HiFiMAN HE-300 Bedienungsanleitung

www.hifiman.com

HiFiMAN HE-300

www.hifiman.com

Owner's Guide

HiFiMAN HE-300 Owner's Guide

Thank you for purchasing the HiFiMAN HE-300, a

full-size headphone that represents our best dynamic

driver technology. We believe the HE-300 is one of the

best headphones of its kind on the market.

This Owner's Guide is intended to provide a useful

overview of your new HE-300 and how to best operate

it for many years of enjoyment, safety and reliability.

Please take the time to familiarize yourself with its

features. If you have any questions or need additional

information, contact your authorized HiFiMAN dealer.

www.hifiman.com

Product Overview

The HiFiMAN HE-300 is a full-size, open-back headphone

design with specially-designed dynamic drivers. While HE-300

can be used with sophisticated audio components, including

dedicated headphone amplifiers, its high efficiency (93dB

sensitivity) means it can also be used with portable audio

devices such as an iPod or iPhone.

The HE-300's robust construction utilizes quality materials

and audiophile-grade detachable cables. Yet its light weight,

plush ear pads and adjustable metal headband provide a

comfortable listening experience you can enjoy for hours on

end.

Connection is made via the supplied cable with screw-on

connections using separate ground leads for each channel

to minimize crosstalk between the channels. An adapter is

supplied so the HE-300 can be used in either a standard

phone jack or in a mini jack as found in portable devices.

HiFiMAN HE-300 Owner's Guide

Key Features and Specifications

● Driver: 50mm diameter Dynamic drivers

● Frequency Response: 15Hz to 22 KHz

● Impedance: 50 Ohms

● Efficiency: 93dB/mW

● Rated Power: 30mW

● Weight: 9.52 Oz (270g)

Accessories

●Storage box

● Silver headphone cable (3m or 10')

● Velour earpads 1 pair (on the headphones)

● 1/4" (6.35mm) headphone adapter

www.hifiman.com

Headband Adjustment for HiFiMAN

Headphones:

If the top of the headband does not touch your head, you can bend

the metal strip inside the headband into shape. To accomplish this,

first use your hands to flatten the top of the headband. Next, you

need increase the curvature of the left and right side. Follow this

procedure until the top of the headband rests on top of your head.

HiFiMAN HE-300 Owner's Guide

Set-up and Operation

1. Please allow at least 150 hours of constant use for break-in of your new

headphone to achieve best sound quality. Volume during the break-in period

does not have to be loud and you can enjoy the HE-300 as you would

normally.

2. To connect your headphones to an amplifier, please use the supplied

cabling. The mini-coax plug with the red dot goes to the right side marked

with R. (Depending on the cable in use, the cable itself can also show L and

R on the plugs.) Push the connector straight onto the socket and then use

your fingers to tighten the washer. When tightening, please make sure to

move the washer only and not the cable as such. A loose connection can

lead to drop outs and distortion. Repeat the process with the other mini-coax

connector.

3. To clean your headphone, please use a soft, slightly damp cloth only. Do not

use any detergents and since it is an open back design, make sure not to let

any fluid enter the open sides of the headphone. The leather headband can

be maintained using standard leather care products. Should your earpads

become worn and no longer offer a good fit with your head, you can replace

them with new ones which can be supplied from your dealer or from www.

head-direct.com.

4. Note: The internal drivers do not require maintenance. Any attempt to

remove, alter or modify them will void your warranty.

www.hifiman.com

Warranty

●One-year free repair when used according to our recommended instructions.

issued. Return shipping to HiFiMAN or authorized service facility is owner's

responsibility.

●For residential use only.

For any further information or questions, please contact your authorized

HiFiMAN dealer. Or email us directly at [email protected].

www.hifiman.com

HiFiMAN HE-300 Owner's Guide

Customer Service Tel: 1-201-443-4626

Email: [email protected]

Address: 143 Rickey Blvd, Bear, DE 19701 US

Web: hifiman.com
