Heinner HC-HS268WDE Series Bedienungsanleitung

COMBI FRIDGE

Model:

HC-HS268WDE++/HC-HS268SWDE++

www.heinner.ro

•Combi fridge

•Energy class: E

•Total capacity: 268 L

www.heinner.com

Please read the instructions carefully and keep the manual for future information.

This manual is designed to give all necessary instructions concerning installation, use and

maintenance of the unit. In order to operate the unit correctly and safely, please read this

instruction manual carefully before installation and use.

I. INTRODUCTION

II. YOUR PACKAGE CONTAINS

➢Refrigerator

➢User manual

➢Certificate of warranty

Thank you for choosing this product!

www.heinner.com

III. SAFETY INFORMATION

For your safety and correct usage, before installing and first using the appliance, read this

user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and

accidents, it is important to make sure that all people using the appliance are thoroughly

familiar with its operation and safety features. Save these instructions and be sure that

they remain with the appliance if it is moved or sold, so that anyone using it throughout

its life, will be properly informed on its usage and safety notices.

For the safety of life and property, keep the precautions of these user's instructions as the

manufacturer is not responsible for damages caused by omission.

Safety for children and others who are vulnerable people

•According to EN standard: This appliance can be used by children aged from 8

years and above and persons with reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe way and understand the

hazards involved. Children shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without supervision.

•Children aged from 3 to 8 years are allowed to load and unload refrigerating

appliances.

•According to IEC standard: This appliance is not intended for use by persons

(including children) with reduced physical, sensory or mental capabilities, or lack

of experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for their

safety.

•Children should be supervised to ensure that they do not play with the appliance.

•Keep all packaging away from children as there is risk of suffocation.

•If you are discarding the appliance, pull the plug out of the socket, cut the

connection cable (as close to the appliance as you can) and remove the door to

prevent children playing from suffering an electric shock or from closing

themselves inside it.

•If this appliance, featuring a magnetic door seals, is to replace an older appliance

having a spring lock (latch) on the door or lid, be sure to make the spring lock

unusable before you discard the old appliance. This will prevent it from becoming

a death trap for a child.

www.heinner.com

General safety

WARNING! This appliance is intended to be used in household and similar applications

such as:

•staff kitchen areas in shops, offices and other working environments;

•farm houses and by clients in hotels, motels and other residential type

environments;

•bed and breakfast type environments;

•catering and similar non-retail applications;

WARNING! Do not store explosive substances such as aerosol cans with a flammable

propellant in this appliance.

WARNING! If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualified persons in order to avoid a hazard.

WARNING! Keep ventilation openings, in the appliance enclosure or in the built-in

structure, clear of obstruction.

WARNING! Do not use mechanical devices or other means to accelerate the defrosting

process, other than those recommended by the manufacturer.

WARNING! Do not damage the refrigerant circuit.

WARNING! Do not use electrical appliances inside the food storage compartments of the

appliance, unless they are of the type recommended by the manufacturer.

WARNING! The refrigerant and insulation blowing gas are flammable. When disposing of

the appliance, do so only at an authorized waste disposal centre. Do not expose to flame.

WARNING! When positioning the appliance, ensure the supply cord is not trapped or

damaged.

WARNING! Do not locate multiple portable socket-outlets or portable power supplies at

the rear of the appliance.

WARNING! Food needs to be packed in bags before putting into the refrigerator, and liquids

need to be packed in bottles or capped containers to avoid the problem that the product

design structure is not easy to clean.

The symbol is a warning and indicates the refrigerant and insulation blowing gas are

flammable.

WARNING! Risk of fire/flammable materials

If the refrigerant circuit should be damaged:

•Avoid opening flames and sources of ignition.

•Thoroughly ventilate the room in which the appliance is situated.

www.heinner.com

Replacing the illuminating lamps

WARNING - The illuminating lamps must not be replaced by the user! If the illuminating

lamps is damaged, contact the customer helpline for assistance. This warning is only for

refrigerators that contain illuminating lamps.

Refrigerant

The refrigerant isobutene (R600a) is contained within the refrigerant circuit of the appliance,

a natural gas with a high level of environmental compatibility, which is nevertheless

flammable. During transportation and installation of the appliance, ensure that none of the

components of the refrigerant circuit becomes damaged. The refrigerant (R600a) is

flammable.

