HIK VISION E-series Bedienungsanleitung

UD.6L0201B1420A01

E Series

Network Speed Dome

Quick Guide

E Series Network Speed Dome·Quick Guide

Thank you for purchasing our product. If there are any questions, or requests, please do not

hesitate to contact the dealer.

This manual applies to E Series network speed dome.

This manual may contain several technical incorrect places or printing errors, and the content is

subject to change without notice. The updates will be added to the new version of this manual. We

will readily improve or update the products or procedures described in the manual.

DISCLAIMER STATEMENT

“Underwriters Laboratories Inc. (“UL”) has not tested the performance or reliability of the security

or signaling aspects of this product. UL has only tested for fire, shock or casualty hazards as

outlined in UL’s Standard(s) for Safety, UL60950-1. UL Certification does not cover the performance

or reliability of the security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS,

WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY

OF ANY SECURITY OR SIGNALING RELATED FUNCTIONS OF THIS PRODUCT.”

0501081040519

E Series Network Speed Dome·Quick Guide

Regulatory Information

FCC Information

FCC compliance: This equipment has been tested and found to comply with the limits for a digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

FCC Conditions

This device complies with part 15 of the FCC Rules. Operation is subject to the following two

conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received, including interference that may cause

undesired operation

EU Conformity Statement

This product and - if applicable - the supplied accessories too are marked with "CE"

and comply therefore with the applicable harmonized European standards listed

under the Low Voltage Directive 2006/95/EC, the EMC Directive 2004/108/EC, the

RoHS Directive 2011/65/EU.

2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed

of as unsorted municipal waste in the European Union. For proper recycling, return

this product to your local supplier upon the purchase of equivalent new equipment, or

dispose of it at designated collection points. For more information see:

www.recyclethis.info.

2006/66/EC (battery directive): This product contains a battery that cannot be

disposed of as unsorted municipal waste in the European Union. See the product

documentation for specific battery information. The battery is marked with this

symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury

(Hg). For proper recycling, return the battery to your supplier or to a designated

collection point. For more information see: www.recyclethis.info.

E Series Network Speed Dome·Quick Guide

Safety Instruction

These instructions are intended to ensure that user can use the product correctly to avoid danger

or property loss.

The precaution measure is divided into Warnings and Cautions:

Warnings: Neglecting any of the warnings may cause serious injury or death.

Cautions: Neglecting any of the cautions may cause injury or equipment damage.

Warnings

All the electronic operation should be strictly compliance with the electrical safety regulations,

fire prevention regulations and other related regulations in your local region.

Please use the power adapter, which is provided by normal company. For standard of the power

adapter, please refer to the specification manual for details. The power consumption cannot be

less than the required value.

Do not connect several devices to one power adapter as adapter overload may cause over-heat

or fire hazard.

Please make sure that the power has been disconnected before you wire, install or dismantle the

speed dome.

When the product is installed on wall or ceiling, the device shall be firmly fixed.

If smoke, odors or noise rise from the device, turn off the power at once and unplug the power

cable, and then please contact the service center.

If the product does not work properly, please contact your dealer or the nearest service center.

Never attempt to disassemble the speed dome yourself. (We shall not assume any responsibility

for problems caused by unauthorized repair or maintenance.)

Cautions

Do not drop the dome or subject it to physical shock, and do not expose it to high

electromagnetism radiation. Avoid the equipment installation on vibrations surface or places

subject to shock (ignorance can cause equipment damage).

Do not place the dome in extremely hot, cold, dusty or damp locations, otherwise fire or

electrical shock will occur. For working temperature, please refer to the specification manual for

details.

The dome cover for indoor use shall be kept from rain and moisture.

Warnings Follow

these safeguards to

prevent serious injury

or death.

Cautions Follow these

precautions to prevent

potential injury or material

damage.

E Series Network Speed Dome·Quick Guide

Exposing the equipment to direct sun light, low ventilation or heat source such as heater or

radiator is forbidden (ignorance can cause fire danger).

Do not aim the speed dome at the sun or extra bright places. A blooming or smear may occur

otherwise (which is not a malfunction however), and affecting the endurance of sensor at the

same time.

Please use the provided glove when open up the dome cover, avoid direct contact with the dome

cover, because the acidic sweat of the fingers may erode the surface coating of the dome cover.

Please use a soft and dry cloth when clean inside and outside surfaces of the dome cover, do not

use alkaline detergents.

