Hartmann PCIE101A Bedienungsanleitung
www.hartmann-electronic.com Rev. 1.0 1
PXI Express
Desktop PC Expansion
PCIE101A \ PXE100A
User’s Manuel
www.hartmann-electronic.com Rev. 1.0 2
Revision History
Version: Notification of Change Date
1.0
10.01.2020
Imprint:
Hartmann Electronic GmbH
Motorstraße 43, D-70499 Stuttgart (Weilimdorf)
Telephone: +49 711 1 39 89-0
Telefax: + 49 711 8 66 11 91
Internet: www.hartmann-electronic.com
Hartmann Electronic is a longstanding partner of the
Embedded industry and has a variety of different backplanes.
With our wide selection of backplanes and enclosure you can
Build your perfect system platform
Copyright © 2017
All rights and technical modifications reserved
www.hartmann-electronic.com Rev. 1.0 3
Contents
1. Safety.....................................................................................................................................................................4
Intended Application..............................................................................................................................................4
Safety Symbols .....................................................................................................................................................4
General Safety Precautions ..................................................................................................................................4
Safety Instructions.................................................................................................................................................5
Protection Against Electromagnetic Interference (EMI).....................................................................................5
Electrostatic Discharge Precautions...................................................................................................................5
Installation ..........................................................................................................................................................5
Location..............................................................................................................................................................5
Voltage Hazards.................................................................................................................................................5
System Overheating...........................................................................................................................................5
Mounting Considerations....................................................................................................................................5
Electrical Hazards...............................................................................................................................................6
Board Installation................................................................................................................................................6
2. Product Description ...............................................................................................................................................7
Related Documentation.........................................................................................................................................7
Chassis Description...............................................................................................................................................8
Block Diagram.......................................................................................................................................................9
PCIE101A PCIe Gen. 3 X4 PC Card..................................................................................................................9
PXE100A PCIe Gen. 2 Uplink to PXI Express.................................................................................................10
Front Panel LEDs................................................................................................................................................11
Cabling ................................................................................................................................................................11
Installation................................................................................................................................................................12
Installing Hardware..............................................................................................................................................12
Installing Software...............................................................................................................................................14
3. Specification ........................................................................................................................................................15
Electrical..............................................................................................................................................................15
DC Input ...........................................................................................................................................................15
Operating Environment ....................................................................................................................................15
Electromagnetic Compatibility..........................................................................................................................16
Environmental...................................................................................................................................................16
CE Compliance.................................................................................................................................................17
Mechanical ..........................................................................................................................................................18
4. Pin Assignment....................................................................................................................................................19
PXI Express System Controller Slot (4 Link Configuration)................................................................................20
5. Ordering Information............................................................................................................................................21
www.hartmann-electronic.com Rev. 1.0 4
1. Safety
Intended Application
The PXE100A series remote controller kit is no end-product, so there is no valid approval for this unit. In
Order to enable stand-alone functionality, additional elements are required. An operational system is
achieved only by way of appropriate PXI Express Cards.
The completion and final testing of the units have been carried out, or at least supervised, by qualified
technicians. These instructions are directed exclusively to these qualified technicians i.e. Engineers,
trained and qualified electricians etc.
Make sure that the finished system complies with the safety regulations currently applicable in the
country it is going to be used.
Safety Symbols
Hazardous voltage!
Familiarise yourself with the danger of electrical voltages and the safety
precautions before starting to work with parts that carry dangerous voltages
Caution!
This symbol indicates a condition where damage of the equipment or injury of
the service personnel could occur. To reduce the risk of damage or injury,
follow all steps or procedures as instructed.
Danger of electrostatic discharge!
Static electricity can damage sensitive components in a system. To avoid
damage, wear ESD wrist straps or at regular intervals touch blank enclosure
parts.
General Safety Precautions
Warning!
Voltages over 60 VDC can be present in this equipment. This equipment is
intended to be accessed, to be installed and maintained by qualified and trained
service personnel only.
This equipment is designed in accordance with protection class 1!
lt must therefore be operated only with protective GND/earth connection!
www.hartmann-electronic.com Rev. 1.0 5
Safety Instructions
The intended audience of this User's Manual are system Integrators and hardware/software engineers.
The product has been designed to meet relevant standard industrial safety requirements. It must not be
used except in its specific area of office telecommunication industry and industrial control. It shall not be
used in safety-critical applications, life-sustaining appliances or in aircraft.
Only trained personnel or persons qualified in electronics or electrical engineering are authorized to
install, operate or maintain the product.
This section provides safety information about:
Protection Against Electromagnetic Interference (EMI)
Electrostatic Discharge Precautions
System Installation
ProtectionAgainstElectromagneticInterference(EMI)
The product has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules, EN 55022 Class A.
