HIK VISION DS-2CD883F-E series Bedienungsanleitung

Network Camera

Operation Guide

UD.6L0201D0041A01

Network Camera·Quick Operation Guide

Thank you for purchasing our product. If there are any questions,

or requests, please do not hesitate to contact the dealer.

About This Manual:

This manual applies to DS-2CD883F-E(W), DS-2CD855F-E,

DS-2CD854F(WD)-E(W), DS-2CD853F-E(W),

DS-2CD864F(WD)-E(W), DS-2CD863PF(NF)-E(W),

DS-2CD893PFWD(NFWD)-E(W), DS-2CD833F-E(W),

DS-2CD893PF(NF)-E(W) series camera.

This manual may contain several technical incorrect places or

printing errors, and the content is subject to change without notice.

The updates will be added to the new version of this manual. We

will readily improve or update the products or procedures

described in the manual.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the

performance or reliability of the security or signaling aspects of

this product. UL has only tested for fire, shock or casualty hazards

as outlined in UL’s Standard(s) for Safety, UL60950-1. UL

Certification does not cover the performance or reliability of the

security or signaling aspects of this product. UL MAKES NO

REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS

WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY

OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS

PRODUCT.

0400031020820

Network Camera·Quick Operation Guide

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to

comply with the limits for a digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the

interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation

EU Conformity Statement

This product and - if applicable - the supplied

accessories too are marked with "CE" and comply

therefore with the applicable harmonized

European standards listed under the Low Voltage Directive

2006/95/EC, the EMC Directive 2004/108/EC.

Network Camera·Quick Operation Guide

2002/96/EC (WEEE directive): Products marked

with this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product

contains a battery that cannot be disposed of as

unsorted municipal waste in the European Union.

See the product documentation for specific battery

information. The battery is marked with this

symbol, which may include lettering to indicate cadmium (Cd),

lead (Pb), or mercury (Hg). For proper recycling, return the battery

to your supplier or to a designated collection point. For more

information see: www.recyclethis.info.

Network Camera·Quick Operation Guide

Contents

1 Appearance Description ................................................ 5

1.1 Camera Description ..............................................5

1.2 Camera wiring diagram .........................................8

2 Installation ................................................................... 9

3 Setting the Network Camera over the LAN .................. 13

4 Accessing via WEB browser......................................... 20

Network Camera·Quick Operation Guide

1Appearance Description

1.1 Camera Description

Figure 1-1 Overview

Table 1-1 Description

No.

Description

Lens mount

Back Focus Ring

SD card slot

Auto-iris interface

10M/100M self-adaptive Ethernet interface

Network Camera·Quick Operation Guide

VIDEO OUT: Video output interface

AUDIO OUT: Audio output interface

POWER: Power LED indicator

Power supply interface

MIC IN: Audio input interface

D+, D-: RS-485 interface

IN, G: Alarm input interface

1A, 1B: Alarm output interface

Ground

RESET: Reset button

Notes:

To reset the default parameters to the camera, you need to

press and hold the RESET button and power on the camera.

After the power on of the camera, you must still press and hold

the Reset button for about 20 seconds.

The type of auto-iris interface is shown as below figure:

Network Camera·Quick Operation Guide

Figure 1-2 Auto-iris Interface

Table 1-2 Pins

DC-driven

Damp-

Damp+

Drive+

Drive-

Power, Video and GND pins are used when the auto-iris is driven by

video; Damp+, Damp-, Drive+ and Drive- pins are used when the

auto-iris is driven by DC.

Network Camera·Quick Operation Guide

1.2 Camera wiring diagram

Figure 1-3 Wiring Diagram

Network Camera·Quick Operation Guide

2Installation

Before you start:

Read the following contents carefully before the installation.

Make sure that all the related equipment is power-off during

the installation.

Check whether the power supply is matched with your AC

outlet to avoid damage.

Do not place the camera in extremely hot or damp

environment. To avoid heat accumulation, good ventilation is

required for a proper operating environment.

If the product does not function properly, please contact your

dealer or the nearest service center. Do not disassemble the

camera for repair or maintenance by yourself.

The box camera can be installed to both wall and ceiling. Ceiling

mounting is taken as an example in this section; if you adopt wall

mounting, you can also take the below procedure as a reference.

Steps:

1. Fix the mounting bracket to the ceiling.
