HD Communications HD28650 Bedienungsanleitung
HD COM
IN WALL BOX ACCESS POINT
Model :
HD28650
In Wall Access Point
2
Copyright Notice
Copyright © 2005-2015 HD COM Technologies Inc. All rights reserved. No part of this document may
be copied, reproduced, or transmitted by any means, for any purpose without prior written permission.
Protected by TW patent 223184, JPN patent 3099924 and China patent ZL 03 2 04640.5.
Disclaimer
We shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or
consequential damages resulting from furnishing this material, or the performance or use of this
product. We reserve the right to change the product specification without notice. Information in this
document may change without notice.
Trademarks
Microsoft Win98, Windows 2000 and WinXP are registered trademarks of Microsoft Corporation.
General:All other brand and product names mentioned herein may be registered trademarks of their
respective owners. Customers should ensure that their use of this product does not infringe upon any
patent rights. Trademarks mentioned in this publication are used for identification purposes only and
are properties of their respective companies.
In Wall Access Point 3
Table of Contents
1Introduction------------------------------------------------------------------------------------------------------------5
1-1 Package Contents ---------------------------------------------------------------------------------------------------5
1-2 Features----------------------------------------------------------------------------------------------------------------6
1-3 Precautions------------------------------------------------------------------------------------------------------------6
1-4 Outlook------------------------------------------------------------------------------------------------------------------6
1-4-1 Top Panel ----------------------------------------------------------------------------------------------------6
1-4-2 Rear Panel---------------------------------------------------------------------------------------------------7
1-5 Technical Specifications -------------------------------------------------------------------------------------------7
1-5-1 Hardware Specifications---------------------------------------------------------------------------------7
1-5-2 Software Specifications ----------------------------------------------------------------------------------8
2Installation -------------------------------------------------------------------------------------------------------------9
2-1 Installation Requirements----------------------------------------------------------------------------------------10
2-2 Getting Start---------------------------------------------------------------------------------------------------------12
3 Configuring the In Wall Access Point -----------------------------------------------------------------------------16
3-1 Internet Setting -----------------------------------------------------------------------------------------------------18
3-1-1 TCP/IP Setting--------------------------------------------------------------------------------------------18
3-2 Wireless --------------------------------------------------------------------------------------------------------------20
3-2-1 Wireless Basic Setting----------------------------------------------------------------------------------20
3-2-2 Wireless Advanced Setting----------------------------------------------------------------------------21
3-2-3 Wireless Security Setting------------------------------------------------------------------------------22
3-3 Advanced ------------------------------------------------------------------------------------------------------------25
3-3-1 Management----------------------------------------------------------------------------------------------25
3-3-2 Firmware ---------------------------------------------------------------------------------------------------27
3-3-3 Configuration----------------------------------------------------------------------------------------------29
3-3-4 SNMP-------------------------------------------------------------------------------------------------------31
3-3-5 System------------------------------------------------------------------------------------------------------32
3-3-6 Ping Command-------------------------------------------------------------------------------------------32
In Wall Access Point
4
3-4 Advanced ------------------------------------------------------------------------------------------------------------32
3-4-1 Restart------------------------------------------------------------------------------------------------------32
3-4-2 Logout ------------------------------------------------------------------------------------------------------34
Appendix A Signal Connection Arrangements--------------------------------------------------------------------34
Appendix B Regulations/EMI Compliance -------------------------------------------------------------------------35
LIMITED WARRANTY---------------------------------------------------------------------------------------------------36
In Wall Access Point 5
1 Introduction
The HD28650 Access Device revolutionizes the way wireless and wired IP-based services are
delivered to hospitality and residential properties. The HD28650 integrates wired and wireless
connectivity into a small unit that can be quickly and discretely installed in a standard wall box. The
HD28650 provides One Ethernet ports, a 2.4GHz 802.11b/g/n wireless access point. The HD28650
requires a single powered cable drop to unlock its utility and, through the reduction in cabling, switch
ports, and power-sourcing equipment, the HD28650 represents the best value for the delivery of next
generation entertainment services.
1-1 Package Contents
Please inspect your package. The following items should be included:
◎HD28650
One In Wall Access Pointt
One Telephone Cable (10cm)
One UTP Ethernet/Fast Ethernet cable (Cat.5 Twisted-pair)
One Wall Faceplate(Top and Bottom )
Bracket (EU STD*2/Set JPN STD*1/Set)
One Quick Installation Guide
If any of the above items are damaged or missing, please contact your dealer immediately.
