HIK VISION DS-2CC102P-IRA Bedienungsanleitung

IR Bullet Camera·User Manual

IR Bullet Camera

User Manual

UD.6L0201D0063A01

IR Bullet Camera·User Manual

Thank you for purchasing our product. If there are any questions,

or requests, please do not hesitate to contact the dealer.

This manual applies to following cameras:

Models

DS-2CC102P(N)-IR1(IR3)

(IR5)

DS-2CC112P(N)-IR1(IR3)

(IR5)

DS-2CC192P(N)-IR1(IR3)

(IR5)

DS-2CC1182P(N)-IR1(IR3)

(IR5)

DS-2CC1192P(N)-IR1(IR3)

(IR5)

DS-2CC11A2P(N)-IR1(IR3)

(IR5)

DS-2CC1172P(N)-IR1T

(IR3T)(IR5T)

DS-2CC1182P(N)-IR1T

(IR3T)(IR5T)

DS-2CC102P(N)-IRA

DS-2CC112P(N)-IRA

DS-2CC192P(N)-IRA

DS-2CC1182P(N)-IRA

DS-2CC1192P(N)-IRA

DS-2CC11A2P(N)-IRA

DS-2CC102P(N)-IR

DS-2CC112P(N)-IR

DS-2CC192P(N)-IR

DS-2CC1132P(N)-IR

IR Bullet Camera·User Manual

This manual may contain several technical incorrect places or

printing errors, and the content is subject to change without notice .

The updates will be added to the new version of this manual. We

will readily improve or update the products or procedures

described in the manual.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the

performance or reliability of the security or signaling aspects of

this product. UL has only tested for fire, shock or casualty hazards

as outlined in UL’s Standard(s) for Safety, UL60950-1. UL

Certification does not cover the performance or reliability of the

security or signaling aspects of this product. UL MAKES NO

REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS

WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY

OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS

PRODUCT.”

0100001021012

IR Bullet Camera·User Manual

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to

comply with the limits for a digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the

interference at his own expense.

FCC Conditions

This device complies w ith part 15 of the FCC Rules. Operation is

subject to the following two condit ions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation

EU Conformity Statement

This product and - if applicable - the supplied

accessories too are marked with "CE" and comply

therefore with the applicable harmonized

European standards listed under the Low Voltage Directive

2006/95/EC, the EMC Directive 2004/108/EC.

IR Bullet Camera·User Manual

2002/96/EC (WEEE directive): Products marked

with this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product

contains a battery that cannot be disposed of as

unsorted municipal waste in the European Union.

See the product documentation for specific battery

information. The battery is marked w ith this

symbol, which may include lettering to indicate cadmium (Cd),

lead (Pb), or mercury (Hg). For proper recycling, return the battery

to your supplier or to a designated collection point. For more

information see: www.recyclethis.info.

IR Bullet Camera·User Manual

Safety Warnings and Cautions

Please pay attention to the following warnings and

cautions:

Hazardous Voltage may be present: Special

measures and precautions must be taken when

using this device. Some potentials (voltages) on the

device may present a hazard to the user. This device

should only be used by Employees from our company with

knowledge and training in working with these types of devices that

contain live circuits.

Power Supply Hazardous Voltage: AC mains voltages

are present within the power supply assembly. This device must be

connected to a UL approved, completely enclosed power supply, of

the proper rated voltage and current. No user serviceable parts

inside the power supply.

System Grounding (Earthing): To avoid shock, ensure

that all AC wiring is not exposed and that the earth grounding is

IR Bullet Camera·User Manual

maintained. Ensure that any equipment to which this device will be

attached is also connected to properly wired grounded receptacles

and are approved medical devices.

Power Connect and Disconnect: The AC

power supply cord is the main disconnect device to

mains (AC power).The socket outlet shall be

installed near the equipment and shall be readily

accessible.

Installation and Maintenance: Do not connect/disconnect

any cables to or perform installation/maintenance on this device

during an electrical storm.

Power Cord Requirements: The connector

that plugs into the wall outlet must be a

grounding-type male plug designed for use in your

region. It must have certification marks showing certification by an

agency in your region. The connector that plugs into the AC

receptacle on the power supply must be an IEC 320, sheet C13,

female connector. See the following website for more information

http://kropla.com/electric2.htm.

Lithium Battery: This device contains a Lithium Battery. There

is a risk of explosion if the battery is replaced by an incorrect type.

IR Bullet Camera·User Manual

Dispose of used batteries according to the vendor’s instructions

and in accordance with local environmental regulations.

Perchlorate Material: Special handling may apply. See

www.dtsc.ca.gov/hazardouswaste/perchlorate. This notice is

required by California Code of Regulations, Title 22, Division 4.5,

Chapter 33: Best Management Practices for Perchlorate Materials.

This device includes a battery which contains perchlorate material.

Taiwan battery recycling:

Please recycle batteries.

Thermal and Mechanical Injury: Some

components such as heat sinks, power regulators,

and processors may be hot; care should be taken

to avoid contact with these components.

Electro Magnetic Interference: This equipment has not

been tested for compliance with emissions limits of FCC and similar

international regulations. This device is not, and may not be,

offered for sale or lease, or sold, or leased until authorization from

the United States FCC or its equivalent in other countries has been

obtained. Use of this equipment in a residential location is

prohibited. This equipment generates, uses and can radiate radio

frequency energy which may result in harmful interference to radio

communications. If this equipment does cause harmful

interference to radio or television reception, which can be

IR Bullet Camera·User Manual

determined by turning the equipment on and off, the user is

required to take measures to eliminate the interference or

discontinue the use of this equipment.

Lead Content:

Please recycle this device in a responsible

manner. Refer to local environmental

regulations for proper recycling; do not dispose

of device in unsorted municipal waste.

IR Bullet Camera·User Manual

Safety Instruction

These instructions are intended to ensure that user can use the

product correctly to avoid danger or property loss.

The precaution measure is divided into “Warnings” and “Cautions”

Warnings: Serious injury or death may occur if any of the

warnings are neglected.

Cautions: Injury or equipment damage may occur if any of the

cautions are neglected.

Warnings

Please adopt the power adapter which can meet the safety

extra low voltage (SELV) request. And source with DC 12V or

AC 24V (depending on models) according to the IEC60950-1

and Limited Power Source standard.

If the product does not work properly, please contact your

dealer or the nearest service center. Never attempt to

Warnings Follow these

safeguards to prevent

serious injury or death.

Cautions Follow these

precautions to prevent

potential injury or material

damage.