Please keep all wrappers after unpack them for future use. In case of any failure occurred, you

need to return the speed dome to the factory with the original wrapper. Transportation without

the original wrapper may result in damage on the speed dome and lead to additional costs.

E Series Network Speed Dome·Quick Guide

Table of Contents

1 Overview......................................................................................................6

1.1 Check package contents ........................................................................................................... 6

1.2 Cables....................................................................................................................................... 6

1.3 Micro SD Card Instructions ....................................................................................................... 7

1.4 Installation Flow ..................................................................................................................... 11

2 Installation ................................................................................................. 12

2.1 Wall Mounting........................................................................................................................ 12

2.1.1 Wall Mount Installation ................................................................................................... 12

2.1.2 Micro SD Card Installation ............................................................................................... 13

2.1.3 Speed Dome Installation.................................................................................................. 13

2.2 In-ceiling Mounting ................................................................................................................ 19

2.2.1 Mini Network Speed Dome ............................................................................................. 19

2.2.2 Mini IR Network Speed Dome ......................................................................................... 22

2.2.3 5-inch Network Speed Dome........................................................................................... 24

2.3 Ceiling Mounting .................................................................................................................... 26

2.3.1 Mini Network Speed Dome ............................................................................................. 27

2.3.2 5-inch Network Speed Dome........................................................................................... 30

3 Setting the Dome over the LAN .................................................................. 34

4 Accessing via Web browser ........................................................................ 37

E Series Network Speed Dome·Quick Guide

1Overview

1.1 Check package contents

Before you start:

Check the package contents and make sure that the device in the package is in good condition and

all the assembly parts are included.

Note: When carrying the speed dome, do not directly pull waterproof group cables. Otherwise, the

waterproof or circuit performance may be affected.

1.2 Cables

The cable interfaces of network speed dome are shown in following figure. The cables are

distinguished by different colors. Please refer to the labels attached on the cables for identification.

The cables of the mini speed dome:

RED AC24V

YELLOW/GREEN

BLACK AC24V

Red AC24V

Black AC24V

Yellow&Green GND

Purple AUDIO-IN

Black GND

Pink AUDIO-OUT

Yellow/Red ALARM-IN

Yellow/Black ALARM-GND

White/Black ALARM-COM

White/Red ALARM-OUT

Network

Figure 1-1 Cables of Mini Network Speed Dome

E Series Network Speed Dome·Quick Guide

The cables of the 5-inch and IR speed dome:

RED AC24V

YELLOW/GREEN

BLACK AC24V

Red AC24V

Black AC24V

Yellow&Green GND

Purple AUDIO-IN

Black GND

Pink AUDIO-OUT

Yellow/Gray ALARM-IN6

Yellow/Red ALARM-IN7

Yellow/Black ALARM-GND

White/Black ALARM-COM1

White/Red ALARM-OUT1

Network

RED AC24V

YELLOW/GREEN

BLACK AC24V

Figure 1-2 Cables of Network Speed Dome

1.3 Micro SD Card Instructions

Purpose:

The speed domes are with built-in micro SD card slots which are for local storage with micro SD

cards. There are four types of speed dome listed as follows.

Mini network speed dome: The micro SD card slots of mini network speed dome are shown

below.

Note: There are two locations of SD card slot for different models of mini network speed dome.

Please take the practicality as standard.

Refer to the following steps to install the micro SD card.

Steps:

1. Loosen the two lock screws on the edge of the lower dome and remove the lower dome.

2. Align the micro SD card with the micro SD card slot and insert it.

3. Remove the protective lens cover, foam and sticker.

4. Install the lower dome back and tighten the two lock screws.

E Series Network Speed Dome·Quick Guide

SD Card Slot

Location

Slot Type 1 Slot Type 2

Figure 1-3 Micro SD Card Slot

Lens Cover

Protective Sticker

Protective Foam

Figure 1-4 Remove the Protective Accessory

Mini IR network speed dome: The micro SD card slot is inside the rear cover. Outdoor mini IR

network speed dome is taken as an example here. Refer to the following steps to install the

micro SD card.

Steps:

1. Loosen 4 screws in the rear cover. Remove the rear cover.

2. Insert the SD card to the slot in the correct direction. Be sure that the SD card is clicked into

place.

