MS1000 Control System
Installation Guide
hanwell.com Page 1 of 31 GD6063-1
Document History
Document Number: GD6063
Issue No. Issue Date Changes By
1 26 October 2018
Changes to take account of introduction
of EMS and reformatting IR
MS1000 Control System
Installation Guide
GD6063-1 Page 2 of 30 hanwell.com
Contents
1Overview of the MS1000 Control System....................................................................... 4
2MS1000 Control System Configuration .......................................................................... 5
2.1Option 1 - Standalone Solution...................................................................................................... 5
2.2Option 2 - Monitoring and Control Solution .............................................................................. 6
2.2.1Controllers/Processors ...............................................................................................................7
2.3Output Cards...................................................................................................................................... 8
2.3.1Output Card Specifications ...................................................................................................... 11
3Pre-Delivery........................................................................................................................12
4Firmware/Software Requirements..................................................................................13
4.1Firmware ............................................................................................................................................ 13
4.2Software ............................................................................................................................................. 13
4.2.1New Systems............................................................................................................................... 13
4.2.2Existing Systems......................................................................................................................... 13
5Pre-Commissioning...........................................................................................................14
6MS1000 Output Card ID Number................................................................................... 15
6.1ID Number .........................................................................................................................................15
6.1.1Setting the ID Number ..............................................................................................................15
7Connecting the MS1000 Control System...................................................................... 16
7.1Power Supply.................................................................................................................................... 16
7.2Controller to MS1000 Control Unit - USB Cable Wiring........................................................ 17
7.3RS485 Wiring from Controller to MS1000 Control Unit ........................................................ 17
7.3.1Standalone MS1000 Systems................................................................................................. 17
7.3.2Monitoring and Control Systems ........................................................................................... 17
7.3.3Wiring Summary ........................................................................................................................20
7.3.4Customer Supplied Wiring Required Specifications .......................................................20
7.4Wiring the Output Cards ................................................................................................................21
8Technical Reference ........................................................................................................22
MS1000 Control System
Installation Guide
hanwell.com Page 3 of 30 GD6063-1
8.1MS1000 Enclosures ....................................................................................................................... 22
8.1.1Standard Case (Code N001) .................................................................................................. 22
8.1.2Large Case (Code N016)......................................................................................................... 22
8.1.3Extra Large Case (Code N051) .............................................................................................. 22
8.1.4MS1000 Output Card Case .................................................................................................... 23
8.2Allowable Temperature and Humidity Ranges ...................................................................... 23
9Hanwell MS1000 System Fault Checking.....................................................................24
9.1Signals are not being received on any channels .................................................................. 24
9.2Signals are not being received on some channels............................................................... 25
9.3Readings are incorrect.................................................................................................................. 26
10Existing Hanwell EMS Users........................................................................................... 27
10.1Hardware .......................................................................................................................................... 27
10.2Software............................................................................................................................................ 27
10.2.1Wiring ........................................................................................................................................... 27
11Contact Information.........................................................................................................28
MS1000 Control System
Installation Guide
GD6063-1 Page 4 of 30 hanwell.com
1Overview of the MS1000 Control System
The Hanwell MS1000 Control System is an interface between a Hanwell Environmental
Monitoring System (EMS) and 3rd party control equipment.
It is designed to generate either latched voltages or currents corresponding to inputs,
proportional to measured values, generated by sensors, in remote locations, that are
compatible with the Hanwell Environmental Monitoring System (EMS) software.
Typical applications could include:
Interfacing radio sensors to a Building Management System (BMS).
Conservation heating systems.
Bespoke heating control.
Providing signals to an Alarm Panel.
The MS1000 Control System can:
Allow radio sensors to directly replace wired-in sensors in applications such as building
environmental control where the 3rd party BMS can directly accept analogue signals.
Trigger relay outputs for alarm or control functions (e.g. motorised valves).
