Network Video Recorder

User Manual

UD.6L0202D1937A01

User Manual of Network Video Recorder

User Manual

Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou

Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user

manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed,

partially or wholly, by any means, without the prior written permission of Hikvision. Unless otherwise stipulated,

Hikvision does not make any warranties, guarantees or representations, express or implied, regarding to the

Manual.

About this Manual

This Manual is applicable to Network Video Recorder (NVR).

The Manual includes instructions for using and managing the product. Pictures, charts, images and all other

information hereinafter are for description and explanation only. The information contained in the Manual is

subject to change, without notice, due to firmware updates or other reasons. Please find the latest version in the

company website (http://overseas.hikvision.com/en/).

Please use this user manual under the guidance of professionals.

Trademarks Acknowledgement

and other Hikvision’s trademarks and logos are the properties of Hikvision in various

jurisdictions. Other trademarks and logos mentioned below are the properties of their respective owners.

Legal Disclaimer

TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE PRODUCT DESCRIBED, WITH

ITS HARDWARE, SOFTWARE AND FIRMWARE, IS PROVIDED “AS IS”, WITH ALL FAULTS AND

ERRORS, AND HIKVISION MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT

LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, FITNESS FOR A PARTICULAR

PURPOSE, AND NON-INFRINGEMENT OF THIRD PARTY. IN NO EVENT WILL HIKVISION, ITS

DIRECTORS, OFFICERS, EMPLOYEES, OR AGENTS BE LIABLE TO YOU FOR ANY SPECIAL,

CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS,

DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR

DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS

BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.

REGARDING TO THE PRODUCT WITH INTERNET ACCESS, THE USE OF PRODUCT SHALL BE

WHOLLY AT YOUR OWN RISKS. HIKVISION SHALL NOT TAKE ANY RESPONSIBILITES FOR

ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER

ATTACK, HACKER ATTACK, VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS;

HOWEVER, HIKVISION WILL PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.

SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR

JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS

THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS

USED WITH ILLEGITIMATE PURPOSES.

IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE

LATER PREVAILS.

User Manual of Network Video Recorder

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to comply with the limits for a digital device,

pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses, and

can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may

cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to

cause harmful interference in which case the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE" and comply

therefore with the applicable harmonized European standards listed under the EMC Directive

2004/108/EC, the RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper recycling, return this product to your local

supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection

points. For more information see: www.recyclethis.info

2006/66/EC (battery directive): This product contains a battery that cannot be disposed of as unsorted

municipal waste in the European Union. See the product documentation for specific battery

information. The battery is marked with this symbol, which may include lettering to indicate

cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a

designated collection point. For more information see: www.recyclethis.info

Industry Canada ICES-003 Compliance

This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.

User Manual of Network Video Recorder

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss.

The precaution measure is divided into “Warnings” and “Cautions”

Warnings: Serious injury or death may occur if any of the warnings are neglected.

Cautions: Injury or equipment damage may occur if any of the cautions are neglected.

Warnings

●Proper configuration of all passwords and other security settings is the responsibility of the installer and/or

end-user.

●In the use of the product, you must be in strict compliance with the electrical safety regulations of the nation

and region. Please refer to technical specifications for detailed information.

●Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with

100~240 VAC or 12 VDC according to the IEC60950-1 standard. Please refer to technical specifications for

detailed information.

●Do not connect several devices to one power adapter as adapter overload may cause over-heating or a fire

hazard.

●Please make sure that the plug is firmly connected to the power socket.

●If smoke, odor or noise rise from the device, turn off the power at once and unplug the power cable, and then

please contact the service center.

Warnings Follow these

safeguards to prevent serious

injury or death.

Cautions Follow these

precautions to prevent

potential injury or material

damage.

User Manual of Network Video Recorder

Preventive and Cautionary Tips

Before connecting and operating your device, please be advised of the following tips:

•Ensure unit is installed in a well-ventilated, dust-free environment.

•Unit is designed for indoor use only.

•Keep all liquids away from the device.

•Ensure environmental conditions meet factory specifications.

•Ensure unit is properly secured to a rack or shelf. Major shocks or jolts to the unit as a result of dropping it

may cause damage to the sensitive electronics within the unit.

•Use the device in conjunction with an UPS if possible.

•Power down the unit before connecting and disconnecting accessories and peripherals.

•A factory recommended HDD should be used for this device.

•Improper use or replacement of the battery may result in hazard of explosion. Replace with the same or

equivalent type only. Dispose of used batteries according to the instructions provided by the battery

manufacturer.

User Manual of Network Video Recorder

Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer.

The figures in the manual are for reference only.

This manual is applicable to the models listed in the following table.

