USER’S OPERATION MANUAL

Before operating this unit, please read this manual

thoroughly, and retain for future reference

RF27A3FSE

For questions about features, operation/performance, parts or service,call:

1-855-344-7367

Contents

Brief introduction…………………………2

Important safety instructions……………3

Installing your new appliance…………… 5

Description of the appliance……………8

Display controls…………………………9

Using your appliance…………………… 12

Cleaning and care………………………13

Helpful hints and tips……………………15

Troubleshooting…………………………17

Disposal of the appliance………………19

Brief Introduction

Thank you for your choosing Hisense. We

are sure you will find your new refrigerator

a pleasure to use. Before you use the

appliance, we recommend that you read

through these instructions carefully, which

provides details about its usage and

functions.

Please ensure that everyone using this

appliance is familiar with its operations and

safety features. It is important that you

install the appliance correctly and pay

careful attention to the safety instructions.

We recommend that you keep this user’s

manual with the appliance for future

reference.

This appliance is intended to be used in

households and similar applications such

as:

-Staff kitchen-areas in shops, offices and

other working environments;

-Clients in hotels, motels and other

residential types of environment;

-Bed and breakfast type of environments;

-Catering and similar non-retail

applications.

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities,

or lack of experience and knowledge,

unless they have supervision or been

given instruction concerning use of the

appliance. Children should be supervised

to ensure that they do not play with the

appliance.

Do not store explosive substances such

as aerosol cans with a flammable

propellant in this appliance.

WARNING—Do not use mechanical

devices or other means to accelerate the

defrosting process, other than those

recommended by the manufacturer.

WARNING—Do not damage the

refrigerant circuit.

WARNING—Do not use electrical

appliances inside the food storage

compartments of the appliance, unless

they are of the type recommended by the

manufacturer.

WARNING—When disposing of the

appliance do so only at an authorized

waste disposal centre. Do not expose to

flame.

WARNING—The instructions include the

following wording regarding the use of

extension cords: Do not use an extension

cord.

WARNING—If the supply cord is damaged,

it must be replaced by the manufacturer, its

service agent or similarly qualified persons

in order to avoid a hazard.

WARNING—Keep ventilation openings, in

the appliance enclosure or in the built-in

structure, clear of obstruction.

WARNING—When positioning the

appliance, ensure the supply cord is not

trapped or damaged.

WARNING—Do not locate multiple

portable socket-outlets or portable power

supplies at the rear of the appliance.

The symbol is a warning and

indicates the refrigerant and insulation

blowing gas are flammable.

Important Safety Instructions

General safety and daily use

It is important to use your

appliance safely. We

recommend that you follow the

guidelines below.

Store any food in accordance with the

storage instructions from the manufacturer.

Don't try to repair the appliance yourself.

It is dangerous to alter the specifications or

modify this product in any way. Any

damage to the power cord may cause a

short circuit, fire or electric shock.

Don’t place too much food directly

against the air outlet on the rear wall of

both the refrigerator and freezer

compartment, as it affects sufficient air

circulation.

Don’t place hot items near the plastic

components of this appliance.

Frozen food must not be refrozen once it

has been thawed out.

Don’t store bottled or canned drinks

(especially carbonated drinks) in the

freezer compartment. Bottles and cans

may explode.

Use caution consuming popsicles or ice

cubes straight from the freezer as this can

cause freezer burn to the mouth and lips.

Safety for children and infirm persons

Keep all packaging away from children to

avoid risk of suffocation.

Protect children from being scalded by

touching the compressor at the rear bottom

of appliance

Don’t place items on top of the appliance

as this could cause injury should they fall

off.

Never allow children to play with the

appliance by hanging or standing over or

on the doors, racks, shelves and drawers

etc.

Electrical Safety

To avoid the risks that are

always present when using an

electric appliance, we

recommend that you pay attention to the

instructions about electricity below.

Unpack and check through the appliance.

Should any damage be evident, don’t plug

in the appliance but contact the shop

immediately from which you purchased it.

Keep all packing materials in this case.

We recommend that you wait for 4 hours

before connecting the appliance to allow

the refrigerant to flow back into the

compressor.

The appliance must be applied with

single phase alternating current of

115V/60Hz. If the voltage fluctuates

exceeding the upper limit, A.C. automatic

voltage regulator of more than 350W

should be applied to the refrigerator for

safety use.

The power plug must be accessible when

the appliance is installed.

This appliance must be grounded.

This appliance is fitted with a plug, in

accordance with local standard. The plug

should be suitable for use in all houses

fitted with sockets in accordance with

current specifications.

If the fitted plug is not suitable for your

socket outlets, it should be cut off and

carefully disposed of. To avoid a possible

shock hazard, do not insert the discarded

plug into a socket. If in doubt contact a

qualified, registered electrician.

Do not use extension cords or multiple

sockets which could cause overloading of

wiring circuits and could cause a fire.

Always plug your appliance into its own

individual electrical socket which has a

voltage rating that matched the rating plate.

Make sure that the plug is not squashed

or damaged. Otherwise, it may cause short

circuit, electric shock or overheat and even

cause a fire.

