Hisense Refrigerator

RB412N4AF1

RB412N4AI1

RB412N4WF1

RB411N4BW1

RB411N4WW1

RB412N4WI1

Disposal of the appliance23

Troubleshooting 22

leaning and care21

Helpful hints and tips 20

Using your appliance 17

Display controls 16

Description of the appliance13

Hisense Refrigerator

Contents

Safety and warning information 2

Installing your new appliance 8

This appliance is in accordance with the following EU guidelines: LVD

2014/35/EU and EM 2014/30/EU and 2009/125/E and E .1060/2010 and

2002/96/E .

Safety and warning information

For your safety and correct

usage, before installing and

first using the appliance, read

this user manual carefully,

including its hints and

warnings. To avoid

unnecessary mistakes and

accidents, it is important to

make sure that all people

using the appliance are

thoroughly familiar with its

operation and safety features.

Save these instructions and

be sure that they remain with

the appliance if it is moved or

sold, so that anyone using it

throughout its life will be

properly informed on usage

and safety notices.

For the safety of life and

property, keep the

precautions of these user's

instructions as the

manufacturer is not

responsible for damages

caused by omission.

Safety for children and others

who are v lnerable

This appliance can be

used by children aged from

8 years and above, and

persons with reduced

physical, sensory or mental

capabilities or lack of

experience and knowledge

if they have been given

supervision or instruction

concerning use of the

appliance in a safe way

and understand the

hazards involved. hildren

shall not play with the

appliance. leaning and

user maintenance shall not

be made by children

without supervision.

Keep all packaging away

from children as there is risk

of suffocation

Hisense Refrigerator

If you are discarding the

appliance, pull the plug out

of the socket, cut the

connection cable (as close

to the appliance as you can)

and remove the door to

prevent children playing

from suffering an electric

shock or from closing

themselves inside.

If this appliance, featuring a

magnetic door seals, is to

replace an older appliance

having a spring lock (latch)

on the door or lid, be sure to

make the spring lock

unusable before you discard

the old appliance. This will

prevent it from becoming a

death trap for a child

General safety

WARNING —This

appliance is intended

to be used in households

and similar applications

such as

-staff kitchen areas in shops,

offices and other working

environments;

-farm houses and by clients

in hotels, motels and other

residential type

environments;

-bed and breakfast type

environments;

-catering and similar

nonretail applications

WARNING — Do not store

explosive substances such

as aerosol cans with a

flammable propellant in this

appliance.

WARNING — If the supply

cord is damaged, it must be

replaced by a qualified

electrician in order to avoid

the risk of electric shock.

WARNING — Keep

ventilation openings in the

appliance enclosure or in

any built-in structure clear of

obstruction.

WARNING — Do not use

mechanical devices or other

means to accelerate the

defrosting process, other

than those recommended by

the manufacturer.

WARNING — Do not

damage the refrigerant

circuit.

WARNING — Do not use

electrical appliances inside

the food storage

compartments of the

appliance, unless they are of

the type recommended by

the manufacturer.

Hisense Refrigerator

WARNING — The

refrigerant and insulation are

flammable. When disposing

of the appliance, do so only

at an authorized waste

disposal center. Do not

expose to flame.

Refrigerant

The refrigerant isobutene

(R600a) is contained within

the refrigerant circuit of the

appliance, a natural gas with

a high level of environmental

compatibility, which is

nevertheless flammable.

During transportation and

installation of the appliance,

ensure that none of the

components of the refrigerant

circuit becomes damaged.

The refrigerant (R600a) is

flammable.

WARNING — Refrigerators

contain refrigerant and

gases in the insulation.

Refrigerant and gases must

be disposed of

professionally as they may

cause eye injuries or ignition.

Ensure that tubing of the

refrigerant circuit is not

damage prior to proper

disposal.

Ca tion: risk of fire

If the refrigerant circuit is

damaged:

-Avoid naked flames and

sources of ignition.

-Thoroughly ventilate the

room in which the appliance

is situated.

It is dangerous to alter the

specifications or modify this

product in any way.

Any damage to the cord may

cause a shortcircuit, fire,

and/or electric shock.

Electrical safety

1. The power cord must not

be lengthened.

2. Make sure that the power

plug is not crushed or

damaged. A crushed or

damaged power plug may

overheat and cause a fire.

3. Make sure that you can

access the main plug of the

appliance.