WARNING! Refrigerators contain refrigerant and gases in the insulation. Refrigerant and

gases must be disposed of professionally as they may cause eye injuries or ignition. Ensure

that tubing of the refrigerant circuit is not damage prior to proper disposal.

If the refrigerant circuit should be damaged:

•

Avoid opening flames and sources of ignition.

•

Thoroughly ventilate the room in which the appliance is situated.

It is dangerous to alter the specifications or modify this product in any way.

Any damage to the cord may cause a shortcircuit, fire, and/or electric shock.

Electrical safety

1. The power cord must not be lengthened.

2. Make sure that the power plug is not crushed or damaged. A crushed or damaged

power plug may overheat and cause a fire.

3. Make sure that you can access the main plug of the appliance.

4. Do not pull the main cable.

5. If the power plug socket is loose, do not insert the power plug. There is a risk of

electric shock or fire.

6. You must not operate the appliance without the interior lighting lamp cover.

7. The fridge is only applied with power supply of single phase alternating current of

220~240V/50Hz. If fluctuation of voltage in the district of user is so large that the

voltage exceeds the above scope, for safety sake, be sure to apply A.C. Automatic

voltage regulator of more than 350W to the fridge. The fridge must employ a

special power socket instead of common one with other electric appliances. Its plug

must match the socket with ground wire.

www.heinner.com

IV. DAILY USE

•Do not store flammable gass or liquids in the appliance. There is a risk of an

explosion.

•Do not operate any electrical appliances in the appliance (e.g.electric ice cream

makers.mixers etc.).

•When unplugging always pull the plug from the mains socket.do not pull on the

cable.

•Do not place hot items near the plastic components of this appliance.

•Do not place food products directly against the air outlet on the rear wall.

•Store pre-packed frozen food in accordance with the frozen food manufacture's

instructions.

•The appliances manufactures storage recommendations should be strictly adhered

to. Refer to relevant instructions for storage.

•Do not place carbonated or fizzy drinks in the freeze compartment as it creates

pressure on the container.which may cause it to explode,resulting in damage to the

appliance.

•Frozen food can cause frost burns if consumed straight from the freezer

compartment.

•Do not place the appliance in direct sunlight.

•Keep burning candles lamps and other items with naked flames away from the

appliance so that do not set the appliance on fire.

•The appliance is intended for keeping food stuff and/or beverages in normal

household as explained in this instruction booklet. The appliance is heavy. Care

should be taken when moving it.

•Do not remove nor touch items from the freezer compartment if your hands are

damp/wet, as this could cause skin abrasions or frost/freezer burns.

•Never use the base drawers, doors etc. to stand on or as supports.

•Frozen food must not be refrozen once it has been thawed out.

•Do not consume ice popsicles or ice cubes straight from the freezer as this can cause

freezer burn to the mouth and lips.

•To avoid items falling and causing injury or damage to the appliance, do not overload

the door racks or put too much food in the crisper drawers.

•This refrigerating appliance is not intended to be used as a a built-in appliance.

www.heinner.com

V. CLEANING AND MAINTENANCE

VI. INSTALLATION

•For electrical connection carefully, follow the instructions given in this manual.

•Unpack the appliance and check if there are damages on it.

•Do not connect the appliance if it is damaged. Report possible damages immediately

to the place you bought it. In this case retain packing.

•It is advisable to wait at least four hours before connecting the appliance to allow the

oil to flow back in the compressor.

•Adequate air circulation should be around the appliance, lacking this leads to

overheating. To achieve sufficient ventilation, follow the instructions relevant to

installation.

•Wherever possible the back of the product should not be too close to a wall to avoid

touching or catching warm parts (compressor, condenser) to prevent the risk of a fire,

follow the instructions relevant to installation.

•The appliance must not be locate close to radiators or cookers.

•Make sure that the mains plug is accessible after the installation of the appliance.

•Before maintenance, switch off the appliance and disconnect the mains plug from the

mains socket.

•Do not clean the appliance with metal objects, steam cleaner, ethereal oils, organic

solvents or abrasive cleansers.

•Do not use sharp objects to remove frost from the appliance. Use a plastic scraper.

www.heinner.com

Service

•Any electrical work required to do the servicing of the appliance should be carried out

by qualified electrician or competent person.

•This product must be serviced by an authorized Service Center, and only genuine

spare parts must be used.

If the appliance is No Frost.

If the appliance contains freezer compartment.

Energy Saving tips

We recommend that you follow the tips below to save energy.

•Try to avoid keeping the door open for long periods in order to conserve energy.

