Himunication HM-360DSC Bedienungsanleitung
- 1 -
Himunication HM-360DSC
Table of
contents
Indledning ................................................................. .....................................................2
Vandtæt design Info………... ........................................ .....................................................3
Taste forklaring............................................................ .....................................................4
Taste funktioner........................................................... .....................................................5
Display ......................................................................... .....................................................5
Menu funktioner………................................................ ...................................................6
Beskrivelse andre menu funktioner...................... .....................................................6
DSC Menu .......................................................... .....................................................7
MMSI ID setup .................................................... .....................................................8
Individuelt kald Pos request, Group/Test kald .....................................................8
All ship call......................................................... ...................................................10
Receive call log .................................................. ................................................... 11
Send call log ....................................................... ................................................... 11
Phone book ........................................................ ................................................... 11
DSC setup .......................................................... ...................................................12
Distress Menu..................................................... ...................................................12
Hoved Menu.......................................................... ...................................................13
VHF operation .................................................... ...................................................13
GPS setting ........................................................ ...................................................14
System config ..................................................... ...................................................14
Taste operationer................................................ ...................................................15
Power ON/OFF Volume control ......................... ...................................................15
Special funktion tast........................................... ...................................................15
SQL tast............................................................. ...................................................15
Up/Down tast..................................................... ...................................................15
16/9 tast............................................................. ...................................................15
Valg af 2. Prioritets kanal………... ...................... ...................................................15
Hi/Lo/Lock tast ................................................... ...................................................16
CH/*/Wx key ...................................................... ...................................................16
SCAN tast.......................................................... ...................................................16
MEM tast............................................................ ...................................................16
DW/Tri Watch tast.............................................. ...................................................17
MOB tast............................................................ ...................................................17
Display lys.......................................................... ...................................................17
Tx Time Out ....................................................... ...................................................17
Batteri………... ............................................................. ...................................................18
Forbindelses kabel........................................................ ...................................................18
Lokal Tid & Dato…........................................................ ...................................................19
Appendix A – Near Lightning Strike Test .......................... ...................................................20
Annexe B – Kanal Liste… ............................................ ...................................................21
Declaration of conformity CE ........................................ ...................................................28
- - 2 - -
Himunication HM-360DSC
HM-360 DSC Instruktions Manual
Indledning
Din nye HM-360 DSC er udviklet af de bedste teknologier. Designet til international brug, giver den dig mulighed for at
sende og modtage på alle de internationale kanaler i det marine bånd VHF som specificeret af den internationale union
(ITU)
Enheden er af høj kvalitet elektronisk udstyr, bygget i henhold til regelbogen med de bedste komponenter, der svarer til
alle markedets standarder for at give dig klar og pålidelig kommunikation.
Din sender-modtager er designet til at levere pålidelig funktion i mange år, takket være en mikroprocessor med optimeret
præstation.
Bemærk: Inden for rammerne af direktivet WEEE skal produkter, der er udtjent, bortskaffes på behørig hvis.
- - 3 - -
Himunication HM-360DSC
EU Regulatory Conformance
As certified by the qualified laboratory, the product is in compliance with the essential requirements
and other relevant provisions of the Directive 1999/5/EC. Please note that the above information is
applicable to EU countries only.
Waterproof design Warning:
Dette produkt er IP67 vandtæt design for at opnå den bedste værdi for brugeren.
Vær opmærksom på følgende to punkter:
1, For at stramme antennen, brug O-ring i bunden af antennen
2, For at tildække mini-USB-hætten tæt, brug O-ring omkring hætten
- 4 -
Himunication HM-360DSC
Taste Beskrivelse
PTT
DISTRESS
MOB
SQL
Power
Battery capacity
Squelch level
Local Date Time
Band
Current channet
GPS position
UP
CH/*/WX
CALL/MENU
16/9
SCAN
HI/LO/LOCK
DW/TRIW
DOWN
MEM
HM‐
360
D
SC
HIMUNICATION
- 5 -
Himunication HM-360DSC
Key function
Tast: Kort tryk mindre end 3 sekunder: Langt tryk mere end 3 sekunder:
HI/Lo /Lock TX Power Hi/Low Key Lock/key unlock
16/9 CH 16 CH09
DW/TriW Dual Watch mode Tri Watch mode
SCAN All Scan/all memory Scan Priority all/memory Scan
MEM MEMORY Mode Save/Delete Memory Channel
Up/Down Channel/ Setting Up/Down Channel up /down(much faster)
Menu/Call DSC menu Hoved menu
MOB MOB aktiveres
Distress Distress menu Distress Alert Call
SQL Sql setting Switch on/off Time& Date display
Volume Knob Power ON / OFF
Juster volume styrke
Display
Battery
capacity Power Band
Current channel
Squelch level
GPS position
Local Date & Time
- 6 -
Himunication HM-360DSC
Menu funktioner
Beskrivelse af menu funktioner
Hoved Menu
VHF Operation Channel Band Set
Priority 2nd ch
GPS Setup GPS Setting
ATIS Operation My ATIS ID
AITS Function
DSC Operation My MMSI ID
DSC Function
System Config System Config
LCD Back Light
Back Light Time
LCD Contrast
Key Beep
Version Info
Factory Reset
DSC Menu
Individual Call Input Address
From Phonebook
Position Request Input Address
From Phonebook
All Ship Call Routine
Safety
Urgency
Group Call Input Address
From Phonebook
Test Call Input Address
From Phonebook
- 7 -
Himunication HM-360DSC
Receive Call Log Distress Call
Others
Call
Send Call Log Distress Call
MOB Call
Others Call
Phone Book Buddy List
Group
List
DSC Setup Position Input
Auto Ch Change
Position Reply
Test Ack
My MMSI ID My MMSI ID
100000008
DSC Menu:
Kort tryk på Call/Menu tast vil gemme nedenstående DSC Menu.
