Heroproof BFGUN STEALTH Bedienungsanleitung
O W N E R S M A N UA L
Ultra-Quiet H y p erDriv e
P e r cussi v e M a ssage r
EN
Preface
With the engineering of BFGun HyperDrive Percussive Massager, the breakthrough technology enables the
powerful massager to increase training efficiency, accelerate muscle mass gain, boost athlec
performance, and relief common injuries & condions.
Numerous independent clinical trials and studies have confirmed the efficacy of HyperDrive Percussive
Therapy/Massage. Percussive massage accelerates the growth and repair of ssues by providing
concentrated, rapid, short-duraon pulses deep into the ssues of the body. This heavily increases blood
flow to the area causing pain relief and an increasing range of moon and funcon. Percussive massage
alsoprovides a gentle stretch to the muscles and connecve ssues improving responsiveness and
performance. In addion, BFGun is a perfect companion for athletes and fitness professionals to achieve
opmal pre-work warm-ups and balanced post-workout warm-downs releases.
Heroproof helps bring out the hero that is in each and everyone of us with unwavering pursuit of
innovaon in performance enhancing and sports recovery technologies.
Detachable Massage Head
Speed Selector
Speed Indicator
Battery Indicator
Battery Release Grip
Battery
OPTIMAL USAGE
Clinical studies have shown that opmal results may be achieved by targeng each area or muscle group
for between 2 and 3 minutes. If you are experiencing extra soreness or pain, you may target the area for
addional 30~60 seconds throughout the day.
Unlike tradional "vibrang" massager, BFGun ulizes HyperDrive Percussive Technology to deliver
concentrated, rapid, and deep-ssue massage. Simply hold the BFGun close to the target area, and
glide the percussive massager over the intended area, enabling the BFGun to do its work. Once you
are comfortable and experienced with the pressure and intensity, you maychoose to apply addional
force as needed.
OPERATIONS GUIDE
1 BATTERY
When inserting the battery, please align the push-release spring on the battery to
the battery release button on to the massager, then insert the battery(Figure 1).
If you wish to remove the battery, press the battery release button, and pull the
battery away from the massager at the same time. (Figure 2).
Figure 1 Figure 2
Figure 3
Figure 4
2 POWER ON/OFF SWITCH
Power switch is located on the bottom of the battery unit. To power on the massager,
slide the power switch to the on position. Prior to removing the battery for storage
or travel, always turn the massager off by sliding the power switch to the off position.
3 BATTERY INDICATOR
The Battery Indicator enables user to quickly identify how much power is remaining.
When display is showing 99, the battery is completely full (this is a 2-digit display, so
99 is the maximum value). Recharge the battery with the supplied power adapter
when battery drops to 20 or below.
Full
Medium
Low
4 GEAR INDICATOR
The number on the left side of the screen represents the current gear setting. For 01
gear, pulse frequency is 1200spm (30PPM). BFGun stealth incorporates an electronic
controlled 6-speed gear box. With each increase in gear, the speed is increased by
400spm (about 7PPM). Highest gear is 6 with a pulse frequency of 3200spm (53PPM).
To ensure safety and prevent injury, BFGun is programmed with built-in safety
timer to limit each percussive therapy session to 10 minutes. And to ensure
long-term performance of the high-speed motor, we recommend to allow the
massager to cool-down for 15 minutes after 3 consecutive 10-minute uses.
Power OffPower On
Figure 5
Increase Speed
(each gear
increases the speed by ~400spm)
Decrease Speed
(each gear
decreases the speed by ~400spm)
*Note: powering on the unit does not start the massager. To start the massager,
*press the “+” button to actuate.
*PPM = Percussion Per Minute.
Figure 6
Charging-Red LED on
Figure 7
Fully Charged-Green LED on
5 QUICK ASSEMBLY MASSAGE HEAD SYSTEM
With the massager off, pull the attachment away from the head to remove. To attach,
align and press the attachment into the massage head.
Prior to charging, turn off the massager by sliding the power switch to the off position.
Never charge the unit while it is in-use.
Battery may remain inserted in the massager while charging. Use only the provided
charging adapter.
Connect the charging plug into the charging port on the bottom of the battery. Red
LED on the charging adapter indicates charging is in progress (full-charge requires
approximately 1.5 ~ 2.0 hours). When fully charged, the LED turns to green.
6 CHARGING
SAET INSTRUCTIONS:
TO REDUCE THE RISK OF ELECTRIC SHOCK, FIRE AND PERSONAL INJURY,
THIS PRODUCT MUST BE USED IN ACCORDANCE WITH THE FOLLOWING
INSTRUCTIONS.
Only allowed for adults.
This device cannot directly massage the surface of the skin to avoid injury to the skin,
the massage area should be worn after wearing dry and clean clothes or a clean and
dry towel, you need to gently press and move, the massage time of the same part
can not exceed 60s.
Use high speed and high pressure only for soft tissue parts of the body without
causing pain and discomfort, do not use high speed and high pressure on the head
and any bone parts of the body.