3. Attach the rear cover back to the speed dome. Secure the rear cover with 4 screws.

E Series Network Speed Dome·Quick Guide

Remove Rear Cover Micro SD Card Slot

Camera

Module

Figure 1-5 Micro SD Card Slot

5-inch network speed dome: The micro SD card slots of 5-inch network speed dome are shown

below.

Note: There are two locations of SD card slot for different models of mini network speed dome.

Please take the practicality as standard.

Refer to the following steps to install the micro SD card.

Steps:

1. Loosen the two lock screws on the edge of the lower dome and remove the lower dome.

2. Align the micro SD card with the micro SD card slot and insert it.

3. Remove the protective lens cover, foam and sticker.

4. Install the lower dome back and tighten the two lock screws.

miscro SD

Figure 1-6 Micro SD Card Slot

Andere Handbücher für E-series

Inhaltsverzeichnis

Andere HIK VISION Sicherheitskamera Handbücher

HIK VISION

HIK VISION DS-2CD2443G0-IW Series Bedienungsanleitung

HIK VISION

HIK VISION DS-2CD6425G0 Bedienungsanleitung

HIK VISION

HIK VISION DS-2XM6522G0-IM/ND Bedienungsanleitung

HIK VISION

HIK VISION DS-2CD8153F-E Bedienungsanleitung

HIK VISION

HIK VISION DS-2CE56H0T-(A)VPIT3ZF Bedienungsanleitung

HIK VISION

HIK VISION U1T Series Bedienungsanleitung

HIK VISION

HIK VISION DS-2CD2512F-I Benutzerhandbuch

HIK VISION

HIK VISION DS-2XC6685G0 Bedienungsanleitung

HIK VISION

HIK VISION DS-2DP0818ZIX Bedienungsanleitung

HIK VISION

HIK VISION HiLook IPC-T250H Bedienungsanleitung

HIK VISION

HIK VISION DS-2CD7A26G0/P-IZHSWG Bedienungsanleitung

HIK VISION

HIK VISION OMNI-IP KNC-p3BR IR Bedienungsanleitung

HIK VISION

HIK VISION DS-2XC6224G0-L Bedienungsanleitung

HIK VISION

HIK VISION DS-2TD4668-35A4/W Bedienungsanleitung

HIK VISION

HIK VISION DS-2CD2443G0-I Bedienungsanleitung

HIK VISION

HIK VISION DS-2CE12KF3T-PIRXO Bedienungsanleitung

HIK VISION

HIK VISION TURBO HD DS-2CE56D5T Bedienungsanleitung

HIK VISION

HIK VISION TURBO HD C5T Series Bedienungsanleitung

HIK VISION

HIK VISION DS-2CC502 / 572P(N)-M Bedienungsanleitung

HIK VISION

HIK VISION DS-2DE5425IWG-4G Bedienungsanleitung

HIK VISION

HIK VISION NETWORK CAMERA Bedienungsanleitung

HIK VISION

HIK VISION DS-2CD2012-I Bedienungsanleitung

HIK VISION

HIK VISION IDS-TCM403-AI/0832 Bedienungsanleitung

HIK VISION

HIK VISION ColorVu DS-2CE12KF3T-E Bedienungsanleitung

Beliebte Sicherheitskamera Handbücher anderer Marken

Okina USA

Okina USA SIR36-870VF650LP Bedienungsanleitung

Divio

Divio NDR155PA Bedienungsanleitung

Canon

Canon VB-C500D Bedienungsanleitung

Easy Access

Easy Access EasyGuard Bedienungsanleitung

Vivotek

Vivotek FD9389-EHV-v2 Bedienungsanleitung

TUYA

TUYA COSMO W2 Bedienungsanleitung

Eusso

Eusso UNC7500-IR Einrichtungshandbuch

urmet domus

urmet domus 1096/204 Bedienungsanleitung

VC VC20 series Bedienungsanleitung

Axis

Axis Q1614 Bedienungsanleitung

ieGeek

ieGeek DD201 Bedienungsanleitung

VADDIO

VADDIO ClearVIEW HD-USB PTZ 999-6990-000 Bedienungsanleitung

Vicon

Vicon V662-D-1 Betriebsanleitung

Grundig

Grundig GCH-K0274P Bedienungsanleitung

Lorex

Lorex VANTAGE LBC7032 Bedienungsanleitung

4xem

4xem WPT Bedienungsanleitung

Samsung

Samsung SCV-3082 Bedienungsanleitung

Vitek

Vitek VTC-C544 Bedienungsanleitung