DSC Menu
Individual Call
Position Request
All Ship Call
Group Call
Tes t Call
Receive Call Log
Send Call log
Phone Book
DSC Setup
My MMSI ID
Exit ▲▼ Enter
Derefter bliver CH/*/WX-tasten Exit-tasten, og Call / Menu-tasten bliver Enter-tasten.
OP/NED-tastfunktionen har den samme funktion til at vælge emnet i menuen uden ændringer.
- 8 -
Himunication HM-360DSC
My MMSI ID setup
For det første skal du oprette MMSI-ID'et, klik på MMSI-ID'et og Enter, så er du i stand til at konfigurere
dit MMSI-ID som nedenfor, du skal indsætte MMSI-ID'et TO gange, så vil dit MMSI-ID blive låst af
radioen.
MY MMSI ID
123456789
Exit
Når du indtaster de 9 cifre, med OP/NED-tasten for at vælge tal fra 1-9, skal du indtaste alle tal
fra venstre mod højre et efter et. Når du har indtastet alle 9 cifre, skal du trykke på enter for at
bekræfte.
Input Address
Input 9 digits
123- - - - - -
Exit ▲▼ Enter
Når du har indtastet de ni tal ”219xxxxxx”, vises skærmen som nedenfor.
Input Address
Input 9 digits
219xxxxxx
Exit ▲▼ Enter
For individuelt opkald, positionsanmodning, gruppeopkald og testopkald.
Klik på det foretrukne emne, så er du i stand til at finde det MMSI-, du vil ringe til via inputadresse eller
fra Telefonbog. Vi tager det individuelle opkald som et eksempel.
Når du har valgt modtager adressen indtast 9 cifre såsom 100000000 for adressen som
nedenfor.
Input Address
Input 9 digits
10000000 0
Exit ▲▼ Enter
- 9 -
Himunication HM-360DSC
Vælg derefter den individuelle type kald såsom Safety-Call
Individual Call
Routine
S af ety
Urgency
Exit ▲▼ Enter
Vælg derefter kanal såsom 01-port (Havn) operation, bekræft derefter for at fortage opkald.
Individual Call
Select Channel:
01 port ops/vts
03 unauthorized
05 port ops/vts
06 inter ship
07 commercial
08 commercial
Exit ▲▼ Enter
Derefter foretages det individuelle opkald.
Individual Call
To: 100000000
Safety
Telephony by
Channel 01
Exit Call
Det individuelle opkald er fortaget.
DSC USA
LO SQL:5
01A
PORT OPERAT/UTS
Elapsed 00：12
Exit
- 10 -
Himunication HM-360DSC
All Ship Call:
Vælg “All Ship Call” punktet
DSC Menu
Individual Call
Position Request
Al l Shi p Cal l
Group Call
Tes t Cal l
Receive Call Log
Send Call log
Phone Book
DSC Setup
My MMSI ID
Exit ▲▼ Enter
Vælg derefter typen af alle opkald, såsom ”Urgency”
All Ship Call
Routine
Safety
Urge n c y
Exit ▲▼ Enter
Vælg derefter kanal såsom 07 Commercial, og bekræft derefter opkald.
Individual Call
Select Channel:
01 port ops/vts
03 unauthorized
05 port ops/vts
06 inter ship
0 7 c o mm e rc i al
08 commercial
Exit ▲▼ Enter
Derefter vil “All Ship Call” sendes.
All Ship Call
To : All Ship
Urgency
Telephony by
Channel 07
Exit Call