According to the massage needs of different parts, please choose the right massage
head.
Frequent use of high-speed high pressure to apply pressure on the same part will
cause abrasions, if you feel painful and uncomfortable, please stop using immediately.
Finger, hair or any part of the body, please keep away from the telescopic rod of the
device and the heat dissipation hole of the motor to prevent from pinching injury.
Do not place anything in the heat sink of the motor.
The equipment should not be diffused into the water, never let the water from the
motor cooling hole into the equipment.
Do not discard and misuse this device.
Only use the original charger to charge.
Carefully check your device and battery before each use.
Do not make any private modifications to the equipment.
Do not run the device and charge the device in an unmanned state.
Do not stay in the water, keep the machine away from liquids and heat sources, to
ensure the motor cooling holes are free of dust and debris.
Do not remove the screws by yourself.
Turn off the device after one hour of operation and use it after rest for half an hour.
Remove the charger from the battery after charging, and do not use the device
during charging.
The use of this device for the injured part of the body is prohibited without consulting
the doctor.
MAINTENANCE:
Wipe the surface of the device with a slightly damp towel and dry with a soft cloth.
When storing or traveling for a long time, separate the device from the battery and
place it in the device's original case.
ARNING:
G EA R 1 G EA R 2 G EA R 3 G EA R 4 G EA R 5 G EA R 6
SPM
St r o k e Pe r
Mi n u t e
12 00 1600 2000 2400 2 800 3200
PPM
Pe r c u s s i o n Pe r
Mi n u t e
202633 404653
TECHNICAL DETAILSDISCLAIMER:
Please read the instruction manual carefully before using this equipment,use this
equipment correctly in accordance with the instructions, our company will not be
liable for any damage or loss to the customer caused by the uncorrect use of this
equipment as explained.
Do not use this device without the approval of your doctor if:pregnancy, diabetes and
complications, neuropathy or retinal damage, pacemaker wear, had surgery recently,
migraines,disc protrusion or spinalinflammation,recently, IUDs have been had or have
health problems.
You must consult your doctor first and use it with your doctor's permission.
We are studying the effects of the device on specific medical conditions,this may cause
the above taboo symptoms to be not detailed enough, if you are unwell please stop
using, follow the advice of a physician or physiotherapist.
Damage to this equipment caused by man-made incorrect operation or transport.
Unauthorized removal and repair of this equipment.
Did not follow the instruction manual.
Overloaded use of this product design parameter.
Damage due to the customer's unusually poor storage or maintenance environment.
Failure to provide proof of purchase date.
WARRANTY INSTRUCTIONS:
WE PROVIDE WARRANTY FOR BATTERY, MOTOR, CONTROLLER OF ONE
YEAR, OTHER WEARING PARTS WARRANTY OF THREE MONTHS.
EXCEPT WHILE:
AC Charger
Rated input 100-240V~50/60Hz
25.2V/1.0A
Rated output
Battery
Rated Voltage 24V DC
Li-ion
1500mAh
3h
1.5h
Type
Capacity
Working time
Charging time
Massager
No-load speed 1200-3200spm
12mm
Stroke length
Contact Support:
www.heroproof.com
Contact Support:
MANUEL D’UTILISATION
Appareil de massage à percussion
très silencieux
FR
Preface
L’ingénierie, la technologie révoluonnaire et la puissance de l’appareil de massage à percussion BFGun HyperDrive
vous permeent d'augmenter l'efficacité de votre entraînement sporf, d'accélérer la croissance de votre masse
musculaire, de booster votre performance sporve et de soulager les blessures et condions physiques qui sont
fréquentes telles que la raideur musculaire, la mobilité, les courbatures et la douleur.
Le BFGun est doté de la technologie brevetée WhisperDrive, qui réduit considérablement le niveau sonore
(jusqu'à 46 % plus silencieux que les produits concurrents) vous permeant d’uliser
l’appareil de massage où vous voulez et quand vous voulez.
De nombreuses études et essais cliniques indépendants ont confirmé l'efficacité de l’appareil de massage/thérapie à
percussion HyperDrive. Le massage à percussion permet d’accélérer la croissance et la réparaon des ssus grâce à
des impulsions concentrées, rapides et courtes en profondeur dans les ssus de votre corps. Ceci augmente
considérablement le flux sanguin vers la zone douloureuse soulageant la douleur et améliorant le mouvement et les
foncons. Le massage à percussion permet également d'érer tout en douceur les muscles et les ssus conjoncfs, ce
qui améliore leur réacvité et performance. De plus, l’appareil BFGun est idéal pour les athlètes et les professionnels
du condionnement physique pour l’échauffement avant l'entraînement et il offre la possibilité de faire des exercices
équilibrés après l'entraînement.
Heroproof fait ressorr le héros qui est en vous à la recherche d’innovaon en technologies
d'amélioraon de performances et de récupéraon sporve.
T ê te de m assage dé tachable
Sé lection de la v itesse
V oyant de la v itesse
V oyant de la batterie
Bou ton de relâ che de la batterie
Batterie