Do not insert the power plug if the socket

is loose, there is a risk of electric shock or

fire.

Switch off the appliance and disconnect

it from the main power before you clean or

move it.

Never unplug the appliance by pulling on

the electrical cord. Always grip the plug

firmly and pull straight out from the socket

to prevent damaging the power cord.

Do not operate the appliance without the

cover of interior lighting.

Any electrical component must be

replaced or repaired by a qualified

electrician or authorized service engineer.

Only genuine replacement parts should

be used.

Do not use electrical appliances such as

ice cream makers inside the food storage

compartments of the appliance unless they

are approved by the manufacturer.

To avoid eye injury, do not look direct

into the LED light located in the

refrigerator compartment. If it is not

functioning correctly, consult a qualified,

registered electrician or replace it in

accordance with the “cleaning and care”

chapter.

Refrigerant

The refrigerant isobutene (R600a) is

contained within the refrigerant circuit of

the appliance. During transportation and

installation of the appliance, ensure that

none of the components of the refrigerant

circuit becomes damaged.

The refrigerant (R600a) is flammable.

Caution: Risk of Fire

Don't store products which contain

flammable propellants (e.g. spray cans) or

explosive substances in the appliances.

Should the refrigerant circuit be

damaged:

Avoid open flames (candles, lamps

etc.)and sources of ignition.

Thoroughly ventilate the room in which

the appliance is situated.

Installing Your New Appliance

Before using the appliance for the first time,

you should be informed of the following tips.

Warning!

For proper installation, this refrigerator

must be placed on a level surface of hard

material that is the same height as the rest

of the flooring. This surface should be

strong enough to support a fully loaded

refrigerator.

The rollers, which are not castors, should

be only used for forward or backward

movement. Moving the refrigerator

sideways may damage your floor and the

rollers.

Ventilation of appliance

In order to improve efficiency of

the cooling system and save

energy, it is necessary to

maintain good ventilation around the

appliance for the dissipation of heat. For

this reason, sufficient clear space should

be available around the refrigerator.

Suggestion: It is advisable for there to be

at least75mm of clearance from the back

of the fridge to the wall, at least 100mmof

clearance from its top, at least 100mm from

its side to the wall and a clear space in front

to allow the doors to open 125°. As shown

in following diagrams.

Note:

This appliance performs well within the

climate class from N to T shown in the table

below. It may not work properly if left at a

temperature above or below the indicated

range for a long period.

Climate class Ambient temperature

SN 10℃～32℃

N 16℃～32℃

ST 16℃～38℃

T 16℃～43℃

Stand your appliance in a dry place to

avoid high moisture.

Keep the appliance out of direct sunlight,

rain or frost. Stand the appliance away

from heat sources such as stoves, fires or

heaters.

Leveling of appliance

For sufficient leveling and air circulating in

the lower rear section of the appliance, the

bottom feet may need to be adjusted. You

can adjust them manually by hand or by

using a suitable tool.

To allow the doors to self-close, tilt the top

backwards by 10-15mm.

Door Removal

In case your home access door is too

narrow for the refrigerator to pass through,

remove the refrigerator doors and drawers.

If you do not need to remove the appliance

doors, proceed to ‘Installing Water Lines’

on page 8.If you need to remove the doors,

continue below.

Tools you will need(Not provided):

Allen Wrench (4mm) Wrench(8mm)

Philips Screwdriver

1.With the door closed, remove the 3

screws holding the top cover (A) with

Philips (+) screwdriver, and then remove

the top cover with the entire-harness

attached.

2. Remove the screws (B) fixed on the

hinges with a wrench (8mm)and 1 ground

screws(C) attached to the hinge with

Philips (+) screwdriver. Remove the upper

left and right door hinges(D).

3.Use your both hands to open the door

more than 90°.Lift it up and take it off.

4.Remove the 4 hex head bolts hinges (E)

with an Allen wrench (4mm).Remove the

lower left and right door hinges (F).

Disassembling the freezer door

1. Pull out the freezer door and the upper

freezer drawer (A) to the final position.

2. Ta k e out the ice storage box (B) by lifting

it upin the direction of the arrow.

3.Tak e out the upper freezer drawer (A) by

lifting it up from the rail system.

4. Remove the lower freezer drawer (C) by

lifting it up.

5. Remove the 4 screws attached to the

supporting frame (D).

6. Pull out the freezer door and lift it upin

the direction of the arrow.

Re-assembling the freezer door

To reattach the drawer after you moved the

appliance to its final location, assemble the

parts in reverse order.

Description of the Appliance

Note！

Due to unceasing modification of our products, your refrigerator may be slightly different

from this instruction manual, but its functions and using methods remain the same.

To get the best energy efficiency of this product, please place all shelves, drawers and

baskets on their original position as per the illustration above.

Display Controls

Your product has one control panel which is installed on the top cover, it may be different

depending on the model. Use your appliance according to the following control

guidelines.

When the appliance is powered on for the first time, the backlighting of the icons on the

display panel will light up immediately. If no buttons have been touched or the doors are

closed, the backlighting will turn off after 60seconds.

