

PRECAUTIONS MUST BE OBSERVED TO PREVENT THE POSSIBILITY OF INJURY OR

DAMAGE.

-7-

H&S MANUFACTURING CO., INC.

SAFETY INFORMATION

-8-

RECOGNIZE SAFETY INFORMATION

This is the safety-alert symbol. When you see this

symbol on your machine or in this manual, be alert to the

potential for personal injury.

Follow recommended precautions and safe operating

practices.

UNDERSTAND SIGNAL WORDS

A single word; DANGER, WARNING, or CAUTION is used

with the safety-alert symbol. DANGER identifies the most

serious hazards.

Safety signs with signal word DANGER or WARNING are

typically near specific hazards.

General precautions are listed on CAUTION safety signs.

FOLLOW SAFETY INSTRUCTIONS

Carefully read all safety messages in this manual, and all safety signs on your machine. Follow all

recommended precautions and safe operating procedures.

OBSERVE MAXIMUM TRANSPORT SPEED

The maximum transport speed for this implement is 32 km/h (20 m.p.h.).

Some tractors are capable of operating at speeds that exceed the maximum

transport speed of this implement. Regardless of the maximum speed capability

of the tractor being used to tow this implement, do not exceed the implement’s

maximum transport speed.

Exceeding the implements maximum transport speed can result in:

* Loss of control of the tractor/implement combination

* Reduced or no ability to stop during braking

* Implement tire failure

* Damage to the implement structure or its components

Use additional caution and reduce speed when towing under adverse surface

conditions, when turning, and when on inclines.

Do not attempt transport if the fully loaded implement weighs more than 1.5 times

the weight of the tractor.

Keep signs in good condition. Immediately replace any missing or damaged signs.

SAFETY INFORMATION