In Wall Access Point
6
1-2 Features
Wireless data rates up to 150Mbps
Comprehensive security
64/128-bit WEP encryption
WPA encryption
WPA2 encryption
Intelligent Management
1-3 Precautions
Never remove or open the cover. You may suffer serious injury if you touch these parts.
Never install the system in the wet locations.
1-4 Outlook
Figure 1 In Wall Box Access PointOutlook
1-4-1 Top Panel
The top panel of the In Wall Box Access Pointis shown below.
Figure 2 In Wall Box Access PointTop Panel
LEDs Indication
LED State Description
Off The In Wall Box Access Pointis not receiving electrical power.PWR
Green The In Wall Box Access Pointis receiving electrical power.
Off The In Wall Box Access Pointstatus is defective.
Green The In Wall Box Access Pointstatus is complete.
SYS
Green (Blinking) During firmware upgrades, this system LED will blink.
Off Port has not established any network connection.
Yellow A port has established a valid 10/100Mbps network connection.
LINK / WAN
Yellow (Blinking) 10/100Mbps traffic is traversing the port.
Off Port has not established any network connection.
Green A port has established a valid 10/100Mbps network connection.
LAN
Green (Blinking) 10/100Mbps traffic is traversing the port.
Off The Wireless is not ready.
Green The In Wall Box Access Pointhas established a valid wireless connection.
WLAN
Green (Blinking) The Wireless connection is active.
In Wall Access Point 7
1-4-2 Rear Panel
The rear panel of the In Wall Access Pointt
Figure 3 In Wall Box Access PointRear Panel
1-5 Technical Specifications
1-5-1 Hardware Specifications
Network Specification
IEEE802.3 10 Base TX Ethernet
IEEE802.3u 100 Base TX Fast Ethernet
IEEE802.3af Power over Ethernet
IEEE802.11b Wireless LAN
IEEE802.11g Wireless LAN
IEEE802.11n Wireless LAN
ANSI/IEEE 802.3 NWay auto-negotiation
Static IP Client
DHCP Client
Wi-Fi Compatible
Connectors
One LAN Ports (10BaseT/100BaseTX Auto cross-over)
1. RJ-11 Telephone Connector
2. RJ-45 Ethernet Connector
3. WPS Button
4. Reset Button
5. WLAN
6. SYSTEM
7. POWER
8. LAN Port
9. LINK Port
In Wall Access Point
8
One LINK Port (10BaseT/100BaseTX Auto cross-over)
Two Tel Port (Telephone Line transparent used)
Encryption
WEP (Wired Equivalent Privacy) 64/128-bit RC4
WPA (Wi-Fi Protected Access)
WPA2 (Wi-Fi Protected Access)
WPS (Wi-Fi Protected Setup)
LED Indicators
One POWER LED
One Link 10/100M Link/Activity LED
One LAN 10M/100M Link/Activity LEDs
One Wireless Link/Activity LED
One System LED
Environment Conditions
Operating Temperature: 0 to 50°C
Storage Temperature: -10 to 60°C
Operating Humidity: 10~80% non-condensing
Storage Humidity: 10% to 90% non-condensing
Certifications
FCC part 15 Class B, CE, NCC
Dimension
Size: 39.3(W) x 71.6(L)x 55(H)/ mm
Weight: About 85g (Net)
1-5-2 Software Specifications
Networking
• IEEE802.3 10BaseT Ethernet
• IEEE802.3u 100BaseTX Fast Ethernet
• IEEE802.3af Power over Ethernet
• IEEE802.11b Wireless LAN
In Wall Access Point 9
• IEEE802.11g Wireless LAN
• IEEE802.11n Wireless LAN
• Static IP WAN Client
• DHCP WAN Client
Security and Firewall
• WEP
• WPA
• WPA2
• WPS
Management
• Web-based Management Tool
• Firmware Upgrade via HTTP/TFTP
• Backup/Restore/Factory Default Setting
• Remote Authorized Management
• SNMP v1/v2 (MIB II, Private MIB)
• System Information Table
2 Installation
The followings are instructions for setting up the In Wall Access Point. Refer to the illustration and
follow the simple steps below to quickly install your In Wall Access Point.
Step 1：Slide the Bracket to align with screw holes on the HD28650, and fasten the Bracket tightly with
screws on the HD28650.
In Wall Access Point
10
Step 2：Slide the HD28650 into the Bottom Faceplate and fasten tightly into the Bottom Faceplate until
it’s flushed into the wall.
Step 3：Line-up and push the Top faceplate onto Bottom faceplate until snaps securely into place.
2-1 Installation Requirements
Before installing the In Wall Access Point, make sure your network meets the following
requirements.
System Requirements