4. Do not pull the main

cable.

5. If the power plug socket

is loose, do not insert the

power plug. There is a risk

of electric shock or fire.

6. You must not operate the

appliance without the

interior lighting lamp cover.

Hisense Refrigerator

7. The fridge is only supplied

with power supply of single

phase alternating current of

220 ~ 240 V/50Hz. If

fluctuation of voltage in the

district of user is so large

that the voltage exceeds the

above scope, for safety sake,

be sure to apply A. .

Automatic voltage regulator

of more than 350W to the

fridge. The fridge must

employ a special power

socket instead of common

one with other electric

appliances. Its plug must

match the socket with

ground wire.

Daily se

Do not store flammable

gas or liquids in the

appliance. There is a risk of

an explosion.

Do not operate any

electrical appliances in the

appliance (e.g. electric ice

cream makers, mixers etc.).

When unplugging always

pull the plug from the mains

socket, do not pull on the

cable.

Do not place hot items near

the plastic components of

the fridge.

Do not place food products

directly against the air outlet

on the rear wall.

Store pre-packed frozen

food in accordance with the

frozen food manufacture’s

instructions.

The manufactures storage

recommendations should be

strictly adhered to. Refer to

relevant instructions for

storage.

Do not place carbonated or

fizzy drinks in the freeze

compartment as it creates

pressure on the container,

which may cause it to

explode, resulting in

damage to the appliance.

Frozen food can cause frost

burns if consumed straight

from the freezer

compartment.

Do not place the appliance

in direct sunlight.

Keep burning candles,

lamps and other items with

naked flames away from the

appliance so that do not set

the appliance on fire.

The appliance is intended

for keeping food and/or

beverages in normal

households as explained in

Hisense Refrigerator

this instruction booklet The

appliance is heavy. are

should be taken when

moving it.

Do not remove or touch

items from the freezer

compartment if your hands

are damp/wet, as this could

cause skin abrasions or

frost/freezer burns.

Never use the base,

drawers, doors etc. to stand

on or as supports.

Frozen food must not be

refrozen once it has been

thawed out.

Do not consume ice

popsicles or ice cubes

straight from the freezer as

this can cause freezer burn

to the mouth and lips.

To avoid items falling and

causing injury or damage to

the appliance, do not

overload the door racks or

put too much food in the

crisper drawers.

Ca tion!

Care and cleaning

Before maintenance, switch

off the appliance and

disconnect the mains plug

from the mains socket.

Do not clean the appliance

with metal objects, steam

cleaner, ethereal oils,

organic solvents or abrasive

cleansers.

Do not use sharp objects to

remove frost from the

appliance. Use a plastic

scraper.

Installation important!

For electrical connection

carefully, follow the

instructions given in this

manual.

Unpack the appliance and

check if there are damages

on it. Do not connect the

appliance if it is damaged.

Report possible damages

immediately to the place you

bought it. In this case retain

packing.

It is advisable to wait at least

four hours before connecting

the appliance to allow the oil

to flow back in the

compressor.

Adequate air circulation

should be allowed around

the appliance reducing the

risk of overheating. To

achieve sufficient ventilation,

follow the instructions

relevant to installation.

Hisense Refrigerator

Wherever possible the back

of the product should not be

close to a wall to avoid

touching or catching warm

parts (compressor,

condenser) to prevent the

risk of a fire, follow the

instructions relevant to

installation

The appliance must not be

locate close to radiators or

cookers.

Make sure that the mains

plug is accessible after the

installation of the appliance.

Service

Any electrical work required

to do the servicing of the

appliance should be carried

out by qualified electrician or

competent person. This

product must be serviced by

an authorized Serviced

enter, and only genuine

spare parts must be used.

Hisense Refrigerator

Installing yo r new appliance

Before using the appliance for the first

time, you should be informed of the

following tips.

Ventilation of appliance

In order to improve efficiency of

the cooling system and save

energy, it is necessary to maintain good

ventilation around the appliance. For this

reason, sufficient clear space should be

available around the refrigerator.

Suggest :It is advisable for there to be at

least 75mm of space from the back to the

wall, at least 100mm from its top, at least

100mm from its side to the wall and a clear

space in front to allow the doors to open

115°. As shown in follow diagrams.

Note:

 This appliance performs well within the

climate class showed in the table below.