To ensure proper EMC shielding, operate the chassis only with all free slots populated with filler panels.
Ensure that all EMI gaskets make correct contact.
ElectrostaticDischargePrecautions
Electronic components can easily be destroyed by electrostatic discharge which can occur between
chassis components and a person.
Before working on the chassis make sure that you are working in an ESD-safe environment.
Installation
To avoid chassis damage verify that the system environment meets the environmental and power
requirements given in this guide before installation consider these guidelines:
Location
Locate the system in a stable area free of excessive movement and jarring, dust, smoke, and
electrostatic discharge (ESD). Make sure that the temperature does not exceed the operating
temperature given in the environmental requirements in this guide and allow room for proper air flow for
cooling.
VoltageHazards
The system is powered with a power supply the mains voltage is 115/230VAC.
(Voltage range 90VAC to 264VAC)
This voltage is considered hazardous.
SystemOverheating
Ensure clearance of at least 10 cm to the air inlet on the left side of the chassis, and a free path of at
least 10 cm for the air exhaust on the right.
Shelf ambient temperature may not exceed 50°C.
MountingConsiderations
During the course of handling, shipping, and assembly, parts could become loose or damaged.
Do not operate a shelf in this condition, as this may cause damage to other equipment.
www.hartmann-electronic.com Rev. 1.0 6
ElectricalHazards
The caution label on the system's rear near the grounding studs shows that you have
to create an earth connection because there may be a high leakage current which is considered
hazardous.
High leakage current can cause injuries.
Ensure that the system is properly grounded at all times, the following conditions shall be met:
This equipment shall be connected directly to the AC supply system earthing
BoardInstallation
Electrostatic discharge and incorrect board installation or removal can damage circuits or shorten their
life.
Before touching the boards or electronic components, make sure that you are working in an ESD-
safe environment
Boards should be inserted and removed using their handles, do not force the board by applying pressure to
the front panel.
www.hartmann-electronic.com Rev. 1.0 7
2. Product Description
The PXE100A series PXI Express Remote Controller is designed to operate in a PXI Express System Slot. The
controller complies with the PXI Express module form factor. With its use, a conventional Desktop PC is used ,to
control a PXI Express Chassis.
With the use of a Hartmann Electronic PCIE101A PC adapter, the Remote Controller is connected with a
standard PCIe X4 cable to the desktop PC. The interface of the PXE100A as well as the interface of the
PCIE101A are fully comply with the PCI Express External Cable Specification, Revision 2.0.
Related Documentation
- PXI-5 PXI Express Hardware Specification
- CompactPCI PICMG 2.0 R. 3.0
- CompactPCI Express Specification PICMG EXP.0 Revision 2.0
- PCI Express External Cable Specification, Revision 2.0
www.hartmann-electronic.com Rev. 1.0 8
Chassis Description
The PXI Express Remote controller is plugged into the PXI Express Backplane’s System Slot. The Space saving
4 TE design allows to place System Components, as well as further PXI Express Modules, direct next to the
controller, without loosing space.
The Controller is suitable for PXI Express Chassis that implement a PXI Express System Slot 4-Link
configuration.
www.hartmann-electronic.com Rev. 1.0 9
Block Diagram
PCIE101APCIeGen.3X4PCCard
Figure 2-2 illustrates the hardware implementation of the PCIE101A PC Card.
Figure 2-1 PXI Express Remote Controller Block Diagram
The Block Diagram above outlines the Hardware implementation of the PCIe PC Card PCIE101A. As shown in
Figure 2-1 the PC-Card is available in a high profile and a low profile version of the front panel. That allows the
PC Card to be plugged in any Desktop PC Chassis.
The PC Card can be plugged into a PCIe X4, PCIe X8 or PCIe X16 slot. The card re-drives a PCIe X4 link to the
standard PCIe X4 Cable Connector.
PCIe Gen. 3 data rates are supported with the card by utilizing a PCIe X4 Link.
www.hartmann-electronic.com Rev. 1.0 10
PXE100APCIeGen.2UplinktoPXIExpress
Figure 2-2 illustrates the hardware implementation of the PXI Express Remote Controller.
Figure 2-2 PXI Express Remote Controller Block Diagram
The Block Diagram above outlines the PXI Express Controllers Hardware implementation. The Controller’s
Upstream Port is implemented through a standard PCIe X4 Cable connector. A PCIe Gen. 2 X4 Link is
supported, for the connection with the desktop PC.
The controller can be plugged into any CPCI Express or PXI Express chassis’ system controller slot, which is
compliant with the specifications, that are listed in the “related document” section.