•Ensure the appliance is away from any sources of heat (Direct sunlight, electric oven

or cooker etc).

•Don't set the temperature colder than necessary.

•Don't store warm food or evaporating liquid in the appliance.

•Place the appliance in a well ventilated, humidity free, room. Please refer to Installing

your new appliance chapter.

•If the diagram shows the correct combination for the drawers, crisper and shelves, do

not adjust the combination as this is designed to be the most energy efficient

configuration.

VII. SERVICE AND ENERGY SAVING

www.heinner.com

VIII. PRODUCT DESCRIPTION

1. Controller box and LED light

2. Door switch

3. Shelves

4. Crisper box cover

5. Crisper drawer

6. Freezer upper drawer

7. Freezer lower drawer

8. Adjustable bottom feet

9. Egg tray (inside)

10. Upper rack

11. Middle rack

12. Water storage box pack

13. Refrigerator door

14. Lower rack

15. Freezer door

Due to constant development of our products, your refrigerator may be slightly different from

this instruction manual, but its functions and usage remain the same. To get more space in

freezer, you can remove drawers (except the bottom freezer drawer), ice tray.

To get the best energy efficiency of this product, please place all shelves, drawers and baskets

on their original position as the illustration above.

www.heinner.com

IX. INSTALLING

Before using the appliance for the first time, you should review the following tips.

Ventilation of appliance

In order to improve efficiency of the cooling system and save energy, it is necessary to maintain

good ventilation around the appliance. For this reason, sufficient clear space should be available

around the refrigerator.

It is advisable for there to be at least (50~70) mm of space from the back to the wall, at least

100mm from its top, at last 100mm from its side to the wall and a clear space in front to allow

the doors to open 135°. Please see the following diagrams.

Note: This appliance performs well within the climate class from N to ST showed in the table

below. It may not work properly if left at a temperature above or below the indicated range for

a long period.

Climate class

Ambient temperature

+10°C to +32°C

+16°C to +32°C

+16°C to +38°C

+16°C to +43°C

Stand your appliance in a dry place to avoid moisture damage.

Keep the appliance out of direct sunlight, rain or frost. Stand the appliance away from heat

sources such as stoves, fires or heaters.

Levelling of appliance

For sufficient leveling and air circulating in the lower rear section of the appliance, the bottom

feet may need to be adjusted

You can adjust them manually using a suitable spanner. To allow the doors to self-close, tilt the

top backwards by about 10mm.

Reversing the door

The side at which the door opens can be changed, from the right side (as supplied) to the left

side, if required.

Warning! When reversing the door, the appliance must not be connected to the mains. Ensure

that the plug is removed from the mains socket.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Heinner Kühlschrank Handbücher

Heinner

Heinner HC-V336F+ Bedienungsanleitung

Heinner

Heinner HF-205A+ Bedienungsanleitung

Heinner

Heinner HF-M207SA+ Bedienungsanleitung

Heinner

Heinner HCNF-V291XWDF+ Bedienungsanleitung

Heinner

Heinner HC-M241NFBI+ Bedienungsanleitung

Heinner

Heinner HMB-47NHA+ Bedienungsanleitung

Heinner

Heinner HC-V286WDF+ Bedienungsanleitung

Heinner

Heinner HSBS-441NFXF+ Bedienungsanleitung

Heinner

Heinner HF-N250F+ Bedienungsanleitung

Heinner

Heinner HMB-41NHF+ Bedienungsanleitung

Heinner

Heinner HF-V89F+ Bedienungsanleitung

Heinner

Heinner HSBS-M490ICEX++ Bedienungsanleitung

Heinner

Heinner HF-H425NFWA+ Bedienungsanleitung

Heinner

Heinner HC-H292A+ Bedienungsanleitung

Heinner

Heinner HF-V401NFWF+ Bedienungsanleitung

Heinner

Heinner HC-V270SWDE++ Bedienungsanleitung

Heinner

Heinner HMB-42A+ Bedienungsanleitung

Heinner

Heinner HF-302A+ Bedienungsanleitung

Heinner

Heinner HF-V122F+ Bedienungsanleitung

Heinner

Heinner HF-H355NFDXE++ Bedienungsanleitung

Heinner

Heinner HMB-N45F+ Bedienungsanleitung

Heinner

Heinner HF-227A+ Bedienungsanleitung

Heinner

Heinner HF-250A+ Bedienungsanleitung

Heinner

Heinner HC-290A+ Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