Series

Model

9600NI-ST

DS-9608NI-ST

DS-9616NI-ST

DS-9632NI-ST

DS-9664NI-ST

9600NI-RT

DS-9608NI-RT

DS-9616NI-RT

DS-9632NI-RT

DS-9664NI-RT

9600NI-XT

DS-9616NI-XT

DS-9632NI-XT

DS-9664NI-XT

8600NI-ST

DS-8608NI-ST

DS-8616NI-ST

DS-8632NI-ST

DS-8664NI-ST

7700NI-ST

DS-7708NI-ST

DS-7716NI-ST

DS-7732NI-ST

DS-7764NI-ST

7700NI-SP

DS-7708NI-SP

DS-7716NI-SP

DS-7732NI-SP

7600NI-ST

DS-7608NI-ST

DS-7616NI-ST

DS-7632NI-ST

7600NI-SP

DS-7608NI-SP

DS-7616NI-SP

DS-7632NI-SP

DS-8600NI-E8

DS-8664NI-E8

DS-8600NI-F8

DS-8608NI-F8

DS-8616NI-F8

DS-8632NI-F8

DS-8664NI-F8

DS-9600NI-F8

DS-9608NI-F8

DS-9616NI-F8

DS-9632NI-F8

DS-9664NI-F8

User Manual of Network Video Recorder

Product Key Features

General

Connectable to network cameras, network dome and encoders.

Connectable to the third-party network cameras like ACTI, Arecont, AXIS, Bosch, Brickcom, Canon,

PANASONIC, Pelco, SAMSUNG, SANYO, SONY, Vivotek and ZAVIO, and cameras that adopt

ONVIF or PSIA protocol.

Connectable to the smart IP cameras.

PAL/NTSC adaptive video inputs.

Each channel supports dual-stream.

Up to 32 network cameras for DS-7600NI-ST&SP and DS-7700NI-SP series NVR and up to 64 network

cameras for other models.

Independent configuration for each channel, including resolution, frame rate, bit rate, image quality, etc.

The quality of the input and output record is configurable.

Local Monitoring

Simultaneous HDMI, VGA and CVBS outputs.

HDMI output and VGAoutput at up to 1920×1080 resolution.

Multiple screen display in live view is supported, and the display sequence of channels is adjustable.

Live view screen can be switched in group. Manual switch and auto-switch are provided and the

auto-switch interval is configurable.

Quick setting menu is provided for live view.

Motion detection, video tampering, video exception alert and video loss alert functions.

Privacy mask.

Multiple PTZ protocols supported; PTZ preset, patrol and pattern.

Zooming in by clicking the mouse and PTZ tracing by dragging mouse.

HDD Management

For 9600NI-XT series, up to 16 SATA hard disks and 2 eSATA disks can be connected. For

7700NI-ST/SP series, 4 SATA hard disks and 1 eSATA disk can be connected. For 7600NI-ST/SP series,

2 SATA hard disks and 1 eSATA disks can be connected. And up to 8 SATA hard disks and 1 eSATA disk

can be connected for other models. (Each disk with a maximum of 4TB storage capacity.)

Support 8 network disks (NAS/IP SAN disk).

Support eSATA disks for recording or backup.

Support S.M.A.R.T. and bad sector detection. (Not supported with DS-9600NI-RT series NVR.)

HDD group management.

Support HDD standby function.

HDD property: redundancy, read-only, read/write (R/W).

HDD quota management; different capacity can be assigned to different channel.

Hot-swappable HDD supporting RAID0, RAID1, RAID5 and RAID10 storage scheme. And 8 virtual

disks can be configured. (Only for the DS-9600NI-RT series NVR.)

Hot-swappable HDD supporting RAID0, RAID1, RAID5 and RAID10 storage scheme, and can be

enabled and disabled on your demand. And 16 arrays can be configured. (Only for the DS-9600NI and

DS-8600NI series NVR.)

Support disk clone to the eSATA disk.

User Manual of Network Video Recorder

Recording, Capture and Playback

Holiday recording schedule configuration.

Continuous and event video recording parameters.

Multiple recording types: manual, continuous, alarm, motion, motion | alarm, motion & alarm and VCA

8 recording time periods with separated recording types.

Pre-record and post-record for alarm, motion detection for recording, and pre-record time for schedule

and manual recording.

Searching record files and captured pictures by events (alarm input/motion detection).

Tag adding for record files, searching and playing back by tags.

Locking and unlocking record files.

Local redundant recording and capture.

Provide new playback interface with easy and flexible operation.

Searching and playing back record files by channel number, recording type, start time, end time, etc.

Smart search for the selected area in the video.

Zooming in when playback.

