Haskris OPC3-OPC15 Bedienungsanleitung
Effective Date: 02 September 2022
Revision: 00
MANUAL
MODELS OPC3 THROUGH OPC60
Page 2 of 46
Phone: 001 847 956 6420
Email: service@haskris.com
Table of Contents
I. Haskris Contact Information .................................................................................5
II. Confirm Chiller Model and Number of Frame Sections
Frame Sections ...............................................................................................6
III. Installation: Foundation, Vibration, Elevation, Clearances, Transportation
Foundation .....................................................................................................7
Vibration ........................................................................................................9
Elevation ...................................................................................................... 10
Clearances.................................................................................................... 10
Transportation –OPC3 through OPC30...........................................................14
Transportation –OPC36 through OPC60......................................................... 17
IV. Installation: Line Sizing, Piping
Line Sizing....................................................................................................18
Piping...........................................................................................................19
V. Installation: Electrical
Electrical ......................................................................................................21
VI. Installation: Piping Flush, Purge
Piping Flush.................................................................................................. 23
Piping Purge .................................................................................................23
VII. Installation: Glycol Mixture, Filling
Glycol Mixture...............................................................................................24
Fill the Reservoir –Standard Type (Non-Pressurized) ......................................25
Fill the Reservoir –Optional Sealed Type (Pressurized).................................... 25
Fill the Piping................................................................................................ 26
Page 3 of 46
Phone: 001 847 956 6420
Email: service@haskris.com
VIII. Installation: Final Checks
Phase Monitor............................................................................................... 27
Controller Faults ........................................................................................... 27
IX. Optional Modbus or BACnet Communication Capability
Building Management System ........................................................................28
Haskris Capability..........................................................................................28
Physical Connection ......................................................................................29
Settings Configuration ...................................................................................29
Baud Rate Support........................................................................................30
X. Startup
Phase Monitor............................................................................................... 31
ON/OFF Switch .............................................................................................32
Pump Priming ...............................................................................................33
Pump Supply Pressure...................................................................................34
XI. Controller Display
Main Display .................................................................................................35
Status Modes................................................................................................35
Adjusting Set Value (sv) ................................................................................36
Units of Measure........................................................................................... 36
Faults...........................................................................................................38
Page 4 of 46
Phone: 001 847 956 6420
Email: service@haskris.com
XII. Chiller Features
E-coated Condensers for Corrosion Resistance................................................ 40
Dynamic Capacity Control..............................................................................40
Local Monitoring ...........................................................................................41
Remote ON/OFF Contacts.............................................................................. 42
Optional Feature –Remote Control Panel ....................................................... 43
Optional Feature –Redundant Primary/Standby Pumps................................... 44
Optional Feature –Louvered Hail Guard Panels...............................................44
XIII. Maintenance
Frequency .................................................................................................... 45
Glycol Mixture...............................................................................................45
Wye Strainer................................................................................................. 46
Condenser Coils ............................................................................................46
Electrical Inspection ......................................................................................46
Page 5 of 46
Phone: 001 847 956 6420
Email: service@haskris.com
I. Haskris Contact Information
Contact Haskris with any questions about a unit and/or the information in this manual. Haskris has a
team of engineers available to answer questions, troubleshoot issues, or provide supplemental
information as needed.
Phone: 001 847 956 6420
Page 6 of 46
Phone: 001 847 956 6420
Email: service@haskris.com
II. Confirm Chiller Model and Number of Frame Sections
Frame Sections
Details: The Haskris OPC series chillers are built with a system of parallel refrigeration circuits and
associated frame sections to house those components. Larger models of chiller have more
refrigeration circuits and more frame sections.
Instructions: Use the chiller model and the table below to determine the number of refrigeration
circuits and sheet metal sets are used in the design.
Haskris Chiller Model
Refrigeration Circuits
Frame Sections*
OPC3 through OPC15
1
1
OPC16 through OPC26
2
2
OPC30
2
3
OPC36
3
3 or 4
OPC48
4
4 or 5
OPC60
5
5 or 6
*Some units are designed with customizations that may change the number of frame sections
Refrigeration Circuits and Frame Sections by Model
Page 7 of 46
Phone: 001 847 956 6420
Email: service@haskris.com
III. Installation: Foundation, Vibration, Elevation, Clearances,
Transportation
Foundation
•The chiller must be installed on a level concrete foundation, level roof curb, or level perimeter
beam system.
•Comply with local codes for proper anchoring and vibration isolation.
•Use of a level roof curb or perimeter beam system requires the specifying engineer to identify
all necessary materials of construction, thickness, and additional bracing or supports.
•See the diagrams below for mounting hole locations.
oNote that the example in the drawings has a cutaway that shows 2.5 frame sections.
The actual number of sections varies, refer to the prior section for details.
•Point load at each mounting location is 200 lbs. or less.
Mounting Hole Locations for Non-OSHPD Sites
Page 9 of 46
Phone: 001 847 956 6420
Email: service@haskris.com
Vibration
•The chiller does not require vibration isolation on the mounting for the chiller to operate
normally.
•The motors in the chiller are hard mounted to the metal structure of the chiller. They are not
internally isolated.
•It is common for the chiller to be hard mounted directly to a pad on grade, roof curb, or
perimeter beam system.
•If vibration transmission to the building structure is a concern, an engineer should provide a
detailed specification for vibration damping.
•There are two common approaches
oRubber or synthetic pads between the chiller and the mounting
oSpring vibration isolators. These cannot be installed directly between the chiller and the
mounting. The chiller must be mounted on a perimeter beam. The spring vibration
isolators can be installed between the beam and the mounting.
OSHPD: If OSHPD compliance is required and isolators are used, the spring isolators must comply
with Haskris OSHPD OSP-0673 file.
Page 10 of 46
Phone: 001 847 956 6420
Email: service@haskris.com
Elevation
For chillers located at a
higher
elevation than the application
•The maximum recommended height difference varies depending on several factors including
the maximum inlet water pressure for the application, normal water pump discharge pressure,
and pressure losses in the piping to the application.
•Consult Haskris if there are questions about locating a chiller.
For chillers located at a
lower
elevation than the application
•The maximum recommended height difference is 32 ft (9.8 m).
oIt is best if the height difference can be less than 32 ft (9.8 m).
oConsult Haskris if there are questions.
Clearances
•See the diagrams below showing recommended clearances for chiller models OPC3 through
OPC30.
oNote that these show the dimensions and clearances for a standard design. Some
customizations may alter the dimensions and/or clearance requirements. Consult
Haskris if there are questions about a specific design.
•For models OPC36 and larger, consult Haskris to get information about recommended
clearances.
•Air flow is horizontal into the chiller and vertical out of the chiller.
•Maintain an unobstructed space for free air discharge above the chiller.
•Consult Haskris if clearances will be smaller than these recommendations. Haskris will evaluate
individual site conditions as needed to ensure proper operation.
•Avoid areas where a heat source will discharge heat towards the chiller.
oExamples: condenser vents, heating exhaust, etc.
•Avoid areas where debris may accumulate on the condenser.