Provide a combination of all output types within a single MS1000 system.
MS1000 Control System
Installation Guide
hanwell.com Page 5 of 30 GD6063-1
2MS1000 Control System Configuration
There are two main options for configuring the MS1000 Control System:
Standalone Solution
Monitoring and Control Solution
2.1 Option 1 - Standalone Solution
Radio sensors transmit directly back to the MS1000 Control Unit via either a standalone
Receiver connected to the MS1000 or a receiver incorporated into the MS1000 Control
Unit.
The MS1000 Control Outputs are sent to, for example, a 3rd Party Building Management
System (BMS).
Figure 1 - Stand Alone Solution Schematic
MS1000 Control System
Installation Guide
GD6063-1 Page 6 of 30 hanwell.com
2.2 Option 2 - Monitoring and Control Solution
Radio sensors transmit to an SR2 or CR2 Controller/Processor/Base Station (Controller).
The Controller sends the data to both a monitoring PC and the MS1000 Control Unit.
The MS1000 Control Outputs are sent to, for example, a Building Management System
(BMS). See Figure 2 below:
Sensor 1’s output controls Plant A.
Sensor 2’s output controls Plants B and C.
Note: In some applications, the Controller may be enclosed within the MS1000 Control Unit;
the Controller PCB being either in a separate Control Unit or mounted within the
MS1000’s Control Unit, depending on the exact system supplied.
Figure 2 - Monitoring and Control Solution Schematic
MS1000 Control System
Installation Guide
hanwell.com Page 7 of 30 GD6063-1
Figure 3 – General System Schematic
2.2.1 Controllers/Processors
The CR2 and SR2 Controllers both provide an interface/controls for the MS1000 Control
System in addition to their other functions as outlined in Sections 2.2.1.1 and Error! Reference
source not found. below.
2.2.1.1 Hanwell CR3
The CR3 Controller receives and processes data signals from Hanwell radio and wired
sensors and is designed for continuous monitoring of an entire system.
Received data is then logged and stored, pending transfer to a PC for analysis and
archival storage.
The CR3 also signals alarm conditions via the front panel LEDs (should any sensor
measure above or below individual pre-set levels).
Although the CR3 Controller has an extensive memory capacity, it is intended that the
data is transferred to a PC for detailed interpretation and permanent storage. This can
be done automatically or manually, at any time.
A built in GSM modem for remote communications is also available.
MS1000 Control System
Installation Guide
GD6063-1 Page 8 of 30 hanwell.com
2.2.1.2 Hanwell SR2
The SR2 Hanwell Smart Receiver/Controller is a network enabled receiver, designed for
continuously monitoring environmental data from multiple points within a site, or across
multiple sites, receiving and processing data signals from Hanwell radio and wired sensors.
Additionally, the SR2 can be fitted with up to eight onboard probes and can be upgraded to a
transceiver to both receive and re-transmit the data.
Each SR2 can handle data from up to 253 sensors and, as up to 16 SR2s can be run on a
single system, up to 4048 sensors can be connected to a single system.
The SR2 logs all received data in its on-board 512kb memory.
The software continually interrogates the SR2 for the most recent data and downloads
the data according to user-defined logging periods to the server or operating PC from
where software users can view live and historic data, produce out of specification and
summary reports and set alarms for both the data values and the rate of change of the
data’s values.
An optional remote Receiver can be connected to improve radio reception in difficult
areas.
Alarm relays are included: these can indicate that the readings are out of specification
and can, optionally, be set to indicate a network failure.
An MS BUS connection allows the SR2 to drive the Hanwell MS1000 Control System.
2.3 Output Cards
Input signals generated by sensors are either passed directly to the MS1000 Control System
or passed to a CR3 or SR2 Controller for processing, before transmission to the MS1000
Control System.
Output signals from the MS1000 Control System to the systems/equipment under control are
generated by Output Cards located within the MS1000 Control Unit.
