Heinner HCP-Z2000 Bedienungsanleitung

CONVECTOR

Model: HCP-Z2000/ HCP-Z2000TV

www.heinner.ro

CONVECTOR

Rated Frequency: 220-240 V~,50Hz

Power: 2000W

www.heinner.com 2000W, 50Hz, 220-240V

Before using the appliance, please read carefully this instruction manual and keep it for

future reference.

This instruction manual is designed to provide you with all required instructions related to

the installation, use and maintenance of the appliance.

In order to operate the unit correctly and safety, please read this instruction manual carefully

before installation and usage.

I. INTRODUCTION

II.

II. YOUR PACKAGE CONTAINS

Convector

User manual

Warranty card

Thank you for purchasing this product!

www.heinner.com 2000W, 50Hz, 220-240V

1. Read all instructions carefully before using.

2. Make sure the voltage is the same as that indicated on the rating plate of the appliance.

3. Do not operate this appliance if the cable or plug becomes damaged.

4. Keep the appliance and cable away from sources of heat, sharp objects or anything that may cause

damage.

5. If the cord is damaged, it must be replaced by the manufacturer, its service agent or similarly

qualified persons in order to avoid a hazard.

6. Ensure the appliance is switched off before connecting to the mains power supply.

7. Switch off the power supply and disconnect from mains supply when not in use, before cleaning or

other maintenance.

8. To disconnect the appliance, switch it “OFF”, and then remove the plug from outlet. Do not pull the

cord to disconnect the plug.

9. The heater must not be located immediately below a socket-outlet.

10. Do not operate in areas where gasoline, paint or other flammable liquids are used or stored.

11. Indoor use only.

12. In order to avoid overheating, do not cover the heater.

13. To prevent a possible fire, do not block air intakes or exhaust in any manner.

14. Don’t touch the hot surfaces.

15. Do not insert or allow foreign objects to enter any ventilation or exhaust opening, as this may cause

an electric shock, fire or damage to the appliance.

16. Always ensure that hands are dry before operating or adjusting any switch on the product or

touching the plug and socket-outlet.

17. This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been given

supervision or instruction concerning use of the appliance by a person responsible for their safety.

18. Children should be supervised to ensure that they do not play with the appliance.

19. Do not leave this appliance unattended when it’s in use.

20. The most common cause of overheating is deposits of dust or fluff in the appliance. Ensure these

deposits are removed regularly by disconnect the appliance and vacuum cleaning air vents and grilles.

21. Do not place the heater on carpet, also don’t place the cable under carpets. Arrange cord away

from traffic areas so that it will not be tripped over.

22. Do not use this heater in the immediate surroundings of a bath, a shower or a swimming pool.

23. Do not store the appliance away until the heater cools down; store the heater in cool dry location

when not in use.

24. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cutout, this

appliance must not be supplied through an external switching device, such as a timer, or connected

to a circuit that is regularly switched on and off by the utility.

III. SAFETY MEASURES

www.heinner.com 2000W, 50Hz, 220-240V

Air outlet

Handle

Power selecting switch

Thermostat

Foot

Air outlet

V. ASSEMBLY

1. Carefully turn the radiator on it’s side to fit the feet

2. Position each feet as shown below and secure using the self tapping screws provided.

3. Two screws are required for each feet and this unit must not be used without the feel firmly

attached.

WALL MOUNTING

The heater is supplied with 4 sets of fixing brackets, screws and plastic wall plugs to enable it to be

mounted onto a wall if required.

If the heater is intended to mount onto the wall, the feet should not be fitted. The position must be

chosen carefully. It must not be in front of or below a power socket and must not be below a shelf,

curtains or any other obstruction. Also refer to the safety instructions.

Having decided on the location of the heater it is necessary to drill 2 fixing holes with the distance of

415mm on a horizontal line at a minimum height of 400mm from the floor, at a minimum distance of

600mm from ceiling and 300mm from side wall (see bellow). Allowance must be made for any floor

coverings, carpet etc and if any skirting boards are present, the fixing holes must be a minimum of

400mm above the top edge of the skirting board. Using the plastic plugs and fixing screws provided,

attach 2 of the fixing brackets to the wall. The other pair of fixing brackets must be attached to the

base of the heater using the feet retaining screws so that the brackets project out at the rear of the

heater and space the bottom edge away from the wall.

If required, these brackets may also be secured to the wall using the remaining fixing screws and

plastic wall plugs.

IV. PRODUCT DESCRIPTION

www.heinner.com 2000W, 50Hz, 220-240V

If required, these brackets may also be secured to the wall using the remaining fixing screws

and plastic wall plugs.

www.heinner.com 2000W, 50Hz, 220-240V

VI. USING INSTRUCTIONS

1. Turn the heater to the “OFF” position before plugging in.

2. The operating temperature is selected by a combination of the heater switches and

thermostat. The hottest setting will be when the heater switches are both on and the thermostat

is turned to “Maximum”.

