Speed Dome
Technical Manual
Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2012 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
overseabusiness@hikvision.com
Find out more about HIKVISION at www.hikvision.com
Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
3
DS-2AF1-7XY-B
Key feature
IR function:
0 Lux minimum illumination
Up to 80m radiation distance
IR light MTBF reaching up to 30,000 hours
System function:
1/4’’ SONY high performance CCD
±0.1°Preset Accuracy
Self-adaptive to HIKVISION, Pelco-P/D protocol
3D intelligent positioning function
Power-off memory function: restore PTZ & Lens status after reboot
Fiber optical interface optional
3D NR
Built-in temperature sensor, with display of internal temperature
RS-485 communication diagnosis capability
Manchester code communication diagnosis capability
Scheduled PTZ movement
Password protection
Camera title programmable
Zone Scanning
Camera function:
Auto iris, auto focus, auto white balance, backlight compensation, WDR and auto/manual day & night switch
Privacy masks programmable
PTZ function:
360°endless pan range and -10°-90°tilt range
240°/s Pan Preset Speed and 200°/s Tilt Preset Speed
0.1°-160°/s Manual Pan Speed and 0.1°-120°/s Manual Tilt Speed
256 presets programmable; preset image freezing capability
Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
4
8 patrols, up to 32 presets per patrol
4 patterns, with the total recording time not less than 10 min
Proportional zoom function
Park action: auto callup of PTZ movement, after a defined time of inactivity
2 alarm inputs and 2 alarm outputs（7 alarm inputs and 2 alarm outputs optional）
Application Scenarios
It can be widely applied to places with no lights or weak lights requiring wide-area and high-speed monitoring, such as
rivers, forests, highways, railways, airports, ports, sentries, squares, parks, scenic sites, streets, stations, large venues,
outside of residential areas, etc
Specifications
Model
Parameter
DS-2AF1-715-B(Outdoor)
IR High Speed Dome
Camera
Image Sensor
1/4" SONY EXVIEW HAD progressive scan CCD
Effective Pixel
PAL:752(H)×582(V)
NTSC:768(H)×494(V)
Horizontal
Resolution
Color: 540 TVL
B/W: 570 TVL
Signal System
PAL /NTSC
Min.Illumination
Color: 0.65Lux/F1.35
B/W: 0.005Lux/F1.35
0 Lux with IR
White Balance
Auto / Manual / ATW / Indoor / Outdoor / Outdoor Auto /sodium lamp
AGC
Auto / Manual
S / N Ratio
≥ 50dB
NR
High/Medium/Low/off
BLC
On / Off
WDR
128x( On / Off/Auto)
Anti-shake
On / Off
Shutter Time
PAL: 1/3-1/10,000s
NTSC: 1/4-1/10,000s
Day & Night
IR Cut Filter
Digital Zoom
12x
Privacy Mask
24 privacy masks programmable; a maximum of 8 zones can be masked simultaneously on the
same video screen
Focus Model
Auto / Semiautomatic / Manual
Lens
Focal Length
3.5-98mm,28X
Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
5
Zoom Speed
Approx.1.7s(Optical Wide-Tele)
Angle of View
55.8-2.1degree(Wide-Tele)
Min. Working
Distance
10-1,500mm(Wide-Tele)
Aperture Range
F1.35-F3.7
Pan and
Tilt
Pan Range
360°endless
Pan Speed
Pan Manual Speed: 0.1°-160°/s,
Pan Preset Speed: 240°/s
Tilt Range
-10°-90°(Auto Flip )
Tilt Speed
Tilt Manual Speed: 0.1°-120°/s,
Tilt Preset Speed: 200°/s
Proportional Zoom
Rotation speed can be adjusted automatically according to zoom multiples
Number of Preset
256
Patrol
8 patrols, up to 32 presets per patrol
Pattern
4 patterns, with the total recording time not less than 10 min
Power-off Memory
Support
Park Action
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
PTZ Position Display
On / Off
Freeze Frame
Support
Password
Protection
Support
Zone
Scanning/Display
Scanning within programmed zone, display zone title
Camera Title
Programmable title display
Compass
Support , the north can be set
Scheduled Task
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan
RS-485
communication
diagnosis
Including failure information, e.g., wrong address, baud rate errors, et., displayed on the video
screen in text
Manchester code
and connection
failures diagnosis
Including failure information, e.g., wrong address, baud rate errors s displayed on the video screen
in special characters
Infrared
IR Range
80m
IR irradiation angle
Adjustable by zoom
Alarm
Alarm Input
2（7 alarm inputs optional）
Alarm Output
2 relay outputs, alarm response actions configurable
Alarm Action
Preset / Patrol / Pattern / Pan scan / Tilt scan / Random scan / Frame scan / Panorama scan /
Relay output
Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
6
Input/
Output
Monitor Output
1.0V[p-p] / 75Ω, NTSC (or PAL) composite, BNC
Fiber
Interfac
e
(availabl
e for
fiber
dome
only)
Data Mode
1-channel analog video and 1-channel reverse RS-485 data
Physical Interface
FC(SC optional)
Fiber Wavelength
TX1310/RX1550nm
Fiber Type
Single Fiber/Singlemode
Transmission
Distance
20Km, 40Km / 60Km/ 80Km optional
General
Menu Language
English, Chinese
RS-485 Protocols
HIKVISION, Pelco-P, Pelco-D, self-adaptive
Power Supply
24VAC (12V DC optional)
Power
Consumption
50W max
Working
Temperature /
Humidity
-30 ℃-65℃(-22℉-149℉)(outdoor dome)
90% or less
Protection Level
IP66 standard (outdoor dome)
TVS 3,000V lightning protection, surge protection and voltage transient protection
Mounting
Various mounting modes optional
Dimension
Φ230.6 ×351.5mm (Φ9.08” ×13.84” ) (Outdoor)
Weight (approx.)
5.5kg(12.13Ibs)
Mount Option
Long-arm wall mount: DS-1614ZJ; Indoor short-arm wall mount: DS-1615ZJ
Corner mount: DS-1633ZJ; Pole Mount: DS-1622ZJ;Power box mount:DS-1634ZJ
Hikvision Technical Manual
©2006 –2012 by HIKVISION. All rights reserved.
7
Dimension
Unit: mm
Accessories
DS-1614ZJ Long-arm Wall Mount Bracket
