Haztec 4-1815-X Bedienungsanleitung

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK

T: +44(0)113 202 9115 ∙ inf[email protected] ∙ www.haztec.uk

4-1815-X

15-LED Scene Light

M301.1.0 - 1 - January 2021

Thank you for purchasing this Haztec product. Before proceeding with installation, it is essential

to read and understand this instruction booklet.

▪This product must be installed by persons competent in vehicle electrical installations

▪Care should be taken to ensure that water ingress cannot occur through mounting or

wiring holes

▪Regularly inspect the product to confirm correct operation

▪DO NOT stare directly into the light it produces as permanent damage to the eyes

may result

▪Use only a mixture of soap and water to clean this product

▪DO NOT allow solvents and fuels etc. to come into contact with this product

Basic Operating Specifications:

Supply voltage range:

10-30VDC

Maximum current draw:

1.71A @ 12.5VDC

LED power:

15 x 3W

Lumen output:

2025lm

Beam angle:

0-70 degrees asymmetric

Operating temperature range:

-40 to +55OC

IP rating:

IP67

Dimensions (mm):

230.13 (L) x 47.95 (H) x 34.1 (D)

235 (L) x 52.5 (H) x 35.5 (D) with 0Ogasket

235 (L) x 53 (H) x 39.5 (D) with 7Ogasket

Bezel RAL colours:

Black

9017 (Traffic black)

White

9003 (Signal white)

Yellow

1016 (Sulphur yellow)

Red

3000 (Flame red)

▪15-LED Scene light

▪12/24VDC

▪Surface mount

▪Choice of bezel colour

▪IP67 rated

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK

T: +44(0)113 202 9115 ∙ inf[email protected] ∙ www.haztec.uk

4-1815-X

15-LED Scene Light

M301.1.0 - 2 - January 2021

Connection Instructions:

Wire

Connect to

Function

Red

Positive [+] via switch & fuse

Main feed

Black

Permanent negative [-]

Earth / Chassis ground

Installation Instructions:

▪The scene light is supplied with two gaskets –0 degrees for standard installations and

7 degrees which allows the light to be angled further away from the vehicle

▪Typical beam spread

Haztec International Ltd ∙ Moorfield Road ∙ Leeds ∙ LS19 7BN ∙ UK

T: +44(0)113 202 9115 ∙ inf[email protected] ∙ www.haztec.uk

4-1815-X

15-LED Scene Light

M301.1.0 - 3 - January 2021

▪Ensure that the mounting surface is flat, clean, and dry before commencing with

installation

▪Always use the fixings provided, however if a different fixing is required, it is essential

that it fits correctly into the housing

▪Ensure that the mounting holes will not cause damage to, or interfere with, any of the

vehicles wiring and always refer to the manufacturer’s manual for the location of any

airbag systems

▪Using the gasket as a template, mark the mounting holes and position of the cable entry

▪Drill the holes adequately to accept the M4 machine screws and power cables

▪If required, use a suitable customer supplied sealant to prevent water ingress

▪Attach the gasket to the lamp, then pass the power cables through the hole and fit the

lamp using the M4 x 20mm machine screws, nuts, and washers

▪Should the power cables need to be extended, always use cables of equal gauge and it is

recommended that joints are made waterproof

Basic Dimensions:
