HIK VISION DS-2CE1582P-VFIR3 Bedienungsanleitung

High-definition IR Water-proof

Bullet Camera

User Manual

UD.6L0201D0086A01

High-definition IR Water-proof Bullet Camera·User Manual

Thank you for purchasing our product. If there are any questions,

or requests, please do not hesitate to contact the dealer.

This manual applies to

DS-2CE1582P (N)-VFIR3

DS-2CC1283P-VFIR3

DS-2CC1283P-AVFIR3

DS-2CC1281P (N)-VFIR3

DS-2CC1281P (N)-AVFIR3

DS-2CC12A1P (N)-VFIR3

DS-2CC12A1P (N)-AVFIR3

This manual may contain several technical incorrect places or

printing errors, and the content is subject to change without notice.

The updates will be added to the new version of this manual. We

will readily improve or update the products or procedures

described in the manual.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the

performance or reliability of the security or signaling aspects of

this product. UL has only tested for fire, shock or casualty hazards

as outlined in UL’s Standard(s) for Safety, UL60950-1. UL

Certification does not cover the performance or reliability of the

security or signaling aspects of this product. UL MAKES NO

REPRESENTATIONS, WARRANTIES OR CERTIFICATIONS

WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY

OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS

PRODUCT.”

0100001030320

High-definition IR Water-proof Bullet Camera·User Manual

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to

comply with the limits for a digital device, pursuant to part 15 of

the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is

operated in a commercial environment. This equipment generates,

uses, and can radiate radio frequency energy and, if not installed

and used in accordance with the instruction manual, may cause

harmful interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the

interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including

interference that may cause undesired operation.

EU Conformity Statement

This product and - if applicable - the supplied

accessories too are marked with "CE" and comply

therefore with the applicable harmonized

European standards listed under the Low Voltage Directive

2006/95/EC, the EMC Directive 2004/108/EC.

High-definition IR Water-proof Bullet Camera·User Manual

2002/96/EC (WEEE directive): Products marked

with this symbol cannot be disposed of as unsorted

municipal waste in the European Union. For proper

recycling, return this product to your local supplier

upon the purchase of equivalent new equipment, or dispose of it at

designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product

contains a battery that cannot be disposed of as

unsorted municipal waste in the European Union.

See the product documentation for specific battery

information. The battery is marked with this

symbol, which may include lettering to indicate cadmium (Cd),

lead (Pb), or mercury (Hg). For proper recycling, return the battery

to your supplier or to a designated collection point. For more

information see: www.recyclethis.info

High-definition IR Water-proof Bullet Camera·User Manual

Table of Contents

1 Introduction ........................................................................6

1.1 Product Features ......................................................6

1.2 Overview .................................................................7

2 Installation..........................................................................8

2.1 Ceiling Mounting ......................................................8

2.2 Power Supply ......................................................... 12

3 Menu Description (A) .......................................................14

3.1 Menu Overview ...................................................... 14

3.2 Exposure................................................................ 15

3.3 Color...................................................................... 22

3.4 Day & Night ........................................................... 23

3.5 Function.................................................................26

3.6 Motion ................................................................... 28

3.7 Privacy................................................................... 30

3.8 Setup..................................................................... 33

3.9 System .................................................................. 36

3.10 Exit ...................................................................... 37

4 Menu Description (B) .......................................................38

4.1 Main Menu ............................................................. 38

4.2 Lens Settings ......................................................... 39

4.3 Shutter/AGC Settings ............................................. 41

4.4 White Balance Settings........................................... 43

4.5 Backlight Settings .................................................. 47

4.6 Picture Adjust Settings ........................................... 47

4.7 ATR Settings .......................................................... 49

4.8 Motion Detection Settings ....................................... 50

4.9 Privacy Mask Settings............................................. 52

High-definition IR Water-proof Bullet Camera·User Manual

4.10 Day/Night Settings ............................................... 53

4.11 NR Settings .......................................................... 56

4.12 Camera ID Settings .............................................. 56

4.13 SYNC Settings ...................................................... 58

4.14 Language Settings................................................ 59

4.15 Camera Reset Settings ......................................... 59

4.16 Pixel Correct Settings ........................................... 59

4.17 Save All/Exit ........................................................ 60

High-definition IR Water-proof Bullet Camera·User Manual

1Introduction

1.1 Product Features

This camera adopts a high-sensitivity sensor and advanced circuit

design technology. It possesses features of high resolution, low

image distortion and low noise, which are suitable for surveillance

system and image processing system.

Adopt high-performance sensor, and w ith a high resolution

which brings high-quality images.

High co lor rendition with Auto White Balance function.

High S/N ratio which makes the image is vivid and clear.

Support Auto Electronic Shutter control to adapt to different

environments.

Support auto gain control to adapt to changing light conditions.

Support Backlight Compensation (BLC), which can adjust the

iris so that the object in the sensitive area is properly exposed.

Bullet camera adopts an advanced product design and the

mounts of them support wiring out from inside.

Adopt unique two-shell design which can ensure the senor has

a proper temperature to get a high quality image.

Ingress Protection level reaches IP66.

High-definition IR Water-proof Bullet Camera·User Manual

1.2 Overview

Figure 1-1 Overview

Bracket

Mounting Base

Power Cable

Video Cable

Zoom

Focus

High-definition IR Water-proof Bullet Camera·User Manual

2Installation

Before you start:

Read the following contents carefully before the installation.

Make sure that all the related equipment is power-off during

the installation.

Check the specification of the products for the installation

environment.

Check whether the power supply is matched w ith your AC

outlet to avoid damage.

If the product does not function properly, please contact your

dealer or the nearest service center. Do not disassemble the

camera for repair or maintenance by yourself.

Ceiling mounting is recommended, we will take ceiling mounting

as an example to explain the installation steps in this chapter.

2.1 Ceiling Mounting

Notes:

1. When mounting the camera, for the cement wall, you need to

mount the base with expansion screws. For the wooden wall,

you need to mount the base with self-tapping screws.

2. Please ensure that the wall is strong enough to withstand more

than 3 times the weight of the camera and the bracket. If the

wall is not strong enough, the camera may fall and cause

serious damage.

High-definition IR Water-proof Bullet Camera·User Manual

3. Before any operation, please make sure that the device in the

package is in good condition and all the assembly parts are

completed.

Steps:

1. Drill the holes on the wall with the supplied drilling template.

2. Route the cables inside the ceiling or on the surface. If you

want to route the cables inside the ceiling, drill the cable hole in

the ceiling for wiring; pull all cables through the hole and

terminate all wires (if not yet terminated).

3. Connect the power cable and video cable and secure the

mounting base w ith camera to the wall with supplied screws.

Figure 2-1 Secure the Camera

4. Three-axis adjustment.

1). Preview the image of the camera on a monitor.

Wall