The control panel consists of two areas about temperature, and one area about different

modes.

Caution!

When you set a temperature, you set an average temperature for the whole refrigerator

cabinet. Temperatures inside each compartment may vary from the temperatures

displayed on the panel, depending on how much food you store and where you place it.

High or low room temperature may also affect the actual temperature inside the appliance.

Fridge Temperature Control

Press the Fridge button to turn on the refrigerator temperature control, then press

the Fridge button to select a temperature setting.

If you have set the temperature type to Celsius, the temperature settings cycle from 8°C to

2°C in one degree decrement.

If you have set the temperature type to Fahrenheit, the temperature settings cycle from

47°F to 35°F in one degree decrement.

Note:

If you want to exchange the "℉" to "℃", please press and hold the "Super Cool" and

"Energy Saving” buttons for 3 seconds.

Super Cool

If you want to increase the cooling accelerator to cool products in Fridge, please

touch this button. The super cool icon “ ” will be illuminated, and the fridge

temperature is set to 35℉（2°C）.

Super cool automatically switches off after 3 hours, and the refrigerator temperature setting

will revert back to the previous setting.

When super cool function is on you can turn it off by pressing the "Super Cool" button

or setting fridge temperature. To manually turn off the Super Cool function, the fridge

temperature setting will revert back to the previous setting.

The fridge will not retain the Super Cool function when powered off.

Freezer Temperature Control

Press the Freezer button to turn on the freezer temperature control, then press the

Freezer button to select a temperature setting.

If you have set the temperature type to Celsius, the temperature settings cycle from -14°C

to -24°C in one degree decrement.

If you have set the temperature type to Fahrenheit, the temperature settings cycle from 6°F

to -12°F in one degree decrement.

Super Freeze

If you want to increase the freezing accelerator in Freezer, please touch this button,

the Super Freeze icon “ ” will be illuminated, the freezer temperature is set to

-12℉（-24°C）.

Super Freeze can quickly lower the temperature and freeze your food faster than usual.

This can retain more of the vitamins and nutrients in fresh food and keep your food longer.

The super freeze mode allows you to freeze items inside with maximum speed. We

recommend that you let the appliance operate for 6 hours first. Super Freeze automatically

switches off after 52 hours, and the freezer temperature setting will revert back to the

previous setting.

When the Super Freeze function is on, you can touch the "Super Freeze" button again or

setting freezer temperature to switch off. To manually turn off the Super freezer

function, the freezer temperature setting will revert back to the previous setting.

If power cutoff happens while super freeze is activated, the super freeze will not be

reactivated after power resupplied.

NOTE: When you selecting the Super Freeze function, ensure there are no bottled or

canned drinks (especially carbonated drinks) in the freezer compartment. Bottles and

cans may explode.

Energy Saving

You can touch this button to turn Energy Saving mode on and off. When you turn

Energy Saving on, the Energy Saving icon “ ” lights up.

The temperature of the fridge is automatically switched to 42℉（6°C）and the

freezer to 2℉（-17°C）.

If Energy Saving is off, the icon “ ” will go off and the temperature setting will revert back

to the previous setting.

Power on/off

You can switch on or switch off your appliance by pressing “Power” button. When

the power function is on, the display board will show “OF”.

When the appliance is switched off, you can switch it on by pressing “Power” button.

Caution!

Inhaltsverzeichnis

Sprachen:

Andere Hisense Kühlschrank Handbücher

Hisense

Hisense RB17N6DWE Montageanleitung

Hisense

Hisense HR6TFF526 Montageanleitung

Hisense

Hisense HRT180N6ABD Bedienungsanleitung

Hisense

Hisense RS694N4TC2 Montageanleitung

Hisense

Hisense RR220D4AB2 Montageanleitung

Hisense

Hisense RS694N4TBE Montageanleitung

Hisense

Hisense RD-35DC4SAB/CV2-002 Montageanleitung

Hisense

Hisense HRF254N6TSE Bedienungsanleitung

Hisense

Hisense HR6TFF600SD Montageanleitung

Hisense

Hisense HRF254N6T E Series Bedienungsanleitung

Hisense

Hisense HR6TFF350 Montageanleitung

Hisense

Hisense RF728N4AIF Montageanleitung

Hisense

Hisense RQ758N4SWFE Montageanleitung

Hisense

Hisense RC-76WS Bedienungsanleitung

Hisense

Hisense BCD-620WP Montageanleitung

Hisense

Hisense FV306N4CW2 Montageanleitung

Hisense

Hisense RS818N4TCE Montageanleitung

Hisense

Hisense RB434N4BFD Technisches Handbuch

Hisense

Hisense HRFD560SW Montageanleitung

Hisense

Hisense H415BI-WD Montageanleitung

Hisense

Hisense RS-77WC1SQD/UPE-001 Bedienungsanleitung

Hisense

Hisense RS-47WL4SBA/CLA2 Montageanleitung

Hisense

Hisense HAF350A Bedienungsanleitung

Hisense

Hisense RD-43WC4SBA/CSA2 Montageanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
