Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
1
Speed Dome
Technical Manual
Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2012 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
overseabusiness@hikvision.com
Find out more about HIKVISION at www.hikvision.com
Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
3
DS-2AF1-4XYZ
Key feature
System function:
SONY high performance CCD
±0.1°Preset Accuracy
Self-adaptive to HIKVISION, Pelco-P/D protocol
3D intelligent positioning function
Power-off memory function: restore PTZ & Lens status after reboot
3D DNR
Built-in temperature sensor, with display of internal temperature
RS-485 communication diagnosis capability
Manchester code communication diagnosis capability
Scheduled PTZ movement
Password protection
Camera title programmable
Zone Scanning
Camera function:
Auto iris, auto focus, auto white balance, backlight compensation and auto/manual day & night switch
Privacy masks programmable
PTZ function:
360°endless pan range and -2°-90°tilt range
200°/s Pan Preset Speed and 120°/s Tilt Preset Speed
0.1°-200°/s Manual Pan Speed and 0.1°-120°/s Manual Tilt Speed
255 presets programmable; preset image freezing capability
8 patrols, up to 32 presets per patrol
4 patterns, with the total recording time not less than 10 minutes
Proportional zoom function
Park action: auto call up of PTZ movement, after a defined time of inactivity
2 alarm inputs and 1 alarm outputs
Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
4
Application Scenarios
It can be widely applied to places requiring wide-area monitoring display, such as streets, stations, large venues, outside
of residential areas, etc.
Specifications
Model
Parameter
DS-2AF1-412
DS-2AF1-402
DS-2AF1-432
4 Inch High Speed Dome
Camera
Image Sensor
1/4" SONY Interline Transfer Super HAD-ⅡCCD
Effective Pixel
PAL:752(H)×582(V)
NTSC:768(H)×494(V)
Horizontal
Resolution
Color: 540 TVL
B/W: 600 TVL
Signal System
PAL /NTSC
Min. Illumination
Color: 0.2Lux/ (F1.6 AGC ON)
B/W: 0.02Lux/(F1.6 AGC ON)
White Balance
Auto/ATW/Indoor/Outdoor/One push
AGC
Auto / Manual
S / N Ratio
≥ 50dB
DNR
High/Medium/Low/off
BLC
On / Off
DWDR
128x(On/Off/Auto)
Shutter Time
PAL: 1/50-1/10,000s
NTSC: 1/60-1/10,000s
Day & Night
IR Cut Filter
Digital Zoom
16x
Privacy Mask
8 privacy masks programmable; a maximum of 8 zones can be masked simultaneously on the same video
screen
Focus Model
Auto / Semiautomatic / Manual
Lens
Focal Length
3.8-45.6mm,12x
Zoom Speed
Approx.2s(Optical Wide-Tele)
Angle of View
50.69-4.5degree(Wide-Tele)
Min. Working
Distance
10-1500mm(Wide-Tele)
Aperture Range
F1.6-F2.7
Pan and
Tilt
Pan Range
360°endless
Pan Speed
Pan Manual Speed: 0.1°-200°/s,
Pan Preset Speed: 200°/s
Tilt Range
-2°-90°(Auto Mirror)
Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
5
Tilt Speed
Tilt Manual Speed: 0.1°-120°/s,
Tilt Preset Speed: 120°/s
Proportional
Zoom
Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset
255
Patrol
8 patrols, up to 32 presets per patrol
Pattern
4 patterns, with the total recording time not less than 10 minutes
Power-off
Memory
Support
Park Action
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
PTZ Position
Display
On / Off
Freeze Frame
Support
Password
Protection
Support
Zone
Scanning/Display
Scanning within programmed zone, display zone title
Camera Title
Programmable title display
Compass
Support , the north can be set
Scheduled Task
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
RS-485
communication
diagnosis
Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video screen in
text
Manchester code
communication
diagnosis
Including failure information, e.g., wrong address, baud rate errors s displayed on the video screen in
special characters
Alarm
Alarm Input
2
Alarm Output
1 relay outputs, alarm response actions configurable
Alarm Action
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan / Relay output
Input/
Output
Monitor Output
1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC
General
Menu Language
English, Chinese
RS-485 Protocols
HIKVISION, Pelco-P, Pelco-D, self-adaptive
Power Supply
24VAC/2A (12VDC/2A optional)
Power
Consumption
Max.18 W
Working
Temperature /
Humidity
-30 ℃-65℃(-22℉-149℉)(outdoor dome) / -10℃-50℃(14℉-122℉)(indoor dome )
90% or less
Protection Level
IP66 standard (outdoor dome)
TVS 4,000V lightning protection, surge protection and voltage transient protection
Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
6
Mounting
Various mounting modes optional
Dimension
Φ180×239.5mm (Φ7.08”×9.43”)(Outdoor)
Φ165×172.5mm(Φ6.50”×6.79”) (Indoor)
Φ165×167mm(Φ6.50”×6.57”) (In-ceiling)
Weight (approx.)
4Kg (8.82Ibs) (Outdoor)
3Kg(6.61Ibs) (Indoor/In-ceiling))
Mount Option
Long-arm wall mount: DS-1618ZJ;
Long-arm pendant mount: DS-1662ZJ; Short-arm pendant mount: DS-1661ZJ;
Dimensions
Unit: mm
Bore Size
Embeded
IndoorOutdoor