Reverse playback of multi-channel.

Supports pause, play reverse, speed up, speed down, skip forward, and skip backward when playback,

and locating by dragging the mouse.

Up to 16-ch synchronous playback at 4CIF real time.

Manual capture, continuous capture of video images and playback of captured pictures.

Backup

Export video data by USB, SATA or eSATA device.

Export video clips when playback.

Management and maintenance of backup devices.

Either Normal or Hot Spare working mode is configurable to constitute an N+1 hot spare system.

Alarm and Exception

Configurable arming time of alarm input/output.

Alarm for video loss, motion detection, tampering, abnormal signal, video input/output standard

mismatch, illegal login, network disconnected, IP confliction, abnormal record/capture, HDD error, and

HDD full, etc.

VCA detection alarm is supported.

VCA search for face detection, vehicle plate, behavior analysis, people counting and heat map.

Alarm triggers full screen monitoring, audio alarm, notifying surveillance center, sending email and

alarm output.

Automatic restore when system is abnormal.

Other Local Functions

Operable by front panel, mouse, remote control, and control keyboard.

Three-level user management; admin user is allowed to create many operating accounts and define their

operating permission, which includes the limit to access any channel.

Operation, alarm, exceptions and log recording and searching.

Manually triggering and clearing alarms.

Import and export of device configuration information.

Network Functions

2 self-adaptive 10M/100M/1000M network interfaces, and various working modes are configurable:

multi-address, load balance, network fault tolerance, etc. (Two NICs are only for the DS-9600NI and

User Manual of Network Video Recorder

DS-8600NI series NVR.)

8 independent PoE network interfaces are provided for DS-7600NI-SP series and up to 16 independent

PoE network interfaces are provided for DS-7700NI-SP series.

IPv6 is supported.

TCP/IP protocol, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, and iSCSI are

supported.

TCP, UDP and RTP for unicast.

Auto/Manual port mapping by UPnPTM.

Remote web browser access by HTTPS ensures high security.

The ANR (Automatic Network Replenishment) function is supported, it enables the IP camera save the

recording files in the local storage when the network is disconnected, and synchronizes the files to the

NVR when the network is resumed.

Remote reverse playback via RTSP.

Support accessing by the platform via ONVIF.

Remote search, playback, download, locking and unlocking of the record files, and support downloading

files broken transfer resume.

Remote parameters setup; remote import/export of device parameters.

Remote viewing of the device status, system logs and alarm status.

Remote keyboard operation.

Remote locking and unlocking of control panel and mouse.

Remote HDD formatting and program upgrading.

Remote system restart and shutdown.

RS-232, RS-485 transparent channel transmission.

Alarm and exception information can be sent to the remote host

Remotely start/stop recording.

Remotely start/stop alarm output.

Remote PTZ control.

Remote JPEG capture.

Virtual host function is provided to get access and manage the IP camera directly.

Two-way audio and voice broadcasting.

Embedded WEB server.

Development Scalability:

SDK for Windows system.

Source code of application software for demo.

Development support and training for application system.

User Manual of Network Video Recorder

TABLE OF CONTENTS

Product Key Features ..............................................................................................................................6

Chapter 1 Introduction........................................................................................................................14

1.1 Front Panel ....................................................................................................................................15

1.2 IR Remote Control Operations......................................................................................................22

1.3 USB Mouse Operation ..................................................................................................................24

1.4 Input Method Description..............................................................................................................25

1.5 Rear Panel .....................................................................................................................................26

Chapter 2 Getting Started ...................................................................................................................31

2.1 Starting Up and Shutting Down the NVR......................................................................................32

2.2 Setting the Admin Password..........................................................................................................33

2.3 Using the Wizard for Basic Configuration.....................................................................................34

2.4 Login and Logout..........................................................................................................................38

2.4.1 User Login ...........................................................................................................................38

2.4.2 User Logout.........................................................................................................................38

2.5 Adding and Connecting the IP Cameras........................................................................................40

2.5.1 Activating the IP Camera.....................................................................................................40

2.5.2 Adding the Online IP Cameras.............................................................................................41

2.5.3 Editing the Connected IP Cameras and Configuring Customized Protocols........................44

2.5.4 Editing IP Cameras Connected to the PoE Interfaces ..........................................................47

Chapter 3 Live View.............................................................................................................................50

3.1 Introduction of Live View .............................................................................................................51

3.2 Operations in Live View Mode......................................................................................................52

3.2.1 Front Panel Operation on Live View....................................................................................52

3.2.2 Using the Mouse in Live View.............................................................................................53

3.2.3 Using an Auxiliary Monitor.................................................................................................54

3.2.4 Quick Setting Toolbar in Live View Mode ..........................................................................54

