- 2 - T1RHC3 Installation Guide
Overview:
Altronix T1RHC3 rack kit is pre-assembled and consist of Trove1HC1R enclosure/backplane with factory
installed Altronix power supply/charger. These kits also accommodate various combinations of Hartmann boards
for up to eight (8) doors in a single enclosure.
Configuration Chart:
Altronix
Model Number
115VAC 60Hz
Input
(current draw)
Power Supply
Board Input
Fuse Rating
Maximum
Battery
Charge Current
12VDC Total
Output Current
24VDC Total
Output Current
T1RHC3 3.5A 5A/250V 0.7A 6A 6A
Hardware and Accessories:
Specifications:
Agency Listings:
• CE European Conformity.
Mechanical:
• Black enclosure with ample knockouts for
convenient access.
• Includes: tamper switch, cam lock and
mounting hardware.
• Modular 2U standard EIA 19” drawer with
extendable slides up to 48”.
• Dimensions (H x W x D): 3.375” x 19.0” x 26.5”
(85.8mm x 482.6mm x 673.1mm)
Included Accessories:
• One (1) tamper switch
(Altronix Model TS112 or equivalent).
• Cam lock.
Available Accessories (not included):
• RE2: Rack Mount Battery Enclosure accommodates
up to four (4) 12VDC/7AH batteries.
• WM5, WM25, WM100: Magnetic Cable Tie Mounts
(5, 25, 100 counts).
Spacer | 5/16” Pan Head Screw | Lock Nut
Installation Instructions for T1RHC3:
Wiring methods shall be in accordance with the National Electrical Code/NFPA 70/ANSI, and with all local
codes and authorities having jurisdiction. These products are for indoor use only and must be installed within
the protected premises.
Note: First assemble and Install Z Bracket Wire Management Accesory
(refer to Z Bracket Installation pg. 4)
1. Remove backplane from enclosure prior to installing into rack cabinet
(do not discard hardware).
2. In order to mount included UL Listed tamper switch (Altronix Model TS112 or
equivalent) turn the enclosure upside down. Punch out the knockout in
designated location, on the back of the unit, from outside of the drawer
(Fig. 1, pg. 3). Insert the tamper switch into the knockout from outside of the
drawer with the button facing outwards and spaded connectors inside the drawer.
Connect tamper switch wiring to the Access Control Panel input or the
appropriate UL Listed reporting device.
To activate alarm signal open the rack drawer.
3. Slide the rack enclosure into an open 2U location in the four post rack cabinet.
4. Utilizing proper fasteners attach front ears to the rack rails.
5. Attach the rear of the adjustable slides to the rear rails of the rack cabinet with the proper fasteners.
6. Secure the rack cover (Fig. 2a, pg. 3) and rack drawer to earth ground (Fig. 2b, pg. 3).
7. Make sure that all internal cofigurations (wiring, voltage selection, switch settings, etc.) are
complete before mounting backplane back into enclosure.
8. Refer to the ULXB Power Supply/Charger Installation Guide AL600ULXB for further instructions.
Fig. 1
Back of the drawer,
viewed from outside.
Tamper Switch
mounting location