3. To determine the correct working temperature for your conditions, turn the heater to “High”

and the thermostat to “Maximum” when the room has reached the required temperature turn

the thermostat slowly to the left until the temperature is off. The temperature will now be kept

constant.

4. If you want to lower the operating temperature select the one of the heater switch only and

repeat the above procedure.

5. The heater is fitted with an automatic cutout in the event that it overheats. if is this activates,

turn the heater to the off position and unplug. Allow the heater to cool and remove anything

restricting the airflow before using the heater again. If the automatic cut out operates repeatedly

contact a quantified electrician for advice.

NOTES

For maximum benefit, closing windows and door when the heater is open

Do not cover the ventilation holes as this will cause overheating and will activate the cut out.

USING THE TURBO(WHEN FITTED)

This is operated by means of the switch with the fan symbol along side it. The fan will only

operate with the thermostat in the “ON”position and can be used when the heating elements

are “ON”to blow warm are into the room. In warm conditions the fan can be used with the

heating

Elements “OFF”to blow cool air into the room.

Using the Timer(where fitted)

1.Set the timer by moving the disc so that the point on the timer is the same sa the time. For

example at 1000hrs(100’clock) set the disc to the number 10.

2. Position the side switch to the central position ( )

3. Set the periods of time that you want the radiator to work each day by pulling the outer teeth

forward. Each tooth represents 15 minutes.

4.To reset the programming,move the teeth back to the original position before repeating step 3.

5. If the heater is required to run continuously, set the side switch on the timer to the position

indicated by I

6. If you do to wish to use the heater function but want the timer to continue to run, move slider

switch to the position indicated by O. Slide back to central( )

www.heinner.com 2000W, 50Hz, 220-240V

Rated Voltage

220-240 V~

Rated Frequency

50Hz

Max Power

2000W

VIII. TEHNICAL DATA

VII. CLEANING AND MAINTENANCE

To maximum the efficiency of the heater cleans regularly.

Switch power switches to “OFF”position, unplug and allow the heater to cool.

Wipe surfaces with a soft cloth. Do not use detergent or abrasives as this with scratch the

surface.

Ensure the intake grills free front dust, as this will reduce the airflow. Light accumulated dust

can be removed with soft cloth or vacuum cleaner.

Allow surface to fully dry before using the heater again.

To maximum the efficiency of the heater cleans regularly.

Switch power switches to “OFF” position, unplug and allow the heater to cool.

Wipe surfaces with a soft cloth. Do not use detergent or abrasives as this with scratch the

surface.

Ensure the intake grills free front dust, as this will reduce the airflow. Light accumulated dust

can be removed with soft cloth or vacuum cleaner.

Allow surface to fully dry before using the heater again.

www.heinner.com 2000W, 50Hz, 220-240V

Environment friendly disposal

You can help protect the environment!

Please remember to respect the local regulations: hand in the non-working electrical equipment’s to

an appropriate waste disposal center.

Importer: Network One Distribution

Marcel Iancu Street, 3-5, Bucharest, Romania

Tel: +40 21 211 18 56, www.heinner.ro , www.nod.ro

HEINNER is a registered trademark of Network One Distribution SRL. Other brands and product

names are trademarks or registered trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by any means or used to make any

derivative such as translation, transformation, or adaptation without permission from NETWORK

ONE DISTRIBUTION..

http://www.heinner.com, http://www.nod.ro

This product is in conformity with norms and standards of European Community.

www.heinner.com 2000W, 50Hz, 220-240V

CONVECTOR

Model: HCP-Z2000/ HCP-Z2000TV

www.heinner.ro

CONVECTOR

Alimentare: 220-240 V~,50Hz

Putere: 2000W

www.heinner.com 2000W, 50Hz, 220-240V

Înainte de a utiliza acest aparat, citiți cu atenție manualul de instrucțiuni și păstrați-l

pentru consultări ulterioare.

Acest manual este conceput pentru a vă oferi toate instrucțiunile necesare referitoare la

instalarea, utilizarea și întreținerea aparatului.

Pentru utilizarea corectă și în siguranță a aparatului, vă rugam să citiți cu atenție acest

manual de instrucțiuni înainte de instalare și utilizare.

I. INTRODUCERE

II.

II. CONȚINUTUL PACHETULUI DUMNEAVOASTRĂ

Convector

Manual de utilizare

Certificat de garanție

Vă mulțumim pentru achiziționarea acestui produs!