3.3 Adjusting Live View Settings........................................................................................................57

3.4 Channel-zero Encoding .................................................................................................................59

Chapter 4 PTZ Controls......................................................................................................................60

4.1 Configuring PTZ Settings..............................................................................................................61

4.2 Setting PTZ Presets, Patrols & Patterns.........................................................................................62

4.2.1 Customizing Presets.............................................................................................................62

4.2.2 Calling Presets .....................................................................................................................62

4.2.3 Customizing Patrols.............................................................................................................63

4.2.4 Calling Patrols .....................................................................................................................64

4.2.5 Customizing Patterns...........................................................................................................65

4.2.6 Calling Patterns....................................................................................................................65

4.2.7 Customizing Linear Scan Limit ...........................................................................................66

4.2.8 Calling Linear Scan .............................................................................................................67

4.2.9 One-touch Park....................................................................................................................67

4.3 PTZ Control Panel.........................................................................................................................69

Chapter 5 Recording and Capture Settings.......................................................................................70

Andere Handbücher für DS-9608NI-ST Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere HIK VISION Netzwerk-Hardware Handbücher

HIK VISION

HIK VISION HWN-4116MH Bedienungsanleitung

HIK VISION

HIK VISION UD04701B Bedienungsanleitung

HIK VISION

HIK VISION iDS-9600NXI-I16/4F Series Bedienungsanleitung

HIK VISION

HIK VISION DS-3WF Series Bedienungsanleitung

HIK VISION

HIK VISION DS-7100NI-SL series Bedienungsanleitung

HIK VISION

HIK VISION DS-7600NI-12 Series Bedienungsanleitung

HIK VISION

HIK VISION DS-76xxNI-Ex/xP Bedienungsanleitung

HIK VISION

HIK VISION DS-7600NI-KI/W Series Bedienungsanleitung

HIK VISION

HIK VISION DS-8600 Series Bedienungsanleitung

HIK VISION

HIK VISION DS-96064NI-I16 Bedienungsanleitung

HIK VISION

HIK VISION DS-9608NI-I8 Bedienungsanleitung

HIK VISION

HIK VISION DS-9632NI-I8 Bedienungsanleitung

HIK VISION

HIK VISION UD.6L0202B1194A01 Benutzerhandbuch

HIK VISION

HIK VISION iDS-96000NXI-I16B Series Bedienungsanleitung

HIK VISION

HIK VISION DS-3WF03C Bedienungsanleitung

HIK VISION

HIK VISION HiLook NVR-104H-D Bedienungsanleitung

HIK VISION

HIK VISION DS-9608NI-I8 Bedienungsanleitung

HIK VISION

HIK VISION DS-7716NI-I4/16P Bedienungsanleitung

HIK VISION

HIK VISION 7600NI-SE Series Bedienungsanleitung

HIK VISION

HIK VISION DS-7604NI-KI/W Bedienungsanleitung

HIK VISION

HIK VISION DeepinMind Super iDS-96128NXI-I24 Bedienungsanleitung

HIK VISION

HIK VISION DS-9616NI-I8 Bedienungsanleitung

HIK VISION

HIK VISION DS-9616NI-I8 Bedienungsanleitung

HIK VISION

HIK VISION DS-7104NI-SL Bedienungsanleitung

Beliebte Netzwerk-Hardware Handbücher anderer Marken

Matrix Switch Corporation

Matrix Switch Corporation MSC-HD161DEL Bedienungsanleitung

B&B Electronics

B&B Electronics ZXT9-IO-222R2 Bedienungsanleitung

Yudor

Yudor YDS-16 Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-320L Bedienungsanleitung

Samsung

Samsung ES1642dc Gebrauchsanweisung

Honeywell Home

Honeywell Home LTEM-PV Montageanleitung

evertz

evertz 7700 Series Bedienungsanleitung

D-Link

D-Link ShareCenter DNS-343 Bedienungsanleitung

Asante

Asante AsanteBridge 1012 Bedienungsanleitung

FireBrick

FireBrick FB2700 Bedienungsanleitung

Audiovox Electronics

Audiovox Electronics ARWH2T Bedienungsanleitung

ADC

ADC DSX-1 Handbuch

NetComm

NetComm NF2 Bedienungsanleitung

Alcatel-Lucent

Alcatel-Lucent 5620 Bedienungsanleitung

Dell EMC

Dell EMC XC6420 Series Bedienungsanleitung

Lanner

Lanner NCA-1020A Bedienungsanleitung

Allied Telesis

Allied Telesis AT-TN121-A Bedienungsanleitung

Arista

Arista CCA-ETM-Q12 Bedienungsanleitung