It may not work properly if being left at a

temperature above or below the indicated

range for a long period.

limate class Ambient temperature

SN +10° to +32°

N +16° to +32°

ST +16° to +38°

T +16° to +43°

Stand your appliance in a dry place to

avoid high moisture.

Keep the appliance out of direct sunlight

，

rain or frost. Stand the appliance away

from heat sources such as stoves, fires

or heaters.

Leveling of appliance

For sufficient leveling and air circulating

in the lower rear section of the appliance,

the bottom feet may need to be adjusted.

You can adjust them manually by hand or

by using a suitable spanner.

To allow the doors to self-close, tilt the

top backwards by about 10mm.

Reversing the door

The side at which the door opens can be

changed, from the right side (as supplied)

to the left side, if the installation site

requires.

Warning! When reversing the door, the

appliance must not be connected to the

mains. Ensure that the plug is removed

from the mains socket..

Tools you will need

Note:

When required, tilt the refrigerator back

in order to gain access to the base, you

should rest the appliance on soft foam

packaging or similar material to avoid

damaging the backboard of the

refrigerator. To reverse the door, the

following steps are generally

recommended. Different models may

Hisense Refrigerator

correspond to different pictures. Models

will be written in the picture. If some parts

are not shown in the picture, please ignore

the relevant description.

1. Stand the refrigerator upright. Open the

upper door to take out all door racks (to

avoid racks damaged) and then close the

door.

2. Remove part

①

, loose part

②

from the

top right side of refrigerator and be careful

of the electrical connector

③

below,

because electrical connectors are still

connected. Then disconnect electrical

connector

③

and take down part

②

3. Remove screws

①

and hinge

②

. Then

pass connector

③

through the hole of

hinge

②

.(Please hold upper door by hand

when installing)

4. Remove the upper door from the middle

hinge by carefully lifting the door straight

up. Then place the upper door on a

smooth surface with its upper cover

upwards.

Hisense Refrigerator

5. Take screw hole cover(right) from

plastic bag and install it onto the top right

side of refrigerator body. Then remove

screw hole cover(left) from the top left side

of appliance and put it into plastic bag.

6. Remove part

①

from the top left side of

upper cover and take out part

②

. Then

remove part

③

and part

④

from the top

right side of upper cover. Put part

⑤

into

the top right side of upper cover. Refer to

above operation, install part

③

and part

④

onto the top left side of upper cover. Install

part

①

of the top right side of upper cover.

7. Loose screw

③

and take down part

②

and part

①

, Install replacement door

stopper-left

④

provided (in the plastic bag)

and part

②

(stop block) to the left side with

screw

③

. Keep part

①

with the appliance

for future reference.

8. Loose screws used to fix the middle

hinge and remove middle hinge. Then

remove the lower door.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Hisense Kühlschrank Handbücher

Hisense

Hisense hr6af243 Montageanleitung

Hisense

Hisense RR130DAGS Montageanleitung

Hisense

Hisense RS694N4TFF Montageanleitung

Hisense

Hisense RT749N4ABVI Montageanleitung

Hisense

Hisense RIB291F4AWF Montageanleitung

Hisense

Hisense RB438N4GB3 Montageanleitung

Hisense

Hisense RT33D6AAE Bedienungsanleitung

Hisense

Hisense FV105D4BC21 Montageanleitung

Hisense

Hisense H420BMEI-WD Montageanleitung

Hisense

Hisense BCD440WYHC2 Montageanleitung

Hisense

Hisense RS700N4AWBUI Montageanleitung

Hisense

Hisense RS696N4IB1 Bedienungsanleitung

Hisense

Hisense RIB291F4AW1 Montageanleitung

Hisense

Hisense RS723N4WC1 Montageanleitung

Hisense

Hisense RS840N4WBE Montageanleitung

Hisense

Hisense RUL178D4AW1 Montageanleitung

Hisense

Hisense RB418D4AD2 Technisches Handbuch

Hisense

Hisense RT318N4ABN Montageanleitung

Hisense

Hisense FCN300ACE Bedienungs- und Wartungshandbuch

Hisense

Hisense RT286N4ABN Montageanleitung

Hisense

Hisense FMN544I20S Montageanleitung

Hisense

Hisense RD-31WC4S series Bedienungsanleitung

Hisense

Hisense BCD-543WPAZR/HC1(E) Bedienungsanleitung

Hisense

Hisense FV298N4AWE Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
